BTA6001 - Radio BLAUPUNKT - Free user manual and instructions

Brand	Blaupunkt
Model	BTA6001
Product type	Desktop/portable analog radio
Mains power supply	230 V AC, 50 Hz
Battery power	4 x 1.5 V batteries type R14/UM2/C (not included)
Frequency bands	FM 87.5 - 108 MHz, MW 530 - 1600 KHz
FM antenna	Telescopic
MW antenna	Built-in ferrite
Speaker	Built-in
Headphone jack	3.5 mm jack
AUX IN jack	3.5 mm jack
Controls	Volume, tuning, on/off, band selector
Additional functions	Carrying handle, listening via speaker or headphones
Safety	Do not open the casing, avoid moisture, do not obstruct ventilation
Maintenance	Clean with a dry, soft cloth
Included accessories	Detachable mains power cord
Compatibility	Auxiliary sources (MP3 player, etc.)

Frequently Asked Questions - BTA6001 BLAUPUNKT

How to turn on the radio?

Slide the ON/OFF switch to the ON position. The radio turns on and you can select the desired band.

What types of batteries to use?

Use 4 x 1.5 V batteries type R14/UM2/C (not included). Observe the polarities shown in the compartment.

How to improve FM reception?

Fully extend the telescopic antenna. For MW, rotate the device horizontally for optimal reception.

Can I connect my smartphone?

Yes, connect your smartphone or other audio source to the AUX IN jack (3.5 mm) and set the band selector to AUX IN.

How to clean the device?

Unplug the device and use a dry, soft cloth. Do not use chemical or abrasive products.

What to do if no sound comes out?

Check that the device is on, the volume is sufficient, and the source is correctly selected (FM/MW/AUX). If using headphones, ensure they are properly connected.

Is it possible to use headphones?

Yes, connect headphones (not included) to the 3.5 mm headphone jack. Excessive sound pressure can damage hearing.

What is the required mains voltage?

The device operates on 230 V AC, 50 Hz. Use only the supplied power cord.

How to switch between FM and MW?

Use the band selector FM/MW/AUX IN located on the front panel. Set it to FM or MW according to the desired band.

What to do in case of malfunction?

Turn the device off and on (ON/OFF cycle). If the problem persists, unplug the mains power and remove the batteries for a few minutes. If this does not solve the problem, contact a qualified repair service.

USER MANUAL BTA6001 BLAUPUNKT

USER MANUALS
Models: BTA-6000 / BTA-6001

Page 2	German
Page 5	English
Page 8	French
Page 11	Italian
Page 14	Spanish
Page 17	Portuguese
Page 20	Dutch
Page 23	Swedish
Page 26	Danish
Page 29	Finnish
Page 32	Norwegian
Page 35	Russian
Page 38	Greek
Page 41	Turkish
Page 44	Polish
Page 47	Bulgarian
Page 50	Romanian
Page 53	Czech
Page 56	Hungarian
Page 59	Japanese
Page 62	Chinese
Page 65	Arabic

Please read the instrucons carefully before operang the unit.

GENERAL CONTROLS

1. Tuning control
2. Dial scale
3. Dial pointer
4. VOLUME control
5. Carrying handle
6. Speaker
7. FM telescopic antenna
8. Baery compartment
9. AC socket (\~ AC IN)
10. FM/MW/LINE IN selector
11. ON/OFF switch
12. Earphone jack
13. LINE IN jack

POWER SUPPLY

This set operates on AC 230\~50Hz or 4 x 1.5 V R14/UM2/"C" size baeries (not provided).

AC operaon

Connect the detachable AC cord (included) to the AC socket on the rear of the unit, Insert the AC power cord into a convenient AC wall outlet.

DC operaon

1. Remove the lid of the baery compartment.
2. Insert 4 R14/UM2/"C"size batteries into the compartment. Make sure to match their polaries (+/-) to the markings inside the compartment.
3. Put the lid back in place.

Note:

-The AC cord must be unplugged from both the socket on the unit and the power outlet for the unit to run on the baeries.

- When the set is connected to the mains, the power source automacally switches to AC.

Notes on baeries (not supplied)

- Do not mix dierent types of baeries or old baeries with new ones.

·Never recharge the baeries, apply heat to them or take them apart.

·Baeries shall not be exposed to excessive heat such as sunshine, re or the like.

- Do not throw the baeries in re!

·Aenon should be drawn to the environmental aspects of baery disposal.

The baeries need to be replaced when: The volume decreases, or sound is distorted during operaon.

·In order to avoid leakage, remove the baeries when unit will not be used for a long period of me.

- Please respect the environment. Before throwing any baeries away, consult your distributor who may be able to take them back for specific recycling.

CAUTION:

Danger of explosion if baeries are incorrectly replaced. Replace only with the same or equivalent type.

USING THE RADIO

1. Slide the ON/OFF switch to "ON" posion to turn on the radio.
2. Use the FM/MW/LINE IN selector to select band.
3. Use the Tuning control to tune to your desired radio staon.
4. Adjust the volume level.
5. Slide the ON/OFF switch to "OFF" posion to turn o the radio.

To enhance radio recepon ability:

FM: Extend the telescopic antenna.

MW: Rotate the unit horizontally for opmum recepon.

CONNECTING LINE IN SOURCE

1. Connect your LINE IN source (e.g. mp3 player) to the LINE IN jack on the le side of the unit.
2. Slide the FM/MW/LINE IN selector to LINE IN posion.
3. Start playback from your LINE IN source.
4. Adjust the volume to desired level.
5. To stop playback, disconnect your LINE IN source from the LINE IN jack.

PRODUCT INFORMATION

Power consumpon: 5W

Frequency Range:

FM 87.5-108.0 MHz

MW 530-1600 KHz

LISTENING WITH EARPHONES

Connect earphones (not included) to the earphone jack on unit.

Connuous use of earphones at high volume can damage the user's hearing.

SAFETY INSTRUCTION

CAUTION: To reduce the risk of electric shock, do not remove the cover (or back). There are no

user serviceable parts inside the unit. Refer all servicing to qualify personnel.

The lightening ash with arrowhead symbol within the triangle is a warning sign alerng the user of “dangerous

voltage" inside the unit.

The exclamaon point within the triangle is a warning sign alerng the user of important instrucons accompanying product.

IMPORTANT!

• The venlaon should not be impeded by covering the openings with items such as newspapers, table-cloths, curtains, etc.
• No naked ame sources, such as lighted candles, should be placed on the apparatus.
• The use of apparatus in moderate climates.
• The apparatus should not be exposed to dripping or splashing.
• Ensure a minimum distance of 5cm around the apparatus for sucient venlaon.
• Do not place objects lled with liquids, such as vases, on the apparatus.
• The rang plate is located at back of unit.
  -Excessive sound pressure from earphones and headphones can cause hearing loss.
• Mains plug is used as the disconnect device and it shall remain readily operable. To be completely disconnected the power input, the mains plug of the apparatus shall be disconnected from the mains completely. The mains plug should not be obstructed or should be easily accessed during intended use.
• Under the inuence of electrical fast transient or/and electrostac phenomenon, the product may malfuncon and require user to power reset.

If at any me in the future you should need to dispose of this product please note that Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. (Waste Electrical and Electronic Equipment Directive)

Note: Design and specicaon are subject to change without noce.

© 2011 All rights reserved by Blaupunkt. This material may be reproduced, copied or distributed for personal use only.

INFORMATIONS PRODUIT

Consommaon : 5W

1. Manopola Tuning
2. Scala sintonia
3. Lancea
4. Manopola VOLUME
5. Maniglia
6. Altoparlante
7. Antenna telescopica FM
8. Vano baerie
9. Presa CA
10. Seleore FM/MW/LINE
11. Interruore ON/OFF
12. Presa auricolare
13. Presa LINE

ALIMENTAZIONE

1. Inställningskontroll
2. Sierskala
3. Siervisare
4. VOLUME kontroll
5. Bärbart handtag
6. Högtalare
7. FM teleskopantenn
8. Baerifack
9. AC anslutning
10. FM/MW/LINE-IN väljare
11. ON/OFF strömbrytare
12. Hörlursuag
13. LINE-IN jack

POWER SUPPLY

1. Tuning kontrol
2. Dial scale
3. Dial pointer
4. VOLUMEN kontrol
5. Håndtag
6. Højtaler
7. FM Teleskopantennen
8. Baerirum
9. AC indgang
10. FM/MW/LINE valg
11. ON/OFF (TÆND/SLUK) knap
12. Hovedtelefon indgang
13. LINE in jack

STR∅MFORSYNING

ΤΡΟΦΟΔΟΣΙΑ

INFORMACJA O PRODUKCIE

Pobór mocy: 5W

INFORMATII DESPRE PRODUS

INFORMACE O PRODUKTU

Přikon: 5W

Rozsah frekvenční:

FM 87.5-108.0 MHz

MW 530-1600 KHz

POSLECH SE SLUCHÁTKY
