USER MANUAL TravelMate 7750G ACER

© 2010 All Rights Reserved.

TravelMate Series Generic User Guide

Original Issue: 02/2011

Model number: ____

Serial number: ____

Date of purchase: ____

Place of purchase: ____

Information for your safety and comfort

Safety instructions

Read these instructions carefully. Keep this document for future reference. Follow all warnings and instructions marked on the product.

Turning the product off before cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

CAUTION for plug as disconnecting device

Observe the following guidelines when connecting and disconnecting power to the power supply unit:

Install the power supply unit before connecting the power cord to the AC power outlet.

Unplug the power cord before removing the power supply unit from the computer.

If the system has multiple sources of power, disconnect power from the system by unplugging all power cords from the power supplies.

CAUTION for Accessibility

Be sure that the power outlet you plug the power cord into is easily accessible and located as close to the equipment operator as possible. When you need to disconnect power to the equipment, be sure to unplug the power cord from the electrical outlet.

CAUTION for bundled dummy cards (only for certain models)

Your computer shipped with plastic dummies installed in the card slots. Dummies protect unused slots from dust, metal objects or other particles. Save the dummies for use when no cards are in the slots.

CAUTION for Listening

To protect your hearing, follow these instructions.

• Increase the volume gradually until you can hear clearly and comfortably.
• Do not increase the volume level after your ears have adjusted.

• Do not listen to music at high volumes for extended periods.

- Do not increase the volume to block out noisy surroundings.

- Decrease the volume if you can't hear people speaking near you.

Warnings

- Do not use this product near water.

- Do not place this product on an unstable cart, stand or table. If the product falls, it could be seriously damaged.

- Slots and openings are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near or over a radiator or heat register, or in a built-in installation unless proper ventilation is provided.

- Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind onto or into the product.

- To avoid damage of internal components and to prevent battery leakage, do not place the product on a vibrating surface.

- Never use it under sporting, exercising, or any vibrating environment which will probably cause unexpected short current or damage rotor devices, HDD, optical drive, and even exposure risk from lithium battery pack.

- The bottom surface, areas around ventilation openings and AC adapter may get hot. To avoid injury, ensure they do not come in contact with your skin or body.

- Your device and its enhancements may contain small parts. Keep them out of the reach of children.

Using electrical power

- This product should be operated from the type of power indicated on the marking label. If you are not sure of the type of power available, consult your dealer or local power company.

- Do not allow anything to rest on the power cord. Do not locate this product where people will walk on the cord.

- If an extension cord is used with this product, make sure that the total ampere rating of the equipment plugged into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating of all products plugged into the wall outlet does not exceed the fuse rating.

- Do not overload a power outlet, strip or receptacle by plugging in too many devices. The overall system load must not exceed 80% of the branch circuit rating. If power strips are used, the load should not exceed 80% of the power strip's input rating.

- This product's AC adapter is equipped with a three-wire grounded plug.

The plug only fits in a grounded power outlet. Make sure the power outlet is properly grounded before inserting the AC adapter plug. Do not insert the plug into a non-grounded power outlet. Contact your electrician for details.

Warning! The grounding pin is a safety feature. Using a power outlet that is not properly grounded may result in electric shock and/or injury.

Note: The grounding pin also provides good protection from unexpected noise produced by other nearby electrical devices that may interfere with the performance of this product.

•The system can be powered using a wide range of voltages: 100 to 120 or 220 to 240 V AC. The power cord included with the system meets the requirements for use in the country/region where the system was purchased. Power cords for use in other countries/regions must meet the requirements for that country/region. For more information on power cord requirements, contact an authorized reseller or service provider.

Product servicing

Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel.

Unplug this product from the wall outlet and refer servicing to qualified service personnel when:

•The power cord or plug is damaged, cut or frayed.
•Liquid was spilled into the product.
•The product was exposed to rain or water.
•The product has been dropped or the case has been damaged.

- The product exhibits a distinct change in performance, indicating a need for service.

- The product does not operate normally after following the operating instructions.

Note: Adjust only those controls that are covered by the operating instructions, since improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal condition.

Guidelines for safe battery usage

This notebook uses a Lithium-ion battery. Do not use it in a humid, wet or corrosive environment. Do not put, store or leave your product in or near a heat source, in a high temperature location, in strong direct sunlight, in a microwave oven or in a pressurized container, and do not expose it to temperatures over 60^ C ( 140^ F). Failure to follow these guidelines may cause the battery to leak acid, become hot, explode or ignite and cause injury and/or damage. Do not pierce, open or disassemble the battery. If the battery leaks and you come into contact with the leaked fluids, rinse thoroughly with water and seek medical attention immediately. For safety reasons, and to prolong the lifetime of the battery, charging will not occur at temperatures below 0^ C ( 32^ F) or above 40^ C ( 104^ F).

The full performance of a new battery is achieved only after two or three complete charge and discharge cycles. The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the operation time becomes noticeably shorter than normal, buy a new battery. Use only the approved batteries, and recharge your battery only with the approved chargers designated for this device.

Use the battery only for its intended purpose. Never use any charger or battery that is damaged. Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object such as a coin, clip or pen causes direct connection of the positive (+) and negative (-) terminals of the battery. (These look like metal strips on the battery.) This might happen, for example, when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the battery or the connecting object.

The capacity and lifetime of the battery will be reduced if the battery is left in hot or cold places, such as in a closed car in summer or winter. Always try to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is especially limited in temperatures well below freezing.

Do not dispose of batteries in a fire as they may explode. Batteries may also explode if damaged. Dispose of batteries according to local regulations. Please recycle when possible. Do not dispose as household waste.

Wireless devices may be susceptible to interference from the battery, which could affect performance.

Replacing the battery pack

The notebook uses lithium batteries. Replace the battery with the same type as that which came bundled with your product. Use of another battery may present a risk of fire or explosion.

Warning! Batteries may explode if not handled properly. Do not disassemble or dispose of them in fire. Keep them away from

children. Follow local regulations when disposing of used batteries.

Caution for Optical Drive Device (only for certain models)

CAUTION: This appliance contains a laser system and is classified as a "CLASS 1 LASER PRODUCT." In case of any trouble with this device, please contact your nearest AUTHORIZED service station. To prevent direct exposure to the laser beam, do not try to open the enclosure.

CLASS 1 LASER PRODUCT

CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Telephone line safety

- Disconnect all telephone lines from the equipment when not in use and/or before servicing.

• To avoid the remote risk of electric shock from lightning, do not connect the telephone line to this equipment during lightning or thunderstorms.

Warning! For safety reasons, do not use non-compliant parts when adding or changing components. Consult your reseller for purchase options.

Operating environment

Warning! For safety reasons, turn off all wireless or radio transmitting devices when using your laptop under the following conditions. These devices may include, but are not limited to: wireless LAN (WLAN), Bluetooth and/or 3G.

Remember to follow any special regulations in force in any area, and always switch off your device when its use is prohibited or when it may cause interference or danger. Use the device only in its normal operating positions. This device meets RF exposure guidelines when used normally, and it and its antenna are positioned at least 1.5 centimeters (5/8 inches) away from your body. It should not contain metal and you should position the device the above-stated distance from your body. To successfully transmit data files or messages, this device requires a good quality connection to the network. In some cases, transmission of data files or messages may be delayed until such a connection is available. Ensure that the above separation distance instructions are followed until the transmission is completed. Parts of the device are magnetic. Metallic materials may be attracted to the device, and persons with hearing aids should not hold the device to the ear with the hearing aid. Do not place credit cards or other magnetic storage media near the device, because information stored on them may be erased.

Medical devices

Operation of any radio transmitting equipment, including wireless phones, may interfere with the functionality of inadequately protected medical devices.

Consult a physician or the manufacturer of the medical device to determine if they are adequately shielded from external RF energy or if you have any questions. Switch off your device in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF transmissions.

Pacemakers. Pacemaker manufacturers recommend that a minimum separation of 15.3 centimeters (6 inches) be maintained between wireless devices and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research. Persons with pacemakers should do the following:

•Always keep the device more than 15.3 centimeters (6 inches) from the pacemaker
- Not carry the device near your pacemaker when the device is switched on. If you suspect interference, switch off your device, and move it.

Hearing aids. Some digital wireless devices may interfere with some hearing aids. If interference occurs, consult your service provider.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles such as electronic fuel injection systems, electronic anti-skid (anti-lock) braking systems, electronic speed control systems, and air bag systems. For more information, check with the manufacturer, or its representative, of your vehicle or any equipment that has been added. Only qualified personnel should service the device, or install the device in a vehicle. Faulty installation or service may be dangerous and may invalidate any warranty that may apply to the device. Check regularly that all wireless equipment in your vehicle is mounted and operating properly. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the device, its parts, or enhancements. For vehicles equipped with an air bag, remember that air bags inflate with great force. Do not place objects, including installed or portable wireless equipment in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed, and the air bag inflates, serious injury could result. Using your device while flying in aircraft is prohibited. Switch off your device before boarding an aircraft. The use of wireless teledevices in an aircraft may be dangerous to the operation of the aircraft, disrupt the wireless telephone network, and may be illegal.

Potentially explosive environments

Switch off your device when in any area with a potentially explosive atmosphere and obey all signs and instructions. Potentially explosive atmospheres include areas where you would normally be advised to turn off your vehicle engine. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Switch off the device at refueling points such as near gas pumps at service stations. Observe restrictions on the use of radio equipment in fuel depots, storage, and distribution areas; chemical plants; or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include below deck on boats, chemical transfer or storage facilities, vehicles using liquefied petroleum gas (such as propane or butane), and areas where the air contains chemicals or particles such as grain, dust or metal powders. Do not switch the notebook on when wireless phone use is prohibited or when it may cause interference or danger.

Emergency calls

Warning: You cannot make emergency calls through this device. To make an emergency call you shall dial out through your mobile phone or other telephone call system.

Disposal instructions

Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit www.acer-group.com/public/Sustainability/sustainability01.htm

Mercury advisory

For bulb-inside projectors or electronic products containing a non-LED-backlit-LCD/CRT monitor or display: Lamp(s) inside this product contain mercury and must be recycled or disposed of according to local, state or federal laws. For more information, contact the Electronic Industries Alliance at www.eiae.org. For lamp-specific disposal information, check www.lamprecycle.org.

ENERGY STAR

ENERGY STAR

Acer's ENERGY STAR qualified products save your money by reducing energy cost and protecting the environment without sacrificing features or performance. Acer is proud to offer our customers products with the ENERGY STAR mark.

What is ENERGY STAR?

Products that are ENERGY STAR qualified use less energy and prevent greenhouse gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency. Acer is committed to offering products and services worldwide that help customers save money, conserve energy and improve the quality of our environment. The more energy we can save through higher energy efficiency, the more we reduce greenhouse gases and the risks of climate change. More information refers to www.energystar.gov or www.energystar.gov/powermanagement.

Acer ENERGY STAR qualified products: (only for certain models)

• Produce less heat and reduce cooling loads, and warmer climates.
• Automatically go into "display sleep" and "computer sleep" mode after 10 and 30 minutes of inactivity respectively.
• Wake the computer from sleep mode by pushing keyboard or moving mouse.
  • Computers will save more than 80% energy at "sleep" mode.

ENERGY STAR and the ENERGY STAR mark are registered U.S. marks

Tips and information for comfortable use

Computer users may complain of eyestrain and headaches after prolonged use. Users are also at risk of physical injury after long hours of working in front of a computer. Long work periods, bad posture, poor work habits, stress, inadequate working conditions, personal health and other factors greatly increase the risk of physical injury.

Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis, tenosynovitis or other musculoskeletal disorders. The following symptoms may appear in the hands, wrists, arms, shoulders, neck or back:

• Numbness, or a burning or tingling sensation.
  •Aching, soreness or tenderness.
  •Pain, swelling or throbbing.
  •Stiffness or tightness.
  •Coldness or weakness.

If you have these symptoms, or any other recurring or persistent discomfort and/or pain related to computer use, consult a physician immediately and inform your company's health and safety department.

The following section provides tips for more comfortable computer use.

Finding your comfort zone

Find your comfort zone by adjusting the viewing angle of the monitor, using a footrest, or raising your sitting height to achieve maximum comfort. Observe the following tips:

•Refrain from staying too long in one fixed posture.
- Avoid slouching forward and/or leaning backward.
- Stand up and walk around regularly to remove the strain on your leg muscles.
•Take short rests to relax your neck and shoulders.
- Avoid tensing your muscles or shrugging your shoulders.
• Install the external display, keyboard and mouse properly and within comfortable reach.
- If you view your monitor more than your documents, place the display at the center of your desk to minimize neck strain.

Taking care of your vision

Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive room lighting, poorly focused screens, very small typefaces and low-contrast displays could stress your eyes. The following sections provide suggestions on how to reduce eyestrain.

Eyes

•Rest your eyes frequently.
- Give your eyes regular breaks by looking away from the monitor and focusing on a distant point.
- Blink frequently to keep your eyes from drying out.

Display

• Keep your display clean.
• Keep your head at a higher level than the top edge of the display so your eyes point downward when looking at the middle of the display.
• Adjust the display brightness and/or contrast to a comfortable level for enhanced text readability and graphics clarity.

• Eliminate glare and reflections by:

• placing your display in such a way that the side faces the window or any light source

• minimizing room light by using drapes, shades or blinds
• using a task light
• changing the display's viewing angle
  • using a glare-reduction filter

• using a display visor, such as a piece of cardboard extended from the display's top front edge

• Avoid adjusting your display to an awkward viewing angle.

• Avoid looking at bright light sources for extended periods of time.

Developing good work habits

The following work habits make computer use more relaxing and productive:

•Take short breaks regularly and often.
- Perform some stretching exercises.
- Breathe fresh air as often as possible.
•Exercise regularly and maintain a healthy body.

Warning! We do not recommend using the computer on a couch or bed. If this is unavoidable, work for only short periods, take breaks regularly, and do some stretching exercises.

Note: For more information, please refer to "Regulations and safety notices" on page 51.

First things first

We would like to thank you for making an Acer notebook your choice for meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your computer.

The TravelMate Generic User Guide contains useful information applying to all models in the TravelMate product series. It covers basic topics such as using the keyboard and audio, etc. Please understand that due to its nature, the Generic User Guide will occasionally refer to functions or features which are only contained in certain models of the series, but not necessarily in the model you purchased. Such instances are marked in the text with language such as "only for certain models."

The Quick Guide introduces you to the basic features and functions of your new computer. For more on how your computer can help you to be more productive, please refer to the TravelMate Generic User Guide. This guide contains detailed information on such subjects as system utilities, data recovery, expansion options and troubleshooting. In addition it contains warranty information and the general regulations and safety notices for your notebook. It is available in Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click Start > All Programs > AcerSystem.

2 Click TravelMate Generic User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not installed on your computer, clicking on TravelMate Generic User Guide will run the Adobe Reader setup program first. Follow the instructions on the screen to complete the installation. For instructions on how to use Adobe Reader, access the Help and Support menu.

Basic care and tips for using your computer

Turning your computer on and off

To turn on the computer, simply press and release the power button. Please refer to the setup poster for the location of the power button.

To turn the power off, do any of the following:

• Use the Windows shutdown command: click Start then Click Shut Down.
- Use the power button.

You can also put the computer in sleep mode by pressing the sleep hotkey + .

Note: If you cannot power off the computer normally, press and hold the power button for more than four seconds to shut down the computer. If you turn off the computer and want to turn it on again, wait at least two seconds before powering up.

Taking care of your computer

Your computer will serve you well if you take care of it.

• Do not expose the computer to direct sunlight. Do not place it near sources of heat, such as a radiator.
• Do not expose the computer to temperatures below 0^ C ( 32^ F) or above 50^ C ( 122^ F).
• Do not subject the computer to magnetic fields.
• Do not expose the computer to rain or moisture.
• Do not spill water or any liquid on the computer.
• Do not subject the computer to heavy shock or vibration.
• Do not expose the computer to dust or dirt.
• Never place objects on top of the computer.
  • Do not slam the computer display when you close it.
• Never place the computer on uneven surfaces.

Taking care of your AC adapter

Here are some ways to take care of your AC adapter:

- Do not connect the adapter to any other device.

- Do not step on the power cord or place heavy objects on top of it. Carefully route the power cord and any cables away from foot traffic.

- When unplugging the power cord, do not pull on the cord itself but pull on the plug.

- The total ampere ratings of the equipment plugged in should not exceed the ampere rating of the cord if you are using an extension cord. Also, the total current rating of all equipment plugged into a single wall outlet should not exceed the fuse rating.

Taking care of your battery pack

Here are some ways to take care of your battery pack:

• Use only batteries of the same kind as replacements. Turn the power off before removing or replacing batteries.
• Do not tamper with batteries. Keep them away from children.
• Dispose of used batteries according to local regulations. Recycle if possible.

Cleaning and servicing

When cleaning the computer, follow these steps:

1 Turn off the computer and remove the battery pack.
2 Disconnect the AC adapter.
3 Use a soft, moist cloth. Do not use liquid or aerosol cleaners.
If either of the following occurs:
•The computer has been dropped or the body has been damaged;
•The computer does not operate normally
Please refer to "Frequently asked questions" on page 45.

Information for your safety and comfort iii

Safety instructions iii

Caution for Optical Drive Device (only for certain models) vii

Operating environment viii

Medical devices viii

Vehicles ix

Potentially explosive environments ix

Emergency calls ix

Disposal instructions x

Mercury advisory x

ENERGY STAR x

Tips and information for comfortable use xi

First things first xiii

Your guides xiii

Basic care and tips for using your computer xiii

Turning your computer on and off xiii

Taking care of your computer xiv

Taking care of your AC adapter xiv

Taking care of your battery pack xv

Cleaning and servicing xv

Touchpad 1

Touchpad basics (with two buttons) 1

Using the keyboard 3

Lock keys and embedded numeric keypad* 3

Hotkeys 4

Windows keys 5

Acer ProShield 7

Overview 7

Setting up ProShield 7

Personal Secure Disk 8

BIOS Settings 9

Credential Manager 9

Data Protection 10

Here you can select files for encryption or decryption, and manage your PSD. 10

Data Removal 10

Remote Manageability 11

Acer eRecovery Management 12

Creating a recovery backup (Optical drive) 13

Creating a recovery backup (USB flash drive) 15

Recovering your system (Optical drive) 17

To recover your system 17

Types of recovery 17

Recovering pre-installed software and drivers 17

Returning to a previous system condition 18

Returning your system to its factory condition 19

Recovering your system (USB flash drive) 21

To recover your system 21

Types of recovery 21

Recovering pre-installed software and drivers 21

Returning to a previous system condition 22

Returning your system to its factory condition 23

Acer Backup Manager 25

Power management 26

Acer PowerSmart key 26

Battery pack 27

Battery pack characteristics 27

Maximizing the battery's life 27

Installing and removing the battery pack 28

Charging the battery 29

Checking the battery level 29

Optimizing battery life 29

Battery-low warning 29

Taking your notebook PC with you 31

Disconnecting from the desktop 31

Moving around 31

Preparing the computer 31

What to bring to meetings 32

Taking the computer home 32

Preparing the computer 32

What to take with you 32

Special considerations 32

Setting up a home office 33

Traveling with the computer 33

Preparing the computer 33

What to take with you 33

Special considerations 33

Traveling internationally with the computer 34

Preparing the computer 34

What to bring with you 34

Special considerations 34

Securing your computer 35

Using a computer security lock 35

Using passwords 35

Entering passwords 36

Setting passwords 36

Expanding through options 37

Connectivity options 37

Fax/data modem (only for certain models) 37

Built-in network feature 38

Consumer Infrared (CIR) (only for certain models) 38

Universal Serial Bus (USB) 39

IEEE 1394 port (only for certain models) 39

High-Definition Multimedia Interface

(only for certain models) 40

ExpressCard (only for certain models) 40

Installing memory (only for certain models) 41

BIOS utility 43

Boot sequence 43

Enable disk-to-disk recovery 43

Password 43

Using software 44

Playing DVD content 44

Frequently asked questions 45

Requesting service 48

International Travelers Warranty (ITW) 48

Before you call 48

Troubleshooting 49

Troubleshooting tips 49

Error messages 49

Regulations and safety notices 51

FCC statement 51

Modem notices (only for certain models) 52

LCD pixel statement 53

Radio device regulatory notice 53

General 54

The FCC RF safety requirement 54

Canada — Low-power license-exempt radio

communication devices (RSS-210) 55

Exposure of humans to RF fields (RSS-102) 55

LCD panel ergonomic specifications 56

Touchpad

The built-in touchpad is a pointing device that senses movement on its surface. This means the cursor responds as you move your finger across the surface of the touchpad. The central location on the palmrest provides optimum comfort and support.

Touchpad basics (with two buttons)

The following items show you how to use the touchpad with two buttons.

• Move your finger across the touchpad to move the cursor.
• Press the left and right buttons located beneath the touchpad to perform selection and execution functions. These two buttons are similar to the left and right buttons on a mouse. Tapping on the touchpad is the same as clicking the left button.

Function Left button	Right button	Main touchpad
Execute Quickly click twice.		Tap twice (at the same speed as double-clicking a mouse button).
Select Click once. Tap once.
Drag Click and hold, then use finger on the touchpad to drag the cursor.		Tap twice (at the same speed as double-clicking a mouse button); rest your finger on the touchpad on the second tap and drag the cursor.
Access context menu	Click once.

Note: Illustrations for reference only. The exact configuration of your PC depends on the model purchased.

Note: When using the touchpad, keep it — and your fingers — dry and clean. The touchpad is sensitive to finger movement; hence,

the lighter the touch, the better the response. Tapping harder will not increase the touchpad's responsiveness.

Note: By default, vertical and horizontal scrolling is enabled on your touchpad. It can be disabled under Mouse settings in Windows Control Panel.

Using the keyboard

The keyboard has full-sized keys and an embedded numeric keypad*, separate cursor, lock, Windows, function and special keys.

Lock keys and embedded numeric keypad\*

The keyboard has three lock keys which you can toggle on and off.

Lock key Description

Caps Lock When Caps Lock is on, all alphabetic characters typed are in uppercase.
Num Lock+*	When Num Lock is on, the embedded keypad is in numeric mode. The keys function as a calculator (complete with the arithmetic operators +, -, *, and /). Use this mode when you need to do a lot of numeric data entry. A better solution would be to connect an external keypad.
Scroll Lock+	When Scroll Lock is on, the screen moves one line up or down when you press the up or down arrow keys respectively. Scroll Lock does not work with some applications.

The embedded numeric keypad functions like a desktop numeric keypad. It is indicated by small characters located on the upper right corner of the keycaps. To simplify the keyboard legend, cursor-control key symbols are not printed on the keys.

Desired access Num Lock on Num Lock off

Number keys on embedded keypad	Type numbers in a normal manner.
Cursor-control keys on embedded keypad	Holdwhile using cursor-control keys.	Holdwhile using cursor-control keys.
Main keyboard keys	Holdwhile typing letters on embedded keypad.	Type the letters in a normal manner.

* only for certain models

Hotkeys

The computer employs hotkeys or key combinations to access most of the computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the key before pressing the other key in the hotkey combination.

Hotkey Icon Function Description
	+		Communication key
	+		Sleep
	+		Display toggle
	+		Display off
	+		Touchpad toggle
	+	[558S]	Speaker toggle
	+		NumLk
	+		Brightness up Increases the screen brightness.
	+		Brightness down
	+		Volume up Increases the sound volume.

Hotkey Icon Function Description

+ <

Volume down Decreases the sound volume.

Windows keys

The keyboard has two keys that perform Windows-specific functions.

Key Description

Windows key

Pressed alone it launches the Start menu. It can also be used with other keys for other functions:

<②Open or close the Start menu
<○> + : Display the desktop
<图标> + : Open Windows Explorer
<> + < F>: Search for a file or folder
<@> + < G>: Cycle through Sidebar gadgets
<○> + : Lock your computer (if connected to a domain), or switch users (if not connected to a domain)
<> + < M>: Minimize all windows
<@> + : Open the Run dialog box
<○> + : Cycle through programs on the taskbar
<@> + : Open Ease of Access Center
<@> + < X>: Open Windows Mobility Center
<图标> + < Break>: Display System Properties
<○> + : Restore minimized windows
<○> + : Cycle through programs on the taskbar by using Windows Flip 3-D
+ : Bring all gadgets to the front and select Windows Sidebar
+ <图标> + : Search for network computers
+ + : Use the arrow keys to cycle through open programs using Windows Flip 3-D

Key Description

Application key

This key has the same effect as clicking the right mouse button; it opens the application's context menu.

Note: Depending on your edition of Windows, some shortcuts may not function as described.

Acer ProShield

Overview

An all-in-one security solution, Acer ProShield provides an embedded security solution to address the following points of vulnerability:

•Securing the device against unauthorized access
- Protecting local storage
•Securing the network

Acer ProShield includes five modules that will secure your device from unauthorized access and intrusion.

•Credential Manager - Password, Bio-Protection, TPM configuration
•BIOS Migration - Boot sequence and device security
- Data Encryption - Personal secure drive, file and folder encryption
•Data Removal - File shredder
- Remote Manageability - ProShield remote UI

Setting up ProShield

The first time you run ProShield, you will be led through a setup wizard that allows you to set up the parameters for ProShield. Click Start to begin. You will be required to set a password.

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Note: Select a password that you will remember, but is difficult to guess. Do not use words that can be found in a dictionary. It is advisable to use a combination of letters and numbers.

Once you've set the password, you can click Next to proceed to setting up a Personal Secure Disk or click Finish to exit the wizard.

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Personal Secure Disk

The Personal Secure Disk (PSD) is a secure section of your hard disk where you can save files. You can only get access to the PSD via password or fingerprint authentication.

Once setup is finished, you can go to the ProShield Console to manage your computer or make changes to the settings.

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data.

Use the menu in the left-hand pane to make changes.

BIOS Settings

Here you can set the BIOS Supervisor and User passwords, enable or disable password checking at bootup, and add an Asset Tag for the device.

Acer ProShield BIOS Settings BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. Set Clear OK Cancel Apply Help

You can also set the boot device order, enable or disable ports and built-in devices, and import or export BIOS settings.

Credential Manager

Here you can set and manage your credentials, including Pre-boot authentication.

ProShield ACER ProShield ACER PROShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Help OK Cancel Apply NCS Settings Credential Manager Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help

You can change your ProShield and Windows passwords, manage online account information, and back up or restore credential information.

Data Protection

Here you can select files for encryption or decryption, and manage your PSD.

ProShield Acer ProShield File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folders() to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In Folder Size Encrypt Cancel

Data Removal

Here you can select files to be completely removed from the hard disk. The File Shredder overwrites the data to make recovering the data impossible.

Acer ProShield File Shredder Add files for shredding by dragging and dropping files or clicking the Add Files) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name Sin Folder Size Strad Cancel

Note: You can also double-click the File Shredder icon on the desktop to open this function.

Warning: Make sure you select only the information you want to shred. Once you have shredded a file or folder, it is impossible to recover the data.

Remote Manageability

This module allows Acer Client Manager to control the functions of Acer ProShield from a remote station. The flexibility of remote management allows efficient use of IT resources and timely implementation of security updates.

Acer eRecovery Management

If your computer experiences problems that are not recoverable by other methods, you may need to reinstall the Windows operating system and factory-loaded software and drivers. To ensure you can recover your computer when needed, you should create a recovery backup as soon as possible.

Note: All of the following content is for general reference only. Actual product specifications may vary.

Acer eRecovery Management consists of the following functions:

1 Backup:

• Create Factory Default Backup
• Backup Drivers and Applications

Note: Models that do not have an ODD will allow you to make backup copies to a USB drive.

2 Restore:

• Restore Operating System to Factory Defaults
• Restore Operating System and Retain User Data
• Reinstall Drivers or Applications

This chapter will guide you through each process.

To use the password protection feature of Acer eRecovery Management, you must first set the password. The password is set by launching Acer eRecovery Management and clicking Settings.

Acer eRecovery Management Backup Restore Settings Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Creating a recovery backup (Optical drive)

To reinstall using a backup on optical discs, you must create the recovery disc beforehand. Throughout the process, you will be guided by onscreen instructions. Please read them carefully!

1 Click Start > All Programs > Acer, then click Acer eRecovery Management.

Ace recovery Management Backup Restore Settings ? Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use the disc to reinstall drivers or applications if you encounter any problems with them.

2 To create recovery discs for the hard drive's entire original contents, including Windows and all factory-loaded software and drivers, click Create Factory Default Disc.

- OR -

To create a recovery disc for only the factory-loaded software and drivers, click Create Drivers and Applications Backup Disc.

Important: We recommend that you create each type of recovery backup as soon as possible.

The Create Factory Default Backup dialog box tells you the number of blank, recordable discs you will need to complete the recovery discs. Make sure that you have the required number of identical, blank discs ready before continuing.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (0) Options: 50 ROM SC-35001 Estimated size: 5.54 GB 8 needs 2 blank DVDo(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

3 Insert a blank disc into the drive indicated in the Backup to list, then click Next. You will be shown the backup progress on the screen.

Acer eRecovery Management Backup Preferences Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

The drive ejects each disc as it completes burning it.

4 Remove the disc from the drive and mark it with a permanent marker.

Important: Write a unique, descriptive label on each disc, such as 'Windows Recovery Disc 1 of 2' or 'Apps/Drivers Recovery disc'. Make sure you keep the discs in a safe place that you will remember.

5 If multiple discs are required, insert a new disc when prompted, then click OK. Continue recording discs until the process is complete.

Creating a recovery backup (USB flash drive)

To reinstall using a backup on a USB flash drive, you must create the recovery backup beforehand. Throughout the process, you will be guided by onscreen instructions. Please read them carefully!

Important: If you are using a USB flash drive, ensure it is at least 12 GB and does not contain any previous data.

Important: This section only applies to computers without an optical drive.

1 Click Start > All Programs > Acer, then click Acer eRecovery Management.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

2 To create recovery backup for the hard drive's entire original contents, including Windows and all factory-loaded software and drivers, click Create Factory Default Backup.

- OR -

To create a recovery backup for only the factory-loaded software and drivers, click Create Driver and Applications Backup.

Important: We recommend that you create each type of recovery backup as soon as possible.

The Create Factory Default Backup dialog box opens. This dialog box tells you the estimated size of the backup file on your USB flash drive.

Acet eRecovery Management Backup Handlers Settings Help Create Factory Default Backup Backup to: (D) Options: BD ROM BC-25001 Estimated size: 3.54 GB 3 needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

3 Plug in the USB disk, then click Next. You will be shown the backup progress on the screen.

Acer eRecovery Management Backup Settings Help Create Factory Default Backup Create on: Recovery1 Backup media 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

4 Unplug the USB flash drive and mark it with a permanent marker.

Important: Write a unique, descriptive label on each backup, such as 'Windows Recovery Backup' or 'Apps/Drivers Recovery Backup'. Make sure you keep the USB flash drive in a safe place that you will remember.

Recovering your system (Optical drive)

If calling Acer support did not help fix your problem, you can use the Acer eRecovery Management program. This will restore your computer to the same state as when you purchased it, while giving you an option to retain all settings and personal data for later retrieval.

To recover your system

1 Perform minor fixes.

If only one or two items of software or hardware have stopped working correctly, the problem may be solved by reinstalling the software or the device drivers. To recover software and drivers that were pre-installed at the factory, see "Recovering pre-installed software and drivers" on page 17. For instructions on reinstalling software and drivers that were not pre-installed, see that product's documentation or technical support Web site.

2 Revert to a previous system condition.

If reinstalling software or drivers does not help, then the problem may be solved by returning your system to a previous state when everything was working correctly. For instructions, see "Returning to a previous system condition" on page 18.

3 Reset your system to its factory condition.

If nothing else has solved the problem and you want to reset your system to factory condition, see "Returning your system to its factory condition" on page 19.

Types of recovery

Recovering pre-installed software and drivers

As a troubleshooting step, you may need to reinstall the software and device drivers that came pre-installed on your computer from the factory. You can recover using either your hard drive or the recovery discs you have created.

• New software: If you need to recover software that did not come pre-installed on your computer, you need to follow that software's installation instructions.
• New device drivers: If you need to recover device drivers that did not come pre-installed on your computer, follow the instructions provided with the device.

To recover your pre-installed software and drivers:

1 Click Start > All Programs > Acer, then click Acer eRecovery Management. - OR -

If you are recovering from your driver and application recovery disc, insert it into the disc drive, then go to Step 3 after the Acer Application Recovery main menu opens.

2 Click the Restore tab, then click Reinstall Drivers or Applications to display the Acer Application Recovery main menu.

Acer eRecovery Management Backup Restore Settings ? Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c\ drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

3 Click Contents to show a list of software and device drivers.
4 Click the install icon for the item you want to install, then follow the onscreen prompts to complete the installation. Repeat this step for each item you want to reinstall.

Returning to a previous system condition

Microsoft System Restore periodically takes 'snapshots' of your system settings and saves them as restore points. In most cases of hard-to-resolve software problems, you can return to one of these restore points to get your system running again.

Windows automatically creates an additional restore point each day, and also each time you install software or device drivers.

Tip: For more information about using Microsoft System Restore, click Start, then click Help and Support. Type windows system restore in the Search Help box, then press Enter.

To return to a restore point:

1 Click Start > Control Panel > System and Security > Action Center, then click Recovery.
2 Click Open System Restore, then Next.

3 Select the restore point you want, click Next, then Finish. A confirmation message box will appear.
4 Click Yes. Your system is restored using the restore point you specified. This process may take several minutes, and may restart your computer.

Returning your system to its factory condition

If your computer experiences problems that are not recoverable by other methods, you may need to reinstall everything to return your system to its factory condition. You can reinstall using either your hard drive or the recovery discs you have created.

Warning: This complete recovery deletes everything on your hard drive, then reinstalls Windows and all software and drivers that were pre-installed on your system. If you can access important files on your hard drive, back them up now.

If you can still run Windows, see "Recovering from within Windows" on page 19.

If you cannot run Windows and your original hard drive is still working, see "Recovering from the hard drive during startup" on page 20.

If you cannot run Windows and your original hard drive has been completely reformatted or you have installed a replacement hard drive, see "Recovering from your recovery discs" on page 20.

Recovering from within Windows

To reinstall Windows and all pre-installed software and drivers:

Click Start > All Programs > Acer, then click Acer eRecovery Management.

Click the Restore tab, then Restore Operating System to Factory Defaults.

Click Yes, then Start. A dialog box will display information about the hard drive that the operating system will be recovered to.

Warning: Continuing the process will erase all files on your hard drive.

Click OK. The recovery process begins by restarting your computer, then continues by copying files to your hard drive. This process may take a while, the Acer eRecovery Management screen displays the progress.

When the recovery has finished, a dialog box will prompt you to restart your computer.

Click OK to restart your computer.

Follow the onscreen prompts for first-time system setup.

Recovering from the hard drive during startup

To reinstall Windows and all pre-installed software and drivers:

1 Turn on your computer, then press + during startup to open Acer eRecovery Management.

2 Click Restore Operating System to Factory Defaults.

Warning: Continuing the process will erase all files on your hard drive.

3 Click Next. Your hard drive's original, factory-loaded contents will be recovered. This process will take several minutes.

Recovering from your recovery discs

To reinstall Windows and all pre-installed software and drivers:

1 Turn on your computer, insert the first system recovery disc into your optical disc drive, then restart your computer.

Warning: Continuing the process will erase all files on your hard drive.

If it is not already enabled, you must enable the F12 Boot Menu:

Press when starting your computer.

Use the left or right arrow keys to select the Main menu.

Press the down key until F12 Boot Menu is selected, press to change this setting to Enabled.

Use the left or right arrow keys to select the Exit menu.

Select Save Changes and Exit and press Enter. Select OK to confirm.

Your computer will restart.

2 During startup, press to open the boot menu. The boot menu allows you to select which device to start from, such as the hard drive or an optical disc.
3 Use your arrow keys to select the line CDROM/DVD (this line may start with 'IDE 1...'), then press . Windows will install from the recovery disc you inserted.
4 Insert the second recovery disc when prompted, then follow the onscreen prompts to complete the recovery.

Recovering your system (USB flash drive)

If calling Acer support did not help fix your problem, you can use the Acer eRecovery Management program. This will restore your computer to the same state as when you purchased it, while giving you an option to retain all settings and personal data for later retrieval.

To recover your system

1 Perform minor fixes.

If only one or two items of software or hardware have stopped working correctly, the problem may be solved by reinstalling the software or the device drivers. To recover software and drivers that were pre-installed at the factory, see "Recovering pre-installed software and drivers" on page 21. For instructions on reinstalling software and drivers that were not pre-installed, see that product's documentation or technical support Web site.

2 Revert to a previous system condition.

If reinstalling software or drivers does not help, then the problem may be solved by returning your system to a previous state when everything was working correctly. For instructions, see "Returning to a previous system condition" on page 22.

3 Reset your system to its factory condition.

If nothing else has solved the problem and you want to reset your system to factory condition, see "Returning your system to its factory condition" on page 23.

Types of recovery

Recovering pre-installed software and drivers

As a troubleshooting step, you may need to reinstall the software and device drivers that came pre-installed on your computer from the factory. You can recover using either your hard drive or the backup you have created.

• New software: If you need to recover software that did not come pre-installed on your computer, you need to follow that software's installation instructions.
• New device drivers: If you need to recover device drivers that did not come pre-installed on your computer, follow the instructions provided with the device.

To recover your pre-installed software and drivers:

1 Click Start > All Programs > Acer, then click Acer eRecovery Management. - OR -

If you are recovering from your driver and application recovery backup, insert the USB flash drive into a USB port. Open the USB flash drive in Windows Explorer and double-click Recovery.

2 Click Reinstall Drivers or Application from a USB device.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C drive will be deleted. Reinstall Drivers or Application from a USB device Reinstall factory default drivers or applications.

3 Click Contents to show a list of software and device drivers.
4 Click the install icon for the item you want to install, then follow the onscreen prompts to complete the installation. Repeat this step for each item you want to reinstall.

Returning to a previous system condition

Microsoft System Restore periodically takes 'snapshots' of your system settings and saves them as restore points. In most cases of hard-to-resolve software problems, you can return to one of these restore points to get your system running again.

Windows automatically creates an additional restore point each day, and also each time you install software or device drivers.

Tip: For more information about using Microsoft System Restore, click Start, then click Help and Support. Type windows system restore in the Search Help box, then press Enter.

To return to a restore point:

1 Click Start > Control Panel > System and Security > Action Center, then click Recovery.
2 Click Open System Restore, then Next.

3 Select the restore point you want, click Next, then Finish. A confirmation message box will appear.
4 Click Yes. Your system is restored using the restore point you specified. This process may take several minutes, and may restart your computer.

Returning your system to its factory condition

If your computer experiences problems that are not recoverable by other methods, you may need to reinstall everything to return your system to its factory condition. You can reinstall using either your hard drive or the recovery backup you have created.

Warning: This complete recovery deletes everything on your hard drive, then reinstalls Windows and all software and drivers that were pre-installed on your system. If you can access important files on your hard drive, back them up now.

If you can still run Windows, see "Recovering from within Windows" on page 23.

If you cannot run Windows and your original hard drive is still working, see "Recovering from the hard drive during startup" on page 24.

If you cannot run Windows and your original hard drive has been completely reformatted or you have installed a replacement hard drive, see "Recovering from your recovery backup" on page 24.

Recovering from within Windows

To reinstall Windows and all pre-installed software and drivers:

Click Start > All Programs > Acer, then click Acer eRecovery Management.

Click the Restore tab, then Restore Operating System to Factory Defaults to open the Confirm Restoration dialog box.

Click Yes, then Start. A dialog box will display information about the hard drive that the operating system will be recovered to.

Warning: Continuing the process will erase all files on your hard drive.

Click OK. The recovery process begins by restarting your computer, then continues by copying files to your hard drive. This process may take a while, the Acer eRecovery Management screen displays the progress.

When the recovery has finished, a dialog box prompts you to restart your computer.

Click OK to restart your computer.

Follow the onscreen prompts for first-time system setup.

Recovering from the hard drive during startup

To reinstall Windows and all pre-installed software and drivers:

1 Turn on your computer, then press + during startup to open Acer eRecovery Management.

2 Click Restore Operating System to Factory Defaults.

Warning: Continuing the process will erase all files on your hard drive.

3 Click Next. Your hard drive's original, factory-loaded contents will be recovered. This process will take several minutes.

Recovering from your recovery backup

To reinstall Windows and all pre-installed software and drivers:

1 Plug in the USB flash drive and turn on your computer.

Warning: Continuing the process will erase all files on your hard drive.

If it is not already enabled, you must enable the F12 Boot Menu:

Press when starting your computer.

Use the left or right arrow keys to select the Main menu.

Press the down key until F12 Boot Menu is selected, press to change this setting to Enabled.

Use the left or right arrow keys to select the Exit menu.

Select Save Changes and Exit and press Enter. Select OK to confirm.

Your computer will restart.

2 During startup, press to open the boot menu. The boot menu allows you to select which device to start from, such as a flash drive.

3 Use your arrow keys to select the line USB HDD, then press . Windows will install from the recovery backup on the USB flash drive.

4 Follow the onscreen prompts to complete the recovery.

Acer Backup Manager

Note: This feature is only available on certain models.

Acer Backup Manager is a simple three-step process that allows you to create backup copies of your entire system or selected files and folders according to a schedule or as you need to.

To start Acer Backup Manager, press the Acer Backup Manager key above the keyboard. Alternatively, you can go to Start > All Programs > Acer Backup Manager > Acer Backup Manager. This will open the Welcome screen; from this screen you will be taken through the three steps to setup scheduled back ups. Click Continue to proceed to the following screen. Click the + button and follow the onscreen instructions:

1 Select the content you want to back up. The less content you select, the quicker the process will be, but it will increase your risks of losing data.
2 Select where you want the backup copies to be stored. You will need to select an external drive or your D: drive; Acer Backup Manager cannot store a backup on the source drive.
3 Select how often you want Acer Backup Manager to create back ups.

Once you have finished these three steps, backups will be created according to the schedule. You can also create backups manually by pressing the Acer Backup Manager key.

If you wish to change your settings at any time, run Acer Backup Manager from the Start menu and go through the steps outlined above.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy!

Power management

This computer has a built-in power management unit that monitors system activity. System activity refers to any activity involving one or more of the following devices: keyboard, mouse, hard disk, peripherals connected to the computer, and video memory. If no activity is detected for a period of time (called an inactivity timeout), the computer stops some or all of these devices in order to conserve energy.

This computer employs a power management scheme that supports the advanced configuration and power interface (ACPI), which allows for maximum power conservation and maximum performance at the same time. Windows handles all power-saving chores for your computer.

Acer PowerSmart key

Note: This feature is only available on certain models.

Acer PowerSmart uses the power-saving features of your computer's graphics sub-system to reduce overall power consumption. When you press the Acer PowerSmart key, the screen brightness is reduced and the graphics chip switched to a lower speed; PCI and WLAN switch to power-saving modes. Press the Acer PowerSmart key again to return to your previous settings.

Battery pack

The computer uses a battery pack that gives you long use between charges.

Battery pack characteristics

The battery pack has the following characteristics:

- Employs current battery technology standards.

- Delivers a battery-low warning.

The battery is recharged whenever you connect the computer to the AC adapter. Your computer supports charge-in-use, enabling you to recharge the battery while you continue to operate the computer. However, recharging with the computer turned off results in a significantly faster charge time.

The battery will come in handy when you travel or during a power failure. It is advisable to have an extra fully charged battery pack available as backup. Contact your dealer for details on ordering a spare battery pack.

Maximizing the battery's life

Like all other batteries, your computer's battery will degrade over time. This means that the battery's performance will diminish with time and use. To maximize your battery's life, you are advised to adhere to the recommendations set out below.

Conditioning a new battery pack

Before you use a battery pack for the first time, there is a conditioning process that you should follow:

1 Insert the new battery without turning the computer on.

2 Connect the AC adapter and fully charge the battery.

3 Disconnect the AC adapter.

4 Turn on the computer and operate using battery power.

5 Fully deplete the battery until the battery-low warning appears.

6 Reconnect the AC adapter and fully charge the battery again.

Follow these steps again until the battery has been charged and discharged three times.

Use this conditioning process for all new batteries, or if a battery hasn't been used for a long time. If the computer is to be stored for more than two weeks, you are advised to remove the battery pack from the unit.

Warning: Do not expose battery packs to temperatures below 0^ C ( 32^ F) or above 45^ C ( 113^ F). Extreme temperatures may adversely affect the battery pack.

By following the battery conditioning process you condition your battery to accept the maximum possible charge. Failure to follow this procedure will prevent you from obtaining the maximum battery charge, and will also shorten the effective lifespan of the battery.

In addition, the useful lifespan of the battery is adversely affected by the following usage patterns:

• Using the computer on constant AC power with the battery inserted. If you want to use constant AC power, you are advised to remove the battery pack after it is fully charged.
• Not discharging and recharging the battery to its extremes, as described above.
• Frequent use; the more you use the battery, the faster it will reach the end of its effective life. A standard computer battery has a life span of about 300 charges.

Installing and removing the battery pack

Important! Before removing the battery from the unit, connect the AC adapter if you want to continue using your computer. Otherwise, turn off the computer first.

To install a battery pack:

1 Align the battery with the open battery bay; make sure that the end with the contacts will enter first, and that the top surface of the battery is facing up.
2 Slide the battery into the battery bay and gently push until the battery locks in place.

To remove a battery pack:

1 Slide the battery release latch to release the battery.
2 Pull the battery from the battery bay.

Charging the battery

To charge the battery, first make sure that it is correctly installed in the battery bay. Plug the AC adapter into the computer, and connect to a mains power outlet. You can continue to operate your computer on AC power while your battery is charging. However, charging the battery with the computer turned off results in a significantly faster charge time.

Note: You are advised to charge the battery before retiring for the day. Charging the battery overnight before traveling enables you to start the next day with a fully charged battery.

Checking the battery level

The Windows power meter indicates the current battery level. Rest the cursor over the battery/power icon on the taskbar to see the battery's present charge level.

Optimizing battery life

Optimizing battery life helps you get the most out of battery operation, prolonging the charge/recharge cycle and improving recharging efficiency. You are advised to follow the suggestions set out below:

•Purchase an extra battery pack.
• Use AC power whenever possible, reserving battery for on-the-go use.
- Eject a PC Card if it is not being used, as it will continue to draw power (for selected models).
- Store the battery pack in a cool, dry place. The recommended temperature is 10^ (50°F) to 30^ (86°F). Higher temperatures cause the battery to self-discharge faster.
- Excessive recharging decreases the battery life.
- Look after your AC adapter and battery.

Battery-low warning

When using battery power pay attention to the Windows power meter.

Warning: Connect the AC adapter as soon as possible after the battery-low warning appears. Data will be lost if the battery to become fully depleted and the computer shuts down.

When the battery-low warning appears, the recommended course of action depends on your situation:

Situation Recommended Action

The AC adapter and a power outlet are available.	1. Plug the AC adapter into the computer, and then connect to the mains power supply.2. Save all necessary files.3. Resume work.Turn off the computer if you want to recharge the battery rapidly.
An extra fully charged battery pack is available.	1. Save all necessary files.2. Close all applications.3. Turn off the computer.4. Replace the battery pack.5. Turn on the computer and resume work.
The AC adapter or a power outlet is unavailable. You have no spare battery pack.	1. Save all necessary files.2. Close all applications.3. Turn off the computer.

Taking your notebook PC with you

This section gives you tips and hints to consider when moving around or traveling with your computer.

Disconnecting from the desktop

Follow these steps to disconnect your computer from external accessories:

1 Save any open files.
2 Remove any media, floppy disks or compact disks from the drive(s).
3 Shut down the computer.
4 Close the display cover.
5 Disconnect the cord from the AC adapter.
6 Disconnect the keyboard, pointing device, printer, external monitor and other external devices.
7 Disconnect the Kensington lock if you are using one to secure the computer.

Moving around

When you are just moving within short distances, for example, from your office desk to a meeting room.

Preparing the computer

Before moving the computer, close and latch the display cover to place it in Sleep mode. You can now safely take the computer anywhere you go within the building. To bring the computer out of Sleep mode, open the display; then press and release the power button.

If you are taking the computer to a client's office or a different building, you may choose to shut down the computer:

Click Start then click Shut Down.

Or:

You can put the computer in Sleep mode by pressing + . Then close and latch the display.

When you are ready to use the computer again, unlatch and open the display; then press and release the power button.

Note: If the Sleep indicator is off, the computer has entered Hibernation mode and is turned off. If the power indicator is off

but the Sleep indicator is on, the computer has entered Sleep mode. In both cases, press and release the power button to turn the computer back on. Note that the computer may enter Hibernation mode after being in Sleep mode for a period of time.

What to bring to meetings

If your meeting is relatively short, you probably do not need to bring anything with you other than your computer. If your meeting will be longer, or if your battery is not fully charged, you may want to bring the AC adapter with you to plug in your computer in the meeting room.

If the meeting room does not have an electrical outlet, reduce the drain on the battery by putting the computer in Sleep mode. Press + or close the display cover whenever you are not actively using the computer. To resume, open the display (if closed), then press and release the power button.

Taking the computer home

When you are moving from your office to your home or vice versa.

Preparing the computer

After disconnecting the computer from your desktop, follow these steps to prepare the computer for the trip home:

• Check that you have removed all media and compact discs from the drive(s). Failure to remove the media can damage the drive head.
• Pack the computer in a protective case that can prevent the computer from sliding around and cushion it if it should fall.

Caution: Avoid packing items next to the top cover of the computer. Pressure against the top cover can damage the screen.

What to take with you

Unless you have some items at home, take the following items with you:

• AC adapter and power cord.
  •The printed setup poster.

Special considerations

Follow these guidelines to protect your computer while traveling to and from work:

- Minimize the effects of temperature changes by keeping the computer

with you.

• If you need to stop for an extended period of time and cannot carry the computer with you, leave the computer in the trunk of the car to avoid exposing the computer to excessive heat.
• Changes in temperature and humidity can cause condensation. Allow the computer to return to room temperature, and inspect the screen for condensation before turning on the computer. If the temperature change is greater than 10^ C ( 18^ F), allow the computer to come to room temperature slowly. If possible, leave the computer for 30 minutes in an environment with a temperature between outside and room temperature.

Setting up a home office

If you frequently work on your computer at home, you may want to purchase a second AC adapter for use at home. With a second AC adapter, you can avoid carrying the extra weight to and from home.

If you use your computer at home for significant periods of time, you might also want to add an external keyboard, monitor or mouse.

Traveling with the computer

When you are moving within a larger distance, for instance, from your office building to a client's office building or traveling locally.

Preparing the computer

Prepare the computer as if you were taking it home. Make sure that the battery in the computer is charged. Airport security may require you to turn on your computer when carrying it into the gate area.

What to take with you

Take the following items with you:

• AC adapter
• Spare, fully-charged battery pack(s)
  •Additional printer driver files if you plan to use another printer

Special considerations

In addition to the guidelines for taking the computer home, follow these guidelines to protect your computer while traveling:

•Always take the computer as carry-on luggage.
- If possible, have the computer inspected by hand. Airport security X-ray machines are safe, but do not put the computer through a metal detector.

- Avoid exposing floppy disks to hand-held metal detectors.

Traveling internationally with the computer

When you are moving from country to country.

Preparing the computer

Prepare the computer as you would normally prepare it for traveling.

What to bring with you

Bring the following items with you:

• AC adapter
  • Power cords that are appropriate for the country to which you are traveling
• Spare, fully-charged battery packs
  •Additional printer driver files if you plan to use another printer
  •Proof of purchase, in case you need to show it to customs officials
  •International Travelers Warranty passport

Special considerations

Follow the same special considerations as when traveling with the computer. In addition, these tips are useful when traveling internationally:

- When traveling in another country, check that the local AC voltage and the AC adapter power cord specifications are compatible. If not, purchase a power cord that is compatible with the local AC voltage. Do not use converter kits sold for appliances to power the computer.

- If you are using the modem, check if the modem and connector are compatible with the telecommunications system of the country you are traveling in.

Securing your computer

Your computer is a valuable investment that you need to take care of. Learn how to protect and take care of your computer.

Security features include hardware and software locks — a security notch and passwords.

Using a computer security lock

The notebook comes with a Kensington-compatible security slot for a security lock.

Wrap a computer security lock cable around an immovable object such as a table or handle of a locked drawer. Insert the lock into the notch and turn the key to secure the lock. Some keyless models are also available.

Using passwords

Passwords protect your computer from unauthorized access. Setting these passwords creates several different levels of protection for your computer and data:

• Supervisor Password prevents unauthorized entry into the BIOS utility. Once set, you must enter this password to gain access to the BIOS utility. See "BIOS utility" on page 43.
• User Password secures your computer against unauthorized use. Combine the use of this password with password checkpoints on boot-up and resume from Hibernation for maximum security.
• Password on Boot secures your computer against unauthorized use. Combine the use of this password with password checkpoints on boot-up and resume from Hibernation for maximum security.

Important! Do not forget your Supervisor Password! If you forget your password, please get in touch with your dealer or an authorized service center.

Entering passwords

When a password is set, a password prompt appears in the center of the display screen.

• When the Supervisor Password is set, a prompt appears when you press to enter the BIOS utility at boot-up.
• Type the Supervisor Password and press to access the BIOS utility. If you enter the password incorrectly, a warning message appears. Try again and press .
• When the User Password is set and the password on boot parameter is enabled, a prompt appears at boot-up.
• Type the User Password and press to use the computer. If you enter the password incorrectly, a warning message appears. Try again and press .

Important! You have three chances to enter a password. If you fail to enter the password correctly after three tries, the system halts. Press and hold the power button for four seconds to shut down the computer. Then turn on the computer again, and try again.

Setting passwords

You can set passwords using the BIOS utility.

Expanding through options

Your notebook PC offers you a complete mobile computing experience.

Connectivity options

Ports allow you to connect peripheral devices to your computer as you would with a desktop PC. For instructions on how to connect different external devices to the computer, read the following section.

Fax/data modem (only for certain models)

Your computer has a built-in V.92 56 Kbps fax/data modem (only for certain models).

Warning! This modem port is not compatible with digital phone lines. Plugging this modem into a digital phone line will damage the modem.

To use the fax/data modem port, connect a phone cable from the modem port to a telephone jack.

Diagram showing four types of electrical connectors: socket, switch, plug, and telephone

Warning! Please make sure that the cable you use is appropriate for the country in which you are working.

Built-in network feature

The built-in network feature allows you to connect your computer to an Ethernet-based network.

To use the network feature, connect an Ethernet cable from the Ethernet (RJ-45) port on the chassis of the computer to a network jack or hub on your network.

Diagram showing various types of connectors and cable connections with Chinese labels

Consumer Infrared (CIR) (only for certain models)

The computer's Consumer Infrared (CIR) port is used to receive signals from your remote control, or other devices with CIR capability.

Universal Serial Bus (USB)

The USB 2.0 port is a high-speed serial bus which allows you to connect USB peripherals without taking up precious system resources.

Diagram showing three connected devices: a digital camera, a USB flash device with USB plug, and a digital camera.

IEEE 1394 port (only for certain models)

The computer's IEEE 1394 port allows you to connect to an IEEE 1394-compatible device like a video camera or digital camera. See your video or digital camera's documentation for details.

Diagram showing a digital camera and its internal structure with labeled ports and directional arrows

High-Definition Multimedia Interface (only for certain models)

HDMI (High-Definition Multimedia Interface) is an industry-supported, uncompressed, all-digital audio/video interface. HDMI provides an interface between any compatible digital audio/video source, such as a set-top box, DVD player, and A/V receiver and a compatible digital audio and/or video monitor, such as a digital television (DTV), over a single cable.

Use the HDMI port on your computer to connect with high-end audio and video equipment. Single cable implementation allows tidy setup and fast connection.

ExpressCard (only for certain models)

The ExpressCard is the newest version of the PC Card. It is a smaller and faster interface that further enhances the usability and expandability of your computer.

ExpressCards support a vast number of expansion options, including flash memory card adapters, TV-tuners, Bluetooth connectivity and IEEE 1394b adapters. ExpressCards support USB 2.0 and PCI Express applications.

Important! There are two types, ExpressCard/54 and ExpressCard/34 (54mm and 34mm), each with different functions. Not all ExpressCard slots will support both types. Please refer to your card's manual for details on how to install and use the card, and its functions.

Inserting an ExpressCard

Insert the card into the slot and push gently until it clicks into position.

EXPRESS CARD

Ejecting an ExpressCard

Before ejecting an ExpressCard:

1 Exit the application using the card.
2 Left-click the remove hardware icon on the taskbar and stop the card operation.
3 Push the card gently into the slot and release to pop out the card. Then pull the card free from the slot.

Installing memory (only for certain models)

Follow these steps to install memory:

1 Turn off the computer, unplug the AC adapter (if connected) and remove the battery pack. Then turn the computer over to access its base.
2 Remove the screws from the memory cover; then lift and remove the memory cover.

3 (a) Insert the memory module diagonally into the slot, then (b) gently press it down until it clicks into place.

Diagram showing a device with labeled components (a, b) and an upward arrow indicating motion or operation.

4 Replace the memory cover and secure it with the screw.

5 Reinstall the battery pack, and reconnect the AC adapter.

6 Turn on the computer.

The computer automatically detects and reconfigures the total memory size. Please consult a qualified technician or contact your local Acer dealer.

BIOS utility

The BIOS utility is a hardware configuration program built into your computer's BIOS.

Your computer is already properly configured and optimized, and you do not need to run this utility. However, if you encounter configuration problems, you may need to run it.

To activate the BIOS utility, press during the POST while the notebook PC logo is being displayed.

Boot sequence

To set the boot sequence in the BIOS utility, activate the BIOS utility, then select Boot from the categories listed at the top of the screen.

Enable disk-to-disk recovery

To enable disk-to-disk recovery (hard disk recovery), activate the BIOS utility, then select Main from the categories listed at the top of the screen. Find D2D Recovery at the bottom of the screen and use the and keys to set this value to Enabled.

Password

To set a password on boot, activate the BIOS utility, then select Security from the categories listed at the top of the screen. Find Password on boot: and use the and keys to enable this feature.

Using software

Playing DVD content

Note: This feature is only available on certain models.

When the DVD drive module is installed in the optical drive bay, you can play DVD content on your computer.

1 Eject the DVD.

Important! When you launch the DVD player for the first time, the program asks you to enter the region code. DVD disks are divided into 6 regions. Once your DVD drive is set to a region code, it will play DVD disks of that region only. You can set the region code a maximum of five times (including the first time), after which the last region code set will remain permanent. Recovering your hard disk does not reset the number of times the region code has been set. Refer to the table below for DVD movie region code information.

2 The DVD movie will automatically play after a few seconds.

Region code Country or region

1 USA, Canada

2 Europe, Middle East, South Africa, Japan

3 Southeast Asia, Taiwan, South Korea

4 Latin America, Australia, New Zealand

5 Former USSR, parts of Africa, India

6 People's Republic of China

Note: To change the region code, insert a DVD movie of a different region into the DVD drive. Please refer to the online help for more information.

Frequently asked questions

The following is a list of possible situations that may arise during the use of your computer. Easy solutions are provided for each one.

I turned on the power, but the computer does not start or boot up.

Look at the power indicator:

- If it is not lit, no power is being supplied to the computer. Check the following:

• If you are using on the battery, it may be low and unable to power the computer. Connect the AC adapter to recharge the battery pack.
• Make sure that the AC adapter is properly plugged into the computer and to the power outlet.

- If it is lit, check the following:

- Is a non-bootable (non-system) disk in the external USB floppy drive? Remove or replace it with a system disk and press + + to restart the system.

Nothing appears on the screen.

The computer's power management system automatically blanks the screen to save power. Press any key to turn the display back on.

If pressing a key does not turn the display back on, three things might be the cause:

• The brightness level might be too low. Press + <▷> (increase) to adjust the brightness level.
• The display device might be set to an external monitor. Press the display toggle hotkey + to toggle the display back to the computer.
• If the Sleep indicator is lit, the computer is in Sleep mode. Press and release the power button to resume.

No audio is heard from the computer.

Check the following:

• The volume may be muted. In Windows, look at the volume control (speaker) icon on the taskbar. If it is crossed-out, click the icon and deselect the Mute all option.
• The volume level may be too low. In Windows, look at the volume control icon on the taskbar. You can also use the volume control buttons to adjust the volume.
• If headphones, earphones or external speakers are connected to the line-

out port on the computer, the internal speakers automatically turn off.

I want to eject the optical drive tray without turning on the power.

There is a mechanical eject hole on the optical drive. Simply insert the tip of a pen or paperclip into the hole and push to eject the tray.

The keyboard does not respond.

Try attaching an external keyboard to a USB port on the computer. If it works, contact your dealer or an authorized service center as the internal keyboard cable may be loose.

The printer does not work.

Check the following:

- Make sure that the printer is connected to a power outlet and that it is turned on.

- Make sure that the printer cable is connected securely to a USB port and the corresponding port on the printer.

I want to restore my computer to its original settings without recovery CDs.

Note: If your system is the multilingual version, the operating system and language you choose when you first turn on the system will be the only option for future recovery operations.

This recovery process helps you restore the C: drive with the original software content that is installed when you purchased your notebook. Follow the steps below to rebuild your C: drive. (Your C: drive will be reformatted and all data will be erased.) It is important to back up all data files before using this option.

Before performing a restore operation, please check the BIOS settings.

1 Check to see if Acer disk-to-disk recovery is enabled or not.
2 Make sure the D2D Recovery setting in Main is Enabled.
3 Exit the BIOS utility and save changes. The system will reboot.

Note: To activate the BIOS utility, press during POST.

To start the recovery process:

1 Restart the system.
2 While the Acer logo is showing, press + at the same time to enter the recovery process.
3 Refer to the onscreen instructions to perform system recovery.

Important! This feature occupies 15 GB in a hidden partition on your hard disk.

Requesting service

International Travelers Warranty (ITW)

Your computer is backed by an International Travelers Warranty (ITW) that gives you security and peace of mind when traveling. Our worldwide network of service centers are there to give you a helping hand.

An ITW passport comes with your computer. This passport contains all you need to know about the ITW program. A list of available, authorized service centers is in this handy booklet. Read this passport thoroughly.

Always have your ITW passport on hand, especially when you travel, to receive the benefits from our support centers. Place your proof-of-purchase in the flap located inside the front cover of the ITW passport.

If the country you are traveling in does not have an Acer-authorized ITW service site, you can still get in contact with our offices worldwide. Please visit www.acer.com.

Before you call

Please have the following information available when you call Acer for online service, and please be at your computer when you call. With your support, we can reduce the amount of time a call takes and help solve your problems efficiently. If there are error messages or beeps reported by your computer, write them down as they appear on the screen (or the number and sequence in the case of beeps).

You are required to provide the following information:

Name:

Address:

Telephone number:

Machine and model type:

Serial number:

Date of purchase:

Troubleshooting

This chapter shows you how to deal with common system problems.

Read it before calling a technician if a problem occurs. Solutions to more serious problems require opening up the computer. Do not attempt to open the computer yourself; contact your dealer or authorized service center for assistance.

Troubleshooting tips

This notebook PC incorporates an advanced design that delivers onscreen error message reports to help you solve problems.

If the system reports an error message or an error symptom occurs, see "Error messages" below. If the problem cannot be resolved, contact your dealer. See "Requesting service" on page 48.

Error messages

If you receive an error message, note the message and take the corrective action. The following table lists the error messages in alphabetical order together with the recommended course of action.

Error messages Corrective action

CMOS battery bad Contact your dealer or an authorized service center.
CMOS checksum error Contact your dealer or an authorized service center.
Disk boot failure	Insert a system (bootable) disk, then pressto reboot.
Equipment configuration error	Press(during POST) to enter the BIOS utility, then press Exit in the BIOS utility to reboot.
Hard disk 0 error Contact your dealer or an authorized service center.
Hard disk 0 extended type error	Contact your dealer or an authorized service center.
I/O parity error Contact your dealer or an authorized service center.
Keyboard error or no keyboard connected	Contact your dealer or an authorized service center.

Error messages Corrective action

Keyboard interface error	Contact your dealer or an authorized service center.
Memory size mismatch	Press <F2> (during POST) to enter the BIOS utility, then press Exit in the BIOS utility to reboot.

If you still encounter problems after going through the corrective measures, please contact your dealer or an authorized service center for assistance.

Regulations and safety notices

FCC statement

This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.
- Increase the separation between the device and receiver.
- Connect the device into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/television technician for help.

Notice: Shielded cables

All connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations.

Notice: Peripheral devices

Only peripherals (input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to this equipment. Operation with non-certified peripherals is likely to result in interference to radio and TV reception.

Caution

Changes or modifications not expressly approved by the manufacturer could void the user's authority, which is granted by the Federal Communications Commission, to operate this computer.

Notice: Canadian users

This Class B digital apparatus complies with Canadian ICES-003.

Compliant with Russian regulatory certification

ME61

Modem notices (only for certain models)

Notice for USA

This equipment complies with Part 68 of the FCC rules. Located on the modem is a label that contains, among other information, the FCC Registration Number and Ringer Equivalence Number (REN) for this equipment. Upon request, you must provide this information to your telephone company.

If your telephone equipment causes harm to the telephone network, the telephone company may discontinue your service temporarily. If possible, they will notify you in advance. But, if advance notice is not practical, you will be notified as soon as possible. You will also be informed of your right to file a complaint with the FCC.

Your telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the proper functioning of your equipment. If they do, you will be notified in advance to give you an opportunity to maintain uninterrupted telephone service.

If this equipment should fail to operate properly, disconnect the equipment from the phone line to determine if it is causing the problem. If the problem is with the equipment, discontinue use and contact your dealer or vendor.

Caution: To reduce the risk of fire, use only No. 26 AWG or larger UL Listed or CSA Certified Telecommunication Line Cord.

TBR 21

This equipment has been approved [Council Decision 98/482/EC - "TBR 21"] for single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN termination point. In the event of problems, you should contact your equipment supplier in the first instance. For more information about applicable countries, please refer to "Regulations and safety notices" on page 51.

Notice for Australia

For safety reasons, only connect headsets with a telecommunications compliance label. This includes customer equipment previously labeled permitted or certified.

Notice for New Zealand

1 The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted that the item complies with minimum conditions for

connection to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty. Above all, it provides no assurance that any item will work correctly in all respects with another item of Telepermitted equipment of a different make or model, nor does it imply that any product is compatible with all of Telecom's network services.

2 This equipment is not capable, under all operating conditions, of correct operation at the higher speeds for which it is designed. Telecom will accept no responsibility should difficulties arise in such circumstances.
3 Some parameters required for compliance with Telecom's Telepermit requirements are dependent on the equipment (PC) associated with this device. The associated equipment shall be set to operate within the following limits for compliance with Telecom's Specifications:

a There shall be no more than 10 call attempts to the same number within any 30-minute period for any single manual call initiation, and

b The equipment shall go on-hook for a period of not less than 30 seconds between the end of one attempt and the beginning of the next call attempt.

4 Some parameters required for compliance with Telecom's Telepermit requirements are dependent on the equipment (PC) associated with this device. In order to operate within the limits for compliance with Telecom's specifications, the associated equipment shall be set to ensure that automatic calls to different numbers are spaced such that there is not less than 5 seconds between the end of one call attempt and the beginning of another.
5 This equipment shall not be set up to make automatic calls to Telecom's 111 Emergency Service.
6 This device is equipped with pulse dialing while the Telecom standard is DTMF tone dialing. There is no guarantee that Telecom lines will always continue to support pulse dialing.
7 Use of pulse dialing, when this equipment is connected to the same line as other equipment, may give rise to bell tinkle or noise and may also cause a false answer condition. Should such problems occur, the user should NOT contact the telecom Fault Service.
8 This equipment may not provide for the effective hand-over of a call to another device connected to the same line.
9 Under power failure conditions this appliance may not operate. Please ensure that a separate telephone, not dependent on local power, is available for emergency use.

LCD pixel statement

The LCD unit is produced with high-precision manufacturing techniques. Nevertheless, some pixels may occasionally misfire or appear as black or red dots. This has no effect on the recorded image and does not constitute a malfunction.

Radio device regulatory notice

Note: Below regulatory information is for models with wireless LAN and / or Bluetooth only.

General

To prevent radio interference to the licensed service, this device is intended to be operated indoors.

This product complies with the radio frequency and safety standards of any country or region in which it has been approved for wireless use. Depending on configurations, this product may or may not contain wireless radio devices (such as wireless LAN and/or Bluetooth modules). Below information is for products with such devices.

Declaration of Conformity for EU countries

Hereby, Acer, declares that this notebook PC series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

List of applicable countries

EU member states as of July 2009 are: Belgium, Denmark, Germany, Greece, Spain, France, Ireland, Italy, Luxembourg, the Netherlands, Austria, Portugal, Finland, Sweden, United Kingdom, Estonia, Latvia, Lithuania, Poland, Hungary, Czech Republic, Slovak Republic, Slovenia, Cyprus, Malta, Bulgaria and Romania. Usage is allowed in the countries of European Union, as well as Norway, Switzerland, Iceland and Liechtenstein. This device must be used in strict accordance with the regulations and constraints in the country of use. For further information, please contact local office in the country of use. Please see ec.europa.eu/enterprise/rtte/implem.htm for the latest country list.

The FCC RF safety requirement

The radiated output power of the wireless LAN Mini PCI Card and Bluetooth card is far below the FCC radio frequency exposure limits. Nevertheless, the notebook PC series shall be used in such a manner that the potential for human contact during normal operation is minimized as follows:

1 Users are requested to follow the RF safety instructions on wireless option devices that are included in the user's manual of each RF option device.

Caution: To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm (8 inches) must be maintained between the antenna for the integrated wireless LAN Mini PCI Card built in to the screen section and all persons.

Auxiliary Main 20cm 20cm

Note: The wireless Mini PCI adapter implements a transmission diversity function. The function does not emit radio frequencies simultaneously from both antennas. One of the antennas is selected automatically or manually (by users) to ensure good quality radiocommunication.

2 This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.
3 High power radar is allocated as the primary user of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device.
4 An improper installation or unauthorized use may cause harmful interference to radio communications. Also any tampering of the internal antenna will void the FCC certification and your warranty.

Canada — Low-power license-exempt radio communication devices (RSS-210)

Exposure of humans to RF fields (RSS-102)

The notebook PC series employs low gain integral antennas that do not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada's website at www.hc-sc.gc.ca/rpb.

This device complies with RSS210 of Industry Canada.

This Class B digital apparatus complies with Canadian ICES-003, Issue 4, and RSS-210, No 4 (Dec 2000) and No 5 (Nov 2001).

"To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing."

Caution: When using IEEE 802.11a wireless LAN, this product is restricted to indoor use due to its operation in the 5.15- to 5.25-GHz frequency range. Industry Canada requires this product to be used indoors for the frequency range of 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel mobile satellite systems. High power radar is allocated as the primary user of the 5.25- to 5.35-GHz and 5.65 to 5.85-GHz bands. These radar stations can cause interference with and/or damage to this device.

The maximum allowed antenna gain for use with this device is 6dBi in order to comply with the E.I.R.P limit for the 5.25- to 5.35 and 5.725 to 5.85 GHz frequency range in point-to-point operation.

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance	•Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

Gamme TravelMate

Acer eRecovery Management 10

Acer Backup Manager 24

(International Travelers Warranty; ITW) 47

Avant d'appeler 47

Dépannage 48

CD panel ergonomic specifications 54

Touchpad

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

Acer ProShield PROShield Password Windows Password Change your ProShield Password, Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Apply BOS Settings Credential Manager Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help

Acer ProShield File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Nanopy File File Name In Folder Size Encrypt Cancel NOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information Help

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In folder Size Help Saved Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Optiac BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings ? Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55006 Estimated size: 5.54 GB 3 Hends 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c1, drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c1;backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reninstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! Continue

Diagram showing four types of electrical connectors: socket, switch, diode, and telephone

Diagram showing various types of connectors and components with Chinese labels

Diagram showing three types of electronic devices: a digital camera, a USB device with USB plug, and a digital camera.

Diagram showing a camera and its internal structure with labeled ports and an upward arrow indicating flow or movement.

Diagram showing a device with labeled parts (a, b) and an upward arrow indicating motion or change, possibly illustrating a physical or engineering concept.

This Class B digital apparatus complies with Canadian ICES-003.

Auxiliary Main 20cm 20cm

This device complies with RSS210 of Industry Canada.

This Class B digital apparatus complies with Canadian ICES-003, Issue 4, and RSS-210, No 4 (Dec 2000) and No 5 (Nov 2001).

"To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing."

Caution: When using IEEE 802.11a wireless LAN, this product is restricted to indoor use due to its operation in the 5.15- to 5.25-GHz frequency range. Industry Canada requires this product to be used indoors for the frequency range of 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel mobile satellite systems. High power radar is allocated as the primary user of the 5.25- to 5.35-GHz and 5.65 to 5.85-GHz bands. These radar stations can cause interference with and/or damage to this device.

CD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

TravelMate Serie

CLASS 1 LASER PRODUCT

ACHTUNG: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Acer eRecovery Management 10

Acer Backup Manager 25

HDMI (High-Definition Multimedia Interface)

(International Travelers Warranty; ITW) 49

Vor einem Anruf 49

Problemlösung 50

Tipps zur Problembehebung 50

Fehlermeldungen 50

LCD panel ergonomic specifications 55

Touchpad

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

ProShield Acer ProShield BRO's Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

ProShield BOS Settings Credential Manager Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password: Password Hint OK Cancel Apply

ProShield Acer ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Narrow File File Name In folder Size Encrypt Cancel...

Datenlöschung

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name: In folder Size Help Stored Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB 3 needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings ? Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Optiac BD RON BC-55001 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\ drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DG NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Renstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! Continue

Energieverwaltung

Pure electrical circuit lines without any symbols

Diagram showing various types of connectors and components with Chinese labels

Diagram showing the installation of a digital camera module via USB, with labeled components and directional arrows.

Diagram showing a device with labeled components (a, b) and an upward arrow indicating motion or operation.

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance • Illuminance level:[250 + (250cosα)] lx where α = 85°• Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	• Ordinary LCD: Class I• Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	• Yn• u'n• v'n
Pixel fault class Class II

Serie TravelMate

Acer eRecovery Management 10

Acer Backup Manager 24

High-Definition Multimedia Interface

ITW (International Traveler's Warranty) 47

LCD panel ergonomic specifications 53

Touchpad

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Personal Secure Disk

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

ProShield BOS Settings Credential Manager Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password: Password Hint OK Cancel Apply

ProShield Acer ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In folder Size Help Encrypt Cancel

Rimozione dati

ProShield Acer ProShield BDO's Settings Credential Manager Data Protection Data Removal * File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In folder Size Help Direct Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings ? Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55006 Estimated size: 5.54 GB 3 Hends 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reninstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Diagram showing five types of electrical connectors and connection points: socket, switch, plug, cable, and phone.

Diagram showing various types of connectors and components with Chinese labels

Diagram showing the installation of a device via USB, connected to a camera and a digital camera.

Diagram showing a device with labeled parts (a, b) and an upward arrow indicating motion or change, possibly illustrating a mechanical or electronic process.

ITW (International Traveler's Warranty)

Auxiliary Main 20cm 20cm

The use of these equipments is regulated by:

1. D.L.gs 1.8.2003, n. 259, article 104 (activity subject to general authorization) for outdoor use and article 105 (free use) for indoor use, in both cases for private use.
2. D.M. 28.5.03, for supply to public of RLAN access to networks and telecom services.

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:	•Yn
Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•u'n•v'n
Pixel fault class Class II

Serie TravelMate

CLASS 1 LASER PRODUCT

PRECAUCIÓN: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D'OUVERTURE.EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Acer eRecovery Management 10

Acer Backup Manager 25

(International Travelers Warranty; ITW) 48

Antes de llamar 48

LCD panel ergonomic specifications 54

Panel táctil

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Disco protegido personal

Acer ProShield BO's Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

ProShield BOS Settings Credential Manager Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password: Password Hint OK Cancel Apply

ProShield Acer ProShield BOS Settings Credential Manager Data Protection + File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In Folder Size Help Encrypt Cancel

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal > File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In folder Size Help Saved Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Ace-eRecovery Management Backup Restore Settings ? Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Optiac: BO RON BC-5500S Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Option: BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\ drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acir Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reinstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Diagram showing four types of electrical connectors: socket, switch, plug, and telephone handset.

Diagram showing various types of connectors and components with Chinese labels

Diagram showing the installation of a device via USB, with labeled components including a camera, USB port, and a digital camera.

Diagram showing a device with labeled components (a, b) and an upward arrow indicating motion or operation on the screen.

Auxiliary Main 20cm 20cm

The operation of this product in the radio channel 2 (2417 MHz) is not authorized in the following cities: Agadir, Assa-Zag, Cabo Negro, Chaouen, Goulmima, Oujda, Tan Tan, Taourirt, Taroudant and Taza.

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

Série TravelMate

CLASS 1 LASER PRODUCT

CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D'OUVERTURE.EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Acer eRecovery Management 10

Acer Backup Manager 24

High-Definition Multimedia Interface

(International Travelers Warranty; ITW) 48

Antes de telefonar 48

LCD panel ergonomic specifications 54

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information BIOIS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply Help

Acer ProShield PROShield Password Windows Password Change your ProShield Password, Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Apply NIUS Settings Credential Manager * Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help

ProShield Acer ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Narrow File File Name In folder Size Encrypt Cancel...

Remoção de dados

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal • File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name: In folder Size Help Stored Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup for: (G) Options: 50 ROM/ BC-$5000 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

AcereRecovery Management Backup Restore Settings ? Help Create Factory Default Backup backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup for: (Q) Options: BD ROM BC-55006 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Factors Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 000150 Verifying: 6% 0% Elapsed time: 000000 acer

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c1. drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c1'.backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reninstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Gestão de energia

Diagram showing five types of electrical connectors: fuse, socket, up/down arrow, down/with cable, and telephone.

Diagram showing various types of connectors and components with Chinese labels

Consumer Infrared (CIR) (apenas para determinados modelos)

Diagram showing the installation of a USB device into a digital camera, with labeled components and an upward arrow indicating process.

Technical diagram showing a device with a labeled component and its assembly, including an arrow indicating upward movement.

High-Definition Multimedia Interface (apenas para determinados modelos)

Diagram showing a device with labeled parts (a, b) and an inset magnified view of a device's internal structure.

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

TravelMate Serie

LASERPRODUCT KLASSE 1

VOORZICHTIG: ONZICHTBARE LASERSTRALING INDIEN GEOPEND. VOORKOM BLOOTSTELLING AAN STRAAL.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Acer eRecovery Management 11

Acer Backup Manager 25

Energiebeheer 26

Acer PowerSmart-toets 26

Batterij 27

High-Definition Multimedia Interface

ITW (International Travelers Warranty) 48

Voordat u belt 48

Problemen oplossen 49

LCD panel ergonomic specifications 53

Touchpad

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Acer ProShield BIDS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data. Help

Acer ProShield BIOS Settings = BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information BIOIS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply Help

ProShield BOS Settings Credential Manager * Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password, password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Help

ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In folder Size Help Exempt Cancel

ProShield BIO's Settings Credential Manager Data Protection Data Removal File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Rename File file Name In folder Size Help Stored Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

AcereRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: 3D ROM BC-55001 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Remove Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 000150 Verifying: 6% 0% Elapsed time: 000000 acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55001 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings ? Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\ drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reninstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! Continue

Energiebeheer

Diagram showing five types of electrical connectors: fuse, socket, up/down arrow, switch, and telephone.

Diagram showing various types of Ethernet connectors with labels and arrows indicating connection directions.

Diagram showing three types of electronic devices: a digital camera, a USB flash unit, and a digital camera with an LED.

Diagram showing a digital camera and its internal component with an arrow indicating upward movement, alongside a separate schematic symbol.

Diagram showing a device with labeled parts (a, b) and an upward arrow indicating motion or change, likely illustrating a mechanical or electronic process.

ITW (International Travelers Warranty)

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

TravelMate-serien

KLASSE 1 LASERPRODUKT

FORSIKTIG: USYNLIG LASERSTRÅLING I ÅPEN TILSTAND. UNNGÅ STRÅLEN.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS

D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Credential Manager 7

Databeskyttelse 8

Datafjerning 8

Acer eRecovery Management 10

Acer Backup Manager 24

Strømstyring 25

Acer PowerSmart-tast 25

Batteri 26

CIR-port (Consumer Infrared) (bare for visse modeller) 37

Universal Serial Bus (USB) 38

IEEE 1394-port (bare for visse modeller) 38

International Travelers Warranty (ITW) 46

Før du ringer 46

LCD panel ergonomic specifications 51

Berøringsplate (Touchpad)

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

PSD (Personal Secure Disk)

PSD (Personal Secure Disk) er et sikkert område på harddisken der du kan lagre filer. Du har bare tilgang til PSD via passord eller autentisering med fingeravtrykk.

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical date. Help

Bruk menyen i venstre rute for å foreta endringene.

BIOS-innstillinger

ProShield Acer ProShield BIOS Settings + BIOS Security Best Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information ? Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

ProShield BOS Settings Credential Manager * Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password, password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Apply

ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive DataRemoval Information Help File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In Folder Size Energy Cancel

Datafjerning

Her kan du velge filer som skal fjernes helt fra harddisken.

ProShield BOS Settings Credential Manager Data Protection Data Removal File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In folder Size Help Send Cancel

Acer eRecovery Management

Hvis det oppstår problemer på datamaskinen som ikke kan løses på andre måter, kan det hende at du må installere Windows-operativsystemet og fabrikkinstallert programvare og drivere på nytt. Hvis du vil sikre at du kan gjenopprette datamaskinen når du har behov for det, bør du lage en sikkerhetskopi så snart som mulig.

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

AcereRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55006 Estimated size: 5.54 GB 3 needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: .00:00:00 acer

Acer eRecovery Management Backup Restore Settings ? Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings ? Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c1. drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c1'.backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acet Recovery Tool Acet Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reinstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Strømstyring

Pure electrical circuit lines without any symbols

Diagram showing various types of electrical connectors with Chinese labels, including a top connector, up/down arrow, and base components.

CIR-port (Consumer Infrared) (bare for visse modeller)

Diagram showing the installation of a USB flash drive, its internal structure, and connection to a digital camera.

IEEE 1394-port (bare for visse modeller)

Datamaskinens IEEE 1394-port lar deg koble til en IEEE 1394-enhet, f.eks. et video- eller digitalkamera. Se dokumentasjonen til video- eller digitalkameraet hvis du vil ha detaljer.

Diagram showing a digital camera and its internal components with an arrow indicating upward movement, alongside a 1394 indicator box.

ExpressCard (bare for visse modeller)

Diagram illustrating a device's internal structure with labeled parts (a, b) and an upward arrow indicating motion or assembly.

International Travelers Warranty (ITW)

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

TravelMate Seriens

CLASS 1 LASER PRODUCT

CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS

D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

www.acer-group.com/public/Sustainability/sustainability01.htm.

Acer eRecovery Management 10

Acer Backup Manager 24

Strømstyring 25

Acer PowerSmart-tast 25

Batteripakke 26

Batteripakke - karakteristika 26

High-Definition Multimedia Interface

International Travelers Warranty (ITW) 47

Inden du ringer 47

LCD panel ergonomic specifications 53

Pegefelt

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings + BIOS Security Best Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information ? Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

ProShield BOS Settings Credential Manager * Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Apply

ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In folder Size Help Energy Cancel

Datafjernelse

ProShield BDO5 Settings Credential Manager Data Protection Data Removal * File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In Folder Size Help Used Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

AcereRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel acer

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:0150 Verifying: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings ? Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55006 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings ? Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c1. drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c1'.backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reinstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Strømstyring

Pure electrical circuit lines without any symbols

Diagram showing various types of electrical connectors with Chinese labels, including a top connector, up/down arrow, and base components.

Diagram showing the installation of a USB flash drive, its internal structure, and connection to a digital camera.

Technical diagram showing a device with a labeled component and its upward arrow, alongside a schematic symbol.

High-Definition Multimedia Interface (kun for udvalgte modeller)

Diagram illustrating a device's internal structure with labeled parts (a, b) and an upward arrow indicating motion or assembly.

International Travelers Warranty (ITW)

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

TravelMate-serien

KLASS 1 LASERPRODUKT

VARNING: OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPEN. UNDVIK ATT UTSÄTTA DIG FÖR STRÅLEN.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Credential Manager 7

Dataskydd 8

Acer eRecovery Management 10

Acer Backup Manager 23

(International Travelers Warranty; ITW) 45

Innan du ringer 45

Felsöka datorn 46

Felsökningstips 46

Felmeddelanden 46

LCD panel ergonomic specifications 50

Pekplatta

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Personal Secure Disk

Acer ProShield BQOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information BIOIS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply Help

ProShield Acer ProShield NIUS Settings Credential Manager * Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password, Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Apply

ProShield Acer ProShield BOS Settings Credential Manager Data Protection * File Encryption File Encryption Personal Secure Drive Data Removal Information File Encryption Add Files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In folder Size Help Encrypt Cancel

Borttagning av data

ProShield BDO's Settings Credential Manager Data Protection Data Removal • File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In folder Size Help Send Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Optics BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed timer: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options BD ROM BC-55006 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verilog: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings ? Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reinstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Strömsparfunktioner

Diagram showing five types of electrical connectors or switches with corresponding icons and labels

Diagram showing various types of electrical connectors with Chinese labels, including a connector, up/down arrow, and base connections.

Consumer infrared (CIR) (endast för vissa modeller)

Diagram showing the installation of a USB device via USB cable, with labeled components including a camera and a digital camera.

IEEE 1394-port (endast för vissa modeller)

Diagram showing a device with labeled components (a, b) and an upward arrow indicating motion or operation.

Aktivera disk-to-disk recovery

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

TravelMate -sarja

Peruskäyttäjän opas

Acer eRecovery Management 10

Acer Backup Manager 24

Virranhallinta 25

High-Definition Multimedia Interface

"International Travelers Warranty" (ITW) 46

LCD panel ergonomic specifications 51

Kosketusalusta

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

ProShield BOS Settings Credential Manager Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password: Password Hint OK Cancel Apply

Acer ProShield File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In folder Size Energy Cancel NOS Settings Credential Manager Data Protection + File Encryption File Decryption Personal Secure Drive Data Removal Information Help

Tiedon poisto

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In folder Size Help Stored Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.34 GB 8 needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: level 6% Elapsed time: 00:01:50 Verifying: level 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings ? Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Repository Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:0150 Verifying: 0% 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reninstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Virranhallinta

Pure electrical circuit lines without any symbols

Diagram showing various types of connectors and components with Chinese labels

Diagram showing the installation of a digital camera module, including an external device, USB plug, and cable.

Diagram showing a digital camera and its internal component with pin labels and an upward arrow indicating direction.

High-Definition Multimedia Interface (vain tietyille malleille)

Diagram illustrating a device with labeled components (a, b) and an upward arrow, likely indicating a process or operation.

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

Серия TravelMate

CLASS 1 LASER PRODUCT

CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS

D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Acer eRecovery Management 10

Acer Backup Manager 25

High-Definition Multimedia Interface

LCD panel ergonomic specifications 54

Сенсорная панель

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Acer ProShield BOOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data.

ProShield Acer ProShield BIOS Settings + BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. Set Clear OK Cancel Apply

Acer ProShield PROShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Apply BOS Settings Credential Manager * Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help

ProShield Acer ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Narrow File File Name In folder Size Encrypt Cancel...

Удаление данных

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal • File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name: In folder Size Help Stored Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Optiac BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: .00:00:00 acer

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB It needs 2 blank Dv/D(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Backsort Settings Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:0150 Veriyeq: 0% Elapsed time: 00:00:00 acer

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c1. drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c1).backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acvr Recovery Tool Acvr Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reinstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Управление питанием

Pure electrical circuit lines without any symbols

Diagram showing various types of connectors and socket components with Chinese labels

Diagram showing three connected devices: a digital camera, a USB flash device with USB symbol, and a digital camera.

Diagram showing a digital camera and its internal structure with labeled ports and an upward arrow indicating flow or connection.

Pure geometric diagram of a rectangular frame with corner brackets and a central rectangle (no text or symbols)

Извлечение карты ExpressCard

Diagram illustrating a device with labeled components (a, b) and an upward arrow, likely indicating a process or operation.

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

Komputer serii TravelMate

Acer eRecovery Management 10

Acer Backup Manager 25

High-Definition Multimedia Interface

(International Travelers Warranty; ITW) 49

LCD panel ergonomic specifications 55

Touchpad

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

ProShield Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Dysk Personal Secure Disk

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings + BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. Set Clear OK Cancel Apply

Acer ProShield PROShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password Password Hint OK Cancel Apply BOS Settings Credential Manager * Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help

ProShield Acer ProShield BOS Settings Credential Manager Data Protection * File Encryption File Decryption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Narrow File File Name In folder Size Encrypt Cancel...

Usuwanie danych

ProShield Acer ProShield BOS Settings Credential Manager Data Protection Data Removal File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name: In folder Size Help Stored Cancel

Acer eRecovery Management

Acerr eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB 3 needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Help Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options BD ROM BC-55006 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verilog: 0% Elapsed time: 00:00:00 acer

AcereRecovery Management Backup Restore Settings ? Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.

Welcome to Acer Recovery Tool Acer Recovery Tool allows you to restore your system to the following status. Please DO NOT remove the USB device while proceeding. What would you like to do? Restore Operating System to Factory Defaults from a USB device Restore your PC to factory default status. All data on C: drive will be deleted. Reinstall Drivers or Application from a USB device Reinstall factory default drivers or applications.

Acer Backup Manager Welcome Acer Backup Manager makes it easy for you to protect your data. Not only can it make a complete system backup of your computer, but also back up or sync important documents at the touch of a button. It's that easy! acer Continue

Zarządzanie energią

Diagram showing four types of electrical connectors: socket, switch, plug-in, and telephone handset.

Diagram showing various types of connectors and components with Chinese labels

Diagram showing the installation of a USB device via USB cable, with labeled components including a camera and a digital camera.

Diagram showing a device with labeled parts (a, b) and an upward arrow indicating motion or change, alongside a magnified inset of a device component.

Auxiliary Main 20cm 20cm

LCD panel ergonomic specifications

Design viewing distance 500 mm
Design inclination angle 0.0°
Design azimuth angle 90.0°
Viewing direction range class Class IV
Screen tilt angle 85.0°
Design screen illuminance •Illuminance level:[250 + (250cosα)] lx where α = 85°•Color: Source D65
Reflection class of LCD panel(positive and negative polarity)	•Ordinary LCD: Class I•Protective LCD: Class III
Image polarity Both
Reference white:Pre-setting of luminance and color temperature @ 6500K (tested under BM7)	•Yn•u'n•v'n
Pixel fault class Class II

TravelMate sorozat

CLASS 1 LASER PRODUCT

CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.

APPAREIL A LASER DE CLASSE 1 PRODUIT

LASERATTENTION: RADIATION DU FAISCEAU LASER INVISIBLE EN CAS

D'OUVERTURE. EVITTER TOUTE EXPOSITION AUX RAYONS.

LUOKAN 1 LASERLAITE LASER KLASSE 1

Acer eRecovery Management 10

Acer Backup Manager 25

(International Travelers Warranty; ITW) 49

Mielött telefonálna 49

Hibaelhárítás 50

LCD panel ergonomic specifications 55

Érintőpad

ProShield Acer ProShield ProShield Introduction ProShield is a complete security application that helps protect against unauthorized access to the computer and its critical data. To begin protecting your system and data, click the Start button below. Start Cancel

Acer ProShield Setup Finished You have finished setting up the required information. Click Finish to close the wizard, or click Next to set up the optional features. Next Finish

Acer ProShield BOS Settings Credential Manager Data Protection Data Removal Information ProShield ProShield is a complete security application that helps protect against unauthorized access to the computer and to critical data.

ProShield Acer ProShield BIOS Settings • BIOS Security Boot Order Settings Port and Device Control Import BIOS Settings Export BIOS Settings Credential Manager Data Protection Data Removal Information Help BIOS Security BIOS Supervisor Password The supervisor password prevents unauthorized access to your PC's BIOS settings. Remove Create BIOS User Password The user password prevents unauthorized access to your PC. Remove Create BIOS Security Enable BIOS password check when system is Power On. Asset Tag Setting an asset tag helps you to track your PC. OK Cancel Apply OK Cancel Apply

ProShield BOS Settings Credential Manager Password Settings Online Accounts Information Backup Restore Data Protection Data Removal Information Help ProShield Password Windows Password Change your ProShield Password. Password length must be 4 to 12 characters. Enter Current Password Enter New Password Confirm New Password: Password Hint OK Cancel Apply

ProShield Acer ProShield BOS Settings Credential Manager Data Protection * File Encryption File Redemption Personal Secure Drive Data Removal Information File Encryption Add files for encryption by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(S) Add Folder(S) Remove File File Name In folder Size Help Encrypt Cancel

Adateltávolítás

ProShield Acer ProShield BDO's Settings Credential Manager Data Protection Data Removal * File Shredder Information File Shredder Add files for shredding by dragging and dropping files or clicking the Add File(s) button. Click Add Folder(s) to add an entire folder. Add File(s) Add Folder(s) Remove File File Name In folder Size Help Saved Cancel

Acer eRecovery Management

Acer eRecovery Management Backup Restore Settings ? Help Password for Restore Process Password Protection: Disabled Create a New Password acer

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Disc Burn the factory default system to disc so that you can restore your PC to its factory default status if needed. It is important to create the factory default disc before using your PC. Create Drivers and Applications Backup Disc Burn the drivers and applications to disc. Use this disc to reinstall drivers or applications if you encounter any problems with them.

AcereRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options: BD ROM BC-55005 Estimated size: 5.54 GB 3 needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. ClickStart to begin creating the backup. Start Cancel

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Create ons: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verifying: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup the factory default system to media so that you can restore your PC to its factory default status if needed. It is important to create the factory default media before using your PC. Create Drivers and Applications Backup Backup the drivers and applications to storage media. Use this media to reinstall drivers or applications if you encounter any problems with them.

Acer eRecovery Management Backup Restore Settings Help Create Factory Default Backup Backup to: (G) Options BD ROM BC-55006 Estimated size: 5.54 GB It needs 2 blank DVD(s) to burn. Label: Recovery Do not disconnect the storage media while creating the backup. Click Start to begin creating the backup. Start Cancel

Acer eRecovery Management Create Factory Default Backup Create on: Recovery1 Backup media: 6% Elapsed time: 00:01:50 Verilog: 0% Elapsed time: 00:00:00

Acer eRecovery Management Backup Restore Settings Help Restore Operating System to Factory Defaults Restore Operating System to factory default status. All data on c:\drive will be deleted. (*Reboot needed) Restore Operating System and Retain User Data Restore only the operating system of your PC to the factory defaults. Files from your user accounts will be transferred to c:\backup. This option will not remove persistent viruses or malware. (*Reboot needed) Reinstall Drivers or Applications Reinstall Factory Default Drivers or Applications.
