Panigale V2 (2026) - Motorcycle DUCATI - Free user manual and instructions

Product Type	Sport motorcycle
Brand	Ducati
Model	Panigale V2 (2026)
Engine	L-twin cylinder, 4 valves per cylinder, liquid cooling
Displacement	890 cm³
Max Power	120.4 hp (88.5 kW) at 10750 rpm
Max Torque	93.3 Nm at 8250 rpm
Fuel System	Electronic injection, unleaded premium gasoline 95-98 RON, max 10% ethanol
Transmission	6-speed gearbox, DQS up/down EVO, Regina 520 chain
Front Brakes	Dual semi-floating 320mm discs, Brembo M50 calipers, Bosch Cornering ABS EVO
Rear Brake	Fixed 245mm disc, Brembo P34 caliper, Cornering ABS EVO
Front Suspension	Marzocchi inverted 43mm fork, adjustable rebound, compression and preload
Rear Suspension	Adjustable Kayaba shock absorber, 150mm travel
Fuel Tank Capacity	15 L (including 4 L reserve)
Max Permissible Weight	410 kg (rider + luggage + accessories)
Electronics	TFT 5" dashboard, Riding Modes (Race, Sport, Road, Wet), DTC, DWC, EBC, ABS, DQS, Cruise Control, Pit Limiter
Connectivity	Ducati Link, Bluetooth (optional multimedia system)
Tires	Front 120/70 ZR17, rear 190/55 ZR17 (Pirelli Diablo Rosso IV)
Maintenance	Follow scheduled maintenance plan in the manual (oil change, periodic checks)
Safety	Electronic immobilizer, ABS, DTC, DWC, automatic hazard lights, emergency braking
Warranty	Standard 24-month warranty (subject to conditions)
Spare Parts	Original Ducati parts available at authorized dealers

Frequently Asked Questions - Panigale V2 (2026) DUCATI

What fuel should I use for the Ducati Panigale V2?

Use unleaded premium gasoline with an octane rating of at least 95 RON, and a maximum ethanol content of 10% (E10). Using fuels with more than 10% ethanol voids the warranty.

What engine oil is recommended?

Ducati prescribes SAE 15W-50 API SP and JASO MA2 oil. It is recommended to use DUCATI Genuine OIL Powered by Shell Advance 15W-50 or SHELL Advance 4T Ultra 15W-50.

How do I adjust the suspension of the Panigale V2?

The front fork is adjustable for rebound (screw on the right tube), compression (screw on the left tube) and spring preload (hex screw). The rear shock absorber is adjustable for rebound, compression (screw) and preload via rings. The manual provides indicative settings for Standard, Race, Sport, Road and Wet modes.

What is the maximum permissible weight for the Panigale V2?

The total curb weight with rider, luggage and accessories must not exceed 410 kg.

How do I maintain the drive chain?

Lubricate the chain regularly with a suitable product and check the tension (refer to the manual). The original chain is a Regina 520 ZRDK with 105+1 links.

Is there a traction control system?

Yes, the motorcycle is equipped with Ducati Traction Control (DTC) adjustable directly from the dashboard in the different Riding Modes.

How do I activate the cruise control?

The Cruise Control is activated via the right-hand switch: press ON/OFF, then SET/- or RES/+ to set the speed. It is available in the appropriate riding modes.

What if the key is not recognized at startup?

You can unlock the motorcycle by entering your personal PIN code (configured in the menu 'Settings - Vehicle - PIN Code'). If the problem persists, contact a Ducati dealer.

How do I connect my smartphone to the motorcycle?

The motorcycle is compatible with the MyDucati app and Ducati Link via Bluetooth. You can connect your phone to access Smart functions (calls, music, navigation). Refer to the manual for the procedure.

What is the recommended tire pressure?

For road use with rider only: front 2.3 bar, rear 2.5 bar. With passenger: front 2.5 bar, rear 2.8 bar. For track: front 2.1 bar, rear 1.9 bar. Always check tires cold.

USER MANUAL Panigale V2 (2026) DUCATI

Utilisation de Ducati Corse Performance Oil by Shell. 252

Nettoyage general 252

Transport vehicule. 256

Attention: Ce motorcycle

Attention: Un cabbage

Attention Le motorcycle

Pit limiter (si present)

Attention Ducati a test

Attention Les construct

Attention Ducatin'a pa

Utilisation de Ducati Corse Performance Oil by Shell

Attention Le motorcycle

Dimension: 120/70 R17.

Arrière

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions:

(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.

RF Exposure Information:

This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20~cm between the radiator and your body.

Canadian Representative:

DUCATI CANADA

777 Bayly Ave. Ajax ON Canada L1S7G7

Tel No.: [phone]

CHINA

(Translation: The use of micropower short range radio transmission equipment shall be in accordance with the relevant provisions of the National Radio Management.)

Dashboard RTADE002

TPMS (17109)

TPMS LDL (171090)

(1) The specific conditions and usage scenarios that comply with the "catalog and technical requirements of micropower short-range radio transmitting equipment", the types and performance of antennas used, control, adjustment and switching methods;
（一）符合“微功率短距离无线电发射设备目录和技术要求”的具体条款和使用场景，采用的天线类型和性能功能，控制、调整及开关等使用方法；
(2) Instruct not to change the use scene or conditions without authorization, expand the transmission frequency range, increase the transmission power (including additional installation of RF power amplifiers), and do not change the transmission antenna without authorization;
（二）不得擅自改变使用场景或使用条件、扩大发射频率范围、加大发射功率（包括额外加装射频功率放大器），不得擅自更改发射天线；
(3) It shall not cause harmful interference to other legitimate radio stations (stations), and shall not propose protection from harmful interference;

(4) Should withstand interference from industrial, scientific, and medical (ISM) application equipment that radiates radio frequency energy or interference from other legal radio stations (stations);
（四）应当承受辐射射频能量的工业、科学及医疗（ISM）应用设备的干扰或其他合法的无线电台（站）干扰；
(5) If it causes harmful interference to other legal radio stations (stations), it shall immediately stop using it and take measures to eliminate interference before continuing to use it;
（五）如对其他合法的无线电台（站）产生有害干扰时，应立即停止使用，并采取措施消除干扰后方可继续使用；
(6) During the use of Low Power equipment in aircraft and in electromagnetic environmental protection areas the regulations of the competent departments of electromagnetic environmental protection and related industries shall be observed;
（六）在航空器内和依据法律法规、国家有关规定、标准划设的射电天文台、气象雷达站、卫星地球站（含测控、测距、接收、导航站）等军民用无线电台
(7) It is forbidden to use various model remote controllers in the area with the center point of the airport runway and a radius of 5000 meters;

（七）禁止在以机场跑道中心点为圆心、半径5000米的区域内使用各类模型遥控器；
(8) Environmental conditions of temperature and voltage when micro power equipment is used.

Your vehicle is equipped with a range of radio equipment. The manufacturers of this radio equipment declare that these equipment complies with Directive 2014/53/EU where required by law. The complete text of the EU declaration of conformity is available at the following web address: certifications.ducati.com

[Italy]

Your vehicle is equipped with a range of radio equipment. The manufacturers of this radio equipment declare that these equipment complies with Directive 2014/53/EU where required by law. The complete text of the EU declaration of conformity is available at the following web address: certifications.ducati.com

JAPAN

This equipment contains specified radio equipment that has been certified to the technical regulation conformity certification under the Radio Law.

This radio device should not be modified (otherwise the granted designation number will become invalid)

Dashboard RTADE002

Ducati Multimedia System MFi (IN2ROUTERX)

TPMS (17110)

MEXICO

Dashboard (RTADE002/A)	TA-2024/2712
TPMS (17109) TA-2019/1178
TPMS (171090) TA-2023/1600

SOUTH KOREA

海当早

[ \text{ Dashboard RTADE002 R-R-Egi-RTADE002} ]

Ducati Multimedia System (IN2ROU-TERX)	R-R-Cbo-1080795
TPMS (17109)	R-C-T46-17109
TPMS (171090)	R-C-T46 -171090

THATLAND

mnnnnaaannnnnnaanennnneaaeennnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn

Type 2: Radiocommunication equipment that is license exempted (e.g. WWAN, WLAN, NFC, WLAN, Bluetooth):

English Translation of content:

This radiocommunication equipment is exempted from a possess license, user license, or radiocommunication station license as per NBTC notification regarding radiocommunication equipment and radiocommunication station exempted from licensing in accordance with radio communication act B.E.2498

Dashboard RTADE002

TPMS (17109)

TPMS (171090)

UK

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation."

"Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment." "NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gene rates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfere nee to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help."

RF exposure Information according 2.1091/2.1093 / OET bulletin 65:

Radiofrequency radiation exposure Information: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20~cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

The manufacturers of these radio equipment declare that devices comply with the FCC.

The TPMS device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Dashboard RTADE002 FCC ID: 2ANYI-RTADE002
Ducati Multimedia System (IN2ROU-TERX))	FCC ID: Z64-2564N
TPMS (17109)	FCC ID: T45-17109
TPMS (171090)	FCC ID: T45-171090
RCU FCC ID:T45-21191

MIX

From responsible

SOURCE

FSC-C110200

Ducati Motor Holding spa

ducati.com

Via Cavalieri Ducati, 3

40132 Bologna, Italy

Ph. [phone]

Fax[phone]

A Sole Shareholder Company

A Company subject to the Management

and Coordination activities of AUDI AG
