Z890 MAX GAMING WIFI7 - Motherboard ASUS - Free user manual and instructions

Product Type	Motherboard
Brand	ASUS
Model	Z890 MAX GAMING WIFI7
Form Factor	ATX
Socket	LGA1851
Chipset	Intel Z890
Supported CPU	Intel Core Ultra (Arrow Lake-S)
Memory Support	4x DDR5, up to 9200+ MHz (OC)
PCIe Slots	1x PCIe 5.0 x16, 1x PCIe 5.0 x8, 2x PCIe 4.0 x4
Storage	5x M.2 (PCIe 5.0 x4), 4x SATA 6Gbps
Wireless	WiFi 7 (802.11be), Bluetooth 5.4
LAN	2.5Gb Ethernet (Realtek RTL8125BG)
USB Ports (Rear)	2x USB4 (Type-C), 2x USB 3.2 Gen2, 4x USB 3.2 Gen1, 2x USB 2.0
Audio	Realtek ALC4082 7.1-ch HD Audio
Power Connectors	24-pin ATX, 2x 8-pin EPS
Dimensions	305 x 244 mm (12.0 x 9.6 in)
Weight	~1.2 kg (with accessories)
Main Features	ROG thermal armor, PCIe Slot Q-Release, BIOS FlashBack, AI Overclocking
Maintenance	Keep dry, clean with soft cloth, avoid dust buildup
Safety	Handle with anti-static wrist strap, avoid liquid contact
Spare Parts & Repairability	Non-user-serviceable; contact ASUS support for replacement

Frequently Asked Questions - Z890 MAX GAMING WIFI7 ASUS

What CPU is compatible with the Z890 MAX GAMING WIFI7?

This motherboard supports Intel Core Ultra processors (Arrow Lake-S) with the LGA1851 socket.

What memory type does it support?

It supports DDR5 RAM with speeds up to 9200+ MHz overclocked, across four slots.

Does it support PCIe 5.0?

Yes, it features PCIe 5.0 on the primary x16 slot and multiple M.2 slots.

How do I update the BIOS on this motherboard?

Use BIOS FlashBack via the USB port on the rear I/O panel. No CPU or RAM required. Download the BIOS file to a FAT32 USB drive, rename it, and press the FlashBack button.

What is the form factor?

The board is ATX (305 x 244 mm). Ensure your case supports this size.

Does it have built-in WiFi?

Yes, it includes WiFi 7 (802.11be) and Bluetooth 5.4.

How many M.2 slots are available?

There are five M.2 slots, all supporting PCIe 5.0 x4.

What is the recommended power supply wattage?

A 850W or higher power supply is recommended, depending on your CPU and graphics card. The board requires 24-pin ATX and two 8-pin EPS connectors.

Can I use liquid cooling?

Yes, it has multiple fan headers and pump headers for water cooling. The VRM heatsink is designed for high thermal loads.

Does it support USB4?

Yes, the rear I/O provides two USB4 Type-C ports for high-speed data and display output.
