SET 5125 - Manicure and pedicure set Orbegozo - Free user manual and instructions

USER MANUAL SET 5125 Orbegozo

White dental appliance with pink and white decorative design, featuring a closed lid open (no text or symbols visible)

SET 5125

Sonifer,S.A

Read this manual carefully before running this appliance and save it for reference in order to obtain the best results and ensure safe use.

Labeled diagram of a dental implant or tooth device with numbered parts from 1 to 13

When using an electrical appliance, basic safety precautions should always be observed, including the following:

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children must never play with the appliance. Cleaning and user maintenance must never be carried out by children without supervision.

2. Children should be supervised to ensure that they do not play with the appliance.

3. Keep the appliance out of the reach of children less than 8 years old.
4. WARNING: In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.
5. Do not use the unit if it is not working properly.
6. Do not handle the appliance with wet hands.
7. Never immerse the appliance in water or any other liquid.
8. Make sure the appliance has been disconnected before cleaning.

9. This appliance is for household use only.

10. In case that you need a copy of the instruction manual, you can ask for it writing an email to [e-mail]

11. WARNING: In case of misuse, there is a risk of possible injury.

12. During its use can generate great heat on the skin.

13. Monitor results repeatedly during use.
14. Do not use the appliance for a long time without interruption, thus avoiding overheating.
15. Only use the accessory parts supplied.
16. Never use the appliance while taking a bath or during the shower.

DESCRIPTION

Labeled diagram of a dental appliance with numbered parts for identification

1. Accessory support.
2. LED light.
3. Fine cylindrical nozzle
4. Felt cover disk.
5. Thick polishing disk.
6. Fine polishing disk.
7. Big conical nozzle.
8. Pouch cover.
9. Small conical nozzle.

10. Pouch.

11. Motor body.

12. Opening button cover.
13. ON/OFF switch (5 positions: 0, OFF; R1, low speed turn to right; R2, high speed turn to right; L1, low speed turn to left; L2, high speed turn to left).

BEFORE FIRST USE

• This appliance works with 2 AA 1.5V batteries (not included).
• To place the batteries, open the lid on the back side of the appliance and insert the batteries according the indicated polarity.
• Close the lid and it can be used.

USE

• Choose the accessory which you want, depending that you desire.
• Put the accessory on the upper support and push firmly.
• Switch on the appliance putting the ON/OFF switch from 0 position (OFF) to R1/R2 position (turning to right) or L1/L2 (turning to left).
• The rotation speed will be low in R1/L1 and high in R2/L2.
• To remove the accessory, simply pull it.
• When you turn on the appliance the light will be on automatically.

CLEANING AND MAINTENANCE

• Disconnect the appliance when you clean it.
• Clean the main body with a damp cloth and dry it immediately.
• Do not immerse the appliance into the water.
• For cleaning the accessories, use alcohol.
• When you do not use the appliance store it in its pouch.

Disposal of old electrical appliances.

The European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance, it must be separately collected.

Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.

DECLARATION OF CONFORMITY: This device complies with the requirements of the EMC directive 2014/30/EU.
