Super Fuzz SF300 - Guitar BEHRINGER - Free user manual and instructions

Product type	Fuzz effect pedal for electric guitar
Operating modes	FUZZ 1 (accentuated mids), FUZZ 2 (scooped mids), BOOST (pure boost)
Controls	TREBLE (treble), BASS (bass), GAIN (distortion/volume in boost)
Switching	True bypass footswitch with indicator LED
Power supply	9 V DC via power adapter (not included) or 9 V battery (not included)
Power consumption	Approximately 20 mA
Input	6.35 mm unbalanced jack (instrument)
Output	6.35 mm unbalanced jack (amp)
Dimensions (approx.)	70 x 120 x 50 mm
Weight (approx.)	300 g
Housing material	Sturdy metal
Battery indicator	ON/BATT LED: turns off if battery low
Maintenance	Clean with a dry, soft cloth
Safety	Do not use near liquids or heat sources; use only recommended accessories
Spare parts	9 V power adapter (center negative), 9 V battery
Serial number	Located under the pedal (on the base)
Warranty	Limited warranty – see community.musictribe.com/support
Repairability	Do not open or repair yourself; contact a qualified technician
Compatibility	Electric guitars, basses (with caution) and other jack instruments
Included accessories	None (battery and adapter sold separately)

Frequently Asked Questions - Super Fuzz SF300 BEHRINGER

How to power the Behringer Super Fuzz SF300?

You can use a 9 V battery (not included) or a 9 V DC power adapter (center negative, not included). The device powers on as soon as a jack is inserted into the IN input.

What are the three modes of the SF300?

The MODE selector offers: FUZZ 1 (classic fuzz with pronounced mids), FUZZ 2 (massive fuzz with scooped mids) and BOOST (pure boost, where the GAIN potentiometer controls volume).

How to adjust the fuzz sound with the SF300?

Use TREBLE for treble, BASS for bass and GAIN for distortion intensity. In BOOST mode, GAIN adjusts the output level.

What does the ON/BATT LED mean?

The LED lights up when the effect is engaged. If it turns off or dims, the battery is nearly depleted and should be replaced.

How to replace the battery of the SF300?

Press the hinge pins with a ballpoint pen, gently remove the pedal cover, then replace the 9 V battery observing polarity.

Why doesn't my SF300 turn off?

The pedal has no switch. It is active as soon as a jack is plugged into the IN input. Unplug the jack to cut power and save the battery.

Can I use the SF300 with a bass?

Yes, but the fuzz may distort the low end. Test the BASS and GAIN settings to adapt the sound to your bass.

How to clean my SF300 pedal?

Unplug it, then clean the housing with a dry, soft cloth. Never use liquid or abrasive cleaner.

Does the SF300 work with a pedalboard/amp setup?

Yes, it is designed to be connected between the guitar and the amp (or any other effect). The OUT output connects to the amp input.

Where to find the serial number of the SF300?

The serial number is printed on the base (bottom) of the pedal. Keep it for any warranty claims.

USER MANUAL Super Fuzz SF300 BEHRINGER

3-Mode Fuzz Distortion Effects Pedal

2 SUPER FUZZ SF300

EN

ES

EN Safety Instruction

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Use only attachments/accessories specified by the manufacturer.

1. Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

1. Correct disposal of this product: This symbol indicates that this product must not be

disposed of with household waste, according to the WEEE Directive (2012/19/EU) and your national law. This product should be taken to a collection center licensed for the recycling of waste electrical and electronic equipment (EEE). The mishandling of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated with EEE. At the same time, your cooperation in the

correct disposal of this product will contribute to the efficient use of natural resources. For more information about where you can take your waste equipment for recycling, please contact your local city office, or your household waste collection service.

1. Do not install in a confined space, such as a book case or similar unit.
2. Do not place naked flame sources, such as lighted candles, on the apparatus.

Music Tribe accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph, or statement contained herein. Technical specifications, appearances and other information are subject to change without notice. All trademarks are the property of their respective owners. Midas, Klark Teknik, Lab Gruppen, Lake, Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera, Aston Microphones and Coolaudio are trademarks or registered trademarks of Music Tribe Global Brands Ltd. © Music Tribe Global Brands Ltd. 2024 All rights reserved.

ES

FR

DE

PT

IT

Thank you for showing your confidence in us by purchasing the Behringer SUPER FUZZ SF300. This effects pedal is ideally suited for electric guitars and recreates the whole variety of famous fuzz tones of the '60s and '70s.

1. Controls

The LEVEL control adjusts the output level.
2 The TREBLE control allows you to boost/cut the high-frequency range.
3 The BASS control allows you to boost/cut the low-frequency range.
4 The GAIN control adjusts the gain for more distorted sounds.
5 The MODE switch lets you choose between 3 effect modes.

FUZZ 1: Basic fuzz sound with emphasis on the midrange.

FUZZ 2: Full-bodied fuzz sound with scooped mids and sharp harmonics.

BOOST: The Level control is inactive and the Gain control adjusts the boost.

6 The ON/BATT LED illuminates when the effect is activated. It also serves as a battery level indicator.
⑦ Use the footswitch to activate/deactivate the effect.
8 Use this 14 " TS IN connector to plug in the instrument cable.
9 The 1/4" TS OUT connector sends the signal to your amp.

Use the DC IN connection to plug in a 9 V power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery (not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful not to scratch the unit.

The SF300 has no on/off switch. As soon as you insert the plug into the in connector, the SF300 is on. When not in use, remove the plug from the in connector. This extends the life of the battery.

The SERIAL NUMBER is located at the underside.

2. Safety Instructions

Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service product yourself. Contact our qualified servicing personnel for servicing or repairs, especially when power supply cord or plug is damaged.

EN

3. Limited Warranty

For the applicable warranty terms and conditions and additional information regarding Music Tribe's Limited Warranty, please see complete details online at community.musictribe.com/support.

Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.

WARNING

• As with all small batteries, the batteries used with this product should be kept away from small children who still put things in their mouths. If they are swallowed, promptly call your local poison control center.
• Always purchase the correct size and grade of battery most suitable for intended use.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and also those of the device prior to battery installation.
• Ensure the batteries are installed correctly with the regard to polarity (+ and -).
• Always remove battery if consumed or if product is to be left unused for a long time.
• Replacement of a battery with an incorrect type that can defeat a safeguard! Replace only with the same or equivalent type!
• Risk of fire or explosion if the battery is replaced by an incorrect type.
• Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion;
• Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; and
• A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas.
• Attention should be drawn to the environmental aspects of battery disposal.

14 SUPER FUZZ SF300

In

Connector 1/4" TS

Impedance 500 kΩ

In

Connector 1/4" TS

Impedance 1 kΩ

Power Supply

9 V	..., 100 mA regulated

Behringer PSU-SB

USA/Canada 120 V~, 60 Hz

Europe/U.K./Australia 230 V~, 50 Hz

China 220 V~, 50 Hz

Korea 220 V~, 60 Hz

Japan 100 V~, 50/60 Hz

Power connector 2 mm DC jack, negative center

Battery 9 V type 6LR61

Power consumption 30 mA

Physical/Weight

Dimensions approx. (H x W x D)	2 1/8 x 2 3/4 x 4 4/5" approx. 54 x 70 x 123 mm
Weight	approx. 0.73 lbs / 0.33 kg

Behringer is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may therefore differ from those listed or shown.

技术参数

In

Responsible Party Name: Music Tribe

Commercial NV Inc.

Address: 122 E. 42nd St.1,

8th Floor NY,

NY 10168,

United States

Email Address:

[e-mail]

SUPER FUZZ SF300

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.

Important information:

Changes or modifications to the equipment not expressly approved by Music Tribe can void the user's authority to use the equipment.

CE

Hereby, Music Tribe declares that this product is in compliance with Directive 2014/30/EU, Directive 2011/65/EU and Amendment 2015/863/EU, Directive 2012/19/EU, Regulation 519/2012 REACH SVHC and Directive 1907/2006/EC.

Full text of EU DoC is available at https://community.musictribe.com/

EU Representative: Music Tribe Brands DK A/S Address: Gammel Strand 44, DK-1202 København K, Denmark

UK Representative: Music Tribe Brands UK Ltd. Address: 8 ^th Floor, 20 Farringdon Street London EC4A 4AB, United Kingdom

We Hear You
