| Product type | Gas cooker (hob) |
| Brand | Rosieres |
| Model | RGV 64 TFM PN |
| Dimensions (W x D x H) | 595 x 510 x 100 mm (estimated) |
| Weight | Approximately 12 kg (estimated) |
| Power supply | Gas (G20/G25 20/25 mbar or G30/G31 28-30/37 mbar) and electrical (220-240 V, 50-60 Hz) |
| Burner type | 4 burners: 1 auxiliary, 1 semi-rapid, 2 rapid |
| Total gas power | Approximately 10 kW |
| Ignition | Integrated electronic |
| Safety | Safety taps with thermocouple; automatic gas shut-off in case of flame extinction |
| Material | Stainless steel and enamel |
| Maintenance and cleaning | Clean with soapy water or non-corrosive detergent; avoid abrasive products; dry after cleaning |
| Installation class | 3 |
| Spare parts and repairability | Parts available via approved after-sales service; injectors can be replaced for gas type adaptation |
| General information | Non-professional domestic use; complies with European (CE) and WEEE directives; do not use with an external timer |
Frequently Asked Questions - RGV 64 TFM PN ROSIERES
How to light the burners on my Rosieres RGV 64 TFM PN cooker?
Press and turn the control knob to the ignition symbol. The integrated electronic ignition system produces sparks. Hold the knob pressed for 5 to 6 seconds after ignition to activate the thermocouple safety device. If the burner does not light within 5 seconds, return the knob to 0 and repeat the operation.
What to do if a burner does not light?
Check that the burner and cap are correctly positioned. Make sure the gas supply is open. If the problem persists, wait a few seconds before trying again or contact after-sales service.
How to adjust the flame to minimum?
After lighting the burner, turn the knob to the minimum setting, gently remove it and adjust the adjustment screw with a small screwdriver. Turn clockwise to reduce the flame, counterclockwise to increase it. The flame should be about 3-4 mm.
Can I use a gas cylinder with this appliance?
Yes, provided you use a pressure regulator compliant with current standards. Ensure that the injector is suitable for butane/propane gas (G30/G31) and that the idle flame adjustment is done by turning the screw fully clockwise.
How to clean the burners and grates?
Use warm soapy water or a non-corrosive detergent. For stubborn stains, a stainless steel cleaner is recommended. Dry thoroughly before reassembling. Never use abrasive products or metal sponges.
What to do in case of a gas leak?
Immediately shut off the gas supply by closing the stop valve. Do not use any flames or operate electrical switches. Ventilate the room and call a qualified technician. Do not search for the leak with a flame.
Is it mandatory to install a hood above the cooker?
It is highly recommended to install a hood or mechanical ventilation to evacuate heat and moisture. The minimum distance between the hob and the hood should be at least 70 cm.
What safety distance should I keep from adjacent furniture?
Leave at least 15 cm between the hob and side cabinets, and 5.5 cm with the back wall. The worktop must withstand temperatures up to 100°C.
How to adapt the hob to another gas type (e.g., switching from natural gas to propane)?
Replace the injectors with those suitable for the new gas (kit supplied with the appliance). Unscrew the injectors with a 7 mm box spanner, insert the new ones and screw them fully. Then adjust the idle flame adjustment screw. Do not forget to change the rating label.
How to clean the electric plates if my model has them?
Use a damp cloth and dish detergent. Do not scrape with hard objects. After cleaning, turn on the plates for a few minutes to dry them. Avoid plastic or aluminum containers on hot plates.
