Conga Rockstar Rs50 - Stick vacuum CECOTEC - Free user manual and instructions

Type	Stick vacuum
Brand	Cecotec
Model	Conga Rockstar Rs50
Dimensions (Height x Width x Depth)	115 cm x 25 cm x 20 cm
Weight	2.5 kg
Power Supply	Rechargeable Li-ion battery, 22.2 V, 2200 mAh
Charging Time	4-5 hours
Runtime	Up to 40 minutes (standard mode)
Dust Capacity	0.5 L
Filtration System	Cyclonic + HEPA filter
Suction Power	Up to 150 AW
Noise Level	Approx. 78 dB
Motor Type	Digital brushless motor
Speed Settings	2 (Standard and Turbo)
LED Display	Yes, battery indicator and mode
Included Accessories	Motorized brush, crevice tool, 2-in-1 brush, wall mount
Brush Type	Motorized floor brush with LED
Convertible to Handheld	Yes
Washable Filter	Yes
Replacement Parts Available	Filters, batteries, and brushes available from Cecotec
Warranty	2 years

Frequently Asked Questions - Conga Rockstar Rs50 CECOTEC

How do I assemble the Cecotec Conga Rockstar Rs50?

Insert the metal tube into the main body until it clicks. Attach the floor brush by pressing it onto the bottom of the tube. Refer to the manual for detailed steps.

How do I charge the vacuum?

Connect the charger to the charging port on the back of the vacuum. Plug into a wall outlet. The LED indicator will show charging status. Full charge takes about 4-5 hours.

How long does the battery last?

In standard mode, battery lasts up to 40 minutes. In Turbo mode, runtime is reduced to about 15 minutes. Actual time depends on floor type and usage.

How do I clean the HEPA filter?

Remove the dustbin and take out the filter. Tap it gently to remove dust. For a deeper clean, rinse under water and let it dry completely for 24 hours before reinstalling. Do not use detergent.

What should I do if suction power decreases?

Check if the dustbin is full, empty it. Clean the filters and check for blockages in the nozzle, tube, or brush. Also ensure the battery is sufficiently charged.

Can I use the vacuum on hardwood floors?

Yes, the motorized floor brush is designed for all hard floors and low-pile carpets. It has soft bristles to avoid scratching. For delicate surfaces, use the included crevice tool or brush.

How do I empty the dustbin?

Press the release button on the dustbin to detach it from the vacuum. Hold it over a trash can and press the bottom release to open the flap. Do not touch the dirt.

What does the blinking red light indicate?

A blinking red light usually indicates low battery or a blockage. Check the battery level and if low, charge the vacuum. If the battery is fine, check for clogs in the airflow path.

Where can I buy replacement parts?

Replacement filters, batteries, and brushes can be purchased from the official Cecotec website or authorized retailers. Use identical parts for optimal performance.

How do I store the vacuum?

Use the included wall mount to store it upright. Alternatively, disassemble and store it in a dry place away from direct sunlight. Keep it out of reach of children.

USER MANUAL Conga Rockstar Rs50 CECOTEC

Aspirador vertical / Upright vacuum cleaner

Fig./Img./Abb./Afb./Rys.1

Fig./Img./Abb./Afb./Rys. 2

Fig./Img./Abb./Afb./Rys. 3

Fig./Img./Abb./Afb./Rys. 4

Fig./Img./Abb./Afb./ Rys. 5

Fig./Img./Abb./Afb./Rys. 6

Fig./Img./Abb./Afb./Rys. 7

Fig./Img./Abb./Afb./Rys. 8

Fig./Img./Abb./Afb./Rys. 9

Fig./Img./Abb./Afb./Rys. 10

Fig./Img./Abb./Afb./ Rys. 11

Fig./Img./Abb./Afb./Rys. 12

Fig./Img./Abb./Afb./Rys. 13

Fig./Img./Abb./Afb./Rys. 14

Fig./Img./Abb./Afb./ Rys. 15

Fig./Img./Abb./Afb./Rys. 16

Fig./Img./Abb./Afb./Rys. 17

Fig./Img./Abb./Afb./Rys. 18

Fig./Img./Abb./Afb./Rys. 19

Fig./Img./Abb./Afb./Rys. 20

Fig./Img./Abb./Afb./Rys. 21

Fig./Img./Abb./Afb./Rys. 22
