USER MANUAL Lucy STADLER FORM

READ AND SAVE THESE INSTRUCTIONS

, Inc. 165 West Broadway Street, Dover, OH 44622, USA Toll free 877-663-7895, www.stadlerformusa.com Stadler Form of SwitzerlandEnglish Congratulations! You have just purchased the exceptional LUCY aroma diffuser. It will bring you a great deal of pleasure and improve the ambient air for you. As with all domestic electrical appliances, particular care is needed with this model also, in order to avoid injury, fire damage or damage to the appliance. Please study these operating instructions carefully before using the appliance for the first time and follow the safety advice on the appliance itself. Description of the appliance The appliance consists of the following main components:

2. Connection for USB-C cable

5. Button for LED dimmer (normal, dimmed, lights-out)

6. Lower part / water container

9. Air outlet opening (Caution: no water may enter this opening!)

10. Upper part / lid

11. Mist outletImportant safety instructions - SAVE THESE INSTRUCTIONS

Please read through the operating instructions carefully before you use the ap- pliance for the first time and keep them safely for later reference; if necessary pass them on to the next owner.

• Stadler Form refuses all liability for loss or damage which arises as a result of failure to follow these operating instructions.

• The appliance is only to be used in the home for the purposes described in these instructions. Unauthorised use and technical modifications to the appliance can lead to danger to life and health.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of ex- perience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user main- tenance shall not be made by children without supervision.

• Only connect the cable to alternating current. Observe the voltage informa- tion given on the appliance.

• Do not use damaged extension cords.

• Do not run the power cord over sharp edges and make sure that it does not get trapped.

• Do not pull the plug from the socket with wet hands or by holding on to the power cord.

• Do not use the appliance in immediate vicinity of a bath tub, a shower or a swimming pool (observe a minimum distance of 2.3 ft / 0.7 m). Place the appliance such that a person in the bath tub cannot touch the appliance.• Keep the device away from heat sources.

• This device contains a lithium battery.

• In case of battery leakage: Avoid contact with human eyes and skin. Collect spillage.

• Do not place the appliance near a heat source. Do not subject the power cord to direct heat (such as a heated hotplate, open flames, hot iron sole plates or heaters for example). Protect power cords from oil.

• Do not drop the device. Otherwise the battery may overheat, cause a fire or malfunction and reduce service life.

• See to it that the appliance is properly positioned to ensure a high stability during its operation and make sure that no one can trip over the power cord.

• The appliance is not splash-proof.

• For indoor use only.

• Do not store the appliance outdoors.

• Store the appliance in a dry place inaccessible to children (pack the appli- ance).

• If the power cord is damaged, it must be replaced by the manufacturer or a repair shop authorized by the manufacturer or by similarly qualified persons in order to avoid a hazard.

• Only use fragrances, aromas or essential oils that do NOT contain alcohol. Alcohol can damage the appliance. Appliances that are damaged by such additives are not covered by the warranty.

• Prior to any maintenance, cleaning and after each use, switch off the appli- ance and unplug the mains cable from the socket.• Repairs to electrical appliances must only be carried out by a qualified elec- trical technician.

• WARNING: Only use the USB cable provided by the manufacturer. Use only an external supply with the following specifications: DC 5V/2A. Setting up / operation

1. Place Lucy in the desired position on a flat surface. Connect the USB-C cable

(1) to the appliance (2) and connect the cable to a suitable power source (PC, external battery, USB socket or to a suitable socket via a power adapter with min. 2 A/5 V). When the appliance is used for the first time, the battery must be charged by connecting the appliance to a power source for at least 6 hours. When the battery is fully charged, the status LED light (3) will go out. After the battery has been fully charged for the first time, you can operate the appliance without the cable using the power from the integrated rechar- geable battery. A fully charged battery will give the appliance a running time of up to 7 h. When the water container is full and the appliance is connected to a power source, Lucy can operate for up to 10 h.

2. Remove the lid (10) to fill with water and fragrance.

3. Fill the water container (6) up to the maximum mark (MAX) (7) with water.

No water may enter the air outlet opening (9). This will damage the appli- ance and will void any claim to the warranty.

4. Important: transport the appliance in an upright position and without making

any jerky movements if there is water in the container (6). If the appliance is moved quickly or tilted, water may leak out and run into the electronicsinside the appliance. This will damage the appliance and will void any claim to the warranty.

5. Add 2–3 drops of your favourite liquid fragrance directly into the water. It is

not necessary to mix them as the ultrasonic membrane (8) does this for you. Only use fragrances, aromas or essential oils that do NOT contain alcohol.

6. Close the lid (10) again.

7. Then switch Lucy on by pressing the on/off button (4).

8. If you would like to top the water up, switch off the appliance and disconnect

the USB cable if it is connected to the appliance (1 + 2). Remove the lid (10) and fill the water up to the maximum mark.

9. If you are disturbed by the brightness of the illuminated mist (in the bedroom,

for example), you can reduce the brightness of the LEDs by pressing the dim- mer button (5). You can choose between three different modes:

• Normal mode (switched on as standard)

• Dimmed mode (press once)

• Light-off mode (press twice) You can return to normal mode by re-pressing the dimmer button (5).

10. On the back of the bottom part above the connection for the USB cable (2),

you will find the status display for the battery (3):

• Normal operation with fully charged battery: LED is not illuminated

• Battery level 10 % or lower: LED flashes

• Battery is charging: LED is illuminated constantly When the device is fully charged, the LED will go out. You can now disconnect the USB cable and use the device in battery mode (for up to 7 hours).Note: If you would like to change the fragrance, empty Lucy completely and clean the water container with a damp cloth. Fill Lucy once again and pour the drops into the device following the instructions. Cleaning Prior to any maintenance and after each use, switch off the appliance and dis- connect the USB cable (1) from it. Careful: Never immerse the device in water (danger of short circuit).

• Regularly as required: To clean the outside, rub with a damp cloth and then dry thoroughly.

• If there are marks caused by water and/or fragrances on the top of the lid (10), clean it with a damp cloth and a squirt of washing-up liquid. Then dry the lid thoroughly before using the appliance again.

• Internal cleaning: You can clean the ultrasonic membrane with a con- ventional household descaler. If there are lime deposits, we recom- mend that you use Stadler Form Cleaner & Descaler (www.stadle- rform.com/accessories). Alternatively, you can use a household descaling agent or vinegar. Please do not try to scratch off deposits from the membrane with a hard object. For stubborn deposits, we recommend that you descale the device several times in a row. After the descaling rinse the base and then dry thoroughly.

• No water may enter the air outlet opening (9). This will damage the appli- ance and will void any claim to the warranty.Repairs

• Repairs to electrical appliances must only be carried out by a qualified elec- trical technician. If improper repairs are carried out, the warranty lapses and all liability is refused.

• Never operate the appliance if the adaptor or plug is damaged, after it has malfunctioned, if it has been dropped or has been damaged in any other way (cracks/breaks in the casing).

• Do not push any object into the appliance.

• If the appliance is beyond repair, make it unusable immediately by cutting through the cable and hand it in at the collection point provided for the pur- pose.

• In the event of a repair, the following points must be observed before the appliance is shipped or taken to the dealer: completely empty the water in the appliance (water tray or water tank), and allow the appliance to dry completely. Appliances containing residual water may be damaged during transport, invalidating the warranty. Disposal

• Do not push any object into the appliance.

• Do not dispose of electrical appliances in the domestic waste. Please use the communal collection points.

• If electrical appliances are disposed of thoughtlessly, exposure to the ele- ments may cause hazardous substances to find their way into the ground- water and from there into the food chain, or to poison the flora and fauna for many years to come.• Battery disposal method: This appliance contains batteries that are non-re- placeable. When the battery is at end of life, the appliance shall be properly disposed of. Do not throw into the trash can, the electrode is wrapped in insulating paper, it can be recycled and reused. Specifications Rated voltage DC 5 V Power output 10 W Running time up to 7 h on battery power and up to 10 h on mains power Dimensions 2.8 x 5.9 inch / 70 x 150 mm (diameter x height) Weight 0.8 lbs / 360 g Tank capacity 1.7 fl. oz / 50 ml Sound level < 26 dB(A) Battery charging temperature range 32–113 °F / 0–45 °C, Humidity ≤85 % RH Battery model MT-3P18650 -6000mAh Complies with regulations cUL All rights for any technical modifications are reserved1 year Limited Warranty A This 1 year limited warranty applies to repair or replacement of product found to be defective in material or workmanship. This warranty does not apply to damage resulting from commercial, abusive, unreasonable use or supplemental damage. Defects that are the result of normal wear and tear will not be considered manufacturing defects under this warranty. SWIZZ STYLE IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAM- AGES OF ANY NATURE. ANY IMPLIED WARRANTY OF MERCHANT- ABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you also may have other rights which vary from jurisdiction to jurisdiction. This warranty applies only to the original purchaser of this product from the original date of purchase. B At its option, Swizz Style will repair or replace this product if it is found to be defective in material or workmanship. Defective product should be re- turned to the place of purchase in accordance with store policy. Thereafter, while within the warranty period purchaser should contact Swizz Style at 1-877-663-7895 Monday – Friday 9am – 4pm EST for product return infor- mation.C This warranty does not cover damage resulting from any unauthorized attempts to repair or from any use not in accordance with the instruction manual. D If the product has replaceable filters, these are not covered under this warranty, except for material or workmanship defects. E The following must accompany all products returned for service: 1) Proof of purchase 2) Brief description of the problem 3) Full contact information (including return shipping address) 4) Check or money order for $10 ($15 if in Canada) for return handling, packaging and shipping charges. All funds are in US dollars. F Swizz Style is not responsible for items lost, stolen or damaged during return shipping.Français Félicitations! Vous venez d’acheter LUCY, le diffuseur d’arômes sortant de l’ordi- naire. Nous espérons que cet appareil vous donnera entière satisfaction et amélio- rera l’air intérieur pour vous. Comme pour tous les appareils ménagers électriques, il est important d‘en-tre- tenir cet appareil correctement afin d’éviter les blessures, les incendies ou les dommages. Veuillez lire attentivement le présent mode d‘emploi avant la mise en service et respecter les conseils de sécurité indiqués sur l’appareil. Description de l’appareil L’appareil est composé des éléments principaux suivants :
