USER MANUAL 10029154 Klarstein

• Read all instructions before operating.

• Do not touch hot surfaces. Use handles or knobs.

• To protect against electrical shock, do not immerse cord, plug or appliance itself in water or other liquids.

• Close supervision is necessary when appliance is used by or near children.

• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.

• Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair or adjustment.

• The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.

• Do not use outdoors.

• Do not let cord hang over edge of table or counter or touch hot surfaces.

• Do not place on or near a hot gas or electric burner, or in a heated oven.

• Always attach plug to appliance first, then plug cord into wall outlet. To disconnect, turn any control to OFF position, then remove plug from wall outlet.

• Oversized foods or metal utensils must not be may cause a fire or risk of electrical shock.7

• A fire may occur if the appliance is covered or touching flammable material including curtains, draperies, walls and the like when in operation.

• Do not clean with metal scouring pads. Pieces can break off the pad and touch electrical parts, involving a risk of electrical shock. Product Description and Accessory 1 Rotary switch 2 Housing 3 Cup base 4 Sealing ring 5 Glass jar 6 Lid 7 Lid insert 8 Bottle (600 ml) 9 Bottle (900 ml) 10 Lid Befor first Use

• All parts of the blender are to be thoroughly cleaned before being used for the first time.

• Take out the required length of cable from the cable tidy on the base of the blender and connect the device to the mains supply. Assembling the Glass Jar

• Place the seal ring (4) onto the blade (3).

• Mount the blade (3) to the bottom of the jar (5). Lock the blade (5) by turning it clockwise.

• Mount the jar (5) onto the appliance. Lock the jar (5) by turning it clockwise.

• Turn the bottle (8 or 9) upside down. Place the bottle (8 or 9) onto the appliance.

• Lock the bottle (8 or 9) by turning it clockwise until it clicks into place.8 Use and Operation Switching on and off IMPORTANT: Do not switch on the appliance when the jar or the bottle is empty. Do not leave the appliance switched on continuously for more than two minutes. After two minutes, switch off the appliance and allow it to cool down for three minutes before switching it on again.

• To switch on the appliance with continuous low speed, set the on/off switch (1) to the „I“ position.

• To switch on the appliance with continuous high speed, set the on/off switch (1) to the „II“ position.

• To switch on the appliance in pulse mode, set the on/off switch (1) to the „P“ position.

• To switch off the appliance, set the on/off switch (1) to the „O“ position. Important Hints for Use

• Do not exceed the maximum mark on the juice level indicator.

• Do not overload the appliance. Do not put too many ingredients into the jar or the bottle at one time. If the motor stops, immediately switch off the appliance, remove the mains plug from the wall socket and allow the appliance to cool down for at least 10 minutes. Operation

• Cut the fruit and/or vegetables into pieces. that fit in the jar or the bottle.

• Put the pieces of fruit and/or vegetables into the jar or the bottle.

• Assemble the appliance. Refer to the section „Assembly“.

• Insert the mains plug into the wall socket. The power indicator comes on in a few seconds. The longer the appliance is switched on, the finer the ingredients will be blended.

• If necessary, add more pieces of fruit and/or vegetables How to use the Jar

• Switch off the appliance.

• Turn the jar lid insert counterclockwise to remove it from the jar lid.

• Cut the fruit and/or vegetables into pieces. Make sure that the pieces of fruit and/or vegetables fit in the jar.

• Put the pieces of fruit and/or vegetables into the jar.

• If the pieces are too large for the filling opening of the jar lid, remove the jar lid and add the pieces of fruit and/or vegetables.

• Mount the jar lid onto the jar. Mount the jar lid insert into the jar lid.

• Switch on the appliance. The appliance blends the ingredients in a few seconds. The longer the appliance is switched on, the finer the ingredients will be blended. How to use the Bottles

• Switch off the appliance.

• Unlock the bottle by turning it counterclockwise. Remove the bottle from the appliance. Turn the bottle straight up again.

• Loosen the blade from the bottle.9

• Cut the fruit and/or vegetables into pieces. Make sure that the pieces of fruit and/or vegetables fit in the bottle.

• Put the pieces of fruit and/or vegetables into the bottle.

• Tighten the blade onto the bottle. Turn the bottle upside down. Place the bottle onto the appliance.

• Lock the bottle by turning it clockwise until it clicks into place.

• Switch on the appliance. The appliance blends the ingredients in a few seconds. The longer the appliance is switched on, the finer the ingredients will be blended.

• After use, switch off the appliance. Remove the mains plug from the wall socket. The power indicator goes off. Allow the appliance to cool down completely. Useful Tips

• To achieve the best results when pureeing solid ingredients, place small portions into the glass jar one by one instead of placing a large quantity all at once.

• If you are processing solid ingredients, cut them into small pieces (2-3cm) first.

• When mixing solid ingredients start off first with a small amount of liquid.

• Gradually add more and more liquid through the opening in the lid.

• Always place your hand on top of the blender when you are operating the device.

• Be careful when processing hot liquids.

• For stirring solid or very thick liquid ingredients we recommend that you use the blender in impulse mode to prevent the blades from becoming stuck. Cleaning and Care

• Never immerse the Housing in water. Wipe it only with a moist cloth.

• Empty the glass jar and fill it with water. Place the glass jar on the Housing and turn the switch to “P” setting several times. Empty the glass jar and rinse until clean.
