Product type Cordless hydraulic scissors
Brand Hilti
Model NCT 85 C22
Rated voltage 21.6 V
Battery type Li-Ion Hilti Nuron B 22 series
Weight (without battery) 15 lb (≈ 6.8 kg)
Max cutting capacity (copper/aluminum) 3.3 in (83.8 mm)
Max cable section 3.3 in (83.8 mm)
Operating temperature -17 °C to 60 °C (1 °F to 140 °F)
Storage temperature -20 °C to 70 °C (-4 °F to 158 °F)
Power supply Rechargeable Li-Ion battery
Main functions Cutting copper and aluminum cables
Safety Anti-start locking device, drop protection
Lighting Work LED
Indicators Status LEDs on battery and tool (charge, error, maintenance)
Maintenance Clean with damp cloth, brush for vents; no silicone cleaners
Spare parts Contact Hilti customer service or Hilti Store
Warranty Hilti manufacturer warranty
Intended use Professional

Frequently Asked Questions - NCT 85 C22 HILTI

How to activate the anti-start locking device?
Remove the battery, press and hold the speed control switch, insert the battery, then release the switch. The green LED flashes twice with two beeps: locking activated.
What type of battery to use with the NCT 85 C22?
Use only Hilti Nuron Li-Ion batteries from the B 22 series. For optimal power, refer to the end of the manual for recommended models.
How to clean the cutting tool?
Clean the housing with a slightly damp cloth (no silicone). Clean the ventilation slots with a dry brush. Always remove the battery before cleaning.
What to do in case of oil leakage?
Stop using the tool and contact Hilti Service. Immediately remove spilled oil. Pressurized oil leakage can cause injury.
How many cuts can I perform before a break?
After about every 50 cuts, take a 15-minute break to allow the tool to cool down, to avoid overheating.
How to interpret the LEDs on the battery?
Briefly press the unlock button: 4 green LEDs = 100-71%, 3 = 70-51%, 2 = 50-26%, 1 = 25-10%, 1 slow flashing = <10%, fast flashing = discharged or error. See the fault table in the manual.
Can I cut live cables?
No. Before any cut, de-energize all live components. If not possible, take appropriate protective measures. Never work on live cables during a thunderstorm.
Where to find spare parts?
Spare parts and accessories are available at the Hilti Store or on www.hilti.group. Use only original parts.
How to transport and store the tool?
Always remove the battery before transport. Do not transport batteries loose. Store in a dry, cool place, out of reach of children, respecting storage temperatures (-20°C to 70°C).
What to do if the tool does not start?
Check the battery charge level, temperature, and anti-start lock. If the red light flashes, contact Hilti Service. Consult the fault table in the manual.
