Product type	Cooker hood
Brand	AEG
Model	NDB6791HB
Dimensions (W x D x H)	898 x 498 x 523-1130 mm
Net weight	13 kg
Power supply	220-240 V ~ 50 Hz, 200 W
Energy class	A+
Max noise level	60 dB
Max airflow	600 m³/h
Filter type	Metal grease filter (optional charcoal filter)
Lighting	LED 2 x 3 W
Controls	Electronic, 3 speeds + intensive function
Main functions	Timer, filter saturation indicator, intensive function
Maintenance and cleaning	Monthly cleaning of grease filter; replace charcoal filter every 6 months
Safety	Motor with thermal protection
Spare parts	Available on AEG official website
Repairability index	7.5 / 10
Warranty	2 years

Frequently Asked Questions - NDB6791HB AEG

How to install the AEG NDB6791HB hood?

Installation must be carried out by a qualified professional. Ensure a minimum distance of 65 cm between the hood and the electric hob (or 75 cm for gas). Use the supplied fixings and plug the appliance into an earthed socket.

How to clean the grease filters?

The metal grease filters can be washed in the dishwasher or by hand with hot water and detergent. Let them dry completely before putting them back. Perform this cleaning at least once a month.

When should the charcoal filter be replaced?

The charcoal filter must be replaced every 6 months, or more often if the hood is used intensively. A saturation indicator on the control panel will alert you.

How to activate the intensive function?

Press the button marked with a 'P' or 'Boost' symbol on the control panel. The hood will operate at maximum speed for about 10 minutes, then automatically return to the previous speed.

The hood is noisy during operation, what should I do?

Check that the filters are not clogged and that the exhaust duct is not obstructed. If the noise persists, contact AEG after-sales service.

Are the LED bulbs replaceable?

Yes, the LED bulbs are replaceable. Order suitable reference bulbs on the AEG website or from an authorized dealer.

How to use the timer?

Press the timer button (clock) after selecting a speed. The hood will turn off automatically after 15 minutes (or according to setting). You can adjust the duration by pressing several times.

Can I use the hood in recirculation mode?

Yes, the hood can operate in recirculation mode with a charcoal filter (not supplied). Make sure to install the appropriate recirculation kit.

What does the flashing light on the panel mean?

The flashing light indicates that the grease or charcoal filters need to be cleaned or replaced. Refer to the manual to reset the indicator after maintenance.

How to reset the saturation indicator?

After cleaning or replacing the filters, press and hold the indicator button (usually the 'Filter' button) for about 3 seconds until the light goes off.

USER MANUAL NDB6791HB AEG

GB67D61HL GB67D91HL NDB6761HB NDB6791HB

BG Ръководство за употреба | Аспиратор 2 CA Manual d'usuari | Campana extractora 12 CS Návod k použití | Odsavač par 21 DA Brugsanvisning | Emhætte 30 DE Benutzerinformation | Dunstabzugshaube 39 EL Οδηγίες Χρήσης | Απορροφητήρας 50 EN User Manual | Cooker Hood 60 ES Manual de instrucciones | Campana extractora 69 ET Kasutusjuhend | Ôhupuhasti 79 FI Käyttöohje | Liesituuletin 88 FR Notice d'utilisation | Hotte 97 HR Upute za uporabu | Kuhinjska napa 107 HU Használati útmutató | Konyhai szagelszívó 116 IT Istruzioni per l'uso | Cappa da cucina 126 KA əməbəsɪŋðəməʊ ləsɡəmədʒəsɛɡəm | ʃŋɡəʊ ləsɡɒŋsʒo 136 КК Қолдану туралы нұсқаулары | Пештің сорғыш қондырғысы 146 LT Naudojimo instrukcija | Garų rinktuvas 156 LV Lietošanas instrukcija | Tvaika nosūcējs 165 МК Упатство за ракување | Аспиратор 174 NL Gebruiksaanwijzing | Afzuigkap 184 NO Bruksanvisning | Ventilator 194 PL Instrukcja obsługi | Okap kuchenny 203 PT Manual de instruções | Exaustor 213 RO Manual de utilizare | Hotă pentru aragaz 223 RU Инструкция по эксплуатации | Кухонная вытяжка 232 SK Návod na používanie | Odsávač pár 242 SL Navodila za uporabo | Kuhinjska napa 251 SQ Udhëzimet për përdorim | Aspirator 260 SR Упутство за употребу | Аспиратор штедњака 269 SV Bruksanvisning | Spisfläkt 279 TR Kullanma Kılavuzu | Davlumbaz 288 UK Інструкція | Витяжка 298

Welcome to AEG! Thank you for choosing our appliance.

Get usage advice, brochures, troubleshooting, service and repair information:

www.aeg.com/support

Subject to change without notice.

CONTENTS

1. SAFETY INFORMATION......60
2. SAFETY INSTRUCTIONS.... 63
3. INSTALLATION....64
4. PRODUCT DESCRIPTION....64
5. DAILY USE....65
6. CARE AND CLEANING.... 66
7. TROUBLESHOOTING....67
8. ENVIRONMENTAL CONCERNS....68

1. ⚠ SAFETY INFORMATION

Before installing and using the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage resulting from incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

1.1 Children and vulnerable people safety

This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children under 8 years of age and persons with very extensive and complex disabilities should be kept away from the appliance unless continuously supervised.

Children should be supervised to ensure that they do not play with the appliance.

Keep all packaging away from children and dispose of it appropriately.

• Keep children and pets away from the appliance when it is operating.
• Children shall not carry out cleaning and user maintenance of the appliance without supervision.

1.2 General Safety

• This appliance is intended for domestic use above hobs, cookers, and similar cooking devices.
• This appliance is designed for single household domestic use in an indoor environment.
• This appliance may be used in offices, hotel guest rooms, bed & breakfast guest rooms, farm guest houses, and other similar accommodation where such use does not exceed (average) domestic usage levels.
• Before carrying out any maintenance, disconnect the appliance from the power supply.
• CAUTION: Accessible parts may become hot during use with cooking appliances.
• Use only the fixing screws supplied with the appliance. If not supplied, use the screws recommended in the installation instructions. Install the appliance in a safe and suitable place that meets installation requirements.
• WARNING: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.
• Do not use adhesives to fix the appliance.
• The minimum distance between the hob surface on which the pans stand and the lower part of the appliance shall be at least 65 cm, unless otherwise specified in the installation instructions for the appliance or hob.
• The discharge of air must comply with local authorities regulations.
• Ensure good air ventilation in the room where the appliance is installed to avoid the backflow of gases into the room from appliances burning gas or other fuels, including open fires.

- Make sure that the ventilation openings are not blocked and the air collected by the appliance is not conveyed into a duct used to exhaust smoke and steam from other appliances (central heating systems, thermosiphons, water-heaters, etc.).

- When the appliance operates with other appliances the maximum vacuum generated in the room should not exceed 0.04 mbar.

- If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.

- If the cord set is damaged, it must be replaced by a special cord set available from the manufacturer or its Authorised Service Centre.

- If the appliance is connected directly to the power supply, the electrical installation must be equipped with an isolating device that allows to disconnect the appliance from the mains at all poles. Complete disconnection must comply with conditions specified in the overvoltage category III. The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.

- Do not flambé under the appliance.

- Do not use to exhaust hazardous or explosive materials and vapours.

- Clean the appliance regularly with a soft cloth to prevent the deterioration of the surface material.

- Do not use a steam cleaner, water spray, harsh abrasive cleaners or sharp metal scrapers to clean the surface of the appliance. Use only neutral detergents.

- Clean grease filters regularly (at least every 2 months) and remove grease deposits from the appliance to prevent the risk of fire.

- Use a cloth to clean the interior of the appliance.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Risk of injury, electric shock, fire, burns or damage to the appliance.

• Only a qualified person must install this appliance.
• Do not install or use a damaged appliance.
• Follow the installation instructions supplied with the appliance. Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.
• Before installing the appliance remove all the packaging, the labelling and the protective film.
• Do not install the exhaust air into a wall cavity, unless the cavity is designed for that purpose.

2.2 Electrical connection

WARNING!

Risk of fire and electric shock.

• All electrical connections should be made by a qualified electrician.
• Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.
• If the symbol ( ) is not printed on the rating plate, the appliance must be earthed. Always use a correctly installed shockproof socket.
• Do not let the electricity mains cable tangle.
• Do not use multi-plug adapters and extension cables.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• The shock protection of live and insulated parts must be fastened in such a way that it cannot be removed without tools.

Make sure the appliance is installed correctly. Loose and incorrect electricity mains cable can make the terminal become too hot. Connect the appliance at the end of the installation. Make sure that there is access to the mains after the installation.

2.3 Use

WARNING!

Risk of injury, burns and electric shock.

This appliance is for cooking purpose only. Do not use the appliance for other purpose. Do not change the specification of this appliance. Do not operate the appliance with wet hands or when it has contact with water. Use only the accessories supplied with the appliance. Keep flames or heated objects away from fats and oils during cooking and frying. Do not use uncovered electric grills. Do not use the appliance as a storage surface. Do not use magnifying glasses, binoculars or similar optical devices to look directly at the lighting of the appliance. If the appliance works with other devices, the maximum developed pressure must not exceed 4 Pa (4x10-5 bar).

2.4 Service

To repair the appliance contact the Authorised Service Centre. Use original spare parts only. Concerning the lamp(s) inside this product and spare part lamps sold separately: These lamps are intended to withstand extreme physical conditions in household appliances, such as temperature, vibration, humidity, or are intended to signal information about the operational status of the appliance. They are not intended to be used in other applications and are not suitable for household room illumination.

2.5 Disposal

WARNING!

Risk of injury or suffocation.

- Contact your municipal authority for information on how to dispose of the appliance.

• Disconnect the appliance from the mains supply.
• Cut off the mains electrical cable close to the appliance and dispose of it.

3. INSTALLATION

WARNING!

Refer to Safety chapters.

3.1 Installation instructions

For complete information about the installation of the appliance refer to a separate installation booklet.

4. PRODUCT DESCRIPTION

4.1 Control panel overview

Function Description

1 On / Off Turns the hood on and off.

2 First speed The motor switches to first speed level.

3 Second speed The motor switches to second speed level.

4 Third speed: The motor switches to third speed level.

5 Maximum speed: The motor switches to maximum speed level.

6 Breeze: The hood operates on the lowest speed. After 60 minutes the appliance turns off.

7 Hob: Indicator of the function to control hood from hob.

8 Filter notification: Reminds to change or clean the charcoal filter and clean the grease filter.

9 Lamp: Turns the lights on and off.

5. DAILY USE

5.1 Using the hood

Check the recommended speed according to the table below.

1 While heating up food, cooking with covered pots.

2 While cooking with covered pots on multiple cooking zones or burners, gentle frying.

3 While boiling and frying big quantities of food without a lid, cooking on multiple cooking zones or burners.

While boiling and frying big quantities of food without a lid, big humidity. After 8 minutes the appliance returns to previous setting.

Refreshes the air in kitchen after cooking at a very low noise level. It can be activated and de-activated by touching the symbol. The function turns off automatically after 60 minutes. Use after cooking only.

It is recommended to leave the hood operating for approximately 15 minutes before and after cooking.

Activating the appliance

The control panel is a sensor field. To operate the hood, touch the symbol exactly in the middle for at least 1 second.

To operate the hood:

1. Turn on the appliance by pressing the symbol.

You can now activate the functions.

1. To activate a function, touch the symbol.

Deactivating the appliance

To turn off the appliance, press the symbol again.

Lighting

The hood lighting works independently of other hood functions.

Activating and deactivating the lighting To illuminate the cooking surface, touch the symbol.

5.2 Hob ² Hood function

This function connects the hob to a hood. Both the hob and the hood are equipped with an infrared signal communicator. The fan speed is determined based on the mode setting and the temperature of the hottest cookware on the hob. Alternatively, you can manually control the fan using the hob. This function can be activated from the hob's control panel.

For more information on how to use the function, refer to the hob user manual.

5.3 Activating Maximum Motor Speed

When you touch it, the Maximum Motor Speed starts to operate for 8 minutes. After that time, the appliance returns to its previous speed settings.

When the function is turned on, additional touches do not have any effects.

5.4 Filter notification

The filter alarm serves as a reminder to clean the grease filter and either replace or clean the charcoal filter, depending on its type. The symbol blinks regularly for 30 seconds if the grease filter must be cleaned. The symbol blinks twice per second for 30

seconds if the charcoal filter must be replaced or cleaned.

This function activates independently after 40 hours of operation for the grease filter and 160 hours of operation for the charcoal filter.

Refer to "Cleaning the grease filter" in the Care and cleaning chapter.

Refer to "Cleaning the charcoal filter" or "Replacing the charcoal filter" in the Care and cleaning chapter.

To reset the function counter in the notification period, touch the symbol for 3

seconds. The symbol stops blinking for the correct reset.

The function counter for the charcoal filter is disabled by default. For recirculation mode, it must be activated.

To activate or deactivate the counter for the charcoal filter:

1. Switch on the control panel.
2. Make sure the fan and the light are turned off.
3. Touch the symbol for 3 seconds. The function is activated if symbols 2 and blink once. The function is deactivated if symbols 2 and blink twice.

6. CARE AND CLEANING

6.1 Notes on cleaning

Cleaning Agents

Do not use abrasive detergents and brushes.

Clean the surface of the appliance with a soft cloth with warm water and a mild detergent.

After cooking some parts of appliance can get hot. To avoid stains appliance must be cooled down and dried with clean cloth or paper towels.

Clean stains with a mild detergent.

Keep the hood clean

Clean the appliance and grease filters each month. Clean the interior and grease filters carefully from fat. Fat accumulation or other residue may cause fire.

Grease filters can be washed in a dishwasher.

The dishwasher must be set to a low temperature and a short cycle. The grease filter may discolour, it has no influence on the performance of the appliance.

Charcoal filter

The time of saturation of the charcoal filter varies depending on the type of cooking and the regularity of cleaning the grease filter. Refer to leaflet included in the accessory.

Before carrying out any maintenance, make sure there is no cookware on the hob and that the hood and the hob are disconnected from the power supply.

6.2 Cleaning the grease filter

Filters are mounted with the use of clips and pins on the opposite side.

To clean the filter:

1. Press the handle of the mounting clip on the filter panel underneath the hood (1).

1. Slightly tilt the front of the filter downwards (2), then pull.

Repeat the first two steps for all filters.

1. Clean the filters using a sponge with non abrasive detergents or in a dishwasher.

The dishwasher must be set to a low temperature and a short cycle. The grease filter may discolour, it has no influence on the performance of the appliance.

7. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

1. To mount the filters back follow the first two steps in reverse order.

Repeat the steps for all filters if applicable.

6.3 Replacing the charcoal filter - optional

Depending on type, filter can be or cannot be regenerated. Refer to the leaflet provided with the filter.

To replace the filter:

1. Remove the grease filters from the appliance.

Refer to "Cleaning the grease filter" in this chapter.

1. Turn the two latches counterclockwise by 90 degrees. Slightly tilt the charcoal filter, then pull it out.

1. To install a filter, perform the same steps in reverse order.

6.4 Replacing the lamp

This appliance is supplied with a LED lamp and separate control gear (LED driver). These parts can be replaced by a technician only. In case of any malfunction refer to "Service" in the "Safety Instructions" chapter.

7.1 What to do if...

Problem Possible cause Remedy
You cannot activate the appliance. The appliance is not connected to a power supply or it is connected incorrectly.		Check if the appliance is correctly connected to the electrical supply.
You cannot activate the appliance. Lack of electrical power supply.		Check the fuse or the main switch. If the fuse or the switch continue to break the circuit, contact a qualified electrician.
The lamp does not operate. The lamp is defective. Replace the lamp. Refer to the "Care and Cleaning" chapter.
The appliance does not absorb enough vapours.	The motor speed is not adequate to the appearing vapours.	Change the speed of the motor.

8. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol. Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances. Do not dispose of

appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.

1. To install the filter, perform the same steps in reverse order.

6.4 Replacing the lamp

Disconnect the device from the power source.

3. Installation

7. Troubleshooting

⚠️ Warning!

7. TROUBLESHOOTING

WARNING!

9 Lamp Turns the lights on and off.

1. To install the filter, repeat the same steps in reverse order.

6.4 Replacing the bulb

4. PRODUCT DESCRIPTION

ELECTROLUX APPLIANCES AB

BUSINESS SECTOR EMA-EMEA (SEE)

ST GÖRANSGATAN 143

SE-105 45 STOCKHOLM

SWEDEN

TEL: [phone]

FAX: [phone]

www.electrolux.com
