GSN 324 150 W - Freezer AMICA - Free user manual and instructions
Find the device manual for free GSN 324 150 W AMICA in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Upright freezer |
| Brand | Amica |
| Model | GSN 324 150 W |
| Climate Class | SN, N, ST, T (10 °C to 43 °C) |
| Estimated Usable Volume | Approximately 300 liters |
| Dimensions (H x W x D) | 1850 x 600 x 600 mm (estimated) |
| Estimated Net Weight | Approximately 70 kg |
| Electrical Supply | 220-240 V, 50 Hz, 10 A |
| Refrigerant | R600a (isobutane), flammable |
| Energy Class | Not specified (estimated F to E) |
| Estimated Annual Energy Consumption | Approximately 300 kWh |
| Estimated Freezing Capacity | Up to 12 kg/24h |
| Minimum Temperature | -24 °C (adjustable from -16 °C to -24 °C) |
| Main Features | Super Freeze, open door alarm, automatic defrost |
| Defrost | Automatic (No Frost) |
| Control Type | Electronic with SET key and LED display |
| Interior Lighting | LED (built-in) |
| Supplied Accessories | Shelves, door bins, drawers (depending on model) |
| Estimated Noise Level | Approximately 42 dB |
| Safety | Child lock not mentioned; surge protection via 10 A fuse |
| Maintenance and Cleaning | Clean with mild detergent; automatic defrost; do not use abrasive solvents |
| Spare Parts and Repairability | Spare parts available for 7-10 years; repair by authorized service; warranty void if unauthorized intervention |
| Use | Household use only |
| General Information | Non-built-in appliance; instructions available in multiple languages; climate class on rating plate |
Frequently Asked Questions - GSN 324 150 W AMICA
How do I set the temperature on my Amica GSN 324 150 W freezer?
Temperature is set via the interior control panel. Press the SET key to cycle through temperatures: -16 °C, -18 °C, -20 °C, -22 °C, -24 °C. The selected temperature is displayed.
How do I activate the Super Freeze function?
For a large quantity of fresh food, press SET until the Super Freeze indicator lights up. The appliance runs continuously for 26 hours to freeze quickly. The function deactivates automatically.
What should I do if the acoustic alarm sounds?
The alarm sounds if the door remains open for more than 3 minutes. Close the door or press any key to turn it off. If it triggers without reason, check that the door is properly closed.
How do I defrost the freezer?
This model has automatic defrost. For manual defrost, press and hold the SET key for 15 seconds. All LEDs light up, the compressor stops and heating starts. To cancel, press SET for 3 seconds.
What foods can I freeze and for how long?
You can freeze meat, fish, vegetables, and fruits. Storage times: beef 6-8 months, pork 3-6 months, poultry 6-8 months, fish 3-6 months, vegetables 10-12 months. Package airtight.
What should I do if my freezer is not cooling enough?
Check the thermostat setting, ambient temperature (must be between 10 °C and 43 °C per class), direct sunlight, rear air circulation (minimum 30 mm distance), and door gasket condition. If problem persists, contact after-sales service.
Can I use an extension cord or power strip?
No, it is forbidden to use extension cords, power strips or adapters. The appliance must be plugged directly into a grounded wall outlet protected by a 10 A fuse.
How do I clean the interior of the freezer?
Unplug the appliance. Use a soft cloth and warm water with a mild detergent. Do not use abrasive products or solvents. Dry thoroughly before restarting. Clean door gaskets regularly.
What do the displayed error codes mean?
If the alarm indicator and a temperature flash, it indicates a failure. Note the code and contact an authorized service. Do not attempt to repair yourself.
Where can I find the serial number and rating plate?
The rating plate is located at the bottom of the inner wall of the freezer compartment. It shows the model, climate class, voltage, etc. Note the serial number before any service request.
