FDR-1 - Effect pedal BOSS - Free user manual and instructions

Product type	Effect pedal
Brand	BOSS
Model	FDR-1
Technology	COSM (Composite Object Sound Modeling)
Built-in effects	Reverb, Vibrato
Power supply	9V battery (carbon 6F22 or alkaline 6LR61) or optional PSA series AC adapter (DC 9V)
Battery life (continuous use)	Carbon: approx. 2.7 hours; Alkaline: approx. 9 hours
Nominal input level	-20 dBu
Nominal output level	-20 dBu
Output impedance	2.2 kΩ
Recommended load impedance	10 kΩ or more
Connectors	INPUT (power switch), OUTPUT, DC 9V adapter
Indicator	CHECK (lights when effect is on; also serves as battery check indicator)
Controls	GAIN, LEVEL, TREBLE, BASS, REVERB, VIBRATO
Additional features	Vibrato speed setting by tapping on pedal, speed memory
Maintenance	Clean with a soft, dry cloth. Do not use solvents.
Safety	Read the provided safety instructions. Use only the specified adapter.
Spare parts and repairability	9V battery, optional PSA series AC adapter. Repair by qualified technician.
General information	Manufactured by BOSS Corporation. This product must be recycled in accordance with local regulations.

Frequently Asked Questions - FDR-1 BOSS

How to power the FDR-1 pedal?

The pedal can be powered by a 9V battery (carbon 6F22 or alkaline 6LR61) or by a specific AC adapter (PSA series, optional). When an adapter is connected, power is drawn from the adapter. If a battery is installed, it serves as backup in case of power interruption. To conserve battery, disconnect the cable from the INPUT jack when not using the pedal.

How to replace the battery?

When the CHECK indicator dims or no longer lights, the battery should be replaced. To do so, step on the pedal, loosen the screw by hand and open the case. Remove the old battery, disconnect its contacts, then connect a new battery observing polarity. Close the pedal and tighten the screw. Alkaline battery is recommended.

What does the CHECK indicator mean?

The CHECK indicator lights when the effect is on (pedal depressed). It also serves as a battery condition indicator: if it dims or goes out when the effect is on, the battery is low and should be replaced. Note: The indicator does not show whether the pedal is powered on; it only shows the effect status.

How to set the vibrato speed using the pedal?

To set the vibrato speed by tapping on the pedal, first turn on the effect (CHECK indicator red). Hold down the pedal for at least two seconds, then tap the pedal at the desired tempo. Finally, hold down the pedal again for two seconds to memorize the speed. You can also adjust the speed using the VIBRATO control while holding down the pedal.

What order should I follow for connections?

For powering on, first connect all cables, then turn on the guitar amplifier last. For powering off, turn off the amplifier first. Always set the volume to minimum before turning on the pedal. Inserting a plug into the INPUT jack powers on the pedal; disconnect it to turn it off.

What settings do you recommend for a Fender amplifier?

For a Fender combo amplifier, set the amp controls as follows: BRIGHT to OFF, TREBLE, MIDDLE, and BASS to taste. On the FDR-1 pedal, start with a clean (undistorted) setting on the amp. Use the GAIN control to adjust distortion and the BASS/TREBLE controls for tone. Adjust LEVEL so there is no volume difference between effect on and bypass.

Why is there no sound or is the volume low?

First check that your instrument is properly connected to the INPUT jack and the amplifier is correctly connected to the OUTPUT jack. Make sure the LEVEL control is not turned too low (turn it to the right). Also check the amplifier volume. If the battery is low, replace it. Finally, confirm the pedal is powered on: a cable must be inserted into INPUT.

How to use the vibrato effect?

Vibrato is an effect that cyclically varies the volume. To activate it, press down the pedal. Adjust its intensity with the VIBRATO control (turn right for more effect). You can change the vibrato speed by tapping on the pedal (see dedicated question) or by turning the VIBRATO control while holding down the pedal. The speed can be memorized.

What is the battery life?

In continuous use, a carbon battery lasts about 2.7 hours and an alkaline battery about 9 hours. These times vary depending on usage. The supplied battery is for testing; replace it with an alkaline battery for longer life. To conserve battery, disconnect the cable from the INPUT jack after use.

How to clean the FDR-1 pedal?

To clean the pedal, use a soft, dry cloth. Never use solvents, alcohol, or chemicals that could damage the finish. If necessary, you can slightly dampen the cloth with water, but wring it well first. Avoid allowing moisture to enter the connectors or the interior of the pedal.

USER MANUAL FDR-1 BOSS

Copyright ©2007 BOSS CORPORATION

Commandes: Pédale, Commande GAIN, Commande LEVEL, Commande TREBLE, Commande BASS, Commande REVERB, Commande VIBRATO

Consommation: 40mA (DC 9V)

Dimensions: 73 (L) x 129 (P) x 59 (H) mm

Poids: 440g (pile comprise)

Accessoires Mode d'emploi, Feuillet ("CONSIGNES DE SECURITE", "REMARQUES IMPORTANTES" et "Information"), Pile sèche 9V (6LR61)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.

Unauthorized changes or modification to this system can void the users authority to operate this equipment.

This equipment requires shielded interface cables in order to meet FCC class B Limit.

Pour le Canada

NOTICE

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

AVIS
