T1 - Sports Watch SUUNTO - Free user manual and instructions

Product type	Heart rate monitor (sports watch)
Brand	Suunto
Model	T1
Weight	45g / 50g / 65g (depending on wristband)
Water resistance (watch)	30 m / 100 ft (ISO 2281)
Water resistance (chest transmitter)	20 m / 66 ft
Power	CR2032 lithium battery (watch and transmitter)
Battery life	Approximately 12 months (4 h training/week)
Operating temperature	-20 °C to +60 °C
Storage temperature	-30 °C to +60 °C
Main functions	Heart rate, stopwatch (99 h), calories, HR zones, HR limits, alarm, dual time zone, backlight, history (summaries and totals), activity class
Display	Clock mode, training mode, setting menus with segments
Memory	30 lap times, last session summary, weekly and monthly totals
Wristband	Adjustable (cut along grooves)
Care and cleaning	Wipe with a cloth slightly dampened with warm water; avoid strong chemicals
Safety	Medical consultation recommended before use for pacemaker wearers
Spare parts and repairability	Replaceable battery; gasket and transmitter cover available; repair by authorized representative
Warranty	2 years (material or manufacturing defects)
General information	Recreational use; ISO 9001 certification; Suunto Training World website

Frequently Asked Questions - T1 SUUNTO

How to set heart rate limits?

Access the HR LIMITS menu via a long press on ENTER in Clock or Training mode. You can enable/disable limits, set lower and upper values, and activate the alarm. Use UP/DOWN to change and ENTER to confirm.

How to use the stopwatch and lap times?

In Training mode, press START to start the stopwatch. During timing, press UP to record a lap time (up to 99 laps, first 30 stored). Press START again to stop, then UP to view summaries.

How to replace the watch battery?

Use a coin to open the battery compartment cover on the back. Remove the old CR2032 battery, insert the new one with the + pole facing up, sliding against the side tab. Close the cover by turning counterclockwise until tight.

What to do if heart rate does not display?

Check that the chest transmitter is positioned correctly (against the skin, electrodes moistened). Exit Training mode and re-enter it. Move away from sources of interference (power lines, magnetic devices). If the problem persists, replace the transmitter battery.

How to set my activity class?

In the PERSONAL menu (personal data settings), select act class. Choose a value from 1 to 10 based on your activity level (see table in the manual). This improves accuracy of calorie calculation and other data.

How to view training summaries and totals?

After a session, press UP in Training mode to see the summary (duration, calories, average/max HR, time in zones). In Clock mode, press UP to access totals (current and previous week, current and previous month). Use UP/DOWN to navigate.

How to set the alarm?

Access the TIME-DATE menu from settings. Select alarm, enable it, then set the hour and minutes. To stop the alarm, press BACK; any other button activates snooze (5 minutes, up to 12 times).

Is the watch waterproof for swimming?

Yes, the watch is water resistant to 30 meters (ISO 2281 standard). You can swim with it, but do not press buttons underwater. The chest transmitter is water resistant to 20 meters, but radio transmission does not work underwater.

How to clean the watch and transmitter?

Wipe with a cloth slightly dampened with warm water. For stubborn stains, use mild soap. Avoid strong chemicals (gasoline, solvents, acetone, alcohol). Dry thoroughly after cleaning.

Can I use the chest transmitter with gym equipment?

Yes, the transmitter is compatible with most treadmills and exercise bikes. However, interference may occur near power lines or magnetic devices. If the signal is lost, move away from the source or temporarily exit Training mode.

USER MANUAL T1 SUUNTO

→	Appui bref
2s	Appui long

1.1. Reglage de Suunto t1

last week laSEMaine derniere

lb lb (livres)

This product is warranted to be free of defects in material and/or workmanship to the original owner for the above noted period (does not include battery life). Keep a copy of the original purchase receipt and make sure to get this warranty card stamped at the place of purchase. The warranty originates from the date of purchase.

All warranties are limited and are subject to the restrictions given in the instruction manual. This warranty does not cover the damage to the product resulting from improper usage, improper maintenance, neglect of care, alteration, improper battery replacement or unauthorized repair.

Suunto's heart rate monitors can be registered online at www.suunto.com.

Model of heart rate monitor:

Serial number:

1

1

1

1

1 1 1 1 1 1 1

Date of purchase

Place of purchase/Store name.

Store City Store Country

Store stamp with date of purchase

---

Name

Address

City Country

Telephone E-mail

Signature

CUSTOMER SERVICE CONTACTS

COORDINNEES SERVICE CLIENTS, KUNDENDIENSTE, DATOS DE CONTACTO DE ATENTION AL CLIENTE, NUMERU UTILI PER IL SERVIZIO CLIENTI, KLANTENSERVICE, ASIAKASPVALUN YHTYSTIEDOT, KUNDSERVICE, KONTAKER

Global Help Desk [phone]

Suunto USA Phone [phone]

Canada Phone [phone]

This publication and its contents are proprietary to Suunto Oy.

Suunto, Wristop Computer, Suunto t1, Replacing Luck and their logos are registered or unregistered trademarks of Suunto Oy. All rights reserved.

While we have taken great care to ensure that information contained in this documentation is both comprehensive and accurate, no warranty of accuracy is expressed or implied. Its content is subject to change at any time without notice.
