USER MANUAL AO660RVS ETNA

Extraction systems Depending on the type, the cooker hoods can be connected in one of two ways:

1. To a duct. To a duct, the cooking vapours

extracted by suction are carried outside, once the grease particles have been filtered. This is the best method.

2. Recirculation hood. As a recirculation

hood, the grease particles and the smell in the extracted vapours are filtered. The air that has been sucked in is not carried outside but recirculates in the kitchen. In this case you must have a carbon filter fitted. Attention! The carbon filter needs to be ordered separately. Read the separate safety instructions before using the device!

DEN 6 USE Controls Opening and closing the electric valve (AO160) Move the slider to position 1. The electric valve opens. Move the slider to position 0. The electric valve closes. Switching the fan on and off (AO460) Move the slider to position 1, 2 or 3. The cooker hood switches at the corresponding speed. Move the slider to position 0. The fan switches off. Switching the light on and off Use slider A to turn the lights on/off.EN 7 Cleaning Note! Before each servicing, first disconnect the cooker hood by removing the plug from the wall socket or by switching off the main switch of the residence. Or if the appliance has been connected through a plug and socket, then the plug must be removed from the socket. The cooker hood should be cleaned regularly (at least with the same frequency with which you carry out maintenance of the fat filters) internally and externally. Do not use abrasive products. Do not use alcohol! Attention! Failure to carry out the basic cleaning recommendations of the cooker hood and replacement of the filters may cause fire risks. Therefore, we recommend oserving these instructions. The manufacturer declines all responsibility for any damage to the motor or any fire damage linked to inappropriate maintenance or failure to observe the above safety recommendations. Cooker hood Clean the cooker hood with soapy water and a soft cloth. Then wipe with clean water to rinse. Do not use aggressive cleaning agents such as soda. The cooker hood paintwork will stay looking nice if you wax it occasionally. Stainless steel canopy hoods Do not use any sort of scourer. Treat with a stainless steel care product and polish with the structure of the stainless steel. Metal grease filters These must be cleaned once a month (or when the filter saturation indication system – if envisaged on the model in possession – indicates this necessity) using non aggressive detergents, either by hand or in the dishwasher, which must be set to a low temperature and a short cycle. The openings must be placed downwards to let the water run out of the filters. The cleaning agents will make the aluminium filter turn dull, this is normal. MAINTENANCEEN 8 Grease filters Clean the grease filters at least once a month. During cleaning, the aluminium parts of the filters may become dull as a result of the cleaning agents used, particularly when placed in the dishwasher. This is normal and is not covered by the warranty. Removing the grease filter

1. Switch off the cooker hood.

2. Release the grill and push it downward.

3. Push the wire brackets (B) aside.

4. Remove the grease filter from the grille.

Carbon filter Replacing the carbon filter The carbon filter must always be used if the cooker hood is not ducted.

1. Switch off the cooker hood.

2. Release the grill and push it downward.

3. Attach the carbon filters to the motor.

• Saturation of the activated charcoal will eventually occur after more or less prolonged use, depending on the type of cooking and how frequently the grease filter is cleaned.

• In all cases it is necessary to replace the cartridge at least every four months.

• DO NOT wash or reuse the carbon filter. Saturated carbon is not environmentally friendly, change the filter regularly. MAINTENANCEEN 9 Lighting Change the light bulbs The lamp in this household appliance is only suitable for illumination of this appliance. The lamp is not suitable for household room illumination. Please note! Disconnect the appliance from the mains by removing the plug from the socket before the changing the light.

1. Release the grill and push it downward.

2. This gives access to the light bulbs.

3. Unscrew the lamp from the fitting and replace it with a lamp of the

4 E14 220-240 107 x 37 DRBB/F-4-220-240 E14-35/100 MAINTENANCEEN 10 INSTALLATION General This appliance should be connected to the power supply by a recognized fitter who is familiar with, and works according to the correct safety regulations. This appliance meets the European requirements. Important that you know:

• The minimum distance between the supporting surface for the cooking vessels on the gashob and the lowest part of the range hood must be not less than 65 cm. For use with an electric, ceramic or induction hob, this distance must be at least 55 cm.

• If the cooker hood is to be fitted to an existing duct no other appliances, such as a geyser or heater, may be connected to that same duct.

• Consider local regulations with respect to the ventilation of gas appliances.

• The shorter the duct, and the fewer the bends in it, the better the cooker hood will work.

• Before you start drilling check that there are no installation cables present.

• The connecting pipe for the cooker hood has a diameter of 120 mm. It is best also to use a flue pipe of the same diameter.

• The installation material supplied with this range hood is designed for fixing to reinforced concrete or masonry walls. For some types of walls you may need special plugs and screws.EN 11 INSTALLATION Connection Electric connection The appliance has been manufactured as a class II, therefore no earth cable is necessary. Make sure the supply voltage ratings correspond with those stated on the appliance data plate. The connection to the mains is carried out as follows: BROWN = phase L BLUE = phase N This canopy hood has been provided with a power plug. When installing the hood, make sure that this plug remains accessible. We recommend installing the wall socket out of view, behind the chimney cover. Attention: If you want to make a fixed connection, ensure that a multi-pole switch with a distance between contacts of 3 mm is installed in the supply cable. max. 140 cmEN 12 INSTALLATION Preparation The exhaust-air pipe can be mounted to the top or the rear of the cooker hood. Remove the lid (A). Connect the exhaust-air pipe to the flange (D). Recirculation This cooker hood is suitable for recirculation use (see ‘Cooker hood systems’). Convert the cooker hood for recirculation use according to the drawings below. 3EN 13 INSTALLATION Mounting

CEN 15 APPENDICE Disposal Disposal of appliance and packaging By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The local authorities can provide you with the relevant information. The packaging of this appliance is recyclable. It could have been made from:

• CFK-free polystyrene (PS-hard foam). You need to dispose of these materials responsibly in accordance with official regulations. To draw attention to the fact that the segregated processing of electric household appliances is compulsory, this appliance carries the symbol of a crossed-out dustbin. This means that at the end of its working life, you may not dispose of the appliance as household refuse. Instead, you should hand it in at a special refuse collection centre run by the local authority or at a dealer’s providing this service. Segregated processing of household appliances avoids any negative effects on the environment and public health that might otherwise occur. It enables the recovery of the materials used in the production of this appliance, thus realising considerable savings in terms of raw materials and energy. Declaration of conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced.EN 16EN 17785702 / VER 1 / 04-10-2018
