Eliminación del embalaje El embalaje está marcado con el Punto Verde. Para eliminar todos los materiales de embalaje, como el cartón, poliuretano y las películas, utilice contenedores adecuados. Así se garantiza la reutilización de los materiales de embalaje. Eliminación de aparatos fuera de uso En base a la Norma europea 2012/19/UE de Residuos de Aparatos Eléctricos y Electrónicos (RAEE), los electrodomésticos viejos no pueden ser arrojados en los contenedores municipales habituales; tienen que ser recogidos selectivamente para optimizar la recuperación y reciclado de los componentes y materiales que los constituyen, y reducir el impacto en la salud humana y el medioambiente. El símbolo del cubo de basura tachado se marca sobre todos los productos para recordar al consumidor la obligación de separarlos para la recogida selectiva. El consumidor debe contactar con la autoridad local o con el vendedor para informarse en relación a la correcta eliminación de su electrodoméstico viejo. Antes de eliminar su aparato, inutilícelo. Tire el cable de alimentación, córtelo y elimínelo.16 Safety Instructions Carefully read the instructions before installing and using the equipment. The manufacturer is not liable for improper installation and use of the equipment that may cause injuries and damage. Always keep the instructions at hand, so they can be easily referred to during use. Children and Vulnerable people safety This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. General Safety There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room). Do not flambé under the range hood. CAUTION: Accessible parts may become hot when used with cooking appliances. Installation The electric system must be equipped with a means for disconnection, with a contact separation in all poles that provides full disconnection under overvoltage category III conditions, in accordance to the wiring rules. If a plug is used for the electric connection, then it must be accessible after installation. The air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels17 english (not applicable to appliances that only discharge the air back into the room). The lower part of the extractor must be located at a minimum height of 60 cm above the hob for electric cookers and 65 cm for gas cookers. If the instructions of a gas cooker indicate a greater distance these must be observed. Before installing the extractor consult the local rules and regulations in force with respect to the discharge of air and fumes. When the extractor is working at the same time as other non-electrical cooking equipment, the outlet air pressure must not exceed 4 Pa (4x10-5 bar). Before connecting the extractor to the mains, check that both the voltage and the frequency conform to that shown on the characteristics label located inside the extractor. To achieve optimum performance the length of the outlet hose should not exceed 4 meters, or include more than two 90º angles (elbows). Although venting to the outside is recommended, activated carbon filter may be used to allow the gas to be returned to the kitchen through the outlet pipe. NOTE: For more Installation information, refer to the end of this user manual. Cleaning There is a fire risk if cleaning is not carried out in accordance with the instructions. Do not allow grease to accumulate in any part of the extractor, especially in the grease filters as this COULD PRODUCE A FIRE RISK! The grease filters and the internal part of the extractor must be cleaned at least once a month depending on how often18 the extractor is used. Note that grease is deposited in the extractor when cooking, whether it is switched on or not. We recommend the use of gloves and caution when cleaning the inside of the extractor. Repairs If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Do not switch on the extractor if the supply cord is worn or has cuts or if there are signs of deterioration around the control panel. If the LED module is malfunctioning, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. If the extractor stops working or functions abnormally, unplug it from the mains and contact the technical service.

A Motor push control that allow 6 speeds to be selected Intensive

Speed B Lamp push control C Lighting by means of lamps D Filters located over cooking area, easily withdrawn for cleaning E Extractable group that allows a greater gas capture area F Possibility of incorporating activated charcoal filter (Fig. 2) G-H Anti return tabs to be located in the outlet mouth, locating their ends in the holes provided (Fig.5). To achieve better extraction, we recommend switching on the extractor a few minutes before starting to cook (3 - 5 minutes) so that the air flow is continuous and stable when extracting the fumes. Likewise, keep the extractor switched on for a few minutes when cooking is complete to allow all fumes and odours to be expelled.19 english Operating settings

1. When the tray is opened, the hood starts

operating at speed 1.

2. To increase speed gradually, press the

maximum speed is set.

3. The sixth speed is timed, so the cooker

hood will automatically revert to the third speed after seven minutes.

4. To reduce the speed gradually, press the

5. To turn off the cooker hood directly at any

seconds. Programming stop delay timer

1. Programming Timer

a. Open Tray with motors switched on or off

aspiration time. Each LED represents 5 minutes of operating time. The maximum operating time is 30 minutes (the LED corresponding to the intensive speed starts flickering fast). d. 5 seconds after pressing the keys, the LED corresponding to the time stops flickering fast and the LED corresponding to the selected speed starts flickering slowly. e. In stop delay timer Mode, speed can be

2. Cancellation of Stop Delay Timer:

pressed until the motors switch off, or close the tray. Lighting The lighting can be switched on and off by When tray is opened, the lighting is switched on or off, depending on how it was used the last time. Before carrying out any cleaning or maintenance activities, ensure that the extractor is disconnected from the mains. To carry out cleaning and maintenance, follow the Safety Instructions. Fire risk exists in case that cleaning does not take place according to the instructions. Filter cleaning To withdraw the filters from their locations release the anchoring points. Clean the filter, either by putting it in the dishwasher (see notes) or leaving it standing in hot water to simplify the removal of grease or, if wished, by means of special sprays (protecting the non metallic parts). Once clean, leave it to dry. Attention: the cooker hood will not work until the main filter was reinstalled. Notes: cleaning in the dishwasher with aggressive detergents may blacken the surface of metallic parts, without this affecting its gas retaining properties. N.B. The filter must be cleaned at least once a month depending on how often the extractor is used. It must be remembered that grease is deposited in the extractor when cooking, whether it is switched on or not. Cleaning of the extractor body The use of warm (40ºC approx.) soapy water is recommended. A cloth moistened in this water is used for cleaning the extractor, paying20 special attention to the grids. Afterwards, dry it using a lint-free cloth. Note: Never use metallic scouring pads or abrasive products that could damage the surface. Do not use scrapers with metallic surfaces such as knives, scissors etc. Activated charcoal filter To install the charcoal filter, the motor anchorage is made to coincide with the anchor points of the activated charcoal filter and turn it clockwise. The carbon filter lasts from three to six months depending on the particular conditions of use. The activated carbon filter can neither be washed nor regenerated. Once it is exhausted, it must be changed. To replace exhausted filters with new ones, withdraw the old one in the reverse order to that of installation. Dimensions: Width = 600/ 900 mm Depth = 300 mm Height = 183/273 mm Electrical characteristics:

REFER TO RATING PLATE

To fix the cooker hood please choose one of the following options: a) Fixing to the upper part of the furniture: Figure 4 must be used where the position of the holes is indicated. b) To the internal side of the furniture: When the body hood fits within the furniture, fasten with two screws on each side from the inside of the body hood, using their side holes. The lower part of the extractor must be located at a minimum height of 60 cm above the hob for electric cookers and 65 cm for gas cookers. If the instructions of a gas cooker indicate a greater distance these must be observed. To achieve optimum performance the length of the outlet hose should not exceed 4 meters, or include more than two 90º angles (elbows). Although venting to the outside is recommended, activated carbon filters may be used, which allow the gas to be returned to the kitchen through the outlet pipe. If you wish to exchange the front for one matching the kitchen units, follow the following instructions (Fig. 3): Withdraw the movable group. Remove the screws (T) that support the front. Install the new front fixing it with the same screws that held the old one.21 english

Before seeking technical assistance carry out the following checks first: Defect Possible cause Solution The extractor does not work The cable is not connected Connect the mains cable No current is reaching the plug Revise/repair the electricity circuit The extractor does not blow enough or vibrates Filter saturated with grease Clean or substitute the filter Outlet obstructed Eliminate obstructions Inadequate air conduit Contact the installer and follow instructions of this manual The lamps do not light Lamp broken Contact the Customer Service ILCOS D Code: DSL-6-S-500
