GSN58EWCV - GSN58EWDV - Fridge Freezer BOSCH - Free user manual and instructions
Find the device manual for free GSN58EWCV - GSN58EWDV BOSCH in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Fridge-freezer |
| Brand | BOSCH |
| Model | GSN58EWCV / GSN58EWDV |
| Power supply | 220-240 V, 50 Hz |
| Protection class | I |
| Climate class | SN, N, ST, T (from +10 °C to +43 °C) |
| Freezer compartment temperature | Adjustable from -16 °C to -26 °C |
| No Frost system | Yes |
| Super freezing | Yes |
| Alarms | Door, temperature, power failure |
| Interior lighting | LED (not replaceable by user) |
| Ice cube dispenser | Yes (depending on model) |
| Ice cube tray | Yes |
| Cold accumulators | Yes (depending on model) |
| Freezing calendar | Yes |
| Refrigerant | R600a (flammable) |
| Freezer useful capacity | See rating plate |
| Maximum freezing capacity | See rating plate |
| Main materials | Steel, plastic |
| Cleaning | Soft cloth, lukewarm water, neutral pH dish soap |
| Maintenance | Do not use steam cleaner |
| After-sales service | Contact customer service (number on rating plate) |
| Warranty | See warranty booklet |
Frequently Asked Questions - GSN58EWCV - GSN58EWDV BOSCH
How to adjust the freezer temperature?
Press the temperature adjustment button (3) until you reach the desired temperature (from -16 °C to -26 °C). The set temperature appears on the display (4). The default value is -18 °C.
What is super freezing and when to use it?
Super freezing quickly lowers the temperature to freeze food thoroughly without loss of vitamins. Activate it a few hours before freezing fresh products, and 24 hours before to use maximum capacity. It deactivates automatically after 2 and a half days.
How to defrost the freezer?
Thanks to the No Frost system, defrosting is automatic. No manual action is necessary. In case of excessive frost (door open for a long time), turn off the appliance, leave the door open and collect the defrost water with a sponge.
What to do if the audible alarm sounds?
The alarm can indicate an open door, too high temperature, or power failure. To turn it off, press the alarm button (5). Check the cause: close the door, reduce the amount of fresh products, or wait for the power to return.
How to clean the interior of the appliance?
Use a soft cloth, lukewarm water and neutral pH dish soap. Never use a steam cleaner or abrasive products. Clean the door seal with a damp cloth then dry it. Disconnect the appliance before cleaning.
What are the climate classes and what do they mean?
The climate class indicates the admissible ambient temperature for optimal operation. For example, SN: +10 °C to 32 °C, N: +16 °C to 32 °C, ST: +16 °C to 38 °C, T: +16 °C to 43 °C. Consult the rating plate for your appliance's class.
How to store frozen food?
Respect the storage duration indicated by the freezing calendar. Approximate durations at -18 °C: fish and meat up to 6 months, fruits and vegetables up to 12 months. Do not refreeze thawed food without cooking it first.
How to make ice cubes with the dispenser?
Fill the water tank with drinking water up to the mark. Once the ice cubes are formed, push the lever downwards to release them. For the classic ice cube tray, fill it three-quarters full with water and place it in the freezer.
What to do in case of a power failure?
The power failure alarm lights up if the temperature has risen too much. Press the alarm button (5) to turn it off. Do not open the door unnecessarily. The cold accumulators slow down warming. Do not refreeze partially thawed food without cooking it.
How to start the self-diagnosis of the appliance?
Turn off the appliance for 5 minutes, then turn it on again. Within 10 seconds, press the super button (2) for 3 to 5 seconds until a beep. The self-test starts. If you hear two beeps, the appliance is working correctly. In case of a fault, 5 beeps sound and the super button flashes: contact customer service.
