C550 - Power Supply (PC) NZXT - Free user manual and instructions

Product Type	PC Power Supply
Brand	NZXT
Model	C550
Standard	ATX12V v2.52 / EPS12V v2.92
Nominal Power	550 W
Input Voltage	100-240 V AC
Input Frequency	50-60 Hz
Input Current	6 A (max)
Power Factor Correction	Active, >0.98
Efficiency	80 PLUS Bronze (82% at 10%, 82% at 20%, 85% at 50%, 82% at 100%)
Fan	120 mm, FDB bearing, airflow 72.80 CFM, noise <44 dBA
Connectors	1x ATX 20+4 pin, 2x CPU 4+4 pin, PCIe, SATA and peripherals
Operating Temperature	0 to 40 °C
MTBF	100,000 hours
Certifications	CB, CE, FCC, TUV, CCC, BSMI, RCM, EAC, UKCA, WEEE, ICES, BIS
Materials	RoHS and China RoHS compliant
Protections	OVP, OCP, OPP, SCP
Dimensions (estimated)	150 x 140 x 86 mm (standard ATX form factor)
Maintenance	Clean ventilation grilles with a dry cloth. Never open the unit.
Safety	High voltages inside. Do not open. Professional installation recommended.
Spare Parts	No user-serviceable parts. Use only supplied cables.
Customer Service	[e-mail] (support) / [e-mail] (suggestions)

Frequently Asked Questions - C550 NZXT

How to install the NZXT C550 power supply?

Install the power supply into the case using the provided screws. Then connect the ATX 20+4 pin connector to the motherboard, the CPU 4+4 pin connectors, the PCIe connectors for the graphics card, then the SATA and peripheral cables. Finally, connect the AC power cable and turn on.

What cables are provided with the NZXT C550?

The NZXT C550 comes with one ATX 20+4 pin power cable, two CPU 4+4 pin cables, PCIe cables, SATA cables, and peripheral cables. See the manual for the exact configuration.

Is the NZXT C550 power supply modular?

The NZXT C550 is not fully modular. Some main cables are fixed, but there may be modular connectors for peripherals. Check the manual for details.

What to do if my PC does not turn on after installation?

First check that all cables are properly connected and that the power supply switch is set to 'I'. Ensure the AC power cable is firmly connected. If the problem persists, contact NZXT support at [e-mail].

Can I use the NZXT C550 power supply in a country with a different voltage?

Yes, the power supply accepts an input voltage of 100-240 V and a frequency of 50-60 Hz, making it compatible with most countries. Just use the appropriate power cable.

How to clean the NZXT C550 power supply?

Unplug the power supply and use a dry cloth or soft brush to clean the ventilation grilles. Never open the case or use any liquid.

Is the NZXT C550 power supply quiet?

Yes, the 120 mm FDB bearing fan is designed to be quiet, with noise less than 44 dBA. The fan only spins when there is sufficient load, reducing noise at low loads.

What is the warranty on the NZXT C550?

The warranty is provided by NZXT. In case of issues, contact [e-mail] with your proof of purchase. Spare parts can be ordered at support.nzxt.com.

Can I replace the power supply fan?

No, the fan is not user-replaceable. Opening the power supply voids the warranty and poses risk of electric shock. Any repairs should be done by a professional.

What does the 80 PLUS Bronze certification mean?

The 80 PLUS Bronze certification guarantees at least 82% efficiency at 20% and 100% load, and 85% at 50% load. This means less energy waste and better efficiency compared to non-certified models.

USER MANUAL C550 NZXT

C550/C650 Bronze - x2 , C750 Bronze - x3

E. Peripériques

X1

G. Vis de fixation

6-32-x5

F. Alimentation SATA

X2

4.1 NZXT Global Warranty Policy A-2
4.2 Support and Service A-8
4.3 Regulatory Notice.. A-11
4.4 Revision History.. A-12

4.1 NZXT GLOBAL WARRANTY POLICY

C SERIES BRONZE

This NZXT Global Warranty Policy governs the sale of products by NZXT to you.

I. WARRANTY LENGTH

Any replacement product will be covered under warranty for the remainder of the warranty period or thirty days, whichever is longer. Proof of purchase is required for warranty service.

II. WHO IS PROTECTED

The Warranty covers only NZXT products purchased by the original consumer.

NEW NZXT PRODUCT WARRANTY LENGTH FOR PARTS

Computer Cases 2 Years

Temperature Meters 2 Years

Fans 2 Years

Lighting 2 Years

Accessories 2 Years

Kraken M Coolers 3 Years

Headset/Headphone 2 Years

Headset/Headphone Storage

2 Years

Mixer

2 Years

Motherboards

3 Years

Gold Power Supply

10 Years

Bronze Power Supply

5 Years

Kraken X/Z Coolers

6 Years

Mini ITX Case with PSU, AIO, and Riser Card

3-year warranty on case, riser card, and AIO. 10-year warranty on PSU.

REFURBISHED NZXT PRODUCT

WARRANTY LENGTH FOR PARTS

All NZXT Certified Refurbished Products

1 Years

III. WHAT IS AND IS NOT COVERED

Please note that our warranty is not an unconditional guarantee. If the product, in NZXT's reasonable opinion, malfunctions within the warranty period, NZXT will provide you at its sole discretion with a repaired or replacement product, either new or refurbished, with a similar function that is equal or greater in value depending on supply.

Our warranty does not cover the following:

• any product or serial number/warranty sticker modification applied without permission from NZXT;
• any damage that is not a manufacturing defect;
• damage, deterioration or malfunction resulting from: accident, abuse, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification or failure to follow instructions included with the product;
• improper installation, unauthorized alterations or modifications, or repair or attempted repair by anyone not authorized by NZXT;
• shipping or transport damage (claims must be made with the carrier);
  normal wear and tear.

NZXT does not warrant that this product will meet your requirements. It is your responsibility to determine the suitability of this product for your purpose. For NZXT Store orders, we cover two way return shipping for all exchanges and returns. For all other authorized dealers, NZXT Support does not cover return shipping and only covers one way shipping from NZXT back to the end user for exchanges. Two way expedited shipping is provided for all PSUs covered under the Less Than Three program, indiscriminate of purchase location, provided the location is an approved NZXT reseller.

IV. EXCLUSION OF DAMAGES (DISCLAIMER)

NZXT's sole obligation and liability under this warranty is limited to the repair or replacement of a defective product with either a new or refurbished product with a similar function that is equal or greater in value at our option. NZXT shall not, in any event, be liable for any incidental or consequential damage, including but not limited to damages resulting from interruption of service and loss of data, business, or for liability in tort relating to this product or resulting from its use or possession.

V. LIMITATIONS OF IMPLIED WARRANTY

There are no other warranties, expressed or implied, including but not limited to those of merchantability or fitness for a particular purpose. The duration of implied warranties is limited to the warranty length specified in Paragraph I.

VI. TO OBTAIN TECHNICAL SUPPORT

If you have already referenced your product owner's manual and still need help, you may contact us by phone at [phone], by email at [e-mail], or visit the NZXT Support site at nzxt.com/customer-support.

VII. HOW TO OBTAIN A WARRANTY SERVICE FROM NZXT

To receive a warranty service for your product when purchased directly from NZXT, you must submit a request via the NZXT Support site outlining the problem. If a technician deems the product defective or requiring testing, you will be required to provide a copy of your proof of purchase, which will enable you to submit a Return Merchandise Authorization "RMA" request.

Once approved, you'll receive an RMA number, upon which you will be asked to ship the defective item back to NZXT with the RMA number clearly marked or labelled on the package. NZXT recommends that appropriate measures are taken to safeguard the product from damage during shipping.

VIII. APPLICABLE LAW AND ADDITIONAL LEGAL RIGHTS FOR CONSUMERS

This warranty gives you specific legal rights. These conditions are governed and construed in accordance with the laws of California (with exception of its conflict of law provisions), and the application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded. The non-exclusive jurisdiction of the courts of California is agreed, which means that you may bring a claim to enforce your consumer protection rights in connection with this Global Warranty in the country which you have your habitual residence where you may have additional rights. These rights may vary.

For original consumers who are covered by consumer protection laws or regulations in their country, state, or province of purchase or, if different, their country, state, or province of residence, the benefits conferred by this warranty are in addition to all rights and remedies conveyed by such consumer protection laws and regulations. To the extent that liability under such consumer laws can be limited, NZXT's liability is limited, and its sole option, to repair or replacement, either new or refurbished, with a similar function that is equal or greater in value depending on supply.

In the United Kingdom:

• For NZXT products sold to customers in the UK, during the expected lifespan of your product your legal rights entitle you to the following:

Up to 30 days: if your goods are faulty, then you can get an immediate refund.

Up to six months: if your goods can't be repaired or replaced, then you're entitled to a full refund, in most cases.

Up to six years: if your goods do not last a reasonable length of time you may be entitled to some money back.

• If the person seeking to rely on the guarantee is not the original consumer, the NZXT Warranty will cover the product in relation to that person provided that they are able to provide proof of the transfer of the benefit of the guarantee from the original consumer.
• The implied warranties under the Consumer Rights Act 2015 says that your goods must be as described, fit for all purposes for which such goods are usually supplied, and of satisfactory quality.

In the EU:

• If you are a consumer and have your habitual residence in the EU, you additionally enjoy the protection afforded to you by provisions that cannot be derogated from by agreement by virtue of the law where you have your habitual residence.

IX. WARRANTY SERVICE FROM RESELLERS

In the event that a warranty service is sought, you must provide proof of purchase (store receipt or invoice) in order to receive the service and if deemed necessary, repair or replacement product.

In North America:

Within the first 60 days after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval and an RMA number.

In Europe:

Within the first year after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval.

In Australasia:

Within the first two years after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval.

The cost of shipping will be borne at the first instance by you; however, if the purchased item is defective, NZXT will reimburse reasonable postage or transportation of costs.

Outside North America, Europe, and Australasia:

If your product needs to be returned within the warranty period, please contact the retailer or distributor from whom you purchased the product.

X.NZXT.COM STORE RETURNS/EXCHANGE POLICY

Eligible products under this NZXT Warranty qualify for a full refund or exchange only with an authorized RMA number and if the item is returned to the NZXT.com store inventory within 30 days of purchase. Returns are not allowed beyond 30 days of the purchase date. The NZXT.com Store reserves the right to deny any return or exchange. Refunds will be credited to the original method of payment. To initiate a return, simply submit a request via NZXT support site.

NZXT, Inc./ 15736 E Valley Blvd, City of Industry, CA 91744, USA NZXT Europe GmbH/ Industriering Ost 66 | 47906 Kempen | Germ [phone] / [e-mail] / NZXT.com

If you have any questions or problems with the NZXT product you purchased, please don't hesitate to contact us using our support system. support.nzxt.com

Please include a detailed explanation of your problem and your proof of purchase. For comments and suggestions, you can e-mail our design team, [e-mail]. Lastly we would like to thank you for your support by purchasing this product.

For more information about NZXT, please visit us online. NZXT Website: NZXT.com

SOPORTEY SERVICIO

CNYKBAIPOIDEPKKNUOBCLYKBAHNA

B cnyae BO3HKnHOBeHn BOpocOB nHn HncnPpABHocTeB n PnpO6peTHebIX
BAMn npOyKtax NZXT o6paaJteCb no apdecy: [e-mail]
c noPpO6hBM ONiCaHmE pO6IeMbl n OoTBePjDeHem Eokynk. O
HaNCHn 3Anacte MoKHO y3HaTb, o6paTHBwncb no apdecy: support.
nzxt.com. 3AmeuHn I npedNoXeHn OTnpabJIeTbe B apdec Haewrpynnb
pap6oTukOB: [e-mail]. 5nAoapIM Bac 3a NOKyNK npOyKTA
NZXT. 50ee npO6hA HfOpMaunn O komnauN NZXT npedctTabHeHa
hauxx Be6-caTax. Be6-caT NZXT: NZXT.com

JIJI

APPLIED SAFETY ITEMS AND REGULATIONS ON C SERIES PSU

ITEMS/REGULATIONS WARRANTY LENGTH FOR PARTS
FCC FCC Part 15B, Class B
ICES	ICES-003 Issue 6:2016
CE	EN 55032: 2012+AC: 2013, Class B
	CISPR 32: 2008, Class B
	EN 61000-3-2: 2014, Class D
	EN 61000-3-3: 2013
	EN 55035: 2010
cTUVus	UL 62368-1: 2007/R:2014-10;CAN/CSA-22.2 no.62368-1
RCM	AS/NZS 62368.1:2018AS/NZS CISPR 32: 2015, Class B
TUV Bauart	EN 62368-1 (ed.2)
CB	IEC 60950-1 (ed.2); am1; am2
	IEC 62368-1 (ed.2)
CCC	GB 4943.1-2011GB17625.1-2013
BSMI	CNS 13438 (2006)CNS 14336-1 (2010)CNS 15663 (2013)
EAC/CU TR	IEC 60950-1-2005
RoHS	2011/65/EU, Restriction of Hazardous Substances Directives
WEEE	2012/19/EU, Waste Electrical and Electronic Equipment Directive
RoHS (China)	China Order No.39, Administration on the Control of PollutionCaused by Electronic Information Products
KC	K 60950-1, K 00022, K00024

4.4 REVISION HISTORY

C SERIES BRONZE

Version 1.0, 2021/06/10
