USER MANUAL TEG1005D Tenda

Safety and Regulatory Information

5/8/16-Port Gigabit Ethernet Switch · TG1005D/TEG1008M/TEG1016M

9-Port 10/100M Ethernet Desktop Switch · TEF1109D

5-Port Fast Ethernet Switch · TEF1005D

Illustration of three people using laptops with Wi-Fi, security, and cloud icons around a large screen (no text or symbols)

Contents

Safety Precautions...... 1

English 1

Deutsch 2

Italiano 3

Español.... 3

Português 4

Français 5

Nederlands...... 6

Svenska....7

Dansk...... 8

Suomi 9

Magyar 9

Polski 11

Čeština.... 11

Ελληνικά...... 12

Română 13

Български ...... 14

Eesti.... 15

CE Mark Warning......29

Declaration of

Conformity......29

Power Adapter

Information......34

FCC Statement ...... 36

NOM (TEG1005D,

TEG1016M)....38

RECYCLING......39

English....39

Deutsch 39

Italiano 39

Español......40

Português ....40

Français ....40

Nederlands......41

Svenska ....41

Dansk......41

Suomi....41

Magyar......42

Polski....42

Čeština 42

Ελληνικά......43

Română......43

Български......43

Eesti....44

Slovenščina ....44

Slovenčina......44

Hrvatski......44

Latviešu 45

Lietuvių ....45

Türkçe......45

Русский......46

Others 46

Safety Precautions

English

Before performing an operation, read the operation instructions and precautions to be taken, and follow them to prevent accidents. The warning and danger items in other documents do not cover all the safety precautions that must be followed. They are only supplementary information, and the installation and maintenance personnel need to understand the basic safety precautions to be taken.

- The device is for indoor usage only.

- For desktop mounting, the device must be horizontally mounted for safe use.

- For wall mounting, the device is only suitable for mounting at heights ≤slant 2m .

- Clean only with dry cloth.

- Do not block any ventilation openings, such as newspapers, table-cloth, curtains.

- Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus that produce heat.

- Do not damage the ground conductor or operate the device in the absence of well-installed ground conductor. Conduct the appropriate electrical inspection. Refer to the Lightning Protection Guide at the official website for instructions.

- Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles and at the point where they exit from the device.

- Only use attachments/accessories specified by the manufacturer.

- Unplug this device when unused for long periods of time.

- The mains plug is used as the disconnect device and shall remain readily operable.

- Warning: To reduce the risk of fire or electric shock, do not expose this device to rain or moisture. The device shall not be exposed to dripping or splashing.

- Warning: To reduce the risk of electric shock, do not remove the cover as there are no user-serviceable parts inside.

- Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, for example, power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the device, the device has been exposed to rain or moisture, does not work normally, or has been dropped.

Deutsch

Sicherheitshinweise

Operating/Storage Environment

English

Item	Operating environment		Storage environment
	Temperature	Humidity	Temperature	Humidity
Device	0°C - 40°C	(10% - 90%) RH, non-condensing	-40°C - 70°C	(5% - 90%) RH, non-condensing

Deutsch

(TEG1016M/TEG1008M/TEF1109D) This is a Class A product.

(TEG1005D/TEF1005D) This is a Class B product.

In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. (2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable.

Declaration of Conformity

English

Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the device is in compliance with directives 2014/35/EU and 2014/30/EU.

The full text of the EU declaration of conformity is available at the following internet address:

https://www.tendacn.com/download/list-9.html

Deutsch

TEG1008M has two power specifications, please use the power adapter that matches the power specification on the device label.

TEF1005D/TEG1005D/TEG1008M

Adapter Model: BN003-A03005E, BN003-A03005B, BN003-A03005U

Manufacturer: SHENZHEN HEWEISHUN NETWORK TECHNOLOGY CO., LTD.

Input: 100 – 240 V, AC, 50/60 Hz, 0.3 A

Output: 5 V, DC, 0.6 A

---: DC Voltage

TEF1109D/TEG1008M

Adapter Model: BN003-A05009E, BN003-A05009B, BN003-A05009U, BN049-A05009E, BN049-A05009B, BN049-A05009U

Manufacturer: SHENZHEN HEWEISHUN NETWORK TECHNOLOGY CO., LTD.

Input: 100 – 240 V, AC, 50/60 Hz, 0.3 A

Output: 9 V, DC, 0.6 A

: DC Voltage

TEG1016M

Adapter Model: BN073-A12012E, BN073-A12012B, BN073-A12012U

Manufacturer: SHENZHEN HEWEISHUN NETWORK TECHNOLOGY CO., LTD.

Input: 100 – 240 V, AC, 50/60 Hz, 0.4 A

Output: 12 V, DC, 1 A

: DC Voltage

FCC Statement

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Caution!

Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. (2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

TEG1005D/TEF1005D

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
  – Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

NOM (TEG1005D, TEG1016M)

This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.

User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic equipment.

Deutsch

RECYCLING

RACCOLTA DIFFERENZIATA

Floor 6-8, Tower E3, No.1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052

Website: www.tendacn.com

E-mail: [e-mail]

[e-mail] (North America)

[e-mail] (United Kingdom)

Copyright © 2023 Shenzhen Tenda Technology Co., Ltd. All rights reserved.

Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders. Specifications are subject to change without notice.

V1.0 Keep for future reference.
