Product Type	2.1 Speaker System
Brand	Krator
Model	N220020
Output Power	20 watts RMS (THD = 10%)
Bandwidth	70 Hz - 20 kHz
Input Impedance	20 kOhms
Transducers	2 x 7.62 cm (3") bullet-shaped, paper-wool dome
Cabinet Material	9 mm MDF panel
Dimensions (Main Cabinet)	W125 x H196 x D146 mm
Weight	3.5 kg
Power Supply	110-240 V, 50/60 Hz
Power Indicator	Blue LED
Audio Input	RCA (via included 3.5mm Jack to RCA cable)
Audio Output	3.5mm Headphone Jack
Controls	Volume, Bass/Treble
Certifications	CE, FCC, BSMI, PSE
Package Contents	2 satellite speakers, 3.5mm Jack to RCA audio cable, user manual, warranty card
Safety	Do not open the cabinet, do not expose to rain or moisture, use on protected mains
Maintenance	Clean with a soft, dry cloth. Do not use abrasive products.
Warranty	Unauthorized disassembly voids the warranty. For any repairs, contact a professional.

Frequently Asked Questions - N220020 Krator

How to connect the speakers to my computer?

Use the included audio cable (3.5mm Jack to RCA). Plug the Jack into the computer's audio output and the RCA plugs into the subwoofer's audio input (RCA Audio Input).

Why is there no sound?

First check the power: the blue LED indicator should be on. Then check that the audio cable is properly connected at both ends. If the sound still lacks, contact your retailer.

What to do if the sound is intermittent?

This may be due to excessive current. Try lowering the volume. If the problem persists, check the connections and audio source.

How to adjust volume and bass/treble?

Use the knobs on the subwoofer: the Volume Control knob for overall volume, and the Bass/Treble Adjustment knob to adjust bass and treble.

Can I connect headphones to this system?

Yes, the subwoofer has a 3.5mm Headphone Jack. Plug in your headphones for private listening.

What is the power of this speaker system?

The maximum output power is 20 watts RMS (with total harmonic distortion of 10%).

How to clean the speakers?

Use a soft, dry cloth to wipe dust. Do not use chemical or abrasive products, and do not let moisture enter the speakers.

Can I repair the device myself in case of failure?

No, do not attempt to open the cabinet. There are no user-serviceable or replaceable parts inside. Unauthorized disassembly voids the warranty. Contact a professional.

What types of cables are included in the package?

The package includes a 3.5mm Jack to RCA audio cable to connect the audio source to the subwoofer.

What to do if one of the satellite woofers produces no sound?

Check the connection between the left and right satellite woofers. Make sure the cables are properly plugged. If the problem persists, contact your retailer.

USER MANUAL N220020 Krator

English User's Guide 02

Safety Instruction Safety Instruction

Thank you for choosing KRATOR. This speaker set from KRATOR will bring you the surround and real sound no matter you are playing games, listening to music, or watching a rental movie. Please briefly read through the following instruction before installation.

Warning:

• Do not expose this product to rain or damp environment to prevent it from electric shock or fire.
• Do not place this product near any Hammable source, fluorescent lighting or neon light.
  ■ The wires and cables of this product must not be pressed, squeezed or stepped to avoid large complications.

damage or malfunction.

Precautions:

• Do not change the accessories provided by this product package.
• Please keep a 4-inches distance between the subwoofer speaker and magnetic materials(tape or floppy disk)
  to prevent disruption of sound or data
  ■ Please use dry, soft cloth if you need to clean this product.
• Please try not to operate this product on excessively high volume for the longevity of the product.
  • This product is CE, FCC and BSMI, PSE certified.

Reminder:

- The warranty is not provided if you disintegrate or take this product apart without permission.

Attention: be careful with the high voltage inside the housing of this product to avoid electric shock.

Please do not try to open the housing to avoid electric shock or injury. There is no parts for replacement. If you require any maintenance or repair services, please contact the professionals.

Please pay attention to the instruction and warnings for this product.

KRATOR

KRATOR®

English

English

Package Contents Package Contents

As you unpack the package, please make sure that all parts shown in this page are included inside.

- 20 watts speakers - 3.5mm to RCA audio cables

- User Manual - Warranty card

KRATOR

KRATOR®

English

English

Product Features Product Features

① All wood enclosure, using 9mm thickness MDF board, which delivers best resonance.
② 3 inch unit wool mixed paper core driver with reinforced bass performance.
3 Bullet-head design on 3 inch drivers provide pointing precision of each sound.
4 A 3.5 mm audio phone jack for connecting to your headphones.
⑤ Extreme low-noise Hi-Fi circuit design.
⑥ Volume control.
⑦ Professional quality performance crossover.

• Max power output: 20 watts R.M.S.(THD=10%)
- Speaker Driver: 3 bullet-head driver x 2
• Impedance: 20k ohm
• Frequency range: 70\~20 KHz
• LED Power Indicator: Blue
• Audio Input: 3.5mm to RCA audio cable
• Audio Output: 3.5mm Headphone Jack
• Power supply: 110V\~240V, 50/60 Hz
• Dimension: Speaker Cabinet /W125*H196*D146 mm
• Weight: 3.5Kgs

KRATOR

The specifications above are subject to change without prior notice

KRATOR®

English

Troubleshooting

If you encounter the following problems, please read through the instructions below. If problem still remains, please contact the local retailer where you purchased the product for assistance. Please do not attempt to do it yourself to avoid electric shock or further damage.

Problems	Possible causes	Solutions
No sound	1. Power adapter not plugged properly. Please re-plug it. 2. If you have properly plugged the power, please check the LED indicator. 3. Improper plug of audio cable. Please re-plug it again.	If it's the second causes mentioned at the left, please contact your local retailer for maintenance and repair.
Disrupted sound	Excessive flow of voltage	Adjust to the appropriate volume
No sound for one of the woothers	Improper connection of the woothers	Check the connection between the left and the right satellite woothers.
Improper sound or low frequency noise	1. the inputs were not connected properly 2. This product is made for high resolution sound. If the music file is compressed with noise, or there is the problem with the cables of MP3 player/computer, the noise will appear.	1. Please check the connection for the cords and cables. If all the cords and cables are linked appropriately, it is recommended to lower the volume to reduce the noise. 2. Switch to another audio source, such as CD player or another song to see if the noise still exists.

• Max power output: 20 watts R.M.S.(THD=10%)
- Speaker Driver: 3" bullet-head driver x 2
• Impedance: 20k ohm
• Frequency range: 70\~20 KHz
• LED Power Indicator: Blue
• Audio Input: 3.5mm to RCA audio cable
• Audio Output: 3.5mm Headphone Jack
• Power supply: 110V\~240V, 50/60 Hz
• Dimension: Speaker Cabinet /W125*H196*D146 mm
- Weight: 3.5 Kgs

KRATOR®
