CDE-9881RB - Car stereo ALPINE - Free user manual and instructions

Product type	Car stereo with CD player, FM/MW/LW tuner, compatible with iPod and MP3/WMA/AAC files
Dimensions (H × W × D)	50 × 170 × 161 mm (front panel: 46 × 170 × 24 mm)
Weight	1.6 kg
Power supply	14.4 V DC (11–16 V allowed), negative ground 12 V
Maximum output power	50 W × 4
Preamp output voltage	2 V / 10 kΩ max
Sound adjustments	Bass ±14 dB at 60 Hz, treble ±14 dB at 10 kHz, balance, fader, subwoofer, high-pass filter, loudness compensation
Radio functions	RDS (AF, TA, TP, EON), memory for 30 stations (6 per band), automatic and manual seek, radio text
Tuner frequency ranges	FM: 87.5–108.0 MHz; MW: 531–1602 kHz; LW: 153–281 kHz
CD player	CD, CD-R, CD-RW; compatible with MP3/WMA/AAC; frequency response 5–20,000 Hz (±1 dB); signal-to-noise ratio 105 dB
Connectivity	Direct iPod connector (via KCE-422i), AUX+ input (for external player), front/rear/subwoofer RCA outputs, steering wheel remote control interface
Practical features	Detachable front panel, MUTE function, automatic dimmer, customizable illumination color (blue/red for this model)
Cleaning	Soft dry cloth; for stubborn stains, water only; discs: wipe from center outward with a soft cloth
Safety	Use only on 12 V negative ground vehicles; 10 A fuse; do not obstruct ventilation outlets; stop the vehicle for any lengthy operations
Maintenance and repairability	Do not attempt to repair yourself; contact an authorized Alpine dealer; spare parts available from Alpine after-sales service
Supplied accessories	Main unit, power cable, mounting sleeve, front panel case, rubber cap, hex bolt, M5×8 screws (4), instruction manual
General information	Brand: ALPINE; Model: CDE-9881RB; Category: Car stereo; Manual available in French (PDF)

Frequently Asked Questions - CDE-9881RB ALPINE

How to turn the CDE-9881RB car stereo on and off?

Press the SOURCE/ button to turn on the unit. To turn it off, press and hold SOURCE/ for at least 2 seconds.

How to adjust the volume?

Turn the rotary knob to increase or decrease the volume. The adjustment range is from 0 to 35.

How to remove and reattach the front panel?

Turn off the unit, press (OPEN) to open the panel, slide it to the left then pull. To reattach, insert the right side, align the grooves and push until it clicks.

How to store a radio station?

Select the band (FM1/FM2/FM3/MW/LW) and tune to the desired station. Press and hold a preset button (1 to 6) for at least 2 seconds to store it.

How to play MP3 files from a CD?

Burn MP3 files onto a CD-R/RW in ISO9660 format. Insert the disc with the label facing up; playback starts automatically. Use the ◀ or ▶ buttons to navigate between folders.

How to connect an iPod to this car stereo?

Use the FULL SPEED™ (KCE-422i) cable (sold separately) and plug it into the direct iPod connector. Set AUX+ SETUP to OFF in the SETUP menu.

What to do if a CD does not eject?

Press the ▼ button for at least 2 seconds to force ejection. If that doesn't work, press the RESET switch with a ballpoint pen, then try again.

How to clean the car stereo and discs?

For the unit, use a soft dry cloth. For discs, wipe from the center outward with a soft cloth. Do not use solvents or abrasive products.

How to adjust bass and treble?

Press AUDIO/RTN repeatedly to select BASS or TREBLE, then turn the rotary knob to adjust the level (from -7 to +7). You can also adjust the center frequency via BAND/TA.

What does the 'ERROR' display on the CD player mean?

This indicates a misinserted disc, irregularity, or mechanical problem. Remove the disc, check it is clean and perfectly round, then reinsert. If the error persists, contact your Alpine dealer.

USER MANUAL CDE-9881RB ALPINE

RDS MP3/WMA/AAC CD Receiver

CDE-9881R/CDE-9881RB

MP3

AAC

Made for iPod

• OWNER'S MANUAL

Please read before using this equipment.

777 Supertest Road, Toronto,

Ontario M3J 2M9, Canada

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

161-165 Princes Highway, Hallam

Victoria 3803, Australia

Phone [phone]

ALPINE ELECTRONICS GmbH

Frankfurter Ring 117,

80807 München, Germany

Phone [phone]

ALPINE ELECTRONICS OF U.K. LTD.

Alpine House

Fletchamstead Highway, Coventry CV4 9TW, U.K.

Phone [phone]

Installation et raccordements

Avertissement 25

Attention 25

Précautions 25

Installation 26

Raccordements 28

Mode d'emploi

AVENTISSEMENT

AVERTISSEMENT

Impossible de receivevoir les stations.

DIMENSIONS DU CHÂSSIS

Largeur 178 mm (7")

Installation et raccordements

Car Audio and Navigation Systems

GERÄTE-PASS

AUDIO SYSTEME

Filling in this Product Information Card is voluntary. If you fill in this card and send it to Alpine, your data will be tabulated into reference data for future Alpine product development. In addition, in the future you may receive information about new products or Survey Mail requesting additional opinions about Alpine products or services. If you agree to the above term, please sign your name in the indicated space and return the card. Any additional comments or inquiries may be sent to: Person in charge of Customer Service department Alpine Electronics (Europe) GmbH. Frankfurter Ring 117, 80807 München, Germany Phone: [phone]

Deutsch

Q1.PRODUCT PURCHASED

1. Cassette Player

2. CD Player

3. MD Player

4.DVD Player

1. CD Changer

2. Amplifier

3. Speaker

4. Subwoofer

5. Monitor Controller

6. Video Monitor

7. Navigation

8. Processor/Equalizer

9. CD/Video CD Changer

10. Other.

Q2. MODEL NUMBER

Q3. DATE OF PURCHASE:

Month: Year:

Q4. If navigation system, which monitor?

Alpine (Model No.)

Other (Brand Name)

Q5. STORE TYPE WHERE PURCHASED:

1. Car Audio Specialist

2. Audio/Video Store

3. Electronics/Appliance Store

4. Car Accessories Shop

5. Other.

Q6. Type of vehicle in which this unit is

installed:

Make: Model:

Purchased Model

Year: Year:

Q7. How was this vehicle purchased?

1. Purchase

2. Lease

Q8. Purpose of buying this unit?

1. Addition

2. Replacement

↓

• Previous brand replaced?

• Factory installed

• Alpine

• Other (Brand Name).

Q9. Have you purchased Alpine products before?

1. First time

2. Two or More times

Q10. When you purchased this Alpine unit, did you compare it with other brand?

1.Yes (Brand Name)

1. No.

Q11.GENDER

1. Male

2. Female

Q12.AGE

Q13. MARITAL STATUS

1. Single

2. Married

Q14.OCCUPATION

1. Company Owner/Self-employed/Freelance

2. Manager

3. Company Employee

4. Civil Servant

5. Educator

6. Student

7. Other

Q15 Comments

Q1. gekauftes Gerät

1. Addition

2. Replacement
