BLP0219 - Wireless Charger BLAUPUNKT - Free user manual and instructions

Brand	Blaupunkt
Model	BLP0219
Product type	Induction wireless charger
Dimensions (approx.)	Diameter 100 mm, height 10 mm
Weight (approx.)	80 g
Input power supply	5 V ⎓ 2 A
Output power supply	5 V ⎓ 1 A
Maximum power	10 W
Charging distance	4 to 6 mm between coils
LED indicators	Blue (charging), green (standby/charged)
Main functions	Wireless charging for Qi-compatible phones
Care and cleaning	Unplug before cleaning; use a dry, soft cloth
Safety	Do not expose to water; leave 10 cm of free space around; do not place metal objects or magnetic cards on the charger
Spare parts and repairability	The power adapter is not repairable; contact the manufacturer if malfunction occurs
Warranty	2 years (according to applicable law)
General information	Induction charger; household use only; compliant with WEEE directive

Frequently Asked Questions - BLP0219 BLAUPUNKT

Which phones are compatible with the BLP0219 charger?

The charger works with any phone compatible with the Qi standard. Check that your phone supports wireless charging.

Why isn't my phone charging?

Make sure the phone is centered on the charging area and that the distance between coils does not exceed 4-6 mm. Remove thick cases or metal objects.

What do the LED indicators mean?

When powered on, the LEDs flash blue and green then stay green in standby. While charging, they flash blue. Charging complete: steady green.

Can I use a thick protective case?

It is not recommended to use a case thicker than 4 mm, as it may prevent charging. Magnetic or metal cases should be avoided.

What is the maximum charging power?

The maximum power is 10 W, but the actual output depends on your phone. The charger delivers 5 V / 1 A.

Is the charger safe for non-compatible devices?

Yes, if no phone is detected, the charger stays in standby. Do not place metal objects (coins, keys) on the surface to avoid overheating.

How to clean the charger?

Unplug it before cleaning. Use a soft, dry cloth. Do not use liquid or abrasive products.

What to do in case of malfunction?

The damaged power cable must be replaced by the manufacturer or a professional. The adapter is not repairable. Contact customer service.

Can I leave the charger plugged in permanently?

Yes, in standby the power consumption is very low. However, for safety reasons, unplug it during a storm or prolonged absence.

Is the charger compatible with recent iPhones?

Yes, iPhone models from iPhone 8 onwards support Qi charging, so they are compatible with this charger.

USER MANUAL BLP0219 BLAUPUNKT

All rights reserved. All brand names are registered trademarks of their respective owners. Specifications are subject to change without prior notice.

BLAUPUNKT

User manual

Enjoy it.

Induction charger

BLP0219-001

Safety Precautions

Read these safety instructions before using your device and store them for possible future reference.

• If the charger cord is damaged, have it repaired by the manufacturer, its service or a similarly qualified person in order to avoid any hazard.
• The power supply must be replaced by a new one in case of malfunction, because this power supply is not repairable.
• The charger is not intended for use by persons (including children) with reduced physical, sensory or mental capacity. Persons who have not read the manual, unless they have received explanations by a person responsible for their safety and supervision should not use this unit.
• Children should be monitored to ensure that they do not play with the charger.
• The charger should always be readily accessible.
• The device should not be exposed to dripping or splashing water.
• No objects filled with liquids such as vases shall be placed on the device.
• Always leave a minimum distance of 10 cm around the unit to ensure sufficient ventilation.
• Open flame sources, such as candles, should not be placed on top of the device.
• The device is intended for use only in a temperate climate.

Specifications of the product

Input: DC 5V = 2A

Output: DC 5V = 4A

Max consumption: 10W

Product Induction

Charging sensing distance: The distance between the magnetic-induction coil built in the mobile phone and the magnetic-induction coil built in the wireless charger should be 4-6mm. Please do not use a thick phone case when using this product.

Directions for use

1. When the wireless charger is connected to the charger, the LED lights around the circle are displayed in a blue-green interval, and after 3 seconds, it is converted into a circle of green. At this time, the charger enters the standby state and can charge the mobile phone.
2. When a mobile phone that supports wireless charging is placed, a circle of LEDs around the wireless charger is converted to a blue breathing light state, which indicates that the mobile phone is being wirelessly charged.
3. When the phone is fully charged, a circle of LEDs around the wireless charger is converted to green.

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE) requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment. The crossed-out "wheeled bin" symbol on the product reminds you of your obligation that when you dispose of the appliance, it must be separately collected.

Imported by Dag Technologie®

79/81 Ancienne Route Nationale 7

69570 Dardilly

FRANCE

BLAUPUNKT

Enjoy it.

Dag Technologie®

79/81 Ancienne Route Nationale 7

69570 Dardilly - France

All rights reserved. All brand names are registered trademarks of their respective owners. Specifications are subject to change without prior notice.
