USER MANUAL 59 Titanium ARCHOS

Consult the declaration of conformity on http://www.archos.com/ products/declaration_conformity.html ARCHOS_59_Titanium_book.indd 1 17/11/2014 16:42:332 Package Contents Check your product box for the following items: - ARCHOS 59 Titanium - Battery - Headset - Micro SIM adaptor - USB cable - Charger - Quick start guide - Warranty Legal & Safety notices The items supplied with your device and available accessories may vary depending on your region or service provider. The supplied items are designed only for your device and may not be compatible with other devices. Unapproved accessories may cause your device to malfunction. ARCHOS_59_Titanium_book.indd 2 17/11/2014 16:42:333

31-07-2014Removed the power and volume buttons, defined middle casing. last modification:CONFIDENTIAL CMF Rev

Description of the phone

31-07-2014Removed the power and volume buttons, defined middle casing. last modification:CONFIDENTIAL CMF Rev

Description of the phone

Search Back Menu: open the list of options available on the current screen. Home/Recent apps/Google NOW: short press to return to the Home screen; double press to open the list of recent applications; long press to access Google Now. Back: return to the previous screen.. ARCHOS_59_Titanium_book.indd 5 17/11/2014 16:42:356 Assembling Opening

1. Use the notch to remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage the cover.

2. Remove the battery.

Inserting a SIM card For your SIM card, slide it facing downwards in the slot 1 or 2. Inserting a Memory card For your Memory card, slide it facing downwards in the slot 3. Closing

1. Align the battery’s 4 contact points with those of the phone and gently

press the battery down into place.

2. Replace the back cover clicking it back into position.

Tip: Before using your device for the first time, charge completely its battery. ARCHOS_59_Titanium_book.indd 6 17/11/2014 16:42:357 Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position

Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position

1. Press and hold the ON/OFF button to turn on the device.

When you turn on your device, a PIN code may be requested.

2. Type the PIN code supplied with your SIM card.

Beware of typing a wrong PIN code.

Through the wizard The rst time you start up your ARCHOS, the installation wizard will help you set up your device: - Language - Date & time - WiFi connection - Location service options Turn OFF To turn o your device, press and hold the ON/OFF button, and then select Power o > OK. Getting started ARCHOS_59_Titanium_book.indd 8 17/11/2014 16:42:359

1. When the device is turned on, press

Touch screen actions: Tap: touch once to select or launch a menu, option, or application. Tap and hold: tap an item and hold it for more than 2 seconds. Drag: tap an item and move it to a new location. Double-tap: tap an item twice quickly. Flick: briskly scroll up, down, left, or right to move through lists or screens. Pinch in/out: place two of your ngers far apart, and then pinch them together. Tip: Your device goes in standby mode when you do not use it for a specified period of time. To wake up your device, press the ON/OFF button. To set the duration, go to Settings > Display > Sleep. Silent Vibrate Sound ARCHOS_59_Titanium_book.indd 9 17/11/2014 16:42:3510 3G connection With your SIM card, you should be connected to the Internet without any further setup. The ARCHOS will only have signal if you are in an area covered by your provider’s 3G network. When connected to the 3G network, the 3G icon is displayed in the status bar. Activating the mobile data 3G & WiFi connection To be able to access Internet, the mobile data icon must be activated.

1. Touch and hold the time & battery icons to reveal

4. Touch the mobile data icon to activate it.

WARNING: Make sure that you are in a WiFi zone. You can access the WiFi

settings quickly from the status bar.

1. Touch and hold the time & battery icons to reveal

4. Touch the “Settings” icon to open the settings

5. In the “Wireless & networks”section, if the WiFi is

o, slide the WiFi switch to the “ON” position. Once the WiFi is on, the ARCHOS will scan for WiFi networks in range.

6. Touch “WiFi” to display available networks.

7. Touch the name of network you want to connect to.

Private networks are shown with a lock icon and will require you to enter your password. ARCHOS_59_Titanium_book.indd 11 17/11/2014 16:42:3712 Adding a Google account A Google account lets you take full advantage of any Google apps and services that you may want to use.

1. Go to “Settings” > “Accounts” > “Add account”.

2. Select the account type “Google” to add.

3. Follow the onscreen instructions to enter information about the account.

Once the account is created, you can access Play Store, Gmail, Hangouts, Maps and many other apps. Synchronizing info Information must be sync to be saved. Your data is backed up on Google servers.

1. Go to “Settings” > “Accounts” > “Google”.

2. Select your account.

The list of information that can be sync are displayed. Automatic sync should be activated. To launch the sync, press the Menu button, then Sync now. You can get them back in case of loss of your device or SIM card. When your Google account is added to a new device, all your saved information is transferred. Google & Contacts ARCHOS_59_Titanium_book.indd 12 17/11/2014 16:42:3713

Saving your contacts When your contacts are saved, they are always available on the web and can be synced to any Android phone that’s set up with your Google account.

1. Install the SIM card with your contacts in your phone.

2. From a Home or All Apps screen, select the People app .

3. Touch the Menu button > “Import/Export”.

4. In Import/export contacts, select “Import from SIM card”.

5. Select your Google account.

6. Check contacts to be imported and validate.

7. Once the contacts are imported in the Google account, go to “Settings” >

“Accounts” > “Google”.

8. Select you Google account.

9. Select the Menu button, then “Sync now”.

Your contacts are saved to via your Google account. ARCHOS_59_Titanium_book.indd 13 17/11/2014 16:42:3714 The extended home screen: You have by default one home screen. You can create as many home screens you want. Select an app icon and slide it right. A new home screen will be created. Select another app icon and slide it right to create a third home screen. Moving a home screen item: Touch and hold your nger onto it until the positioning gridlines appear, then slide it to the desired location, and release your nger. Removing a home screen item: Touch and hold it, slide your nger towards the top of the screen and drop it over the "Remove" icon. Uninstalling an item: From the "All apps" screens, touch and hold it, slide your nger towards the top of the screen and drop it over "Uninstall" bin. Hints & tips for Android

Creating application folders: Drop one app icon over another on a home screen and the two icons will be combined. Widgets: Touch and hold your nger on your home screen. Touch “Widgets”. Changing your wallpaper: Hold your nger on a home screen at an empty location, then choose from the list. Locking the touchscreen: From the quick settings dashboard in the status bar, touch “Settings”. In “Settings”, scroll down and touch “Security”. Touch “Screen lock”. Touch the type of lock you would like to use. After you set a lock, a lock screen is displayed whenever your screen wakes up, requesting the pattern, pin or other specied key. ARCHOS_59_Titanium_book.indd 15 17/11/2014 16:42:3716 Troubleshooting My phone is frozen or cannot switch on Check the battery contacts, remove and reinstall your battery, then turn your phone on. Check the battery power level, charge for at least 20 minutes. My phone cannot connect to a network or “No service” is displayed Try connecting in another location. Verify the network coverage with your operator. Unable to make outgoing calls Make sure your phone is connected to a network, and the network is not overloaded or unavailable. Unable to receive incoming calls Make sure your phone is switched on and connected to a network (check for overloaded or unavailable network). SIM card PIN locked Contact your network operator to obtain the PUK code (Personal Unblocking Key). To configure a new 3G network: On your device, tap Settings. Select Wireless & networks > More... > Mobile networks. Select Network settings. In Network operators, select your operator. In Access Point Names, select the correct access point name and enter the exact connection parameters provided by your 3G provider. ARCHOS_59_Titanium_book.indd 16 17/11/2014 16:42:3717
