| Product type | Portable countertop ice maker |
| Brand | Sheffield |
| Model | PL810 |
| Ice production | Up to 12 kg per 24 hours |
| Cycle time | First batch in 6 to 8 minutes |
| Number of cubes per cycle | 9 crescent-shaped cubes |
| Water tank capacity | 2.0 L |
| Ice storage capacity | 600 g |
| Cube size selection | Small or large ice cubes |
| Control panel | Button control with LED indicators |
| Refrigerant | R600a |
| Power supply | AC 220-240 V, 50 Hz |
| Power consumption | 180 W |
| Dimensions (H x W x D) | Approximately 320 x 220 x 340 mm |
| Weight | Approximately 7.0 kg |
| Water level indicator | Visible transparent water window |
| Self-cleaning function | Built-in rinse cycle for easy maintenance |
| Overheat protection | Automatic shutdown to prevent compressor damage |
| Low water warning | Alerts when refill is required |
| Additional accessories | Ice basket and water scoop included |
Frequently Asked Questions - PL810 Sheffield
How do I install the PL810 ice maker?
Set the machine on a flat and level surface, keep at least 15 cm of clearance around the vents, then plug it in. Ensure the water drainage plug is closed before adding water.
What type of water should I use?
Use clean, drinkable cold water. For better taste and scale reduction, use filtered or bottled water with low mineral content. Do not use hot water.
How long does it take to make ice?
The first batch usually takes 6 to 8 minutes. Subsequent cycles may be slightly faster or slower depending on ambient temperature and water temperature.
How do I clean the ice maker?
Turn off and unplug the unit, remove the ice basket, then run the self-cleaning cycle with a mixture of water and white vinegar. Empty the water through the drain plug and wipe the interior with a soft cloth.
Can I store the ice for a long time?
Ice is best used fresh. The PL810 is designed to make ice quickly, not to store it for days. Transfer unused ice to a freezer bag in your freezer if you need long-term storage.
Why is my ice maker not producing ice?
Check that the water tank has enough water, that the unit is level, and that the ambient temperature is above 10°C. Wait about 30 minutes after restarting the compressor before expecting the first batch.
What does the low water indicator mean?
It means the water tank is empty or below the minimum level. Switch off the machine, add fresh cold water, and restart the ice-making cycle.
Is the machine noisy?
The PL810 produces a low humming sound from the compressor and a water splashing sound during the ice-making process. This is normal. Place the unit on a stable surface to reduce vibration noise.
Can I choose different ice cube sizes?
Yes, the PL810 lets you choose between small and large cubes. Press the size selector button on the control panel before or during a cycle to change the size.
How do I maintain the appliance when not in use?
Drain all water, clean the inside, dry it thoroughly, and leave the lid open for a few hours to prevent odor. Store in a dry, cool place away from direct sunlight.
