HHOB 300 HHG75WK3X - Cooker HOOVER - Free user manual and instructions
Find the device manual for free HHOB 300 HHG75WK3X HOOVER in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Gas hob |
| Brand | Hoover |
| Model | HHOB 300 HHG75WK3X |
| Width | 745 mm |
| Depth | 510 mm |
| Gas supply | Natural gas (G20) at 20 mbar or butane/propane (G30) at 28-30 mbar |
| Number of burners | 5 |
| Burner types | 1 auxiliary (1.0 kW), 2 semi-rapid (1.75 kW), 1 rapid (2.7 kW), 1 dual (5.0 kW) |
| Total gas power | 13.15 kW (natural gas) / 12.75 kW (butane/propane) |
| Electrical supply | 220-240 V ~ 50/60 Hz |
| Electrical power | 1 kW |
| Ignition | Integrated electronic |
| Safety device | Thermocouple (FFD) on each burner |
| Surface material | Stainless steel and enamel |
| Main functions | Gas burners with flame adjustment, electronic ignition, thermocouple safety, adaptation to different gases |
| Cleaning | With soapy water, avoid abrasive and corrosive products |
| Installation | Built-in, requires a qualified professional |
| Built-in dimensions | See diagram in the manual (depending on the model) |
| Installation class | 3 |
| Supplied accessories | Injectors for different gases, fixing brackets, sealing gasket |
| Repairability | Spare parts available from after-sales service |
| Use | Domestic only |
Frequently Asked Questions - HHOB 300 HHG75WK3X HOOVER
How to light a burner?
To light a burner, turn the control knob to the ignition symbol and press the electronic ignition button. If your model is equipped with a thermocouple, keep the knob pressed for 5 to 6 seconds after ignition.
What to do if the burner does not light?
Check that the gas is on and the power plug is connected. If the burner does not light within 5 seconds, turn the knob to 0 and try again. If the problem persists, contact a qualified technician.
How to change the gas type of the hob?
Replace the injectors with those supplied suitable for the new gas (see table in the manual). Then adjust the minimum flame by turning the adjustment screw. Also replace the rating plate. This operation must be carried out by a professional.
How to adjust the minimum flame?
After lighting the burner, turn the knob to the minimum position, remove it and use a small screwdriver to adjust the adjustment screw (diagram 9). The flame should be 3 to 4 mm high. Replace the knob after adjustment.
Which utensils to use on this hob?
Use pans with a flat bottom, with a diameter matching the burner size (see table A in the manual). Avoid concave or convex bottom containers. Never place aluminium foil or plastic on the heating zones.
How to clean the hob?
Wait for the appliance to cool down, then clean with warm soapy water or a non-corrosive detergent. For stainless steel, use an appropriate cleaner. Never use abrasive products, steam or high-pressure jet.
What to do in case of a gas leak?
Immediately turn off the gas supply and electricity. Do not use a flame to detect the leak. Ventilate the room and contact a qualified installer. Do not use the appliance again until repaired.
Why do the burners produce a yellow flame?
A yellow flame indicates incomplete combustion due to incorrect air adjustment or unsuitable injectors. Check that the gas used matches the installed injectors. If the problem persists, have the appliance adjusted by a professional.
How to install the hob in a worktop?
Cut an opening to the dimensions indicated in the manual (diagram 2). Place the sealing gasket around the hob and secure it with the supplied fixing brackets. The installation must comply with safety distances and be carried out by a professional.
Where to find spare parts?
Spare parts are available from the Hoover after-sales service. Contact your dealer or visit the brand's website to order parts such as injectors, grates or thermocouples.
