USER MANUAL KA 4840 SEVERIN

Exterior view of a modern SEVERIM coffee maker with black and silver casing (no visible text or symbols on the device itself)

ART.-NR. KA 4840 / KA 4845

DE Gebrauchsanweisung
GB Instructions for use
FR Mode d'emploi
NL Gebruiksaanwijzing
ES Instrucciones de uso
IT Manuale d'uso
DK Brugsanvisning
SE Bruksanvisning
FI Käyttöohje
PL Instrukcja obstugi
GR Οδηγίες χρήσεως
RU Руководство по эксплуатации
Filterkaffeemaschine mit Thermokanne 4
Filter coffee maker with heat-retaining carafe 12
Cafetière filtre avec verseuse isotherme 20
Filter koffiezetapparaat met thermische karaf 28
Cafetera de filtro con jarra termo 36
Macchina per caffè filtro con caraffa termica 44
Filterkaffemaskine med termokande 52
Filterkaffebryggare med termoskanna 60
Suodatinkahvinkeitin sis. termospannu 68
Ekspres do kawy z filtrem z dzbankiem termicznym 75
Καφετιέρα με φίλτρο και κανάτα διατήρησης θερμότητας 84
Фильтрационная кофеварка с термокувшином 93

QR code image containing encoded data, no visible human-readable text

Filter coffee maker with heat-retaining carafe

Dear Customer,

Before using the appliance, read the following instructions carefully and keep this manual for future reference. The appliance must only be used by those familiar with the instructions below.

Important safety instructions

Intended use

• The appliance must only be used for making coffee from roasted and ground coffee beans.
• Any use other than that described in these instructions (misuse) must be considered improper and may lead to personal injury or material damage.

• This appliance is intended for domestic or similar applications, such as

• in staff kitchens in shops, offices and other similar working environments,

• in agricultural working environments,
• by customers in hotels, motels etc. and similar accommodation,
• in bed-and breakfast type environments.

- Do not leave the appliance unattended while connected.

Danger to certain categories of persons

There is an increased risk of injury for children and for people with reduced capabilities:

• This appliance may be used by children (at least 8 years of age) and by persons with reduced physical, sensory or mental capabilities, or lacking experience and knowledge, provided they have been given supervision or instruction concerning the use of the appliance and fully understand all dangers and safety precautions involved.
  • Children must not be permitted to carry out any cleaning or maintenance work on the appliance unless they are supervised and at least 8 years of age.
• The appliance and its power cord must be kept well away from children under 8 at all times.
  • Children must not be permitted to play with the appliance.
• Caution: Keep any packaging materials well away from children – these materials are a potential source of danger, e.g. of suffocation.

Risk of electric shock

The device is powered by electricity, and so there is always a risk of electric shock. The following precautions are therefore to be taken:

- Every time the appliance is used, the main body including the power cord as well as any attachment fitted should be checked thoroughly for any defects. Should the appliance, for instance, have been dropped onto a hard surface, or if excessive force has been used to pull the power cord, it must no longer be used: even invisible damage may have adverse effects on the operational safety of the appliance.

- The appliance should only be connected to a socket installed in accordance with the regulations. Make sure that the supply voltage corresponds with the voltage marked on the rating label.

• Always remove the plug from the wall socket

- after use,

- in case of any malfunction,

- before cleaning the appliance.

- When removing the plug from the wall socket, never pull on the power cord; always grip the plug itself.

- Do not touch the plug with wet hands.

- Do not clean the appliance with liquids or immerse it; do not clean under running tap water.

Danger of burns and scalding

The appliance heats up water and keeps it hot. The exterior surfaces, the bottom of the carafe and the base become hot during use, and will retain some heat even afterwards. There is thus a danger of burns or scalding.

• Do not touch those components during use: after use, allow them to cool down first.
• Do not open the swing-out filter during use.
  • Always allow the appliance to cool down for about 5 minutes after use and before opening the swing-out filter or filling with fresh water.

Lack of hygiene

Lack of hygiene may result in germs forming inside the appliance:

• Clean the appliance thoroughly before using it for the first time.
• Before cleaning the appliance, ensure it is disconnected from the power supply and has cooled down completely.
• The filter insert and carafe should be cleaned on a daily basis.
• Do not leave any residual water in the container.
• The appliance must be descaled at regular intervals.
  • Detailed information on cleaning the appliance can be found in the section Cleaning and care.

Danger of damage to the unit

Incorrect handling of the appliance can cause damage:

• Always place the unit on a dry, level surface that is water- and heat-resistant, and unaffected by contact with the rubber feet.
• Do not operate the appliance below a hanging cupboard or similar object; there is a risk that escaping steam may be trapped underneath.
• Do not let the power cord hang free.
• Do not kink or pinch the power cord. Keep both the cord and the appliance itself well away from heat sources (eg hot-plates, gas flames).
• Use only cold tap water to fill the container.

In case of a defective appliance

A defective appliance can cause material damage and injury:

• Check the appliance for damage before every use. Do not operate if the appliance shows any sign of damage.
• In the event that you detect damage, please contact our customer service department by phone or email (see appendix).
• Repairs to this appliance or its power cord must only be carried out by our customer service.

Technical specifications

Device category, Art. no.	Filter coffee maker with heat-retaining carafe KA 4840 / KA 4845
Voltage 220-240 V~, 50/60 Hz
Output 850 - 1000 W
Dimensions (W x H x D)	235 x 340 x 290 mm
Weight approx. 2.4 kg
Special markings
	Do not dispose of in domestic garbage
	This product complies with all binding CE labelling directives.
	On/Off button
	CAUTION - Hot surface - Allow the appliance and its components to cool down.
	Lid release
	Lid lock
	Aroma selection Coffee ‘mild’
	Aroma selection Coffee ‘strong’

Overview and parts included

1. Lid for water container
2. Water level indicator
3. Swing-out filter with removable filter insert
4. Aroma selection switch
5. Carafe with drip-through lid
6. Base
7. On/Off switch with indicator light
8. Rating label (on underside)
9. Power cord with plug
10. Cable storage space (at the rear)

Before using for the first time

• Unpack the appliance completely and remove all packaging materials and stickers.
• Clean the carafe and filter insert as described in the section Cleaning and care.
• Before making coffee for the first time, let the appliance go through two or three filtration cycles using the indicated maximum amount of cold water, but without using ground coffee.
• This should also be done if the appliance has not been used for an extended period of time, and after descaling.

Automatic switch-off

To save energy, the appliance will switch off automatically 5 minutes after the brewing cycle is complete.

Power-cord storage compartment

The integrated power-cord storage compartment at the rear is used for storing the power cord.

The recess at the bottom facilitates limiting the length of the power cord.

Making coffee - general information

• The measuring scales on the water container help measuring the correct amount of clean water. The left scales are used for standard-sized cups of approx. 125 ml, the right scales for smaller cups.
• Make sure that the indicated maximum amount of water or number of cups is not exceeded.
• If several consecutive brewing cycles are required, switch off the coffee maker after each cycle and let the appliance cool down for approx. 5 minutes.
• Caution: When filling the appliance with fresh water shortly after a brewing cycle is completed, there is a danger of scalding from hot water or steam escaping through the water outlet.

Aroma selection switch

This appliance features a special aroma function, allowing the user to choose coffee with a normal strong flavour, or alternatively a very mild coffee.

Turn the aroma selection switch to the desired setting before the brewing cycle is started:

• • • for mild coffee
or
●●● for normal coffee

Making coffee

1. Filling with water:

Open the water container and fill it with the desired quantity of water, then close the lid.

2. Preparing the carafe:

Fit the drip-through lid so that the two triangular markings ▼ and ▲ are facing each other.

Lock the lid by turning towards the 🔒 mark. Place the carafe into the appliance.

If correctly inserted, the lid will disable the drip-stop mechanism in the filter holder during the brewing cycle.

3. Inserting the paper filter:

Open the swing-out filter and insert a size-4 paper filter into the filter holder, first folding down the perforated sides of the filter.

4. Filling with ground coffee:

For each regular-sized cup (125 ml), a measure of about 6 g (= 1½ - 2 teaspoons) of medium or finely ground coffee will be required. Close the swing-out filter afterwards.

5. Connecting the appliance:

Insert the power plug.

6. Selecting the coffee strength:

Turn the aroma selection switch to the desired setting.

7. Starting the brewing cycle:

Use the ⏻ button to switch the coffee maker on. The filtration cycle starts and the water passes through the filter.

8. Removing the carafe:

Wait until all the water has passed through; the carafe can now be removed. To pour coffee, simply push down the lid-opening tab on the drip-through lid.

9. Interrupting the brewing cycle:

To interrupt the brewing cycle, use the ⏻ button to turn the appliance off.

10. Switching off the coffee maker:

Remove the plug from the wall socket once brewing is complete.

Heat-retaining carafe

- For technical reasons the lid does not close hermetically. Therefore always hold the carafe in an upright position when filled with coffee.

- Keeping the coffee hot: A heat-retaining carafe accumulates heat energy. Therefore the carafe should preferably be filled to its maximum capacity. If it is only partly filled, the temperature will not be held as efficiently. If you rinse out the carafe with hot water before use, the coffee will be kept warm for a longer time.

- To prevent the risk of scalding, do not leave the heat-retaining carafe unattended near where children may reach it.

- Therefore, do not drink out of the carafe and do not put your hand into it.

- Always close the carafe with its lid. The coffee can be poured out easily by pressing the lid-opening tab.

- Do not wash the carafe in a dishwasher and do not put it in a microwave oven.

Recipes

Are you in the mood for some delicious coffee specialities?

QR code image containing encoded data, no visible human-readable text

- Depending on the water quality (lime content) in your area as well as the frequency of use, all thermal household appliances using hot water need descaling (i.e. removal of lime deposits) on a regular basis to warrant proper functioning.

- Any warranty claim will be null and void if the appliance malfunctions because of insufficient descaling.

- A lengthening of the brewing time, increased noise during brewing or residual water remaining in the container indicate that descaling has become necessary.

- An excessive build-up of lime deposits is very difficult to remove, even when strong descaling agents are used. It may also cause the brewing system to leak. We therefore strongly recommend descaling the appliance after each thirty to forty brewing cycles.

- For descaling, a vinegar solution may be used as follows:

- Mix 80 ml of vinegar essence with the indicated maximum amount of cold water.

- Pour the descaling solution into the water container, insert a paper filter without adding any ground coffee, as described in section Making coffee, and let the appliance run through one filtration cycle.

Models with aroma selection switch: Turn the switch to the position ● ● ● for normal coffee.

- Repeat the procedure if necessary.

- During descaling, ensure sufficient ventilation and do not inhale any vinegar vapours.

- To clean the appliance after descaling, let it run through 2-3 filtration cycles using clean water only.

- Before cleaning the appliance, ensure it is disconnected from the power supply and has cooled down completely.

- To avoid the risk of electric shock, do not clean the appliance with liquids or immerse it; do not clean under running tap water. The appliance may be cleaned with a slightly damp cloth, using a mild detergent. Wipe dry afterwards.

- Do not use abrasives or harsh cleaning solutions.

- To remove the used coffee grounds, open the swing-out filter, lift out the paper filter and dispose of the grounds (as a natural substance they may be composted). Wipe the inside of the swing-out filter with a damp cloth, dry it and close it again.

- The filter insert may be cleaned with warm water or in a dishwasher after use.

- The drip-through lid may be cleaned with warm dish water.

- Do not dismantle the carafe, do not wash in a dishwasher and do not immerse it in water.

- Rinse the inside of the heat-retaining carafe with water and wipe the outside with a clean damp cloth after use.

- To remove any coffee deposits from the inside of the heat-retaining carafe, fill it with hot water and add a tablespoon of dishwasher detergent. Close with the lid and leave it standing for some hours. Rinse out thoroughly with water afterwards.

Disposal

Devices marked with this symbol must be disposed of separately from your household waste, as they contain valuable materials which can be recycled. Proper disposal protects the environment and human health. Your local authority or retailer can provide information on the matter.

Guarantee

This product is guaranteed against defects in materials and workmanship for a period of two years from the date of purchase. Under this guarantee the manufacturer undertakes to repair or replace any parts found to be defective, providing the product is returned to one of our authorised service centres. This guarantee is only valid if the appliance has been used in accordance with the instructions, and provided that it has not been modified, repaired or interfered with by any unauthorised person, or damaged through misuse.

This guarantee naturally does not cover wear and tear, nor breakables such as glass and ceramic items, bulbs etc. This guarantee does not affect your statutory rights, nor any legal rights you may have as a consumer under applicable national legislation governing the purchase of goods. If the product fails to operate and needs to be returned, pack it carefully, enclosing your name and address and the reason for return. If within the guarantee period, please also provide the guarantee card and proof of purchase.

Trouble shooting

Problem Cause Remedy
Functions cannot be activated.	Appliance is not plugged in.	Connect appliance to mains.
	Socket is defective. Check the socket with a different appliance.
The appliance switches off before brewing is complete; residual water remains inside the container.	Descaling required. Descale the appliance (see Cleaning and care).
No coffee comes out of the swing-out filter.	The glass carafe is not properly placed underneath the outlet.	Check that the carafe is properly positioned on the base, pushing the outlet valve up.
	Not enough water. Replenish water.
Water overflow in swing-out filter.	Grind level too fine. Select coarser grind level.
The coffee is too thin. Too little ground coffee was used.		Increase the amount.
	Paper filter inserted incorrectly, or collapsed.	Fold down the perforated sides first before insertion.
	Models with aroma selection switch: Wrong switch position ● ● ●.	Set switch to position ● ● ●.

Should you be unable to solve the problem using the table, please contact our Customer Service. The contact data can be found in the appendix to this manual.

Chère cliente, Cher client,

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

QR code image containing encoded data, no visible human-readable text

B4-061/062 NO,181 Exhibition Road,

Jiangdong District, Ningbo

Tel.: [phone]

Fax.: [phone]

Web: www.nbautin.com.cn

Web: www.autin.com.cn

Czech Republic

BVZ Commerce s.r.o.

Parkerova 618

CZ 25067 Klecany

Tel.: [phone]

Fax: [phone]

Danmark

F&H of Scandinavia A/S

Gl. Skivevej 70

DK-8800 Viborg

Tel.: [phone]

Fax: [phone]

26 Oaktree Business Park

Trim Co., Meath

Tel.: [phone]

Fax: [phone]

Web: www.bluestone.ie

Italia

ASSISTENZA POST-VENDITA

NUMERO VERDE 800224155

E-Mail: [e-mail]

Indonesia

PT. Setai Modern Elektronik

Email.: [e-mail]

Web.: www.severin.co.id

Jakarta

Komp. Glodok Plaza Blok F No. 9, Jl. Pinangsia Raya,

Jakarta Barat

021 65911888 / 021 6592889

Medan

Al Bahar Building P.O. Box 148

Safat 13002 Kuwait

Tel.: [phone]

Latvia

SIA GTCL BALTIC

Piedrujas iela 7

LV - Riga 1073

Tel.: [phone]

Fax: [phone]

Lebanon

Khoury Home

7th Floor, Cité Dora 3 Building, Dora

P.O.Box 70611

Antelias, Lebanon

Tel.: [phone]

Fax:[phone]

E-Mail: [e-mail]

Internet: www.khouryhome.com

Luxembourg

Ser-Tec

A.A.K & Partners L.L.C.

P.O Box:-1650, Muttrah

Postal Code - 114

Sultanate of Oman

Tel.: [phone]

Fax.: [phone]

E-Mail: [e-mail]

Philippines

COLOMBO MERCHANT PHILIPPINES, INC.

Mezzanine 1, South Center Tower

2206 Venture Street, Madrigal Business Park

Alabang, Muntinlupa City

Tel.: [phone]

E-Mail: [e-mail]

Polska

Severin Polska Sp.z o.o.

Al.Jerozolimskie 56 C

00-803 Warszawa

Tel.: [phone]

6 Tagore Drive, #03-04

Singapore 787623

Tel.: [phone]

Fax: [phone]

Web: www.beste.com.sg

E-Mail: [e-mail]

Slovenia

SEVTIS d.o.o.

Smartinska 130

1000 Ljublj

Tel.: [phone]

Fax: [phone]

Slowak Republic

BVZ Commerce s.r.o.

Parkerova 618

CZ 25067 Klecany

Tel.: [phone]

Fax: [phone]

South Africa

AL&CD Ashley (PTY) Ltd.

3rd Floor, Grove Exchange

9 Grove Avenue

Claremont

South Africa

7708

Tel: [phone]

Fax: [phone]

Web: http://www.alcdashley.co.za

Mail: [e-mail]

Svenska

Rakspecialisten HS

Möllevångsgatan 34

214 20 Malmö

Tel.: [phone]

Fax: [phone]

E-Mail: [e-mail]

Switzerland

BLUEPOINT Service Sagl

Via Cantonale 14

CH-6917 Barbengo

Tel.: [phone]

Fax: [phone]

E-Mail: [e-mail]

Thailand

Verasu Ltd. part.

83/7 Wireless Rd., Lumpini,

Patumwan, Bangkok 10330

Tel.: [phone]

E-Mail: [e-mail]

United Kingdom

Homespares Centres Limited

Firwood Industrial Estate

Thicketford Road

Bolton, BL2 3TR

Tel.: [phone]

Fax: [phone]

HO CHI MINH CITY, VIETNAM

Tel.: [phone]

Fax: [phone]

E-Mail: [e-mail]

Stand: 12.2017
