sGo One - Docking station JAYS - Free user manual and instructions

USER MANUAL sGo One JAYS

Getting started, safety and warranty

USERGUIDE-INDEX

Thank You!

Welcome to the new world of JAYS speakers.

Designed and developed with elegance and simplicity as key factors by our Scandinavian team.

Our s-Go line are all wireless speakers using the newest Bluetooth technology, so that music can be enjoyed in many different settings.

We are very excited to present our new speaker line and hope you will enjoy the divine sound performance.

Enjoy, Henrik Andersson CEO,JAYS

EN: User guide in English. 4-9
DK: Brugervejledning på dansk. 10-15
SE: Bruksanvising på Svenska. 16-21
DE: Benutzerhandbuch auf Deutsch. 22-27
FR: Guide d'utilisateur en français. 28-33
EU Declaration of Conformity 34
North American Compliance Information. 35

Check our website for user guide in other languages

Getting started, safety and warranty

CONTENTS

1 x JAYS s-Go One speaker.
1 x Protective pouch.
1 x Micro USB to USB cable for charging only.
1 x User Guide in multiple languages.

ENGLISH - 54-E

CONTROLLING YOUR NEW JAYS S-GO ONE

HOW TO USE YOUR NEW JAYS S-GO ONE

POWER ON/OFF

Press and hold power button for 2 seconds to power ON your s-Go One speaker. You will hear a welcome tone once powered ON. Your speaker will automatically try to connect to the last device used (if any). Press again for 2 seconds and your speaker will power OFF.

Power button with LED indication (Will be RED during charging)

PAIRING/ CONNECTION

If you want to pair a new device with your s-Go One then your speaker must be put into pairing mode first.

Microphone

Micro USB for charging only

When your speaker is powered ON it will automatically be in both Pairing, and Connection mode for 5 mins. In this period, you are able to pair any new devices or re-connect already paired devices. If your speaker is already powered ON you can double press the power button for enabling Pairing Mode again. When your speaker enter pairing mode you will also hear the message "Waiting for connection" and your speaker will now be visible on your Bluetooth device list. When successfully paired/connected, speaker will reply "Time to play".

VOICE CALLS

JAYS s-Go One has built-in mic. for handfree operation during calls. Calls can be accepted from your device, or s-Go One by pressing the Power button once.

ENGLISH-76-E

MAIN TECHNICAL SPECIFICATIONS

IMPORTANT INFORMATION

GENERAL POWER SAVING

Power input 5V DC via micro USB cable (included). Use USB power source.
Product dimensions. 205mm(L) 33mmH)54mmDWeight 275g
Main chipset, Actions RL6988.
- Microphone embedded for enabling handsfree voice calls.

PRODUCT DESCRIPTION

• Portable lifestyle Bluetooth speaker with built-in battery and microphone.
• Stereo speaker with bass enhancement passive radiator.

TECHNICAL SAFETY

• Amplifier 2 x 3W stereo Amp with DSP function.
  Bluetooth v4.2. Profile A2DP1.3/HFP1.7/HSP1.1/AVRCP1.6 (SBC codec).
  Battery Li-ion 2200mAh (3,7V), up to 10 hours playback at around 40% volume.
• Battery charge time from zero to full approximately 3 hours.

JAYS s-Go One will go to standby mode automatically, after 20 mins of no usage or after 5 mins if no device has been connected. This is according to regional regulations and to save battery power.

WARRANTY

Your JAYS s-Go One is of cause covered by warranty according to regional laws, depending on country of purchase. Please always consult your local dealer for warranty issues.

• Only use compatible USB power source to charge the device.
• Do not use s-Go One in wet or dusty environments as it might damage your device and void warranty.
• JAYS s-Go One should not be used in direct sunlight. Damages caused by sunlight or severe heat will risk voiding your warranty.
  JAYS s-Go One has built-in Li-ion battery. Please carefully check rules in your country for safe and correct handling and disposal.
• The battery must not be exposed to excessive heat such as direct sunlight, fire or the like.
• Never try to open or repair JAYS s-Go One. It will void warranty.

PAKKENS INDHOLD

DANSK

EU DECLARATION OF CONFORMITY

NORTH AMERICAN COMPLIANCE INFORMATION

JAYS Group AB

Nellickevagen 22

412 63 Goteborg

Sweden

Hereby declare that JAYS s-Go One portable Bluetooth speaker (Item: SGO101):

Comply with European CE-RED Directive 2014/53/EU, standards:

ETSI EN 301 489-1 V2.1.1 (2017-02), (EMC)

ETSI EN 301 489-17 V3.1.1 (2017-02), (EMC)

ETSI EN 300 328 V2.1.1 (2016-11), (RF)

ETSI EN 60065:2014+A11:2017, (LVD)

Comply with European RoHS Directive 2011/65/EU.

Göteborg, Sweden, August 2019

René Larsen

Head of Product Development

3435

FCC ID COMPLIANCE

This device complies with part 15C of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.

IC ID COMPLIANCE

This device contains license-exempt transmitter(s) / receiver(s) that comply with Innovation, Science and Economic Development Canada's license-exempt RSS(s).

Operation is subject to the following two conditions:

1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.

FCC ID:2AJOO-SGO101

IC:21829-SGO101

Model: s-Go One

s-Go One

Getting started, safety and warranty

User Guide Rev. 1.1 for JAYS s-Go One, Bluetooth speaker

We accept no liability for printing errors.

Specifications are subject to change without notice. JAYS 2019

www.jaysheadphones.com
