• Lave-linge et chargement frontalCongratulations on your purchase and welcome to the LG family. Your new LG washing machine combines the most advanced washing technology with simple operation and high efficiency. Follow the operating and care instructions in this manual, and your washer will provide many years of reliable service. THANK YOU! I N T RO D U C T I O N INSTALLATION INSTRUCTIONS Choose the Proper Location p. 9
• Clearances p. 9
• Flooring p. 10
• Installations With Optional Pedestal Base or Stacking Kit p. 10
• Unpacking and Removing Shipping Bolts p. 11
• Connecting the Water Lines p. 12
• Connecting the Drain Line p. 13
• Leveling the Washer p. 14
• Installation of non-skid pads (optional) p. 14

Basic Safety Precautions .................................. 3–6Key Dimensions and Specifications ..................... 33 Optional Accessories ........................................... 33 Product Registration Information Model:Serial Number:Date of Purchase:The model and serial number can be located on the rating plate on the front of the washer. 2I M P O RTA N T S A F E T Y I N S T RU C T I O N S wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. Your Safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.This is the safety alert symbol.This symbol alerts you to potential hazards that can kill or hurt you and others.All safety messages will follow the safety alert symbol and either the word DANGER or WARNING.These words mean: wDANGER: You can be killed or seriously injured if you don’t immediately follow instructions. wWARNING: You can be killed or seriously injured if you don’t follow instructions. All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

READ ALL INSTRUCTIONS BEFORE USE• Before use, the washer must be properly installed as described in this manual.

• Do not wash articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite or explode.

• Do not add gasoline, dry cleaning solvents, or other flammable or explosive substances to the wash water. These substances give off vapors that could ignite or explode.

• Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using the washer, turn on all hot water faucets and let the water flow from each for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this time.

• Do not allow children to play on or in the washer. Close supervision of children is necessary when the washer is used near children.

• Before the washer is removed from service or discarded, remove the door to prevent children from climbing inside.

• Do not install or store the washer where it will be exposed to the weather or freezing temperatures.

• Do not tamper with controls.

• Do not repair or replace any part of the washer or attempt any servicing other than as described in this manual. We strongly recommend that any service be performed by a qualified individual.

• See Installation Instructions for grounding requirements.

• ALWAYS follow the fabric care instructions supplied by the garment manufacturer.

• Do not place items exposed to cooking oil in your washer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.

• Use fabric softeners or products to eliminate static only as recommended by the manufacturer.

• This washer is not designed for maritime use or for mobile installations such as in RVs, aircraft, etc.

• Turn off the water taps and unplug the washer if the machine is to be left for an extended period of time, such as during vacations.

• Packaging material can be dangerous for children. There is a risk of suffocation! Keep all packaging from children.

• Always check the inside of the washer for foreign objects before loading laundry. Keep the door closed when not in use. wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following.

BASIC SAFETY PRECAUTIONS

wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.

READ ALL INSTRUCTIONS BEFORE USE

I M P O RTA N T S A F E T Y I N S T RU C T I O N S This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. GROUNDING INSTRUCTIONS wWARNING: Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the appliance is properly grounded. Do not modify the plug provided with the appliance. If it does not fit the outlet, have a proper outlet installed by a qualified electrician. Failure to follow these warnings can cause serious injury, fire, electrical shock, or death. 4• Refer to INSTALLATION INSTRUCTIONS for detailed grounding procedures. Installation instructions are packed in the washer for installer

reference. If the washer is moved to a new location, have it checked and reinstalled by a qualified service person. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• Do not, under any circumstances cut or remove the third (ground) prong from the power cord. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• For personal safety, this appliance must be properly grounded. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding) wall outlet to minimize the possibillty of electric shock hazard from this appliance.

• This washer must be plugged into a 120VAC, 60Hz grounded outlet. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• Where a standard 2-prong wall outlet is encountered, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• Do not install on carpet. Install washer on a solid floor. Failure to follow this warning can cause serious leak damage.

• Do not remove ground prong. Do not use an adapter or extension cord. Plug into a grounded 3-prong outlet. Failure to follow these warnings can cause serious injury, fire, electrical shock, or death.

• The washer should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating plate. This provides the best performance and also prevents overloading house wiring circuits which could cause a fire hazard from overheated wires.

• Never unplug your washer by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• When installing or moving the washer, be careful not to pinch, crush, or damage the power cord. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• The washer must be installed and electrically grounded by a qualified service person in accordance with local codes to prevent shock hazard and assure stability during operation.

• Washer is heavy. Two or more people may be need to install and move the appliance. Failure to do so can result in back or other injury.

• Store and install the washer where it will not be exposed to temperatures below freezing or exposed to outdoor weather conditions. Failure to follow this warning can cause serious leak damage.

• Do not install the washer in humid spaces to reduce the risk of electric shock. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• When installing or repairing the washer, put on long gloves and safety glasses. Failure to follow this warning can cause serious injury, fire, electrical shock, or death. wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following.

SAFETY INSTRUCTIONS FOR INSTALLATION

wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.

READ ALL INSTRUCTIONS BEFORE USE

I M P O RTA N T S A F E T Y I N S T RU C T I O N S 5I M P O RTA N T S A F E T Y I N S T RU C T I O N S SAFETY INSTRUCTIONS FOR USE, CARE AND CLEANING, AND DISPOSAL

Unplug the washer before cleaning to avoid the risk of electric shock.

Never use harsh chemicals, abrasive cleaners, or solvents to clean the washer. They will damage the finish.

Do not put oily or greasy rags or clothing on top of the washer. These substances give off vapors that could ignite the materials.

Do not wash items that are soiled with vegetable or cooking oil. These items may contain some oil after laundering. Due to the remaining oil, the fabric may smoke or catch fire by itself.

Disconnect this appliance from the power supply before attempting any user maintenance. Turning the controls to the OFF position does not disconnect this appliance from the power supply. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

Do not combine laundry products for use in one load unless specified on the label.

Do not mix chlorine bleach with ammonia or acids such as vinegar. Follow package directions when using laundry products. Incorrect usage can produce poisonous gas, resulting in serious injury or death.

Do not reach into the washer while parts are moving. Before loading, unloading or adding items, push in the cycle selector knob and allow the drum to coast to a complete stop before reaching inside. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

Do not allow children to play on or in the washer. Close supervision of children is necessary when the washer is used near children. As children grow, teach them the proper, safe use of all appliances. Failure to comply with these warnings could result in serious personal injuries.

Destroy the carton, plastic bag and other packing materials after the washer is unpacked. Children might use them for play. Cartons covered with rugs, bedspreads, or plastic sheets can become airtight chambers. Failure to comply with these warnings could result in serious personal injuries or death.

Keep laundry products out of children’s reach. To prevent personal injury, observe all warnings on product labels. Failure to comply with these warnings could result in serious personal injuries.

Remove the door to the washing compartment to avoid the danger of children or small animals getting trapped inside before your washer is removed from service or discarded. Failure to do so can result in serious personal injury or death. wWARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following.

SAVE THESE INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE

wWARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.PA RTS AND FEAT U R E S

This four-compartment drawer provides separate dispensers for prewash and main wash detergent, liquid bleach, and liquid fabric softener.

CONTROL PANEL WITH LED DISPLAY

Simple electronic controls are user-friendly. The LED display indicates cycle options and cycle time during operation. EASY-ACCESS LOCkING DOOR Extra-large door locks during operation and features a delay to prevent the door from being opened until the washer interior has cooled and the water level has lowered. ROLLERJETS The RollerJet system enhances wash performance while reducing fabric wear. Integrated jets spray clothes to further improve washing efficiency.

The drum light illuminates the washer interior for greater visibility when loading and unloading. The ultra long-life LED bulbs should never need replacement. DIRECT-DRIVE MOTOR Direct-drive motor eliminates the belt and pulleys found on most washers to provide improved performance and reliability while increasing energy efficiency. 7PA RTS AND FEAT U R E S

Hot and Cold Water Inlets Drain Hose Rear of Washer

kEY PARTS AND COMPONENTS In addition to the special features and components outlined in the Special Features section, there are several other important components that are referenced in this manual.

ULTRA-CAPACITY STAINLESS STEEL DRUM

The ultra-large stainless steel drum offers extreme durability and is tilted to improve efficiency and allow easier access for large items. WATER CIRCULATION The water circulation nozzles spray the water/ detergent solution directly onto garments for super cleaning performance. LEVELING FEET Four leveling feet (two in the front and two in the back) adjust to improve washer stability on uneven floors.

Provides access to the drain line and drain pump filter.

Included Accessories Hot and Cold Water Hoses Wrench (for removing shipping bolts and adjusting leveling feet) Tie Strap (for securing drain hose) Elbow Bracket (for securing drain hose) Caps (4) (for covering shipping bolt holes) Non-skid pads 8I N S TA L L AT I O N I N S T RU C T I O N S

CHOOSE THE PROPER LOCATION

CLEARANCES Allow at least 24 in. (61.2 cm) in front of the washer to open the door.

(10 cm) 51" (129.5 cm)

/4" (54 cm) To ensure sufficient clearance for water lines and airflow, allow minimum clearances of at least 1 in. (2.5 cm) at the sides and 4 in. (10 cm) behind the unit. Be sure to allow for wall, door, or floor moldings that may increase the required clearances.

• Do not remove ground prong. Do not use an adapter or extension cord. Plug into a grounded 3-prong outlet. Failure to follow this warning can cause serious injury, fire, electrical shock, or death. Power Outlet

• The power outlet must be within 60 in. (1.5 m) of either side of the washer.

• The appliance and outlet must be positioned so that the plug is easily accessible.

• Do not overload the outlet with more than one appliance.

• The outlet must be grounded in accordance with current wiring codes and regulations.

• Time-delay fuse or circuit breaker is recommended. NOTE: It is the personal responsibility and obligation of the product owner to have a proper outlet installed by a qualified electrician. 27" (68.6 cm)

TUB CLEAN RINSE +SPIN

DRUM LIGHTPRE-WASH CHILD LOCKWATER PLUS STAINCYCLE SPINSENSE™ DELAY WASH STEAM LOAD SENSING WASH RINSESPIN wWARNING

• Washer is heavy! Two or more people are required when moving and unpacking the washer. Failure to do so can result in back or other injury.

• Store and install the washer where it will not be exposed to temperatures below freezing or exposed to outdoor weather conditions. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• Properly ground washer to conform with all governing codes and ordinances. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• To reduce the risk of electric shock, do not install the washer in humid spaces. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• The base opening must not be obstructed by carpeting when the washer is installed on a carpeted floor. 9I N S TA L L AT I O N I N S T RU C T I O N S FLOORING NOTE: Please note that the floor must be strong and rigid enough to support the weight of the washer when fully loaded, without flexing or bouncing. If your floor has too much flex in it, you may need to reinforce it to make it more rigid. A floor that is adequate for a top-loading washer may not be rigid enough for a front- loading washer, due to the difference in the spin speed and direction. If the floor is not solid, your washer may vibrate and you may hear and feel the vibration throughout your house. INSTALLATIONS WITH OPTIONAL PEDESTAL BASE OR STACkING kIT IMPORTANT: If you are installing your washer using an optional pedestal base or stacking kit, please refer to the instructions for your pedestal or stacking kit before proceeding with the installation.

"(190.5 cm) Required Dimensions for Installation With Pedestal Required Dimensions for Installation With Stacking Kit

• To minimize noise and vibration, the washer MUST be installed on a solidly constructed floor. See the NOTE at right.

• Allowable slope under the entire washer is 1° maximum.

• Carpeting and soft tile surfaces are not recommended.

• Never install the washer on a platform or weakly supported structure. Use only an approved accessory pedestal as described below. NOTE: Before installing the washer, make sure the floor is clean, dry and free of dust, dirt, water and oils so the washer feet can not slide easily. Leveling feet that can move or slide on the floor can contribute to excess vibration and noise due to poor contact with the floor. NOTE: If a drip pan must be used, take extra care to follow the instructions provided with the drip pan and make sure the leveling feet are adjusted for firm and even contact with the pan. Use of drip pans and failure to properly level the machine may result in increased vibration and noise during operation.

10I N S TA L L AT I O N I N S T RU C T I O N S When removing the washer from the carton base, be sure to remove the foam tub support in the middle of the carton base. If you must lay the washer down to remove the base packaging materials, always lay it carefully on its side. Do NOT lay the washer on its front or back. IMPORTANT: To prevent internal damage during transport, the washer is equipped with 4 shipping bolts and plastic retainers. These bolts and retainers MUST be removed before operating the washer.

• Failure to remove shipping bolts and retainers may cause severe vibration and noise, which can lead to permanent damage to the washer. The cord is secured to the back of the washer with a shipping bolt to help prevent operation with shipping bolts in place. Remove the retainers by turning them slightly while pulling. Rotate and press the hole caps into the shipping bolt holes. Starting with the bottom 2 shipping bolts, use the included wrench to remove the 4 shipping bolts by turning them counterclockwise.

NOTE: Save the bolts and retainers for future use. To prevent damage to internal components, the shipping bolts and retainers must be installed when transporting the washer. Retainer Hole Cap Carton Base Foam Tub Support UNPACkING AND REMOVING SHIPPING BOLTS 11I N S TA L L AT I O N I N S T RU C T I O N S

CONNECTING THE WATER LINES

Insert a rubber seal into the threaded fittings on each hose.

Rubber Seal Water Hose (to tap) Rubber Seal Water Hose (to water inlet on washer)

Connect the water supply hoses to the HOT and COLD water faucets tightly by hand and then tighten another 2/3 turn with pliers. Turn on the water faucets and check for leaks. Water Tap NOTE: Do not cross-thread the hose fittings. Attach the hot water line to the red hot water inlet on the back of the washer. Attach the cold water line to the blue cold water inlet on the back of the washer. Tighten the fittings securely.

• IMPORTANT: Use new hoses when installing the washer. Do NOT reuse old hoses.

• IMPORTANT: Use ONLY the inlet hoses provided by LG with this laundry product. Aftermarket hoses are not guaranteed to fit or function correctly. Other hoses may not tighten correctly and could cause leaks. Subsequent damage to product or property will not be covered under the terms of LG's warranty.

• Water supply pressure must be between 14.5 PSI and 116 PSI (100~800 kPa). If the water supply pressure is more than 116 PSI, a pressure reducing valve must be installed.

• Periodically check the hose for cracks, leaks, and wear, and replace the hose if necessary.

• Make sure that the water lines are not stretched, pinched, crushed, or kinked.

• The washer should never be installed or stored in a location subject to freezing temperatures. Damage to the water lines and internal mechanisms of the washer can result. If the washer was exposed to freezing temperatures prior to installation, allow it to stand at room temperature for several hours before use. Water Inlets For cold water For hot water 12I N S TA L L AT I O N I N S T RU C T I O N S

CONNECTING THE DRAIN LINE

Insert the end of the drain hose into the floor drain. Secure the hose in place to prevent it from moving. Drain Hose Floor Drain Option 3: Floor Drain Stand Pipe Tie Strap Clip the end of the hose into the elbow bracket. Insert the end of the drain hose into a standpipe. Use tie strap to secure the drain hose in place. NOTE: Total height of the hose end should not exceed 96 in. (244.8 cm) from the bottom of the washer. Option 1: Standpipe Elbow Bracket Drain Hose Clip the end of the hose into the elbow bracket. Hang the end of the drain hose over the side of the laundry tub. Use tie strap to secure the drain hose in place. NOTE: Total height of the hose end should not exceed 96 in. (244.8 cm) from the bottom of the washer. Laundry Tub Option 2: Laundry Tub Elbow Bracket Tie Strap Drain Hose

• The drain hose should always be properly secured. Failure to properly secure the drain hose can result in flooding and property damage.

• Do not install the end of the drain hose higher than 96 in. (244.8 cm) above the bottom of the washer.

• The drain must be installed in accordance with any applicable local codes and regulations.

• Make sure that the water lines are not stretched, pinched, crushed, or kinked. NOTE: If the drain hose is extended more than 4 inches beyond the end of the end of the elbow bracket, mold, or microorganisms could spread to the inside of the washer. No more than 4 inches Elbow Bracket 13I N S TA L L AT I O N I N S T RU C T I O N S

Position the washer in the final location, taking special care to not pinch, strain, or crush the water and drain lines. Place a level across the top of the washer.

LevelLeveling FeetLeveling Feet The drum of your new washer spins at very high speeds, up to 1,200 RPM. To minimize vibration, noise, and unwanted movement, the floor must be a perfectly level, solid surface. NOTE: Adjust the leveling feet only as far as necessary to level the washer. Extending the leveling feet more than necessary can cause the washer to vibrate. Loosen the locknuts on all 4 leveling feet until you can turn the feet with the included wrench. Turn clockwise to raise the washer or counterclockwise to lower it.

RaiseLower Once the washer is level from side to side and front to back, tighten all locknuts securely. Make sure that all 4 leveling feet are in firm contact with the floor. NOTE: To make sure that the washer is properly level, run the washer with a test load: place approximately 6 pounds of laundry in the machine. Then, press POWER, press RINSE+SPIN, and then press the START/PAUSE button. See the following sections for additional information on cycle selection and operation. Verify that the washer does not rock or vibrate excessively during the spin cycle. If the washer vibrates or shakes, adjust the leveling feet until the washer is stable and retest.

Tighten all 4 locknuts securely

• All four leveling feet must rest solidly on the floor. Rock the washer gently from corner to corner to make sure that the washer does not rock. If you are installing the washer on the optional pedestal, you must use the leveling feet on the pedestal to level the washer. The washer’s leveling feet should be fully retracted and locked into position with the locknuts. INSTALLATION OF NON-SkID PADS (OPTIONAL) Some floor surfaces are too slippery to prevent the washer from moving on the floor during heavily unbalanced loads. While it is normal for an occasional load to be out of balance, excess noise and vibration can result from the washer moving out of position. If these conditions are encountered, follow the instructions below for installation of the non-skid pads. These pads will help prevent the washer from moving during heavy out of balance conditions thereby reducing noise and vibration.

Place the pads under both front feet.

This side upStick adhesive side to floorRemove backing

H OW TO U S E Fabric Care Labels Most articles of clothing feature fabric care labels that include instructions for proper care. Grouping Similar Items For best results, sort clothes into loads that can be washed with the same wash cycle. Different fabrics have different care requirements. Always wash dark colors separately from light colors and whites to prevent discoloration. If possible, do not wash heavily soiled items with lightly soiled ones. The chart below shows recommended groupings. Bleach symbols Any bleach(when needed)Only non-chlorine bleach(when needed)Do not bleach Machine wash cycle NormalPermanent press/wrinkle resistantGentle/delicateHand washDo not wash Do not wring Water temperature Hot (50°C/120°F) Warm (40°C/105°F)Cold/cool(30°C/85°F) Fabric Care Labels Sort Laundry... by Colors by Soil by Fabric by Lint Whites Heavy Delicates Lint ProducerLights Normal Easy Care Lint CollectorDarks Light Sturdy Loading the Washer

• Check all pockets to make sure that they are empty. Items such as clips, matches, pens, coins, and keys can damage both your washer and your clothes.

• Close zippers, hooks, and drawstrings to prevent these items from snagging or tangling on other clothes.

• Pretreat heavily stained areas for best results.

• Combine large and small items in a load. Load large items first.

• Large items should not be more than half of the total washload.

• The washer can be fully loaded, but the drum should not be tightly packed with items. The door of the washer should close easily.

• To prevent an out-of-balance load, do not wash single items. Add one or two similar items to the load. Large, bulky items, such as a blanket, comforter, or bedspread should be washed individually.

• Do not wash or spin waterproof clothes.

• When unloading the washer, check under the door seal for small items. NOTE: The capacity of the machine for washing clothes is twice as much as when drying clothes. If the machine is to be used to dry a load, then the wash load must be reduced by half for effective drying performance. If a full load is washed, remove half the clothes prior to starting the dry cycle. NOTE: The front loading washer rotates the wet laundry to wash it with less water. If you do not see the water during washing, it is not a problem because the laundry is sufficiently wet. 15H OW TO U S E SELECTING DETERGENT

The automatic dispenser consists of four compartments which hold:

• Liquid chlorine bleach.

• Liquid fabric softener.

• Liquid or powdered detergent for prewash.

• Liquid or powdered detergent and color-safe bleach for main wash. All laundry products can be added at once in their respective dispenser compartments. They will be dispensed at the appropriate time for the most effective cleaning. After adding the laundry products to the dispenser, close the dispenser drawer. To add detergent, bleach, and fabric softener to the automatic dispenser: Open the dispenser drawer. Load the laundry products into the appropriate compartments. Slowly close the dispenser drawer to avoid early dispensing of the laundry products. NOTE: It is normal for a small amount of water to remain in the dispenser compartments at the end of the cycle.

Liquid Chlorine Bleach Compartment Liquid Fabric Softener Compartment Prewash Detergent Compartment Main Wash Detergent Compartment Liquid Detergent Cup Insert IMPORTANT: Do not place or store laundry products, such as detergent, bleach, or liquid fabric softener, on top of your washer or dryer. Wipe up any spills immediately. These products can damage the finish and controls. Designed specially to use only HE (High-Efficiency) detergent IMPORTANT: Your washing machine is designed for use with only High-Efficiency (HE) detergents. HE detergents are formulated specifically for front-load washers and contain suds-reducing agents. Always look for the HE symbol when purchasing detergent. HE detergents produce fewer suds, dissolve more efficiently to improve washing and rinsing performance, and help to keep the interior of your washer clean. Using a regular detergent may cause oversudsing and unsatisfactory performance. 16H OW TO U S E

LOADING THE DISPENSER

Prewash Detergent Compartment Add liquid or powdered detergent to this compartment when using the Prewash option. Always use HE (High-Efficiency) detergent with your washing machine.

• The amount of detergent added for the Prewash option is 1/2 the amount recommended for the main wash cycle. For example, if the main wash cycle requires one cup of detergent, add 1/2 cup for the Prewash option. NOTE: If liquid detergent is to be used for the main wash when using the pre-wash option, the liquid detergent cup accessory must be used in main wash dispenser to prevent the main wash liquid detergent from being dispensed immediately. Main Wash Detergent Compartment This compartment holds laundry detergent for the main wash cycle, which is added to the load at the beginning of the cycle. Always use HE (High-Efficiency) detergent with your washing machine. Never exceed the manufacturer’s recommendations when adding detergent. Using too much detergent can result in detergent buildup in clothing and the washer. Either powdered or liquid detergent may be used.

• When using liquid detergent, make sure the liquid detergent cup and insert are in place. Do not exceed the maximum fill line.

• When using powdered detergent, remove the insert and liquid detergent cup from the compartment. Powdered detergent will not dispense with the liquid detergent cup and insert in place. NOTE: Liquid or powdered color-safe bleach may be added to the main wash compartment with detergent of the same type. Liquid Bleach Compartment This compartment holds liquid chlorine bleach, which will be dispensed automatically at the proper time during the wash cycle.

• Do not add powdered or liquid color-safe bleach to this compartment.

• Always follow the manufacturer’s recommendations when adding bleach. Do not exceed the maximum fill line. Using too much bleach can damage fabrics.

• Never pour undiluted liquid chlorine bleach directly onto the load or into the drum. Fabric damage can occur. Fabric Softener Compartment This compartment holds liquid fabric softener, which will be automatically dispensed during the final rinse cycle.

• Always follow the manufacturer’s recommendations when adding fabric softener. Do not exceed the maximum fill line. Using too much fabric softener may result in stained clothes.

• Dilute concentrated fabric softeners with warm water. Do not exceed the maximum fill line.

• Never pour fabric softener directly onto the load or into the drum. Designed specially to use only HE (High-Efficiency) detergent 17H OW TO U S E

Press to turn the washer ON. Press again to turn the washer OFF. NOTE: Pressing the ON/OFF button during a cycle will cancel that cycle and any load settings will be lost. CYCLE SELECTOR kNOB Turn this knob to select the desired cycle. Once the desired cycle has been selected, the standard presets will be shown in the display. These settings can be adjusted using the cycle setting buttons anytime before starting the cycle.

Press this button to START the selected cycle. If the washer is running, use this button to PAUSE the cycle without losing the current settings. NOTE: If you do not press the START/PAUSE button within 4 minutes of selecting a cycle, the washer automatically turns off.

A buildup of detergent residue can occur in the wash tub over time and can lead to a mildewy or musty smell. The Tub Clean cycle is specially designed to remove this buildup.

Use these buttons to select the desired cycle options for the selected cycle. Press the button for that setting until the indicator light for the desired value is lit.

Press this button to delay the start of the wash cycle. Each press of the button increases the delay time by one hour, up to 19 hours.

The display shows the settings, estimated time remaining, options, and status messages for your washer. OPTION BUTTONS The option buttons allow you to select additional cycle options and will light when selected. Certain buttons also allow you to activate special functions by pressing and holding the button for 3 seconds. For detailed information about the individual options, please see the following pages.

18H OW TO U S E CYCLE GUIDE Sanitary Bulky/ Large Perm. Press Cotton/ Normal Rinse+ Spin Delicates Hand Wash/ Wool Cotton Quick Cotton Which is lightly soiled. Heavily soiled underwear, work clothes, diapers, etc Extra Hot/Cold Low Medium No spin Normal Heavy Light Warm/Cold Warm/Warm Hot/Cold Cold/Cold Warm/Cold Warm/Warm Hot/Cold Cold/Cold Warm/Cold Warm/Warm Hot/Cold Cold/Cold Cold/Cold Warm/Cold Warm/Warm Warm/Cold Warm/Cold Warm/Warm Cold/Cold Large items such as blankets and comforters Dress shirts/pants wrinkle free clothing, poly/cotton blend clothing, table cloths Cotton, linen, towels, shirts, sheets, jeans, mixed loads Dress shirts/blouses nylons, sheer or lacy garment Items labeled "hand washable" Drying after rinsing without washing High Extra High No spin Low Medium Normal Heavy Light Medium High No spin Low Normal Heavy Light High Extra High No spin Low Medium Normal Heavy Light Warm/Cold Warm/Warm Cold/Cold High Extra High No spin Low Medium High Extra High No spin Low Medium Medium No spin Low Normal Heavy Light Low No spin Normal Light Speed Wash Hot/Cold Cold/Cold Warm/Cold Warm/Warm Lightly soiled clothing and small loads Extra High No spin Low Medium High Light Normal Heavy Normal The cycle guide below shows the options and recommended fabric types for each cycle. NOTE: To protect your garments, not every wash/rinse temperature, spin speed, soil level, or option is available with every cycle. 19H OW TO U S E

This portion of the display shows which stage of the wash cycle is currently underway (WASH, RINSE, SPIN or DRY)

ESTIMATED TIME REMAINING

When the START/PAUSE button is pressed, the washer automatically detects the wash load (weight) and optimizes the washing time, based on the selected cycle and options. The display will then indicate the estimated time remaining for the selected wash cycle. NOTE: The cycle time displayed may appear much longer than that of a top-loading washer. The displayed time is for the complete cycle, rather than just the agitation portion of the cycle, as is typically shown on a top-loading washer.

DOOR LOCk INDICATOR Indicates that the door is locked. The washer door will lock while the washer is operating. The door can be unlocked by pressing the START/ PAUSE button to stop the washer. NOTE: If the temperature in the washer is too high, the door cannot be unlocked until the washer has cooled. If the water level is too high, select the DRAIN & SPIN cycle to drain excess water. Do not try to force open the door.

DELAY WASH INDICATOR

This indicator shows that the washer has been set for DELAY WASH. The washer will start automatically after the set delay time has passed.

The LED display shows the settings, estimated time remaining, options, and status messages for your washer. When the washer is turned on, the display will illuminate.

Press the ON/OFF button to turn on the washer. The lights around the cycle selector knob will illuminate. Turn the cycle selector knob to the desired cycle. The display will show the preset Rinse/Wash Temperature, Spin Speed, Soil Level, and Option settings for that cycle. If you would like to change the settings for that cycle, press the appropriate cycle set- tings button(s) until the indicator light for the desired setting is lit. NOTE: To protect your garments, not every wash/rinse temperature, spin speed, soil level, or option is available with every cycle.

Select any additional cycle options, such as Tub Clean or Delay Wash by pressing the button for that option. NOTE: To protect your garments, not every wash/rinse temperature, spin speed, soil level, or option is available with every cycle.

Press the START/PAUSE button to begin the cycle. The door will latch, the display will change, and the washer will calculate the estimated time remaining. Once the washer has calculated the estimated total cycle time, the washer will start. To pause the cycle at any time, press PAUSE. NOTE: The cycle time displayed may appear much longer than that of a top- loading washer. The displayed time is for the complete cycle, rather than just the agitation portion of the cycle, as is typically shown on a top-loading washer. NOTE: If the temperature in the washer is too high, the door cannot be unlocked until the washer has cooled. If the water level is too high, select the DRAIN & SPIN cycle to drain excess water. Do not try to force the door open. Washing time can be reduced significantly for small or lightly soiled loads by selecting the Speed Wash cycle and setting the Soil Level button to Light.

Once you have loaded the washer and added laundry products (detergent, bleach, and/or fabric softener): When the load is finished, the beeper (if set) will sound and the door will unlock. Remove damp clothes from the washer immediately. Check under the door seal for small items.

TUB CLEAN DELAY WASH 21SPIN SPEED The washer drum spins at up to 1,200 RPM. This reduces drying time and saves energy. Press the SPIN SPEED button until the indicator light for the desired setting is lit. Some fabrics, such as delicates, require a slower spin speed. The Drain & Spin cycle: The Spin Speed button also activates the Drain & Spin cycle to drain the tub and spin clothes; for example, if you want to remove clothes before the cycle has ended. To activate the DRAIN & SPIN cycle: Press the ON/OFF button to turn on the washer. Press the SPIN SPEED button. Select the desired spin speed. NOTE: If NO SPIN is selected, the washer will drain only. Press the START/PAUSE button. H OW TO U S E

CYCLE SETTING BUTTONS

Each cycle has preset settings that are selected automatically. You may also customize the settings using the cycle setting buttons. Press the button for that setting until the indicator light forthe desired value is lit. The washer automatically adjusts the water level for the type and size of wash load for best results and maximum efficiency. It may seem there is no water inside the drum in some cycles, but this is normal. NOTE: To protect your garments, not every wash/ rinse temperature, spin speed, soil level, or option is available with every cycle. See the Cycle Guide for details. SOIL LEVEL Adjusts the selected cycle to allow more time for heavily soiled clothes or less time for lightly soiled clothes. Press the SOIL LEVEL button until the indicator light for the desired setting is lit.

WASH/RINSE Selects the wash and rinse temperature combination for the selected cycle. Press the WASH/RINSE button until the indicator light for the desired setting is lit.

• Your washer features a heating element to boost the hot water temperature for Extra Hot settings. This provides improved wash performance at normal water heater settings.

• Select the water temperature suitable for the type of load you are washing. Follow the fabric care label for best results.

• Warm rinses leave the loads drier than cold rinses. Warm rinses can increase wrinkling.

• In cold climates, a warm rinse makes the load more comfortable to handle.

• The capacity of the machine for washing clothes is twice as much as when drying clothes. If the machine is to be used to dry a load, then the wash load must be reduced by half for effective drying performance. If a full load is washed, remove half the clothes prior to starting the dry cycle.

• The Wrinkle Care feature is set automatically when drying cycle is complete and cannot be disabled.

• This feature will help prevent wrinkling of the clothes if they are not removed promptly when the dry cycle ends. When drying cycle is completed, [COOL DOWN] is displayed on the Multi display. The COOL DOWN is setting automatically when a drying cycle is complete. When you are not remove a load of clothes from the dryer as soon as it stops, wrinkles can form. The COOL DOWN operating periodically tumbles, rearranges and fluffs the load to avoid wrinkles without heat for up to 4 hours. The message will continue to display until the clothes are removed or the Start/Pause button is pressed. Drying Guide–Timed Dry

• Press the Dry button repeatedly to select the drying time in 30 minute increments: 30–60–90–120 minutes.

• Timed dry can last up to 120 min. When selecting Dry only, drying will start after the final Spin cycle.

• Drying times can vary greatly depending on dampness, room temperature, and type of fabric. You may need to add additional time. Your own experience will be your best guide. Drying Guide–Automatic Dry Electronic sensors measure the temperature of the exhaust to increase or decrease the drying temperature for faster reaction time and tighter temperature control. Recommended DRY settings by fabric type: a) Perm Press – LOW TEMP b) If clothes are to be ironed – DAMP c) Cotton/Towels – NORMAL d) Diapers – MORE NOTE: On Automatic Dry settings, the estimated drying time may vary from the actual drying time. The type of fabric, size of the load, and the selected dryness level affect drying time. DRY Drying options are easily selected with the DRY button. For most even drying, make sure all articles in the clothes load are similar in material and thickness. Do not overload the washer by placing too many articles into the drum. Items must be able to tumble freely. If you open door and remove load before washer has finished the DRY cycle, remember to press the START/ PAUSE button. By pressing the DRY button, you can select: LOW TEMP - For delicate fabrics DAMP - For damp drying fabrics NORMAL - For general drying MORE - For heavier fabrics 30/60/90/120 - For timed drying

Drying Tips Woolen Articles Do not tumble dry woolen articles. Pull them to their original shape and dry them flat. Woven and Loopknit Materials

• Some woven and loopknit materials may shrink when dried.

• Always stretch them out immediately after drying. Permanent Press and Synthetics

• Do not overload your dryer.

• Take out permanent press articles as soon as the dryer stops to reduce wrinkles. Fiber or Leather Materials Always check the manufacturer’s instructions. Baby Clothes and Night Gowns Always check the manufacturer’s instructions. Rubber and Plastics Do not dry any items made from or containing rubber or plastics, such as: a) Aprons, bibs, chair covers b) Curtains and table cloths c) Bathmats Fiberglass Do not dry fiberglass articles in your dryer. Glass particles left in the washer could be picked up by your clothes the next time you use the washer and irritate your skin. 23EXTRA RINSE This option will add an extra rinse cycle to the selected cycle. Use this option to help ensure the removal of detergent or bleach residue from fabrics. STAIN CYCLE Select this option for heavily stained clothes, such as play clothes or work clothes. Stain Cycle will add extra wash time to the selected cycle, as well as an additional rinse cycle. WATER PLUS Select this option to add extra water to the wash and rinse cycles for superior results, especially with large or bulky items. H OW TO U S E

CYCLE OPTION BUTTONS

Your Washer features several additional cycle options to customize cycles to meet your individual needs. Certain option buttons also feature a special function (see the following for details) that can be activated by pressing and holding that option button for 3 seconds. To Add Cycle Options to a Cycle: Turn on the washer and turn the cycle selector knob to select the desired cycle. Use the cycle settings buttons to adjust the settings for that cycle. Press the cycle option button(s) for the option you would like to add. The cycle option buttons, except Tub Clean and Delay Wash, will light when selected. Press the START/PAUSE button to start the cycle. The washer will start automatically. NOTE: To protect your garments, not every wash/ rinse temperature, spin speed, soil level or option is available with every cycle. See the Cycle Guide for details.

TUB CLEAN A buildup of detergent residue can occur in the wash tub over time and can lead to a mildewy or musty smell. The TUB CLEAN cycle is specially designed to remove this buildup. Add liquid chlorine bleach to the bleach Compartment. After the cycle has ended, open the door and allow the drum interior to dry completely. NOTE: Do NOT use this cycle with clothes, and do NOT add detergent or fabric softener. DELAY WASH Once you have selected the cycle and other settings, press this button to delay the start of the wash cycle. Each press of the button increases the delay time by one hour, up to 19 hours. DELAY WASH STAINCYCLE SPINSENSE™ WATER PLUS TUB CLEAN DRUM LIGHT The drum is equipped with a blue LED light that illuminates when the washer is turned on. This light automatically turns off when the door is closed and the cycle starts. To turn on the light during a cycle, press and hold the DRUM LIGHT button. The drum light will illuminate and then turn off automatically after 4 minutes. PRE-WASH Select this option to add a 16-minute prewash and spin cycle to the chosen cycle. This is especially useful for heavily soiled items. 24The wool wash cycle of this machine has been approved by Woolmark for the washing of machine washable Woolmark products provided that the products are washed according to the instructions on the garment label and those issued by the manufacturer of this washing machine, M0807. SPECIAL FUNCTIONS The option buttons also activate special functions, including CHILD LOCK, SPINSENSE™. Press and hold the option button marked with the special function for 3 seconds to activate. H OW TO U S E SPINSENSE™ SPINSENSE™ can be used to help reduce or eliminate vibrations, especially on wood floor installations To activate SPINSENSE™: While the washing machine is running in any cycle, press and hold the STAIN CYCLE™ button for 3 seconds. The SPIN SPEED light will remain lit while the washer is running to show that SPINSENSE™ is active. The SPINSENSE™ function will remain active for every cycle, even after a power failure. To cancel SPINSENSE™: Press and hold the STAIN CYCLE button for 3 seconds to turn off the SPINSENSE™ function. STAINCYCLE SPINSENSE™

• Only woolen items that are designated as “Machine-Washable” should be washed in this washing machine

• Wash only small loads for optimum fabric care (less than 8 lbs.)

• Only neutral (wool safe) detergents should be used (Only a small quantity of detergent is needed due to the small load size and low volume of water in the cycle.)

• The HANDWASH/WOOL cycle uses a gentle tumble action and low speed spin for ultimate fabric care CHILD LOCk Use this option to prevent unwanted use of the washer or to keep cycle settings from being changed while the washer is operating. Press and hold the PREWASH button for 3 seconds to activate or deactivate CHILD LOCK. The lock icon will be shown in the display, and all controls are disabled. The washer can be locked during a cycle. Once CHILD LOCK is selected, the display will alternate between CL and the remaining. Certified by NSF Certificado por NSF NSF International (formerly the National Sanitation Foundation), certifies that SANITARY cycle reduces 99.9% of bacteria on laundry, and none of bacteria will carry over onto the next laundry load. 25CA R E A N D C L E A N I N G wWARNING:

• Unplug the washer before cleaning to avoid the risk of electric shock. Failure to follow this warning can cause serious injury, fire, electrical shock, or death.

• Never use harsh chemicals, abrasive cleaners, or solvents to clean the washer. They will damage the finish. Cleaning the Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a mild, nonabrasive household detergent. Immediately wipe off any spills with a soft, damp cloth. IMPORTANT: Do not use methylated spirits, solvents, or similar products. Never use steel wool or abrasive cleansers; they can damage the surface. REGULAR CLEANING Care and Cleaning of the Interior Use a towel or soft cloth to wipe around the washer door opening, door seal, and door glass. These areas should be kept clean to ensure a watertight seal. Be sure to wipe under the inside rubber seal to remove any moisture or soil. Always remove items from the washer as soon as the cycle is completed. Leaving damp items in the washer can cause wrinkling, color transfer, and odor. Run the TUB CLEAN cycle regularly to remove detergent buildup and other residue. NOTE: If you use the TUB CLEAN cycle on a monthly basis, the wash drum will be kept clean. Removing the Stain in Door Seal NOTE: Wear rubber gloves and eye protection while performing the following procedure: Dilute 3/4 cup (177 ml) liquid chlorine bleach with 1 gallon (3.8 L) of warm/hot water. Use this solution to wipe down all surfaces of the gasket to remove the deposits that are causing any odor. (Be sure to fold back the lip of the gasket to get under the edge where residue can build up.) Wipe the gasket with a dry cloth. Leave the door open to allow the gasket to dry completely. Do not use undiluted bleach as this will damage the gasket. Follow the manufacturer’s instructions for proper use of bleach. If the gasket cannot be cleaned properly, it should be replaced.

Read these instructions carefully before beginning the TUB CLEAN cycle. Open the door and remove any clothing in the wash drum. Open the dispenser drawer. Add liquid chlorine bleach or tub cleaner. Some powder or tablet tub cleaners which are manufactured for this purpose can be used. (NOTE : Do not add any laundry detergent or fabric softener to the drawer when using TUB CLEAN.) - If using liquid chlorine bleach Add liquid chlorine bleach to the bleach compartment of the drawer. (NOTE : Do not exceed the maximum fill line and do not pour undiluted liquid bleach directly into the wash drum.) - If using powder cleaner Remove the liquid detergent cup and add powder cleaner to the main wash compartment of the drawer. - If using tablet cleaner Add tablet cleaner to the wash drum directly. (NOTE : Do not add tablet cleaner to the drawer.) Close the drawer and washer door. Select TUB CLEAN and press START. NOTE : It is recommended that TUB CLEAN should be repeated monthly. If mildew or musty smell already exists, run TUB CLEAN for 3 consecutive weeks. After TUB CLEAN is complete or when the washer is not used, leave the washer door open for better ventilation and drying inside of the washer.

26CLEANING THE WASHER

Cleaning the Dispenser The dispenser should be cleaned periodically to remove buildup from detergent and other laundry products. Pull out the dispenser drawer until it stops. Press the button in the center of the drawer and pull to remove the drawer.

Remove the inserts from the drawer, and clean them with warm water and a soft cloth or brush to remove any residue or buildup. Wipe out the inside of the drawer opening with a damp cloth. Reassemble the drawer and reinstall in the drawer opening. NOTE: Do not use anything other than water to clean the drawer, inserts, and drawer opening. If any sort of household cleaner drains into the interior of the washer, run a RINSE

SPIN cycle before washing clothes.

CA R E A N D C L E A N I N G Storing the Washer If the washer will not be used for an extended period of time and is in an area that could be exposed to freezing temperatures: Turn off water supply tap. Disconnect hoses from water supply and drain water from hoses. Plug the power cord into a properly grounded electrical outlet. Add 1 gallon of nontoxic recreational vehicle (RV) antifreeze to the empty wash drum. Close door. Select the spin cycle and let washer spin for 1 minute to drain out all the water. NOTE: Not all of the RV antifreeze will be expelled. Unplug the power cord, dry the drum interior with a soft cloth, and close the door.

Removing Lime Buildup If you live in an area with hard water, lime scale can form on internal components of the washer. Use of a water softener is recommended in areas with hard water. If a descaler is used, make sure that it is suitable for use in a washer, and run the TUB CLEAN cycle before washing clothing. Lime scale and other spots may be removed from the stainless steel drum using a stainless steel cleaner. Do NOT use steel wool or abrasive cleansers; they can damage the surface. NOTE: If you clean the detergent dispenser once a week, it will always dispense properly. REGULAR CLEANING (cont.) Remove the inserts from the dispenser. Drain any water in compartments and dry the compartments. Store the washer in an upright position. To remove the antifreeze from the washer after storage, run washer through a complete cycle using detergent. Do not add laundry! 27CA R E A N D C L E A N I N G Cleaning the Water Inlet Filters If the washer detects that water is not entering the dispenser, an error message will show on the display. If you live in an area with hard water, this may be caused by clogged inlet filters. Turn off both water taps completely. Unscrew the hot and cold water lines from the back of the washer.

Carefully remove the filters from the water inlets, and soak them in white vinegar or a lime scale remover, following the manufacturer’s instructions. Rinse thoroughly before reinstalling. Press the filters back into place and reattach the water lines. Do NOT operate the washer without the inlet filters.

IMPORTANT: Use extreme care when removing and cleaning the filters. If the filters cannot be cleaned or are damaged, do NOT operate the washer without the inlet filters. Contact LG Customer Service or a qualified LG servicer. Inlet Filter MAINTENANCE IMPORTANTE: Use ONLY the inlet hoses provided by LG with this laundry product. Aftermarket hoses are not guaranteed to fit or function correctly. Other hoses may not tighten correctly and could cause leaks. Subsequent damage to product or property will not be covered under the terms of LG's warranty. 28Cleaning the Drain Pump Filter Lint and other objects may accumulate and clog the drain pump filter. If the washer fails to drain properly, unplug the washer and allow the water to cool, if necessary, before proceeding. Open the drain pump filter access panel.

Unclip the drain hose and pull it out. Place the end of the drain hose in a pan, bucket, or floor drain to catch water.

CA R E A N D C L E A N I N G Remove the plug from the drain hose, and allow the water to drain completely. Twist the pump filter counterclockwise to remove. Remove any lint and foreign objects from the pump filter. Reverse the above steps to reinstall the drain pump filter and drain hose. Be sure to close the cover panel when finished.

The following sounds may be heard while the washer is operating. They are normal. Clicking: Door lock relay when the door locks and unlocks. Spraying or hissing: Water spraying or circulating during the cycle. Humming or gurgling: Drain pump pumping water from the washer at the end of a cycle. Splashing: Clothes tumbling in the drum during the wash and rinse cycles.

BEFORE CALLING FOR SERVICE

Your washing machine is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If your washer does not function properly or does not function at all, check the following before you call for service. Problem Possible Causes Solutions Rattling and clanking noise Thumping sound Water leaking around washer

• Foreign objects, such as keys, coins, or safety pins, may be in drum or pump.

• Heavy wash loads may produce a thumping sound.

• Washer load may be out of balance.

• Shipping bolts and/or packaging materials not removed.

• Wash load may be unevenly distributed in the drum.

• Not all leveling feet are resting firmly on the floor.

• Floor not rigid enough.

• Fill hose connection is loose at tap or washer.

• House drain pipes are clogged.

• Stop washer and check drum and drain filter for foreign objects. If noise continues after washer is restarted, call for service.

• This is normal. If sound continues, washer is probably out of balance. Stop and redistribute wash load.

• Stop and redistribute wash load.

• See Installation Instructions for removing shipping bolts and packaging.

• Stop washer and rearrange wash load.

• Adjust the leveling feet. Make sure all four feet are in firm contact with the floor while the washer is in the spin cycle with a load.

• Make sure that the floor is solid and does not flex. Refer to “Flooring” in the Installation section.

• Check hoses. Check and tighten hose connections.

• Unclog drain pipe. Contact a plumber if necessary. Vibrating noise Excessive sudsing

• Too much detergent or incorrect detergent.

• Reduce detergent amount or use low-sudsing detergent. Only use detergent with the HE (High-Efficiency) logo. Staining

• Laundry products added directly to the washer drum.

• Washer not unloaded promptly.

• Clothes not sorted properly.

• Load the laundry products into the dispenser.

• Always remove items from the washer as soon as the cycle is completed.

• Always wash dark colors separately from light colors and whites to prevent discoloration. If possible, do not wash heavily soiled items with lightly soiled ones. 30BEFORE CALLING FOR SERVICE (cont.) T RO U B L E S H O OTING Problem Possible Causes Solutions Washer fills with water slowly or not at all, or the display shows: Washer will not turn on Musty or mildewy odor in washer

• Water supply taps are not open fully.

• Water line hoses are kinked, pinched, or bent.

• Water inlet filters are clogged.

• Water pressure to tap or house is too low.

• Power cord is not properly plugged in.

• House fuse is blown, circuit breaker has tripped, or power outage has occurred.

• The door is not closed properly.

• Incorrect or too much detergent has been used.

• Inside of tub not cleaned properly.

• Make sure that the water taps are open fully.

• Make sure the hoses are not kinked or pinched. Be careful when moving the washer.

• Clean the inlet filters. See the Care and Cleaning section.

• Check another faucet in the house to make sure that household water pressure is adequate.

• Make sure that the plug is plugged securely into a grounded, 3-prong, 120-VAC, 60-Hz. outlet.

• Reset circuit breaker or replace fuse. Do not increase fuse capacity. If the problem is a circuit overload, have it corrected by a qualified electrician.

• Make sure that the door is closed properly and press the START/PAUSE button. After starting a cycle, it may take a few moments before the drum begins to turn or spin. The washer will not spin unless the door is locked (DOOR LOCK will appear in the display).

• If the door is closed and locked and the open door error message is displayed, call for service.

• Use only HE (High-Efficiency) detergent in accordance with the manufacturer’s instructions.

• Run the TUB CLEAN cycle regularly. Be sure to wipe around and under the door seal frequently.

• Clean around door seal/glass to prevent odor or mildew:

1. wipe dry the door seal/glass and the door opening area

2. wipe around the inner drum/door seal and the lower door seal

Washer won’t spin, or the display shows:

• The washer automatically adjusts the wash time for the amount of laundry, water pressure, water temperature, and other operating conditions.

• This is normal. The washer adjusts cycle time automatically to provide optimal results for the selected cycle. Wash cycle time is longer than usual Door will not unlock when cycle is stopped or paused

• Interior temperature of washer is too high.

• Water level in washer is too high.

• The washer door has a safety lock to prevent burns. Allow the washer to cool until the DOOR LOCK indicator turns off in the display.

• Allow the washer to complete the programmed cycle, or run the DRAIN & SPIN cycle to drain the water. Water in the washer drains slowly or not at all, or the display shows:

• Drain hose is bent, pinched, or clogged.

• The drain filter is clogged.

• Make sure the drain hose is free of clogs, kinks, etc., and is not pinched behind or under the washer.

• Load is out of balance.

• The washer has an imbalance detection and correction system. If individual heavy articles are loaded (bath mat, bath robe, etc.) and the imbalance is too great, the washer will make several attempts to restart the spin cycle. If an imbalance is still detected, the washer will stop and the error code will be displayed.

• Add 1 or 2 similar items to help balance the load.

• Rearrange items to help balance the load.

• Unplug the washer and call for service. The display shows:

• Water level is too high due to a faulty water valve.

• Close the water taps, unplug the washer, and call for service. The display shows:

• The water level sensor is not working correctly.

• Close the water taps, unplug the washer, and call for service. The display shows:

• Thermal overload protection circuit in the motor has been tripped.

• Allow the washer to stand for 30 minutes to allow the motor to cool; then restart the cycle. If the LE error code still appears, unplug the washer and call for service. The display shows:

• A power failure has occurred.

• Restart the cycle. The display shows: Drum light does not stay on

• The drum light shuts off automatically when the washer starts. Press and hold the RINSE

SPIN button for 3 seconds to turn on the light; it will turn off automatically after 4 minutes. Wrinkling

• Washer not unloaded promptly.

• Hot and cold water inlet hoses are reversed.

• Always remove items from the washer as soon as the cycle is completed.

• The washer can be fully loaded, but the drum should not be tightly packed with items. The door of the washer should close easily.

• Hot water rinse can set wrinkles in garments. Check the inlet hose connections.

• Turn the tap on. If “ ” is not released, unplug power plug and call for service. The display shows:

68.6 cm (W) X 75.6 cm (D) X 98.3 cm (H), 129.5 cm (D with door open)

Net Weight 201 lb. (91 kg) Max. Spin Speed 1,200 RPM The appearance and specifications listed in this guide may vary due to constant product improvements. S P E C I F I CAT I O N S / O P T I O N A L AC C E S S O R I E S OPTIONAL ACCESSORIES For these and other LG products, contact your local LG dealer, or visit our Web site at us.lge.com, ca.lge.com. Pedestal Give your LG washer and dryer a boost with matching 14-inch high pedestals. They feature a storage drawer for added convenience. 14" Pedestal Color WDP3W White WDP3B Black WDP3S Titanium WDP3N Midnight blue WDP3R Wild Cherry Red Stacking Kit If space is at a premium, use this kit to securely stack your LG front-load washer and dryer. Bracket Kit Color WSTK1 White BSTK1 Black SSTK1 Titanium NSTK1 Midnight blue RSTK1 Wild Cherry Red 33Your LG Washing Machine will be will repaired or replaced, at LG’s option, if it proves to be defective in material or work- manship under normal use, during the warranty period (“Warranty Period”) set forth below, effective from the date (“Date of Purchase”) of original consumer purchase of the product. This warranty is good only to the original purchaser of the product and effective only when used in the United States, including Alaska, Hawaii, and U.S. Territories. THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER THE MANUFACTURER NOR ITS U.S. DISTRIBUTOR SHALL BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above exclusion or limitation may not apply to you. This warranty gives you specific legal rights and you may also have other rights that vary from state to state.THIS LIMITED WARRANTY DOES NOT APPLY TO:

• Service trips to your home to deliver, pick up, and/or install the product, instruct, or replace house fuses or correct wiring, or correction of unauthorized repairs.
• Damages or operating problems that result from misuse, abuse, operation outside environmental specifications or contrary to the requirements of precautions in the Operating Guide, accident, vermin, fire, flood, improper installation, acts of God, unauthorized modification or alteration, incorrect electrical current or voltage, or commercial use, or use for other than intended purpose. The cost of repair or replacement under these excluded circumstances shall be borne by the consumer.CUSTOMER INTERACTIVE CENTER NUMBERS

TO CONTACT LG ELECTRONICS

BY MAIL: LG Customer Interactive Center P. O. Box 240007 201 James Record Road Huntsville, Alabama 35824 ATTN: CIC WARRANTY PERIOD: LABOR: One Year from the Date of Purchase. PARTS (except as listed below): One Year from the Date of Purchase. Drum Motor (Stator, Rotor, Hall sensor) : Ten Years from the Date of Purchase. Stainless Steel Drum: Lifetime Replacement Units and Repair Parts may be new or remanufactured. Replacement Units and Repair Parts are warranted for the remaining portion of the original unit’s warranty period. LG ELECTRONICS, INC. LG WASHING MACHINE LIMITED WARRANTY - USA HOW SERVICE IS HANDLED: In-Home Service: Please retain dealer’s dated bill of sale or delivery ticket as evidence of the Date of Purchase for proof of warranty, and submit a copy of the bill of sale to the service person at the time warranty service is provided. Please call 1-800-243-0000 and choose the appropriate option to locate your nearest LG Authorized Service Center. Or visit our Web site at: http://www.lgservice.com. Call 1-800-243-0000 (24 hours a day, 365 days a year), and select the appropriate option from the menu. Or visit our Web site at: http://www.lgservice.com. To obtain Customer Assistance, Product Information, or Dealer or Authorized Service Center location: Product Registration Information Model: Serial Number: Date of Purchase: The model and serial number can be located on the rating plate on the back of the washer. 34LG ELECTRONICS, INC. LG WASHING MACHINE LIMITED WARRANTY - CANADA LG ELECTRONICS CANADA, INC. LG WASHER LIMITED WARRANTY - Canada WARRANTY: Should your LG Washer (“Product”) fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the Product upon receipt of proof of original retail purchase. This warranty is valid only to the original retail purchaser of the product and applies only to a Product distributed in Canada by LG Canada or an authorized Canadian distributor thereof. The warranty only applies to Products located and used within Canada. Replacement products and parts are warranted for the remaining portion of the original warranty period or ninety (90) days, whichever is greater. Replacement products and parts may be new or remanufactured. LG Authorized Service Center warranties their repair work for thirty (30) days. LG CANADA’S SOLE LIABILITY IS LIMITED TO THE WARRANTY SET OUT ABOVE. EXCEPT AS EXPRESSLY PROVIDED ABOVE, LG CANADA MAKES NO AND HEREBY DISCLAIMS ALL OTHER WARRANTIES AND CONDITIONS RESPECTING THE PRODUCT, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND NO REPRESENTATIONS SHALL BE BINDING ON LG CANADA. LG CANADA DOES NOT AUTHORIZE ANY PERSON TO CREATE OR ASSUME FOR IT ANY OTHER WARRANTY OBLIGATION OR LIABILITY IN CONNECTION WITH THE PRODUCT. TO THE EXTENT THAT ANY WARRANTY OR CONDITION IS IMPLIED BY LAW, IT IS LIMITED TO THE EXPRESS WARRANTY PERIOD ABOVE. LG CANADA, THE MANUFACTURER OR DISTRIBUTOR SHALL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, DIRECT OR INDIRECT DAMAGES, LOSS OF GOODWILL, LOST PROFITS, PUNITIVE OR EXEMPLARY DAMAGES OR ANY OTHER DAMAGE, WHETHER ARISING DIRECTLY OR INDIRECTLY FROM ANY CONTRACTUAL BREACH, FUNDAMENTAL OR OTHERWISE, OR FROM ANY ACTS OR OMISSIONS, TORT, OR OTHERWISE. This warranty gives you specific legal rights. You may have other rights which may vary from province to province depending on applicable provincial laws. Any term of this warranty that negates or varies any implied condition or warranty under provincial law is severable where it conflicts with provincial law without affecting the remainder of this warranty’s terms. THIS LIMITED WARRANTY DOES NOT COVER: 1. Service trips to deliver, pick up, or install the product; instructing a customer on operation of the product; repair or replacement of fuses or correction of wiring , or correction of unauthorized repairs/installation.

2. Failure of the product to perform during power failures and interruptions or inadequate electrical service.

3. Damage caused by leaky or broken water pipes, frozen water pipes, restricted drain lines, inadequate or interrupted water supply or inadequate supply of air. 4. Damage resulting from operating the Product in a corrosive atmosphere or contrary to the instructions outlined in the Product owner’s manual.

5. Damage to the Product caused by accidents, pests and vermin, lightning, wind, fire, floods, or acts of God.

6. Damage resulting from the misuse, abuse, improper installation, repair, or maintenance of the Product. Improper repair includes use of parts not approved or specified by LG Canada. 7. Damage or product failure caused by unauthorized modification or alteration, or use for other than its intended purpose, or resulting from any water leakage due to improper installation. 8. Damage or Product failure caused by incorrect electrical current, voltage, commercial or industrial use, or use of accessories, components, or cleaning products that are not approved by LG Canada. 9. Damage caused by transportation and handling, including scratches, dents, chips, and/or other damage to the finish of your product, unless such damage results from defects in materials or workmanship and is reported within one (1) week of delivery.

10. Damage or missing items to any display, open box, discounted, or refurbished Product.

11. Products with original serial numbers that have been removed, altered, or cannot be readily determined. Model and Serial numbers, along with original retail sales receipt, are required for warranty validation.

12. Increases in utility costs and additional utility expenses.

13. Replacement of light bulbs, filters, or any consumable parts.

14. Repairs when your Product is used in other than normal and usual household use (including, without limitation, commercial use, in offices or recreational facilities) or contrary to the instructions outlined in the Product owner’s manual.

15. Costs associated with removal of the Product from your home for repairs.

TUB CLEAN RINSE +SPIN

86M O D E D ’ E M P LO I

88M O D E D ’ E M P LO I
