USER MANUAL Power Capsule PC18 011 HOOVER

PRINTED IN P.R.C. 48027578/01 *Certain Models Only ** Certain models only, nozzles may vary according to model

*Certain Models Only ** Certain models only, nozzles may vary according to model *Certain Models Only ** Certain models only, nozzles may vary according to model

This appliance should only be used for domestic cleaning, as described in this user guide. Please ensure that this guide is fully understood before operating the appliance. Do not leave the appliance plugged in. Always switch off and remove the plug from the socket after use, or before cleaning the appliance or any maintenance task. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. If the power cord is damaged stop using the appliance immediately. To avoid a safety hazard, an authorised HOOVER service engineer must replace the power cord. Keep hands, feet, loose clothing and hair away from rotating brushes. Use only attachments, consumables or spares recommended or supplied by HOOVER. Static electricity: Some carpets can cause a small build up of static electricity. Any static discharge is not hazardous to health. Do not use your appliance out of doors or on any wet surface or for wet pick up. Do not pick up hard or sharp objects, matches, hot ashes, cigarette ends or other similar items. Do not spray with or pick up ammable liquids, cleaning uids, aerosols or their vapours. Do not run over the power cord when using your appliance or remove the plug by pulling on the power cord. Do not continue to use your appliance if it appears faulty. HOOVER service: To ensure the continued safe and efcient operation of this appliance we recommend that any servicing or repairs are only carried out by an authorised HOOVER service engineer. Do not stand on or wrap the cord around arms or legs when using your appliance. Do not use the appliance to clean animals or people. Do not position the appliance above you when cleaning the stairs. The Environment The symbol on this appliance indicates that this appliance may not be treated as household waste. Instead it must be handed over to the applicable collection point for the recycling of electrical and electronic equipment. Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information about treatment, recovery and recycling of this appliance, please contact your local city ofce, your household and waste disposal service or the shop where you purchased the appliance. This appliance complies with the European Directives 2014/35/EU, 2014/30/EU and 2011/65/EU. CANDY HOOVER GROUP S.r.l. Via Privata Eden Fumagalli, 20861 Brugherio (MB) Italy GB*Certain Models Only ** Certain models only, nozzles may vary according to model

Remove all components from the packaging.

1. Connect the hose to the cleaner main body, ensuring it locks into position. [1] To

release the hose: simply press the two latches on the hose end and pull.

2. Connect the hose handle to the upper tube end. [2]

3. Connect the tube lower end to the carpet and oor nozzle** or accessories if required. [3]

1. Extract power cord and plug it into the power supply. Do not pull the cord beyond

the red marker . [6]

Adjust the telescopic tube to the desired height by moving the telescopic tube adjuster up and raise or lower the handle to the most comfortable cleaning position. [5]

3. Carpet and Floor Nozzle**: Press the oor type selector pedal* on the nozzle to

select the ideal cleaning mode for the oor type. Hard Floor – Brushes are lowered to protect the oor. Carpet – Brushes are raised for the deepest clean. Carpet & Floor Nozzle**: [4] - Hard oor Cleaning: Press the pedal on the nozzle on Hard Floor mode and adjust the slider on the nozzle on ALL FLOORS. In this position brushes, wheels and wiper blade are lowered to protect hard oors. [4a] - Standard Carpet & Rugs Cleaning: Press the pedal on the nozzle on Carpet mode and adjust the slider on the nozzle on ALL FLOORS. In this position brushes and wiper blade are raised while wheels are lowered to allow a perfect ease of movement on such surfaces. [4b] - Deep Carpet Cleaning: Press the pedal on the nozzle on Carpet mode and adjust the slider on the nozzle on DEEP CARPET CLEANING. In this position brushes, wheels and wiper blade are raised for a deeper cleaning of your carpet. [4c]

WARNING: It is recommended to avoid potential scratching of wooden oors that the

pedal is not set on Hard oor mode and the slider on Deep carpet cleaning.

4. Switch the cleaner on by pressing the On/Off button on the cleaner main body.

5. Rotate Variable power rotary knob to increase or decrease the power. [8]

6. Adjust the suction regulator to the desired level. [9]

7. Switch off at the end of use by pressing the on/off button. Unplug and press the cord

rewind button to wind the power cord back into the cleaner.

8. Parking and storage – The tube can be parked for temporary storage while in use, or in

the storage position when not in use. [10] CLEANER MAINTENANCE Replacing the Dust Bag If the bag check indicator is red, please check and, if necessary, replace the bag.

1. Lift the bag door Latch to open the bag door and remove the bag. [11,12] The full

dust bag should be disposed of correctly and carefully.

2. Fold a new bag as shown on the bag and t by inserting the collar into the bag

3. Close the Bag door.

REMEMBER: The bag check indicator may be red if an obstruction has occurred. In this case refer to ‘Removing a Blockage From the System’. Cleaning the Filter: To maintain optimum performance of your cleaner, please wash the pre-motor lter and exhaust lter after each 5 bag changes. Cleaning the pre-motor lter:

1. Lift the bag door release latch to open the bag door and remove the bag.

2. To remove the pre-motor lter slide the pre-motor lter frame from the cleaner. [13]

3. Remove the lter from the holder. [13]

4. Wash it in hand warm water [16], and allow it to dry [17] thoroughly before replacing

to the cleaner. Cleaning the exhaust lter:

1. The remove the exhaust lter, unclip the exhaust lter cover and remove the exhaust

2. Wash the lter in hand warm water [16] and allow it t

o dr y [17] thoroughly before replacing to the cleaner. REMEMBER: Do not use hot water or detergents. In the unlikely event of the lters becoming damaged, t a Genuine Hoover replacement.GB USER CHECKLIST Should you have a problem with the product, complete this simple user checklist before calling your local Hoover service.

• Is there a working electricity supply to the cleaner? Please check with another electrical appliance.

• Is the dust bag over-filled? Please refer to ‘Cleaner Maintenance’.

• Is the Filter blocked? Please refer to ‘Cleaner Maintenance’.

• Is the hose or nozzle blocked? Please refer to ‘Removing a blockage from the system’.

• Has the cleaner overheated? If so, it will take approximately 30 minutes to automatically reset. IMPORTANT INFORMATION HOOVER spares and Consumables Always replace parts with genuine HOOVER spares. These are available from your local HOOVER dealer or direct from Hoover. When ordering parts always quote your model number. Quality HOOVER’s factories have been independently assessed for quality. Our products are made using a quality system which meets the requirements of ISO 9001. Your Guarantee The guarantee conditions for this appliance are as dened by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee. Subject to change without notice. *Certain Models Only ** Certain models only, nozzles may vary according to model

Do not try and use the product without a dust bag or lter tted. Cleaning the permanent cloth dust bag* (certain models only) To maintain optimum performance we recommend that you wash the permanent cloth dust bag under hand warm water after every 5 full bags. Remove excess water and leave to dry fully before replacing. Removing a blockage from the system If the bag check indicator is red:

1. Check if the bag is full. If so refer to ‘Replacing The Dust Bag’.

2. If it is not full, then;

Do the lters need cleaning? If so refer to ‘Cleaning the Filter’. B. Check if there is any other blockage in the system - Use a rod or a pole to remove any blockage from telescopic tube* or exible hose. WARNING*: -The bag check indicator will remain red if the cleaner is used when the bag is full, if there is a blockage or if the lters are dirty. If used for a period over ten 10 minutes with the bag check indicator red, an electronic cut out will switch the cleaner off to prevent any risk of overheating. If this should happen, switch the cleaner off, unplug and correct the fault (see ‘Removing a blockage’). The cut out will automatically reset upon switching the cleaner back on.

ACCESSORIES AND NOZZLES

To obtain the best performance and efciency it is recommended that the correct nozzles are used for the main cleaning operations. These nozzles are indicated in the diagrams by the letters GP, HF or CA. A nozzle type GP can be used to clean both carpet and hard oor. A nozzle type HF is suitable for use only on hard oor. A nozzle of type CA is suitable for use only on carpet. The other nozzles are accessories for specialist cleaning tasks and are recommended for occasional use only. All accessories can be tted to the end of the hose handle [2] or to the end of the tube. 2 in 1 Tool combines several functions into one tool [U]: Crevice Tool – For corners and hard to reach areas. Dusting Brush – For bookshelves, frames, keyboards and other delicate areas. Pet Hair Remover Mini Turbo Nozzle*– Use the mini turbo nozzle on stairs or for deep cleaning on textile surfaces and other hard to clean areas. Particularly suitable for pet hair removal. Allergen Remover Mini Turbo Nozzle* – Use the mini turbo nozzle on stairs or for deep cleaning on textile surfaces and other hard to clean areas. Particularly suitable for allergen removal. Parquet Nozzle* – For parquet oors and other delicate oors. IMPORTANT: Do not use mini turbo nozzles on rugs with long fringes, animal hides and carpet pile deeper than 15mm. Do not keep the nozzle stationary while the brush is rotating. Long Flexible Crevice Tool * - Ideal for car cleaning. Its length enables cleaning of difcult areas to reach, narrow crevices. [Za] Large Dusting Brush with integrated Furniture Nozzle*- Suitable to clean the soft & delicate surfaces for both car and home. [Zb] Accessories’ bag* - For tidy storage of all the accessories. [Zc]4
