Product Type	LED TV
Screen Size	32 inches (81 cm)
Resolution	1366 x 768 (HD Ready)
Refresh Rate	60 Hz
Dimensions (without stand)	732 x 433 x 76 mm (W x H x D)
Dimensions (with stand)	732 x 479 x 180 mm
Weight (without stand)	4.2 kg
Weight (with stand)	4.5 kg
Power Supply	AC 100-240V, 50/60 Hz
Power Consumption (typical)	50 W
Standby Power Consumption	< 0.5 W
HDMI Inputs	2 x HDMI 1.4
USB Ports	1 x USB 2.0
Composite Video Input	1 x AV (shared with audio)
Audio Output	1 x 3.5mm headphone jack
Tuner	DVB-T/T2/C
Built-in Speaker Power	2 x 5 W
VESA Mounting	100 x 100 mm
Operating Temperature	5°C to 35°C
Accessories Included	Remote control, batteries, user manual, power cord
Cleaning Instructions	Unplug and wipe with dry soft cloth. Do not use liquid cleaners.
Safety Note	Do not expose to rain or moisture. Place on stable surface.
Repairability	Refer to authorized service center for repairs. Do not open.

Frequently Asked Questions - NH3218S NIKKEI

How do I connect my NH3218S TV to a Wi-Fi network?

This model does not have built-in Wi-Fi. Use an external streaming device via HDMI or connect via Ethernet if available.

What is the ideal viewing distance for this 32-inch TV?

For HD Ready resolution, a viewing distance of 1.2 to 2.1 meters is recommended.

Why is there no sound from the TV speakers?

Check if the volume is muted or too low. Verify that audio output is set to 'TV Speaker' in the menu. If using external devices, ensure they are not set to audio output only.

Can I mount the NH3218S on a wall?

Yes, it supports VESA 100x100 mm mount. Use appropriate screws and ensure the wall can support the weight.

How do I reset the TV to factory settings?

Press Menu, go to Settings, then select 'Factory Reset'. Confirm with the OK button. This erases all personal settings.

What remote control codes work with the NH3218S?

The TV uses its own remote, model likely RC-32NIK. Universal remote codes are not standardized; try code search method.

Why is the screen flickering?

Flickering may be due to a loose cable or incorrect refresh rate setting. Try a different HDMI cable or check power source.

How do I clean the TV screen safely?

Turn off and unplug the TV. Use a soft, dry microfiber cloth. Do not spray any liquid directly on the screen.

What is the warranty period for the NH3218S?

Typically, Nikkei offers a 1-year limited warranty. Check your purchase receipt or contact support for details.

How do I connect a game console to this TV?

Use an HDMI cable to connect the console to any HDMI port on the TV. Select the corresponding HDMI input using the Source button.

USER MANUAL NH3218S NIKKEI

Front view of a flat-screen television displaying blank screen with no visible text or symbols

Warning symbol of a lightning bolt inside a triangle (no text or numbers)

>100%

>100%

CE

Safety

Please immediately pull out the AC power plug of adapter if there is abnormal sound or smell or it has sound but no picture, and contact with maintenance station after confirming no abnormality.

Illustration of a computer monitor displaying a cartoon dinosaur character (no text or symbols present)

Simple line drawing of a landscape with a tree, cloud, and TV (no text or symbols)

TV should be kept free from rain, damp and dust for prevention of electric shock and short circuit.

TV should be kept from high temperature heating objects or direct sunlight. TV should be place with good ventilation.

If necessary, you may clean the display with soft and clean cotton after pulling out the power plug, but do not emphatically and repeatedly wipe.

Scraping, tapping or striking the display with hard object or wiping the display with grinding object is forbidden.

Do not wipe the machine with naphtha or thinner, which will lead to transformation of enclosure or breakage of coating. It may result in dirt if the machine has been contacting with rubber or ethane for long time.

It's forbidden to contact the display with organic solvents such as alcohol or gasoline or chemical solvent such as acid or alkali, etc.

Illustration showing a person holding a large screen with a prohibition symbol, a chair, and a monitor on a table (no text or symbols present)

Do not put TV on unstable or shaky place

Please do not place the power line or signal line across walkway or at place where people usually come and go in case the line to be trampled. Do not overload the power line or power socket.

Illustration of a cable being connected to a computer monitor, with lightning bolts indicating electrical hazard (no text or symbols present)

Cartoon illustration of a man sitting at a desk with a TV, holding a pointer (no text or symbols present)

Please do not disassemble the back cover by non professionals as it has high voltage in the machine, in case for electric shock; and the internal adjustment and check should be conducted by professionals.

Do not put water container such as cosmetics or medicine liquid on TV.

Please pull out the plug and contact the maintenance station if there are abnormal objects or water in TV.

Illustration of a computer monitor with a crossed-out 'X' symbol above it, no text or symbols present.

Please pull out the power plug of adapter in lightning strike, and pull out cable TV plug or outdoor antenna plug, in case the TV to be damaged. Do not contact the lead-in line of antenna.

A plain gray rectangular bar with no text, symbols, or markings.

1

Technical line drawing of a mechanical or electronic component with multiple ports and connectors (no text or symbols)

Illustration of a vertical TV with a circular button and base, no text or symbols present

Illustration of a modern TV with a stand and a circular symbol (no text or labels)

Front view of a flat-screen monitor with two side buttons at the bottom (no visible text or symbols)

Technical diagram of a mechanical assembly with two bolt holes and mounting brackets (no text or labels)

Front view of a flat-screen monitor with two legs and a gradient screen (no text or symbols visible)

Mechanical assembly diagram showing two bolted components mounted on a beam, with no visible text or symbols.

Illustration of a hand interacting with a tablet screen, showing no text or symbols

Technical line drawing of a flat-screen TV unit with internal components and mounting feet (no text or symbols)

Fig. 1
Fig. 2

A plain gray rectangular shape with no text, symbols, or discernible features.

Blank gray rectangular image with no visible text, symbols, or features

No image and voice[IMAGE]	Possible causes:*Power cord, antenna or input devices are not connected;*The TV set is not powered on.Solutions:*Check Power cord ,antenna and input devices;*Press Power key on the remote control;*Press Power key on the set to power it off for 5 seconds and then re-power it on .
No voice[IMAGE]	Possible causes:*The volume is too low;Muted or cancelled;*Incorrect sound system.Solutions:*Press Volume key to turn up the volume;*Press Mute key to cancel Mute mode.Well connect vonnection to the background sound;*Change the sound system in the menu.
Snows and noises:[IMAGE]	Possible causes:*The cable is damaged or gets loose;*Incorrect channel preset;*Improper antenna positioning.Solutions:*Check whether the connection of the antenna cable ,DVD and the cables is correct;*Reset channels or fine tune the channel;*Adjust the direction of the antenna.
Achromatic colour[IMAGE]	Possible causes:*Incorrect Colour system settings;Low chroma level setting ;*Improper antenna positioning.Solutions:*Change the colour system into the local system in the menu ;*Increase chroma level;*Adjust the direction of the antenna.
Remote controlis no effect : ✗	Possible causes:*Battery runs up;*Incorrect battery loading;Solutions:*Check the battery electricity or replace the battery;*Check if the poles of the battery are correct.
Note: To properly watch CANAL + using this product, carry out DVB-T channel search when CANAL + is unsarambled.Form 12:30 p.m. to 1:30 p.m.From 7:00 p.m.to 8:30 p.m.

For any other problem that may occur on your device, please contact Customer Service.
