10024005 - Heated blanket Klarstein - Free user manual and instructions

Product type	Electric heating blanket
Brand	Klarstein
Model	10024005 (and variants 10024006, 10031579-10031583, 10031657, 10031658, 10033007)
Power supply	220-240 V ~ 50 Hz
Power	120 W
Temperature settings	4 positions: 0 (off), 1 (low), 2 (medium), 3 (high)
Auto shut-off	After 3 hours
Estimated lifespan	8 years
Care and cleaning	Hand wash or machine wash at 30 °C, wool program; do not wring, do not iron, do not dry clean
Drying	Flat, air dry
Safety	Do not use folded, do not pin with sharp objects, do not use with other heating devices, not recommended for heat-sensitive individuals and children without supervision
Use in bed	Must lie flat, do not use on an adjustable bed without caution
Control	Rotary selector with positions 0-3
Cable length	Not specified (fixed non-replaceable cable)
Dimensions	Not specified (standard size for single/double blanket depending on model)
Weight	Not specified
Recycling	Compliant with WEEE directive (2012/19/EU): do not dispose of with household waste
Certifications	CE (directives 2014/30/EU, 2014/35/EU, 2011/65/EU)

Frequently Asked Questions - 10024005 Klarstein

What type of heating blanket is the Klarstein 10024005?

It is an electric heating blanket with manual control and automatic shut-off after 3 hours.

How to adjust the temperature of the Klarstein 10024005 blanket?

Use the rotary selector: position 0 to turn off, 1 for low heat, 2 for medium, 3 for high.

Is there an automatic shut-off on this blanket?

Yes, the blanket turns off automatically after 3 hours of operation.

Can I machine wash the heating blanket?

Yes, you can machine wash it at 30 °C with a wool program. First unplug the cord and remove the controller. Do not wring, do not iron, do not dry clean.

Is it safe to use the heating blanket with other heating devices?

No, it is not recommended to use the blanket at the same time as foot warmers, hot water bottles or other heating devices to avoid the risk of overheating.

Can I use the blanket if it is folded or wrinkled?

No, never use the blanket folded or rolled as this may cause overheating. Make sure it lies flat.

Is the blanket suitable for children or the elderly?

It should not be used by people insensitive to heat (children, elderly, disabled persons) without supervision. Children should only use it under adult supervision.

What is the lifespan of this heating blanket?

Under normal conditions of use, the lifespan is 8 years. After this period, it is recommended to replace it.

What to do if the power cord is damaged?

The power cord is not replaceable. If the cord is damaged, the blanket must be recycled and replaced.

Can I use this blanket on a spring mattress or adjustable bed?

If you use an adjustable bed, make sure the cable is not pinched or damaged. Avoid folds in the blanket.

USER MANUAL 10024005 Klarstein

QR code image containing encoded data, no visible human-readable text

INHALTSVERZEICHNIS

Technische Daten 3

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints to avoid damages. Any failure caused by ignoring the items and cautions mentioned in the instruction manual is not covered by our warranty and any liability. Scan the QR code to get access to the latest user manual and other information about the product:

QR code image containing encoded data, no visible human-readable text

CONTENT

Technical Data 7

Declaration of Conformity 7

Safety Instructions 8

Operation 9

Care and Cleaning 9

Hints on Disposal 10

TECHNICAL DATA

Item number	10024005, 10024006, 10031579, 10031580, 10031581, 10031582, 10031583, 10031657, 10031658, 10033007
Power supply 220-240 V ~ 50 Hz
Power consumption 120 W

DECLARATION OF CONFORMITY

C€

Producer:

Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany.

This product is conform to the following European Directives:

2014/30/EU (EMC)

2014/35/EU (LVD)

2011/65/EU (RoHS)

SAFETY INSTRUCTIONS

• Never fold the inserted blanket.
• Do not roll and do not drape the blanket during use. If the electric blanket is used in bed, make sure it is flat on it. If this is not guaranteed, do not use the electric blanket to avoid overheating.
• Do not use needles, do not scratch with sharp objects on the ceiling, and do not use blunt force against the ceiling. Do not attach the blanket with needles.
• In order not to burn the human body, the blanket should not be used by physically handicapped persons, children or heat-sensitive persons.
• Do not turn off the blanket when folded duvets or heavy items are lying on top of it. The compressed areas could overheat.
• Do not expose the blanket to direct sunlight, burn and iron.
• Do not use the deck with other heaters (such as foot warmer, hot water bottles).
• Do not heat other devices with the ceiling.
• Keep sources of ignition (such as cigarette, sparks) that can cause fire, away from the bed.
• Disconnect the electric blanket from the mains if you do not use it or leave the house. This will avoid possible fires.
  • The device is not intended for use in hospitals.
• Store the electric blanket in a dry place. Do not place heavy objects on the ceiling and do not angle them. After storage, carefully check the blanket before use. Do not use the blanket with a damaged power cord.
• Never disassemble or repair the heating blanket yourself.
• The power cord can not be replaced. Dispose of the electric blanket if the power cord is damaged.
• Do not use the electric blanket in a mechanically adjustable bed. If you should do it anyway, make sure that the cable is not pinched and damaged.
• Children are only allowed to use the electric blanket in the presence of their parents or a caregiver who is familiar with its use.
• Under normal conditions, the electric blanket has a service life of 8 years. After this time you should buy a new blanket. Mishaps damaged by misconduct must be repaired before reuse.
• Do not use folded.
• Do not insert a needle.

OPERATION

Selecting temperature

0 off
1 low	heat
2 medium	heat
3 high	heat

Automatic switch-off function

The electric blanket is automatically switched off after approximately 3 hours. To switch on the electric blanket again, first set the temperature selector switch to position "0" and then again to one of the values "1" to "3".

CARE AND CLEANING

• Always disconnect the power plug from the socket outlet before cleaning the electric blanket.
• Before washing, unplug it from the mains outlet and let it cool down.
• Unplug the control switch unit from the heating blanket using the connector on the underside.

Note: The electric blanket may not be dry cleaned, wrung out, dried by machine, pressed or ironed. The electric blanket may be washed by hand according to the instructions on the label. Never immerse the control switch unit in water as moisture must not be allowed to get into the unit.

• In case of heavier soiling, this electric blanket can be washed in a washing machine.
- Set the washing machine to a particularly gentle, 30 °C cycle (woollens programme). Use a wool laundry detergent and follow the manufacturer's instructions.
- To dry, lay the electric blanket flat on a moisture-absorbent towel or mat. When the electric blanket is completely dry, it should be reconnected to the control switch unit in correct manner. The electric blanket may only be operated with its special control unit.
- When storing the appliance, allow it to cool down before folding. Store the electric blanket in a clean and dry place.
- When storing, do not place any objects on the electric blanket to prevent buckling.

HINTS ON DISPOSAL

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

According to the European waste regulation 2012/19/EU this symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council or your household waste disposal service.
