Product Type	Bluetooth Keyboard for Tablet
Brand	Samsung
Model	EF-DX710
Dimensions (L x W x H)	Approximately 255 x 180 x 5 mm
Weight	Approximately 350 g
Power Source	Rechargeable lithium-ion battery via USB-C
Battery Life	Up to 100 hours of use
Number of Keys	78 keys (depending on layout)
Connectivity	Bluetooth 5.0
Main Features	Android shortcut keys, magnetic support, integrated touchpad
Compatibility	Samsung Galaxy Tab S7, S8, S9 and later models
Material	Plastic and aluminum
Color	Black (or gray depending on version)
Maintenance and Cleaning	Clean with a soft, dry cloth. Do not use liquid products.
Safety	Do not expose to humidity or extreme temperatures.
Spare Parts and Repairability	Keyboard not user-serviceable. No spare parts available.
Box Contents	EF-DX710 keyboard, USB-C charging cable, quick start guide

Frequently Asked Questions - EF-DX710 SAMSUNG

How do I connect the EF-DX710 keyboard to my tablet?

Enable Bluetooth on your tablet and put the keyboard in pairing mode (press and hold the Fn and Bluetooth keys). Select 'Samsung EF-DX710' from the list of devices.

What is the battery life?

The battery lasts up to 100 hours of continuous use. The battery recharges via the USB-C port (cable included).

Is the keyboard waterproof?

No, the keyboard is not waterproof. Avoid any contact with water or liquids to prevent damage to electronic components.

Can I use this keyboard with other tablet brands?

The EF-DX710 is designed specifically for Samsung Galaxy Tab. It may work with other Android devices via Bluetooth, but the shortcut keys and magnetic support might not be compatible.

How do I clean the keyboard?

Use a soft, dry cloth to wipe the surface. For stubborn stains, slightly dampen the cloth (no chemicals) and wipe immediately with a dry cloth.

What to do if a key stops working?

First check the Bluetooth connection and battery charge. If the problem persists, try resetting the keyboard (press and hold Fn + Escape for 5 seconds). If nothing works, contact Samsung support.

Does the keyboard have a touchpad?

Yes, the EF-DX710 features a multifunction touchpad for navigating the interface without using the touchscreen.

What are the dimensions and weight?

The keyboard measures approximately 255 x 180 x 5 mm and weighs about 350 g, making it very slim and light for easy portability.

Can I replace the battery myself?

No, the battery is built-in and not removable. For battery issues, contact an authorized Samsung repair center.

How do I activate Android shortcut keys?

The shortcut keys (like back, home, etc.) are active by default with compatible Samsung tablets. Refer to the user guide for a full list of shortcuts.

USER MANUAL EF-DX710 SAMSUNG

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

Using the keyboard

Attaching the keyboard

▶ EF-DX710, EF-DX810, EF-DX910:

1. Align each corner of the lower part of the cover with the tablet and then attach the cover. 2. After the cover is attached, check that the camera fits the camera hole. If it is crooked, detach it and then attach it again.

3. Line up the connectors of the tablet and the keyboard, and then attach the tablet to the keyboard.

You will immediately be able to use the keyboard.

▶ EF-DX715, EF-DX815, EF-DX915:

1. Check the location of the camera and the camera hole, and then align each corner of the upper part of the cover with the tablet. 2. Attach the upper part of the cover first, and then press the rest part down.

3. Line up the connectors of the tablet and the keyboard, and then attach the tablet to the keyboard.

You will immediately be able to use the keyboard.

• Do not apply excessive pressure on the keyboard while covering the tablet's screen. Doing so may cause screen damage.
• If the tablet and the keyboard connectors are dirty, the keyboard may not be recognised or work properly.
• While moving to another place with the tablet, close the keyboard. If you move while the keyboard is opened, the tablet may separate and be damaged. • Use the product on a flat surface.

You can use the keyboard as a screen cover. The screen turns off when you cover it with the keyboard, and it turns on when you open the keyboard.

Adjusting the tablet angle (EF-DX715, EF-DX815, EF-DX915)

You can adjust the tablet angle with the product's stand. Flip out and adjust the stand until you find the desired angle.

• Do not excessively tilt or apply too much pressure to the stand. Doing so may cause damage or deform it.
• Do not apply pressure to the tablet's screen while the angle of the stand is adjusted low. Doing so may cause the stand to fall over.

Using the keys

Set the input language on the tablet before you use the keyboard. For more information about setting the input language, refer to the tablet's user manual.

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	·[Fn] + [APP1]/[APP2]/[APP3]: Open the favourite apps. (EF-DX910, EF-DX915)To save an app to favourites, open the app you want to save and press and hold the Fn key and the APP1/APP2/APP3 key for 3 seconds.
B	·[Fn] + [DeX]: Start or end Samsung DeX.
C	·Open the Google Assistant app.
D	·[Fn] + [urn the touchpad on or off. (EF-DX715, EF-DX815, EF-DX915)
E	·[Lang]: Change between input languages.·[Fn] + [turn the on-screen keyboard on or off.
F	·▲/▼/◄/►: Move the cursor.·[Fn] + [▲]: Page Up·[Fn] + [▼]: Page Down·[Fn] + [◄]: Home·[Fn] + [►]: End

For more information about Samsung DeX, refer to the tablet's user manual.

Using the touchpad (EF-DX715, EF-DX815, EF-DX915)

You can use the touchpad to control the cursor on the tablet screen or use the additional features.

Actions Functions
Clicking/Tapping	• Click
Dragging	• Move the cursor.
Holding and dragging	• Move the selected object.
Tapping with two fingers	• Open the context menu.
Dragging with two fingers	• Scroll the page.
Spreading/Pinching	• Zoom in / Zoom out
Dragging up/down with three fingers	• Recents/Home
Dragging left/right with three fingers	• Switch between apps.
Tapping with three fingers	• Back

Storing the S Pen

1 Attach the S Pen to the tablet's S Pen charger as shown in the image.

Align the S Pen properly with the S Pen charger. If the S Pen is incorrectly attached, the S Pen cover may not be closed.

2 Cover the S Pen with the S Pen cover.

Replacing the S Pen cover

The product's S Pen cover is interchangeable. When changing the S Pen cover, press the camera hole of the S Pen cover and remove it.

To attach the S Pen cover, align the S Pen cover with the product's S Pen cover groove and push the edge until it clicks into place.

Usage notices

Precautions for using the product

Please read this manual before using the product to ensure safe and proper use.

• Images may differ in appearance from the actual product. Content is subject to change without prior notice.
• The product is optimised to connect with the SAMSUNG Tab S9, Galaxy Tab S9+ and Galaxy Tab S9 Ultra.
• Do not expose the product to humidity, solvents or high temperatures. Doing so may stain, wrinkle, discolour or distort it.
• If there is debris on the product's attachment surface, wipe the surface clean before using the product.
• Avoid placing the product in hot or humid environments. If the product is exposed to direct sunlight, its colour or form may change.
• Be careful not to scratch the product with sharp objects such as nails.
• When using this product, some customers may experience allergic reactions, such as itching, eczema, or swelling. If you experience any of these symptoms, stop using the product and consult a physician.
• While using the product, be cautious to prevent scratches or damage from debris.
• Your product contains magnets. Keep it away from credit cards, implanted medical devices, and other devices that may be affected by magnets. In the case of medical devices, keep your product more than 15 cm apart. Stop using your product if you suspect any interference with your medical device and consult your physician or your medical device manufacturer.
• This product includes certain free/open source software. The licence information of the open source software used in this product can be found at opensource.samsung.com.

Instructional icons

Warning: situations that could cause injury to yourself or others. Caution: situations that could cause damage to your product or other equipment. Notice: notes, usage tips, or additional information.

Notes on package contents and accessories

Check the product box for the following items:

• Product
• Quick start guide

• The items supplied with the product and any available accessories may vary depending on the region or carrier.
• Appearances and specifications are subject to change without prior notice.
• You can purchase additional accessories from the Samsung website. Make sure they are compatible with the product before purchase.
• Use only Samsung-approved accessories. Using unapproved accessories may cause performance problems and malfunctions that are not covered by the warranty.
• Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.

Appendix

FCC Part 15.19

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Part 15.105

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

(USA Only) WARNING! Never dispose of batteries in a fire because they may explode. Do not disassemble, crush, puncture, heat, burn or reuse batteries. For more information, visit call2recycle.org or call 1-800-822-8837. Alternatively, visit: www.samsung.com/recycling or call 1-800-SAMSUNG.

Samsung Electronics America, Inc.

85 Challenger Road,

Ridgefield Park, New Jersey, 07660

Phone: 1-800-SAMSUNG (726-7864)

Copyright

Copyright © 2023 Samsung Electronics Co., Ltd.

Copyright © 2023 Samsung Electronics America, Inc.

This manual is protected under international copyright laws.

No part of this manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system.

Trademarks

• SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics Co., Ltd.
• All other trademarks and copyrights are the property of their respective owners.

Getting Started

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Replacing the S Pen cover

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Usage instructions

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX715:

EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX715:

EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

3 Align the tablet and keyboard connectors, then attach the tablet to the keyboard. You will be able to use the keyboard immediately.

▶ EF-DX715, EF-DX815, EF-DX915:

3 Align the connectors on the tablet and keyboard, then attach the tablet to the keyboard. You will be able to use the keyboard immediately.

• Do not press the keyboard excessively while covering the tablet screen. This may cause damage to the screen.
• If the tablet and keyboard connectors are dirty, the keyboard may not be recognized or may not work properly.
• Close the keyboard when moving to another location with the tablet. If you move while the keyboard is open, the tablet may detach and be damaged. • Use the product on a flat surface.

• Do not tilt or press the stand excessively. This may cause damage or deformation.
• Do not press the tablet screen while the stand angle is set low. This could cause the stand to tip over.

Using the keys

Before using the keyboard, set the input language on the tablet. For more information about setting the input language, refer to the tablet's user manual.

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	[Fn] + [APP1]/[APP2]/[APP3]: Otvorite omiljene aplikacije. (EF-DX910, EF-DX915)Kako biste spremili aplikaciju u favorite, otvorite aplikaciju koju želite spremiti te pritisnite i držite gumb Fn i gumb APP1/APP2/APP3 tijekom 3 sekunde.
B	[Fn] + [DeX]: Pokrenite ili zatvorite Samsung DeX.
C	Otvorite aplikaciju Google Assistant.
D	[Fn] + [☑]: Uključite ili isključite podlogu osjetljivu na dodir. (EF-DX715, EF-DX815, EF-DX915)
E	[Lang]: Mijenjajte između jezika unosa. [Fn] + [☑]: Uključite ili isključite zaslonsku tipkovnicu.
F	▲ / ▼ / ◀ / ▶: Pomaknite pokazivač.\( [Fn] + [▲]: Stranica gore [Fn] + [▼]: Stranica dolje [Fn] + [◀]: Početak [Fn] + [▶]: Završetak

For more information about the Samsung DeX app, refer to the tablet's user manual.

Using the touchpad (EF-DX715, EF-DX815, EF-DX915)

Radnje Funkcije
Klikanje/dodirivanje	• Klik
Povlačenje	• Pomaknite pokazivač.
Držanje i povlačenje	• Premjestite odabrani objekt.
Dodirivanje s dva prsta	• Otvorite kontekstni izbornik.
Povlačenje s dva prsta	• Pomičite stranicu.
Širenje/štipanje	• Uvećavanje/umanjivanje
Povlačenje nagore/nadolje s tri prsta	• Nedavno/Početak
Povlačenje ulijevo/udesno s tri prsta	• Prebacivanje između aplikacija.
Dodirivanje s tri prsta	• Stražnja strana

Storing the S Pen

Align the S Pen correctly with the S Pen charger. If the S Pen is not attached properly, the S Pen cover may not close.

2 Cover the S Pen with the S Pen cover.

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

Using the keyboard

▶ EF-DX710, EF-DX810, EF-DX910:

1 Align each corner of the bottom cover with the tablet, then attach the cover. 2 When attaching the cover, make sure the camera aligns with the camera hole. If it is not properly positioned, detach it and reattach it.

3 Align the tablet and keyboard connectors, then attach the tablet to the keyboard. You will be able to use the keyboard immediately.

▶ EF-DX715, EF-DX815, EF-DX915:

1 Check the location of the camera and the camera hole, then align each corner of the top cover with the tablet. 2 Attach the top cover first, then press the remaining part down.

3 Align the tablet and keyboard connectors, then attach the tablet to the keyboard. You will be able to use the keyboard immediately.

• Do not press the keyboard too hard while covering the tablet screen. This may damage the screen.
• If the tablet and keyboard connectors are dirty, the keyboard may not be recognized or may not work properly.
• Close the keyboard when moving to another location with the tablet. If you move while the keyboard is open, the tablet may detach and be damaged. • Use the product on a flat surface.

You can use the keyboard as a screen cover. The screen turns off when you cover it with the keyboard, and turns on when you open the keyboard.

Adjusting the tablet angle (EF-DX715, EF-DX815, EF-DX915)

You can adjust the angle of the tablet using the product stand. Take out and adjust the stand until you find the desired angle.

• Do not tilt or press the stand excessively. This may cause damage or deformation.
• Do not press the tablet screen while the stand angle is set low. This may cause the stand to tip over.

Using the keys

Set the input language on the tablet before using the keyboard. For more information about setting the input language, refer to the tablet's user manual.

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	[Fn] + [APP1]/[APP2]/[APP3]: Otvorite omiljene aplikacije. (EF-DX910, EF-DX915)Da biste sačuvali aplikaciju u omiljene, otvorite aplikaciju koju želite i pritisnite i držite taster Fn i taster APP1/APP2/APP3 tokom 3 sekunde.
B	[Fn] + [DeX]: Otvorite ili zatvorite „Samsung DeX“.
C	Otvorite aplikaciju Google pomoćnik.
D	[Fn] + [][]: Uključivanje ili isključivanje tačpeda. (EF-DX715, EF-DX815, EF-DX915)
E	[Lang]: Menjajte između jezika unosa. [Fn] + [][][]: Uključivanje ili isključivanje tastature na ekranu.
F	▲ / ▼ / ◀ / ▶: Pomerite kursor. [Fn] + [▲]: Strana na gore [Fn] + [▼]: Strana na dole [Fn] + [◀]: Početak [Fn] + [▶]: Kraj

For more information about the Samsung DeX app, refer to the tablet's user manual.

Using the touchpad (EF-DX715, EF-DX815, EF-DX915)

You can use the touchpad to control the cursor on the tablet screen or to use additional functions.

Radnje Funkcije
Kliktanje/kuckanje	• Klik
Prevlačenje	• Pomerite kursor.
Držanje i prevlačenje	• Pomerite izabrani objekat.
Kuckanje sa dva prsta	• Otvorite kontekstni meni.
Prevlačenje sa dva prsta	• Pomerajte stranicu.
Širenje / štipanje	• Uvećavanje /umanjivanje
Prevlačenje nagore / nadole sa tri prsta	• Nedavno / početak
Prevlačenje ulevo / udesno sa tri prsta	• Menjanje između aplikacija.
Kuckanje sa tri prsta	• Nazad

Storing the S Pen

Align the S Pen correctly with the S Pen charger. If the S Pen is not attached properly, the S Pen cover cannot be closed.

2 Cover the S Pen with the S Pen cover.

Usage notes

Precautions for using the product

Copyright © 2023 Samsung Electronics Co., Ltd.

This manual is protected by international copyright laws.

No part of this manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storage in any information storage and retrieval system.

Trademarks

• SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics Co., Ltd.
• All other trademarks and copyrights are the property of their respective owners.

Getting Started

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

This manual is protected by international copyright laws.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	·[Fn] + [APP1]/[APP2]/[APP3]: atveriet izlases programmas. (EF-DX910, EF-DX915)Lai programmu saglabātu izlasē, atveriet vēlamo programmu un turiet piespiestu taustiņu Fn un taustiņu APP1/APP2/APP3 3 sekundes.
B	·[Fn] + [DeX]: Samsung DeX sākšana vai pabeigšana.
C	·Atveriet Google Assistant programmu.
D	·[Fn] + [☐]: ieslēdziet vai izslēdziet skārienjutīgo paliktni. (EF-DX715, EF-DX815, EF-DX915)
E	·[Lang]: mainiet ievades valodu.·[Fn] + [☐]: ieslēdziet vai izslēdziet ekrāna tastatūru.
F	·▲ / ▼ / ◀ / ▶: pārvietojiet kursoru.·[Fn] + [▲]: lapa uz augšu·[Fn] + [▼]: lapa uz leju·[Fn] + [◀]: sākums·[Fn] + [▶]: beigas

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

!

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Usage notes

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Attach the S Pen correctly to the S Pen charger. If the S Pen is attached incorrectly, the S Pen cover may not close.

2 Cover the S Pen with the S Pen cover.

Usage notes

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	• [Fn] + [APP1]/[APP2]/[APP3]: uw favoriete apps openen. (EF-DX910, EF-DX915)U kunt een app aan uw favorieten toevoegen door de gewenste app te openen en de Fn-toets en de APP1/APP2/APP3-toets gedurende 3 seconden ingedrukt te houden.
B	• [Fn] + [DeX]: Samsung DeX starten of beëindigen.
C	• De Google Assistent-app openen.
D	• [Fn] + [☐]: de touchpad in- of uitschakelen. (EF-DX715, EF-DX815, EF-DX915)
E	• [Lang]: tussen invoertalen wisselen.• [Fn] + [☐]: het schermtoetsenbord in- of uitschakelen.
F	• ▲ / ▼ / ◀ / ▶: de cursor verplaatsen.• [Fn] + [▲]: pagina omhoog• [Fn] + [▼]: pagina omlaag• [Fn] + [◀]: start• [Fn] + [▶]: einde

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Replace the S Pen cover

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

Using the keyboard

Attaching the keyboard

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Usage notes

Precautions when using the product

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

Using the keyboard

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	·[Fn] + [APP1]/[APP2]/[APP3]: Åbn de foretrukne apps (EF-DX910, EF-DX915). For at gemme en app under foretrukne skal du åbne den app, du vil gemme, og trykke og holde på tasten Fn samt tasten for APP1/APP2/APP3 i 3 sekunder.
B	·[Fn] + [DeX]: Start eller luk Samsung DeX.
C	·Åbn appen Google Assistant.
D	·[Fn] + [☐]: Tænd eller sluk touchpad (EF-DX715, EF-DX815, EF-DX915).
E	·[Lang]: Skift mellem inputsprog.·[Fn] + [☐]: Tænd eller sluk skærmtastaturet.
F	·▲ / ▼ / ◀ / ▶: Flyt markøren.·[Fn] + [▲]: Side op·[Fn] + [▼]: Side ned·[Fn] + [◀]: Startside·[Fn] + [▶]: Afslut

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

Using the keyboard

▶ EF-DX710, EF-DX810, EF-DX910:

1 Align both corners of the bottom part of the cover with the tablet, then attach the cover. 2 Once the cover is attached, check that the camera fits into the camera hole. If it is misaligned, remove it and reattach it.

3 Align the connectors on the tablet and keyboard, then attach the tablet to the keyboard.

▶ EF-DX715, EF-DX815, EF-DX915:

1 Check the position of the camera and the camera hole, and align each corner of the top part of the cover with the corners of the tablet. 2 Attach the top part of the cover first, then press down on the rest.

3 Align the connectors on the tablet and keyboard, then attach the tablet to the keyboard.

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	[Fn] + [APP1]/[APP2]/[APP3]: zaženite priljubljene aplikacije. (EF-DX910, EF-DX915) Če želite aplikacijo shraniti med priljubljene, zaženite aplikacijo, ki jo želite shraniti, ter pritisnite tipki Fn in APP1/APP2/APP3 in ju držite 3 sekunde.
B	[Fn] + [DeX]: zaženite ali zaprite Samsung DeX.
C	Zaženite aplikacijo Pomočnik Google.
D	[Fn] + [][]: vklopite ali izklopite sledilno tablico. (EF-DX715, EF-DX815, EF-DX915)
E	[Lang]: spreminjajte jezike za vnos. [Fn] + [][][]: vklopite ali izklopite zaslonsko tipkovnico.
F	▲///: premaknite kazalec. [Fn] + [▲]: stran gor [Fn] + [▼]: stran dol [Fn] + [◀]: domov [Fn] + [▶]: konec

Align the S Pen properly with the S Pen charger. If the S Pen is not attached correctly, the S Pen cover may not close.

2 Cover the S Pen with the S Pen cover.

Replacing the S Pen cover

The S Pen cover can be replaced. To replace the S Pen cover, press the camera hole on the S Pen cover and remove it.

To attach the S Pen cover, align the S Pen cover with the groove on the S Pen cover and push the edge until it snaps into place.

Usage notices

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX715:

EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX810, EF-DX910:

EF-DX715, EF-DX815, EF-DX915:

EF-DX710, EF-DX715:

EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Usage Notice

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

A	·[Fn] + [APP1]/[APP2]/[APP3]: Membuka aplikasi favorit. (EF-DX910, EF-DX915)Untuk menyimpan aplikasi ke favorit, buka aplikasi yang ingin Anda simpan, lalu tekan lama tombol Fn dan tombol APP1/APP2/APP3 selama 3 detik.
B	·[Fn] + [DeX]: Mulai atau akhiri Samsung DeX.
C	·Buka aplikasi Google Assistant.
D	·[Fn] + [☑]: Mengaktifkan atau menonaktifkan pad sentuh. (EF-DX715, EF-DX815, EF-DX915)
E	·[Lang]: Mengubah bahasa masukan.·[Fn] + [☑↑]: Mengaktifkan atau menonaktifkan keyboard di layar.
F	·▲ / ▼ / ◀ / ▶: Memindahkan kursor.·[Fn] + [▲]: Halaman Atas·[Fn] + [▼]: Halaman Bawah·[Fn] + [◀]: Home·[Fn] + [▶]: End

Replacing the S Pen cover

:EF-DX915, EF-DX815, EF-DX715

:EF-DX915, EF-DX815, EF-DX715

Usage Notices

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Replacing the S Pen cover

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX715, EF-DX815, EF-DX915:

Replacing the S Pen cover

Usage precautions

Product usage precautions

▶ EF-DX715, EF-DX815, EF-DX915:

Reinstalling the S Pen cover

Usage precautions

Product usage precautions

設備名稱:書本式鍵盤皮套,型號(型式):EF-DX710,EF-DX715,EF-DX810, EF-DX815,EF-DX910.EF-DX915Equipment name Type designation (Type)
單元Unit	限用物質及其化學符號Restricted substances and its chemical symbols
	鉛Lead(Pb)	汞Mercury(Hg)	鎘Cadmium(Cd)	六價鉻Hexavalent chromium( Cr+6 )	多溴聯苯Polybrominated biphenyls (PBB)	多溴二苯醚Polybrominated diphenyl ethers (PBDE)
電路板-	0 0 0 0	0
塑膠外殼	0 0 0 0	0 0
矽膠00	0 0 0 0
電線00	0 0 0 0
備考1.“超出0.1wt%”及“超出0.01wt%”係指限用物質之百分比含量超出百分比含量基準值。Note 1:“Exceeding 0.1 wt %”and“exceeding 0.01 wt %”indicate that the percentage content of the restricted substance exceeds the reference percentage value of presence condition.備考2.“O”係指該項限用物質之百分比含量未超出百分比含量基準值。Note 2:“O”indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.備考3.“-”係指該項限用物質為排除項目。Note 3:The“-”indicates that the restricted substance corresponds to the exemption.

Copyright

Copyright © 2023 Samsung Electronics Co., Ltd.

This manual is protected by international copyright laws.

▶ EF-DX715, EF-DX815, EF-DX915:

Replacing the S Pen cover

Usage precautions

Precautions when using this product

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Copyright © 2023 Samsung Electronics Co., Ltd.

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Usage notices

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX810, EF-DX910:

▶ EF-DX715, EF-DX815, EF-DX915:

▶ EF-DX710, EF-DX715:

▶ EF-DX810, EF-DX815, EF-DX910, EF-DX915:

Replacing the S Pen cover

Things to know when using the product

Precautions when using the product
