Product Type	Smartphone
Brand	HONOR
Model	7X
Dimensions (estimated)	156.5 x 75.3 x 7.6 mm
Weight (estimated)	165 g
Screen size (estimated)	5.93 inches
Processor (estimated)	Kirin 659
RAM (estimated)	4 GB
Internal storage (estimated)	64 GB
Battery (estimated)	3340 mAh
Recommended charger	Adapter HW-059200XHQ
Recommended earphones	1311-3291, MEMD1632B580C00, EMC309-001, NA12
Dual SIM	Yes (dual nano SIM)
Memory card	microSD (up to 256 GB)
Operating system	Android (EMUI)
Software version	DUK-L09C900B122
Head SAR	1.28 W/kg
Body SAR	1.27 W/kg
Operating temperature	0 °C to 35 °C
Storage temperature	-20 °C to 45 °C
GSM bands	900 / 1800 MHz
WCDMA bands	900 / 2100 MHz
LTE bands	B1 / B3 / B7 / B8 / B20 / B38 / B40
Wi-Fi	2.4 GHz and 5 GHz (5150-5350, 5470-5725 MHz)
Bluetooth	20 dBm
NFC	60 dBuA/m at 10 m

Frequently Asked Questions - 7X HONOR

How to insert SIM cards and memory card?

Use the provided ejection pin to open the card tray. Insert the SIM cards (nano) and microSD card following the orientation. Make sure the device is turned off before removing or inserting the tray. Do not force to avoid damaging the contacts.

What to do if the device won't turn on?

Press and hold the power button until the device vibrates to force a restart. If that doesn't work, plug in the charger and wait a few minutes before trying again. If the problem persists, contact HONOR customer service.

Can I use two SIM cards at the same time?

Yes, your phone supports dual SIM cards. However, when you are on a call with one card, the other is unavailable. Similarly, if you use mobile data on one card, the other loses its data connection. This helps optimize battery life.

How to reduce radiation exposure?

To reduce exposure, use the phone in areas with good reception (strong signal), prefer using a hands-free kit, and keep the device away from your body. The recommended distance is at least 0.5 cm when carrying the phone on you.

What precautions for pacemaker wearers?

Maintain a distance of at least 15 cm between the phone and the pacemaker. Do not carry the phone in the front pocket on the same side as the pacemaker and hold it to the opposite ear during calls.

What are the recommended accessories?

HONOR recommends using the power adapter HW-059200XHQ, battery HB376994ECW, and earphones 1311-3291, MEMD1632B580C00, EMC309-001 or NA12. Using non-approved accessories may damage the device or cause accidents.

How to recycle my device at end of life?

Do not dispose of the device, battery, or accessories with household waste. Follow local regulations for Waste Electrical and Electronic Equipment (WEEE). Drop them off at an approved collection point or contact your municipality for more information.

Where to find legal and safety information?

Go to Settings > About phone > Legal information to view legal information, safety instructions, and certifications. You can also visit the official website consumer.huawei.com/certification.

How to update the software?

Software updates are released by the manufacturer to fix bugs or improve features. Go to Settings > Software update to check for and install available updates. Make sure you are connected to a Wi-Fi network and have sufficient battery.

Can I use the phone on an airplane?

Using wireless devices is generally prohibited on airplanes. Turn off your phone or enable Airplane mode before boarding and follow crew instructions. Non-compliance may disrupt aircraft networks.

USER MANUAL 7X HONOR

Your device at a glance

Thank you for choosing a Honor 8 Pro smartphone. Before you start, let's take a look at your new device.

• To power on your device, press and hold the power button until your device vibrates and the screen turns on.
• To power off your device, press and hold the power button, and then touch .

• To force your device to restart, press and hold the power button until your device vibrates.

Inserting and removing cards

Follow the instructions in the following figures to set up your device.

• Do not insert or remove the card tray when your device is powered on.
• Ensure that the card is correctly aligned and that the card tray is level when you insert it into your device.

Be careful not to scratch your device or hurt yourself when using the SIM eject pin. Store the SIM eject pin out of the reach of children to prevent accidental swallowing or injury.

Do not use cut or modified SIM or microSD cards with your device as these may not be recognised and could damage the card tray.

Dual card dual standby single pass

Your phone supports dual SIM cards. Both SIM cards are available at the same time when you are not using your phone. However, while one SIM card is active, the other is unavailable. This is known as dual card dual standby single pass.

For example, while you are using SIM card 1's data service, SIM card 2's data service will be disabled. And, while you are on a call using SIM card 1, SIM card 2 will be unavailable. Someone calling SIM card 2 while you are on a call using SIM card 1 will either reach your voicemail or hear a message such as "The person you called cannot be reached at the moment. Please try later." The message heard will vary depending on service provider.

Your phone's single pass feature helps reduce power consumption and increase standby time.

Contact your service provider for information about subscribing to notification services.

For more information

If you encounter any problems while using your phone, you can obtain help from the following resources:

Go to HiCare. You can:

• Touch the Manuals tab to view online user guides.
• Touch the Forum tab to request help in the Huawei forums.
• Touch the Service tab for service center, helpline, and customer service information.

Log on to the official Huawei website. You can:

• Visit http://www.hihonor.com to download user guides, view frequently asked questions, and use emulators to test out Huawei products.
• Visit http://www.hihonor.com for the most up-to-date contact information for your country or region.

Go to Settings and touch About phone > Legal information to view legal information for your product.

Go to Settings and touch About phone > Legal information > Safety information to view safety information for your product.

Go to Settings and touch About phone >Authentication info to view regulatory information for your product.

All pictures and illustrations in this guide, including but not limited to the phone colour, size, and display content, are for your reference only. The actual product may vary. Nothing in this guide constitutes a warranty of any kind, express or implied.

Safety Information

Please read all of the safety information carefully before using your device to ensure its safe and proper operation and to learn how to dispose of your device properly.

Operation and safety

• To prevent possible hearing damage, do not listen at high volume levels for long periods.
• Using an unapproved or incompatible power adapter, charger or battery may damage your device, shorten its lifespan or cause a fire, explosion or other hazards.
• Ideal operating temperatures are 0^ to 35^ . Ideal storage temperatures are -20^ to +45^ .
• Pacemaker manufacturers recommend maintaining a minimum distance of 15cm between a pacemaker and a wireless device to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket.
• Keep the device and the battery away from excessive heat and direct sunlight. Do not place them on or in heating devices, such as microwave ovens, stoves or radiators.
• Adhere to local laws and regulations while using the device. To reduce the risk of accidents, do not use your device while driving.

• While flying in an aircraft or immediately before boarding, ensure that you use your device according to the instructions provided. Using a wireless device in an aircraft may disrupt wireless networks, present a hazard to aircraft operations or be illegal under law.

• To prevent damage to your device's parts or internal circuits, do not use it in dusty, smoky, damp or dirty environments or near magnetic fields.

• When charging the device, make sure the power adapter is plugged into a socket near the devices and is easily accessible.
• Unplug the charger from the electric socket and from the device when not in use.
• Do not use, store or transport the device where flammables or explosives are stored (e.g. in a petrol station, oil depot or chemical plant). Using your device in these environments increases the risk of explosion or fire.
• Dispose of this device, the battery and accessories according to local regulations. They should not be disposed of in normal household waste. Improper battery use may lead to fire, explosion or other hazards.
• Please consult your doctor and the device manufacturer to determine if operation of your phone may interfere with the operation of your medical device.
• Adhere to any rules or regulations set forth by hospitals and health care facilities.
• If you must make or answer a call, stop your vehicle at a safe location first.
• Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water heater, radiator, or candle.

Potentially Explosive Atmosphere

Power off your device in any area with a potentially explosive atmosphere, and comply with all signs and instructions. Areas that may have potentially explosive atmospheres include the areas where you would normally be advised to turn off your vehicle engine. Triggering of sparks in such areas could cause an explosion or a fire, resulting in bodily injuries or even deaths. Do not power on your device at refueling points such as service stations. Comply with restrictions on the use of radio equipment

in fuel depots, storage, and distribution areas, and chemical plants. In addition, adhere to restrictions in areas where blasting operations are in progress. Before using the device, watch out for areas that have potentially explosive atmospheres that are often, but not always, clearly marked. Such locations include areas below the deck on boats, chemical transfer or storage facilities, and areas where the air contains chemicals or particles such as grain, dust, or metal powders. Ask the manufacturers of vehicles using liquefied petroleum gas (such as propane or butane) whether this device can be safely used in their vicinity.

Disposal and recycling information

The crossed-out wheeie bin symbol on your product, battery, literature or packaging reminds you that all electronic products and batteries must be taken to separate waste collection points at the end of their working lives; they must not be disposed of in normal household waste. It is the responsibility of the user to dispose of the equipment using a designated collection point or service for separate recycling of waste electrical and electronic equipment (WEEE) and batteries according to local laws.

Proper collection and recycling of your equipment helps ensure EEE waste is recycled in a manner that conserves valuable materials and protects human health and the environment.

Improper handling, accidental breakage, damage, and/or improper recycling at the end of its life may be harmful for your health and the environment. For more information about where and how to drop off your EEE waste, please contact your local authorities, retailer or household waste disposal service or visit the website http://consumer.huawei.com/en/.

Reduction of hazardous substances

This device and any electrical accessories are compliant with local applicable rules on the restriction of the use of certain

hazardous substances in electrical and electronic equipment, such as EU REACH, RoHS and Batteries (where included) regulations, etc. For declarations of conformity about REACH and RoHS, please visit our web site http://consumer.huawei.com/certification.

EU regulatory conformance

Body worn operation

The device complies with RF specifications when used near your ear or at a distance of 0.5cm from your body. Ensure that the device accessories, such as a device case and device holster, are not composed of metal components. Keep the device away from your body to meet the distance requirement.

The highest SAR value reported for this device type when tested at the ear is 1.28W / kg and when properly worn on the body is 1.27W / kg .

Statement

Hereby, Huawei Technologies Co., Ltd. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.

The most recent and valid version of the DoC (Declaration of Confirmation) can be viewed at

http://consumer.huawei.com/certification.

This device may be operated in all member states of the EU. Observe national and local regulations where the device is used. This device may be restricted for use, depending on the local network.

Restrictions in the 2.4 GHz band:

Norway: This subsection does not apply for the geographical area within a radius of 20km from the centre of Ny-Alesund.

Restrictions in the 5 GHz band:

According to Article 10 (10) of Directive 2014/53/EU, the packaging shows that this radio equipment will be subject to some restrictions when placed on the market in Belgium (BE), Bulgaria (BG), the Czech Republic (CZ), Denmark (DK), Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain (ES), France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV), Lithuania (LT), Luxembourg (LU), Hungary (HU), Malta (MT), Netherlands (NL), Austria (AT), Poland (PL), Portugal (PT), Romania (RO), Slovenia (SI), Slovakia (SK), Finland (FI), Sweden (SE), the United

Kingdom (UK), Turkey (TR), Norway (NO), Switzerland (CH), Iceland (IS), and Liechtenstein (LI).

The WLAN function for this device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.

Frequency Bands and Power

(a) Frequency bands in which the radio equipment operates: Some bands may not be available in all countries or all areas. Please contact the local network provider for more details.
(b) Maximum radio-frequency power transmitted in the frequency bands in which the radio equipment operates: The maximum power for all bands is less than the highest limit value specified in the related Harmonized Standard.

The frequency bands and transmitting power (radiated and/or conducted) nominal limits applicable to this radio equipment are as follows: GSM 900: 37 dBm, GSM 1800: 34 dBm, WCDMA 900/2100: 25.7 dBm, LTE Band 1/3/7/8/20/38/40: 25.7 dBm, Wi-Fi 2.4G: 20 dBm, Bluetooth: 20 dBm, Wi-Fi 5G: 5150-5350 MHz: 23 dBm, 5470-5725 MHz: 30dBm, NFC: 60 dBuA/m at 10m.

Accessories and Software Information

Some accessories are optional in certain countries or regions. Optional accessories can be purchased from a licenced vendor as required. The following accessories are recommended:

Adapters: HW-059200XHQ (X represents the different plug types used, which can be either C, U, J, E, B, A, I, R, Z or K, depending on your region)

Batteries: HB376994ECW

Earphones: 1311-3291, MEMD16328580C00, EMC309-001, NA12

The product software version is DUK-L09C900B122. Software updates will be released by the manufacturer to fix bugs or enhance functions after the product has been released. All software versions released by the manufacturer have been verified and are still compliant with the related rules.

All RF parameters (for example, frequency range and output power) are not accessible to the user, and cannot be changed by the user.

For the most recent information about accessories and software, please see the DoC (Declaration of Confirmation) at http://consumer.huawei.com/certification.

ErP Product Information

Hereby, Huawei Technologies Co., Ltd. declares that the product meets the directive 2009/125/EC and its implementation regulation (EC) NO 1275/2008 amended by (EC) 278/2009, (EC) 642/2009, (EU) 617/2013, (EU) 801/2013, and its implementation regulation (EC) NO 278/2009.

The power consumption of the product in connected standby if all wired network ports are connected and all wireless network ports are activated is 1.2W

For the product information displayed on the manufacturers' freely accessible websites required by (EU) No 801/2013, please visit

http://consumer.huawei.com/certification.

Legal Notice

Trademarks and Permissions

Honor, HUWEI, HUWEI and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.

AndroidTM is a trademark of Google Inc.

LTE is a trade mark of ETSI.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Huawei Technologies Co., Ltd. is under license.

Wi-Fi®, the Wi-Fi CERTIFIED logo and the Wi-Fi logo are trademarks of Wi-Fi Alliance.

Privacy Policy

To better understand how we protect your personal information, please see the privacy policy at http://consumer.huawei.com/privacy-policy.

Copyright © Huawei Technologies Co., Ltd. 2017. All rights reserved.

THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT CONSTITUTE ANY KIND OF WARRANTY.
