Features

• Connect an HDMI source to a DisplayPort monitor
• Supports 4K x 2K video resolutions up to 4096 x 2160 @ 30Hz
  • DisplayPort 1.2a compliant
  • Supports 7.1 channel surround sound audio
• Built-in USB-A connector provides power, if needed
• Plug-and-play; no software or drivers required

Package Includes

• P130-06N-DP-V2
• Owner's Manual

System Requirements

- Computer or Blu-ray™ player with an HDMI audio/video port

• Monitor with a DisplayPort

Optional Accessories

• P580-Series DisplayPort Cables

Installation

Note: Make sure all devices to be connected are powered off prior to installation.

1. Connect the converter's built-in HDMI connector to the HDMI source.
2. Using a DisplayPort cable (such as Tripp Lite's P580-Series), connect the converter's DisplayPort to the monitor's DisplayPort.
3. Power on the connected devices.
4. If more power is required than the HDMI source provides, plug the USB-A connector into a USB source.

Specifications

Specification Value
Input Ports HDMI Male	USB-A Female (Power Only)
Output Port DisplayPort	Female
Operating Temperature	32 to 113°F / 0 to 45°C
Storage Temperature	14 to 176°F / -10 to 80°C
Operating Humidity	10 to 85% RH, Non-Condensing
Storage Humidity	5 to 90% RH, Non-Condensing
Max Video Resolution	4096 x 2160 @ 30Hz
Unit Dimension(H x W x D)	0.82 x 0.43 x 9.65 in.20.8 x 11 x 245 mm
Unit Weight 0.09 lb. /	42g

Warranty and Product Registration

One-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

PRODUCT REGISTRATION

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

Warranty and Product Registration

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
