KA CP 10 - Cooker KALORIK - Free user manual and instructions

Brand	KALORIK
Model	KA CP 10
Product type	Double electric hot plate
Dimensions (approx.)	50 x 30 x 8 cm
Weight (approx.)	2.5 kg
Power supply	220-240 V ~ 50/60 Hz
Total power	2000 W (2 x 1000 W)
Number of plates	2 electric plates
Controls	2 rotary knobs (continuous temperature adjustment)
Main functions	Cooking, reheating, keep warm
Residual heat	The plates remain hot after switching off
Plate material	Enameled steel or cast iron (not specified)
Recommended cookware type	Double-bottom utensils, suitable for electric plates
Care and cleaning	Wipe with a soft cloth or paper towel after cooling. Do not immerse, do not use abrasive products.
Safety	Never leave unattended, do not use near flammable materials, do not immerse in water, unplug after use.
Plugs and cable	Removable power cable (not specified), mains plug
Spare parts and repairability	Contact a qualified competent service (manufacturer or importer after-sales service)
General information	Household use only, do not use with an external timer

Frequently Asked Questions - KA CP 10 KALORIK

How to clean the KA CP 10 stove?

Unplug the appliance and wait for it to cool completely. Wipe the plates and the housing with a soft cloth or paper towel. Never use abrasive products and never immerse the appliance in water or any other liquid.

What types of pots can I use?

Only use pots or pans with a double bottom, designed for electric plates. The diameter should not be smaller than that of the plates to avoid heat loss.

Can I use the stove outdoors?

No, the appliance is designed for indoor household use only. Do not use it outdoors and store it in a dry place.

What to do if the power cord is damaged?

If the cable is damaged, it must be replaced by a qualified competent service (manufacturer or importer after-sales service) to avoid any danger.

How to use residual heat?

The plates continue to heat after switching off. You can take advantage of this residual heat to reheat food or keep warm without energy consumption.

Can I leave the appliance plugged in permanently?

No, always unplug the appliance after use, especially if it does not have an ON/OFF switch. Never leave it unattended while it is operating.

What to do if a crack appears on the plate?

Immediately disconnect the appliance and have it checked by a qualified competent service. Do not use the appliance again until it has been repaired.

How to dispose of the appliance at the end of its life?

Do not throw the appliance in the household waste. Deposit it at a public collection point for recycling or reuse in accordance with Directive 2002/96/EC.

Can the stove be used with an external timer?

No, the appliance must never be operated via an external timer or remote control system. This could be dangerous.

What is the procedure for first use?

Before first use, heat the appliance for 10 minutes to set the protective varnish on the plates. Turn off and let cool. Then you can use it normally.

USER MANUAL KA CP 10 KALORIK

Please read these instructions carefully before using the appliance.

Important: People (including children) who are not able to use the appliance in a safe way, due to their physical, sensorial or mental capacity or their lack of experience or knowledge, must never use the appliance except if they are supervised by a person responsible for their safety or if they previously received instructions concerning the safe use of the appliance. Close supervision is necessary to prevent children from using the appliance as a toy.

Check that your mains voltage corresponds to that stated on the appliance.
Never leave the appliance unsupervised when in use.
From time to time check the appliance and its cord for damages. Never use the appliance if cord or appliance shows any signs of damage. All repairs should be made by a competent qualified electrician*).
Only use the appliance for domestic purposes and in the way indicated in these instructions.
Never immerse the appliance in water or any other liquid for any reason whatsoever. Never place it into the dishwasher.
Never use the appliance near hot surfaces.
Before cleaning, always unplug the appliance from the power supply.
Never use the appliance outside and always place it in a dry environment.
Never use accessories which are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.
Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.
Stand the appliance on a table or flat surface.
Make sure the appliance has cooled down before cleaning and storing it.
Make sure the cord never comes into contact with the hot parts of the appliance.
The temperature of the accessible surfaces may be very high when the appliance is in use. Never touch those surfaces during use, and only handle the buttons. Should the

symbol 1e indicated on a certain surface, you need to be careful when handling the product. This symbol means CAUTION, this surface may get very hot during use.

Make sure the appliance never comes into contact with inflammable materials, such as curtains, cloth, etc... when it is in use, as a fire might occur.
Always unplug the appliance when it is not in use, especially since it is not equipped with an on/off switch.
Be extremely careful, as oil or fat preparations might catch fire when overheated.
When using the appliance under an extractor hood, make sure to observe the minimal distance advised by the producer. It is even wiser to double this distance.
Only use the appliance for food that is supposed to be cooked.
- Immediately unplug the appliance if a crack appears and make sure it is controlled by a qualified competent electrician.
- Your appliance must never be switched on through an external timer or any kind of separate remote control system.

USE

• First check that the voltage marked on the product is the same as your supply voltage.
• Select a suitable position close to an electric socket, on a dry and even surface.
  Make sure the controls are in the OFF position (MIN). Plug in.
• The invisible protective coating must be removed before you can use the appliance. To do this, set the controls to the maximum setting and leave switched on for approximately 10 minutes. Smoke will develop, make sure that the room is ventilated. Switch off the cooking plates and allow to cool down completely. The cooking plates are now ready for use.
  Always use flat-bottomed saucepans, which make good contact with the cooking plates. The saucepan bases should ideally be of the same size as the cooking plates.
• Select the temperature. The cooking plates have a range of temperatures.
  Due to the cooking plates' construction, residual heat will remain after switching off. This may be used to keep food warm for a short period.
  After use, turn temperature dial to "MIN" and unplug the appliance from electrical outlet.

CLEANING

• Before cleaning, unplug and wait for the appliance to cool down.
• Wipe with a moistened cloth.
  Do not clean with any abrasive scouring pad or steel wool, as this will damage the finish.
• Do not immerse in water or any other liquid.

PROTECTION OF THE ENVIRONMENT-DIRECTIVE 2002/96/EC

In order to preserve our environment and protect human health, the waste electrical and electronic equipment should be disposed of in accordance with specific rules with the

implication of both suppliers and users. For this reason, as indicated by the symbol the rating label or on the packaging, your appliance should not be disposed of as unsorted municipal waste. The user has the right to bring it to a municipal collection point performing waste recovery by means of reuse, recycling or use for other applications in accordance with the directive.

FR MODE D'EMPLOI

POUR VOTRE SECURITE
