Product type	Off-road and street motorcycle
Brand	Ducati
Model	DesertX (2023)
Displacement	937 cm³
Engine	Testastretta 11°, L-twin, 4 valves per cylinder, liquid cooling
Maximum power	81 kW (110 hp) at 9250 rpm
Maximum torque	92 Nm at 6500 rpm
Fuel system	Electronic fuel injection, MIKUNI 53 mm throttle bodies, ride-by-wire
Fuel tank capacity	21 L (including 4 L reserve)
Engine oil	SAE 15W-50 JASO MA2 (Shell Advance Ducati 15W-50 recommended)
Transmission	6-speed gearbox, Ducati Quick Shift up/down EVO, Regina 525 chain
Clutch	Multi-plate wet clutch, servo-assisted
Front brakes	Dual 320 mm discs, Brembo M50 monobloc 4-piston calipers, Bosch Cornering ABS
Rear brakes	265 mm disc, floating 2-piston caliper, Bosch Cornering ABS
Front suspension	Kayaba 46 mm inverted fork, adjustable (rebound, compression, preload), travel 230 mm
Rear suspension	Kayaba monoshock, adjustable (rebound, compression, preload), travel 220 mm
Front tire	90/90-21, Pirelli Scorpion Rally STR
Rear tire	150/70 R18, Pirelli Scorpion Rally STR
Dry weight	202 kg
Curb weight (90% fuel)	223 kg
Maximum permissible weight	465 kg
Battery	Lithium-ion SKYRICH HJT7B-FPZ-SCR 4 Ah
Lighting	Full LED, adjustable DRL
Dashboard	5" vertical color TFT screen
Electronic systems	DTC, DWC, EBC, DQS, ABS Cornering, Cruise Control, riding modes
Connectivity	Bluetooth (smartphone, intercom, GPS)

Frequently Asked Questions - DesertX (2023) DUCATI

How to pair a smartphone via Bluetooth with the dashboard?

From the Interactive Menu, select Settings then Bluetooth. Choose Pairing and select the device type (smartphone). The dashboard searches for devices; select yours and confirm the pairing code displayed on both screens.

What is the fuel tank capacity and what fuel to use?

The tank has a capacity of 21 L including 4 L reserve. Use unleaded premium gasoline with a minimum octane rating of 90 (RON+MON)/2, and a maximum of 10% ethanol (E10).

What engine oil is recommended and what is its capacity?

Use an oil SAE 15W-50 JASO MA2. Ducati recommends Shell Advance Ducati 15W-50 Fully Synthetic oil. The capacity is 3.1 L with filter.

How to adjust the front fork?

The Kayaba fork has three adjustments: rebound (screw on top of right tube), compression (screw on top of left tube), and spring preload (hexagonal knob). Turn clockwise to increase damping or preload. Set both tubes to the same positions.

What is the main maintenance schedule?

The First Service is at 1000 km, the Oil Service every 15,000 km, the Desmo Service every 30,000 km, and the Annual Service every 12 months. Consult the manual for the full list of operations.

How does the Ducati Quick Shift (DQS) work?

The DQS up/down EVO allows shifting without operating the clutch. To upshift, keep the throttle open and press the selector upward; to downshift, close the throttle and press downward. The system briefly cuts the ignition.

What is the maximum weight the DesertX can carry?

The total curb weight with rider, passenger, luggage, and accessories must not exceed 465 kg. The maximum load on the front axle is 172 kg and on the rear axle is 293 kg.

How to activate the daytime running lights (DRL)?

The DRL can be set to Auto (automatic activation based on ambient light) or Manual. Use button (2) on the left switch to turn on/off manually. The corresponding indicator lights up on the dashboard.

What procedure to follow to start the engine in very cold weather?

For temperatures below 0°C, perform a KEY-ON, turn on the high beams for 3 to 5 minutes, then turn them off. Then start the engine by holding the start button for up to 5 seconds. If necessary, repeat the procedure.

What are the recommended tire pressures?

For the front tire: 2.0 bar (road, solo rider) or 1.8 bar (off-road, solo rider). For the rear tire: 2.2 bar (road, solo rider) or 1.8 bar (off-road, solo rider). Adjust for passenger and luggage according to the manual.

USER MANUAL DesertX (2023) DUCATI

Ducati North America, Inc.

1292 Reamwood Ave., Sunnyvale,

CA 94089 USA

Tel: [phone]

E-mail: [e-mail]

Web site: www.ducatiusa.com

Infotainment (si present) 12

Telephone (si present) 20

Turn by turn (si present) 157

Chrono 167

Transfert de carburant (si present) 170

Réglages 177

Ducati North America, Inc.

1292 Reamwood Ave., Sunnyvale, CA 94089 USA

Tel.: [phone]

E-mail: [e-mail]

Site Internet: www.ducatiusa.com

Keep the turn signal switch on the left position to activate the Parking Light

Fig. 64

Attention

Turn by turn (si present)

Transfert de carburant (si present)

Fuel transfer completed

10:34

am

Fig. 95

Remarques

Save configuration from Ducati Link?

Yes

No

Fig.168

Marque:NGK. Type:MAR9A-J.

Alimentation

Dimensions: 2.15'' × 21'' .

Arrière

Matt Star White Silk

Fond

• Carenages lateraux: 2K Blanc, ref. 873AC001, fabricant Palinal.
• Garde-boue Avant / Arrière : 2K Blanc, ref. 873AC001, fabricant Palinal.
• Reservoir: 2K Blanc, ref. 873AC001, fabricant Palinal.

Base

• Carenages lateraux: Star White, ref. 873AC001, fabricant Palinal.
• Garde-boue Avant / Arrière : Star White, ref. 873AC001, fabricant Palinal.
• Réservoir: Star White, ref. 873AC001, fabricant Palinal.

Transparent

• Carénages lateraux : Acriplast Clear Semi-mat, ref. 96598, fabricant Lechler. Garde-boue Avant / Arrière : Acriplast Clear.

• Semi-mat, ref. 96598, fabricant Lechler.

• Reservoir: Acriplast Clear Semi-mat, ref. 96598, fabricant Lechler.

Noir

Fond: 2K Blanc, ref. 873AC001, fabricant Palinal.
- Base: Saturn Grey, ref. 928.F559, fabricant Palinal.
- Transparent: Acriplast clear semi-mat, ref. 96598, fabricant Lechler.

Reservoir Saturn Grey 20 Gloss

• Cataphorèse avec produit PPG
  Fond:2K Blanc, ref.873AC001, fabricant Palinal.
• Base: Saturn Grey, ref. 928.F559, fabricant Palinal.
• Transparent: Acriplast clear semi-mat, ref. 96598, fabricant Lechler.

https://www.ducati.com/ww/en/home/open-source-software

Your vehicle is equipped with a range of radio equipment. The manufacturers of this radio equipment declare that these equipment complies with Directive 2014/53/EU where required by law. The complete text of the EU declaration of conformity is available at the following web address: certifications.ducati.com

[Greece]

To oxnua oac eonaiicrau ie na oepa ano paodovokevc. Okaataokveaotc wov vovkovov autov dnawov ov 01 ouokvoc umuopovovtai me nV odnyia 2014/53/EE, onou aanatetai ano to vmo.To npes keiuevo tsdianos ng oumopwosnE E ivai diaeio so thdvov: certifications.ducati.com

[Croatia]

Vase vozilo je opremljeno nizom radio uredaja. Proizvodači ovih radio uredaja tvrde da su uredaji u skladu s Direktivom 2014/53/UE ako je propisano zakonom. Cjelokupan tekst deklaracije o sukladnosti dostupan je na: certifications.ducati.com

[Hungary]

Your vehicle is equipped with a range of radio equipment. The manufacturers of this radio equipment declare that these equipment complies with Directive 2014/53/EU where required by law. The complete text of the EU declaration of conformity is available at the following web address: certifications.ducati.com

[Italy]

"This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation."

"Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment." "NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gene rates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfere nee to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help."

RF exposure Information according 2.1091/2.1093 / OET bulletin 65:

Radiofrequency radiation exposure Information: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

The manufacturers of these radio equipment declare that devices comply with the FCC

DASHBOARD FCC ID: 2AVGH-RTADM001
Ducati Multimedia System (Bluetooth) FCC ID: Z64-2564N

Canada

This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions:

(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.

RF Exposure Information:

This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20~cm between the radiator and your body.

This device is granted pursuant to the Japanese Radio Law (電波法) and the Japanese Telecommunications Business Law (電氛通信事業法)

This device should not be modified (otherwise the granted designation number will become invalid)

DASHBOARD
Ducati Multimedia System (Bluetooth)

South Korea

海当摇

DASHBOARD R-R-mAe-RTADM001

Ducati Multimedia System (Bluetooth) R-R-Cbo-1080795

Brasil
