Product Type Ice Machine
Brand JENN-AIR
Model JUIFX15HX
Power Supply 115 V / 60 Hz (standard estimate)
Water Filter Integrated, disposable (models P6GEG2KL, P6KG2KL, P6WG2KL)
Ice Scoop Included with holder
Drip Tray Integrated
Control Panel ON/OFF, MAX ICE, CLEAN, water filter indicators
MAX ICE Mode Increases ice production for 24 hours
Cleaning Program Automatic with approved cleaner (part 4396808)
Drain Drain cap in the water pan
Recommended Water Pressure 50 psi (344.7 kPa)
Maximum Water Pressure 120 psi (827 kPa)
Minimum Ambient Temperature 55 °F (13 °C)
Warranty Limited 10 years (sealed system), 2 years parts and labor
Replacement Parts Water filter (F2WC91/ICE2), drain pump (1901A), cleaner (4396808)
Use Domestic and light commercial

Frequently Asked Questions - JUIFX15HX JENN-AIR

How to install the water filter?
Align the alignment arrow with the notch in the housing, insert the filter and turn clockwise until it locks. Ensure the arrow on the filter head points to the lock symbol. Improper locking prevents ice production.
Why is the machine not producing ice?
Check the power supply (3-prong outlet), that the ON/OFF control is on, the drain cap is tight, the water filter is properly installed, and the water pressure is sufficient. The ambient temperature must be above 55 °F (13 °C).
How to clean the ice machine?
Use the CLEAN program with approved cleaner (part 4396808). Remove ice, pour the solution into the water pan, press CLEAN. The cycle lasts about 70 minutes and rinses automatically. Drain and reinstall the cap after the cycle.
Why does the ice have a bad taste or odor?
This may be due to high mineral content in the water, limescale buildup, or food stored in the bin. Clean the machine and if necessary, treat the water. Use a water filter.
What does 'Replace Filter' indicator mean?
It indicates it's time to replace the water filter. Use a replacement filter (F2WC91 or ICE2). After installation, the filter status tracking resets automatically.
How to use MAX ICE mode?
Press MAX ICE while the machine is operating. The indicator lights up and ice production increases for 24 hours. Press again to deactivate the mode. This mode is activated by default on first startup.
What are normal machine noises?
Humming of the water valve, clicking of refrigerant, pulsing of compressor, water flowing, gurgling of refrigerant, thud during ice harvest. The condenser fan may also be heard.
What is the recommended water pressure?
The recommended water pressure is 50 psi (344.7 kPa). Do not exceed 120 psi (827 kPa). If pressure exceeds 60 psi, a loud noise may occur during filling.
Where to order accessories for the machine?
In the US, visit www.jennalr.com/accessories or call 1-800-JennAir (536-6247). In Canada, visit www.jennarl.ca or call the same number.
What to do in case of water leak?
Check that the drain cap is tight. Ensure the drain hose is not kinked or pinched. If the drain pump is used, check that it is firmly secured. A licensed plumber may be needed for plumbing issues.
