AXIS Q63 - LE Series PTZ Camera AXIS Q6355 - LE PTZ Camera AXIS Q6358 - LE PTZ Camera Installation guideRead this rst Read through this installation guide carefully before you install the product. K eep the installation guide for future reference. Legal considerations Video surveillance can be regulated by laws that vary from country to country . Check the laws in your local region before using this product for surveillance purposes. This product includes the following licenses:

• one (1) H.264 decoder license

• one (1) H.265 decoder license T o purchase further licenses, contact your reseller . Liability Every care has been taken in the preparation of this document. Please inform your local Axis ofce of any inaccuracies or omissions. Axis Communications AB cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the product and manuals without prior notice. Axis Communications AB makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of merchantability and tness for a particular purpose. Axis Communications AB shall not be liable nor responsible for incidental or consequential damages in connection with the furnishing, performance or use of this material. This product is only to be used for its intended purpose. Intellectual property rights Axis AB has intellectual property rights relating to technology embodied in the product described in this document. In particular , and without limitation, these intellectual property rights may include one or more of the patents listed at axis.com/patent and one or more additional patents or pending patent applications in the US and other countries. This product contains licensed third - party software. See the third - party license information in the product’s user interface for more information. This product contains source code copyright Apple Computer , Inc., under the terms of Apple Public Source License 2.0 (see opensource.apple.com/apsl ). The source code is available from developer .apple.com/bonjour/ . Equipment modications This equipment must be installed and used in strict accordance with the instructions given in the user documentation. This equipment contains no user - serviceable components. Unauthorized equipment changes or modications will invalidate all applicable regulatory certications and approvals. T rademark acknowledgements AXIS COMMUNICA TIONS, AXIS, ARTPEC and VAPIX are registered trademarks of Axis AB in various jurisdictions. All other trademarks are the property of their respective owners. Apple, Apache, Bonjour , Ethernet, Internet Explorer , Linux, Microsoft, Mozilla, Real, SMPTE, QuickTime, UNIX, Windows, and WWW are registered trademarks of the respective holders. Java and all Java - based trademarks and logos are trademarks or registered trademarks of Oracle and/or its afliates. The UPnP W ord Mark and UPnP Logo are trademarks of Open Connectivity Foundation, Inc. in the United States or other countries. SD, SDHC, and SDXC Logos are trademarks of SD - 3C LLC. SD, SDHC and SDXC are trademarks or registered trademarks of SD - 3C, LLC in the United States, other countries or both. Regulatory information Europe This product complies with the applicable CE marking directives and harmonized standards:

• Restriction of Hazardous Substances (RoHS) Directive 20 1 1/65/EU and 20 15/863, including any amendments, updates or replacements. See Disposal and recycling on page 3 . A copy of the original declaration of conformity may be obtained from Axis Communications AB . See Contact information on page 4 . Electromagnetic compatibility (EMC) This equipment has been designed and tested to fulll applicable standards for:

• Radio frequency emission when installed according to the instructions and used in its intended environment.

• Immunity to electrical and electromagnetic phenomena when installed according to the instructions and used in its intended environment. USA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference,

2. this device must accept any interference received,

including interference that may cause undesired operation. This equipment has been tested using an unshielded network cable (UTP) and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. This equipment has also been tested using a shielded network cable (STP) and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance 2with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Contact information Axis Communications Inc. 300 Apollo Drive Chelmsford, MA 0 1824 United States of America T el: +1 978 6 14 2000 Canada This digital apparatus complies with CAN ICES - 3 (Class A). The product shall be connected using a shielded network cable (STP) that is properly grounded. Cet appareil numérique est conforme à la norme CAN NMB - 3 (classe A). Le produit doit être connecté à l'aide d'un câble réseau blindé (STP) qui est correctement mis à la terre. Europe This digital equipment fullls the requirements for RF emission according to the Class A limit of EN 55032. The product shall be connected using a shielded network cable (STP) that is properly grounded. Notice! This is a Class A product. In a domestic environment this product may cause RF interference, in which case the user may be required to take adequate measures. Australia/New Zealand This digital equipment fullls the requirements for RF emission according to the Class A limit of AS/NZS CISPR 32. The product shall be connected using a shielded network cable (STP) that is properly grounded. Notice! This is a Class A product. In a domestic environment this product may cause RF interference, in which case the user may be required to take adequate measures. Japan こ の 装 置 は 、 ク ラ ス A 機 器 で す 。 こ の 装 置 を 住 宅 環 境 で 使 用 す る と 電 波 妨 害 を 引 き 起 こ す こ と が あ り ま す 。 こ の 場 合 に は 使 用 者 が 適 切 な 対 策 を 講 ず る よ う 要 求 さ れ る こ と が あ り ま す 。 VCCI ‒ A 本 製 品 は 、 シ ー ル ド ネ ッ ト ワ ー ク ケ ー ブ ル (STP) を 使 用 し て 接 続 し て く だ さ い 。 ま た 適 切 に 接 地 し て く だ さ い 。 本 製 品 は 電 気 通 信 事 業 者 （ 移 動 通 信 会 社 、 固 定 通 信 会 社 、 イ ン タ ー ネ ッ ト プ ロ バ イ ダ 等 ） の 通 信 回 線 （ 公 衆 無 線 LAN を 含 む ） に 直 接 接 続 す る こ と が で き ま せ ん 。 本 製 品 を イ ン タ ー ネ ッ ト に 接 続 す る 場 合 は 、 必 ず ル ー タ 等 を 経 由 し 接 続 し て く だ さ い 。 K orea 이 기 기 는 업 무 용 환 경 에 서 사 용 할 목 적 으 로 적 합 성 평 가 를 받 은 기 기 로 서 가 정 용 환 경 에 서 사 용 하 는 경 우 전 파 간 섭 의 우 려 가 있 습 니 다 . 적 절 히 접 지 된 STP (shielded twist ed p air) 케 이 블 을 사 용 하 여 제 품 을 연 결 하 십 시 오 . Safety The product shall be grounded via an appropriate grounding cable. When used with P ower over Ethernet (P oE), the P ower Sourcing Equipment (PSE) shall comply with IEEE 80 2.3at/80 2.3bt and Limited P ower Source (LPS) according to clause 2.5 of IEC/EN/UL 60950 - 1 or annex Q of IEC/EN/UL 62368 - 1. Photobiological safety This product fullls the requirements for photobiological safety according to IEC/EN 6247 1 (risk group 2). Laser safety This Class 1 laser product complies with IEC 60825 - 1:20 14 and EN 60825 - 1:20 14 + A1 1:20 2 1. Disposal and recycling When this product has reached the end of its useful life, dispose of it according to local laws and regulations. For information about your nearest designated collection point, contact your local authority responsible for waste disposal. In accordance with local legislation, penalties may be applicable for incorrect disposal of this waste. Europe This symbol means that the product shall not be disposed of together with household or commercial waste. Directive 20 12/19/EU on waste electrical and electronic equipment (WEEE) is applicable in the European Union member states. T o prevent potential harm to human health and the environment, the product must be disposed of in an approved and environmentally safe recycling process. For information about your nearest designated collection point, contact your local authority responsible for waste disposal. Businesses should contact the product supplier for information about how to dispose of this product correctly . This product complies with the requirements of Directive 20 1 1/65/EU and 20 15/863 on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS). China This product complies with the requirements of SJ/T 1 1364 - 20 14, Marking for the restriction of hazardous substances in electrical and electronic products. 有 毒 有 害 物 质 或 元 素

• nd answers to resolved problems in the FAQ database, search by product, category , or phrase

• report problems to Axis support staff by logging in to your private support area

• chat with Axis support staff

• visit Axis Support at axis.com/support Learn more! Visit Axis learning center axis.com/learning for useful trainings, webinars, tutorials and guides. 5English Safety information Hazard levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury . W ARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury . CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury . NO NO

TICE TICE TICE Indicates a situation which, if not avoided, could result in damage to property . Other message levels Important Indicates signicant information which is essential for the product to function correctly . Note Indicates useful information which helps in getting the most out of the product. Safety instructions CAUTION IR is emitted from this product. It can be harmful to the eyes. Avoid eye exposure. Use shielding or eye protection. CAUTION P ossibly hazardous radiation exposure from this product. T o avoid exposure, use the specied controls or adjustments or performance of procedures. NO NO

• This is a Class 1 laser product

• The Axis product shall be used in compliance with local laws and regulations.

• This product is for professional use.

• Install this product at a safe distance from children.

• Store the Axis product in a dry and ventilated environment.

• Avoid exposing the Axis product to shocks or heavy pressure.

• Do not install the product on unstable poles, brackets, surfaces or walls.

• Use only applicable tools when installing the Axis product. Using excessive force with power tools could cause damage to the product.

• Do not use chemicals, caustic agents, or aerosol cleaners.

• Use a soft cloth dampened with pure lukewarm water to clean the device.

• Don’t use chemicals such as window cleaner or acetone to clean your device.

• Use only accessories that comply with the technical specication of your product. These can be provided by Axis or a third party . Axis recommends using Axis power source equipment compatible with your product.

• Use only spare parts provided by or recommended by Axis.

• Do not attempt to repair the product yourself. Contact Axis support or your Axis reseller for service matters.

• Do not point the camera lens toward the sun or other high - intensity radiation sources because this could cause damage to the camera.

• Use a yellow/green colored grounding cable of at least 0.5 mm

• When transporting the Axis product, use the original packaging or equivalent to prevent damage to the product. Battery The Axis product uses a 3.0 V BR2032 lithium battery as the power supply for its internal real - time clock (RT C). Under normal conditions this battery will last for a minimum of ve years. Lithium coin cell 3.0 V batteries contain 1,2 - dimethoxyethane; ethylene glycol dimethyl ether (EGDME), CAS no. 1 1 0 - 7 1 - 4. Dome or front glass NO NO

• Be careful not to scratch, damage or leave ngerprints on the dome or front glass since this can decrease image quality . K eep the protective plastic on until the installation is complete.

• Don’t clean a dome or front glass that looks clean to the eye, and never polish the surface. Excessive cleaning can damage the surface.
