STS 850 D1 - Toaster SILVERCREST - Free user manual and instructions

Product Type	Toaster
Brand	SilverCrest
Model	STS 850 D1
Number of Slots	2
Browning Control	Adjustable rotary dial with 7 levels
Functions	Toast, reheat, defrost, bagel mode, cancel button
Self-Centering Racks	Yes
High Lift Function	Yes, for easy removal of small items
Removable Crumb Tray	Yes, pull-out for easy cleaning
Cord Storage	Yes, under the base
Power Source	AC 220-240 V, 50/60 Hz
Power Consumption	850 W
Dimensions (W x D x H)	Approx. 30 x 19 x 21 cm
Weight	Approx. 1.4 kg
Housing Material	Stainless steel and plastic
Safety Features	Automatic shut-off, overheat protection, non-slip feet
Cleaning	Wipe exterior with damp cloth; empty crumb tray regularly
Spare Parts Availability	Crumb tray, heating elements, control knob (contact manufacturer)
Repairability	Modular design; repair possible with basic tools
Package Contents	Toaster, user manual
Warranty	3 years (check local regulations)

Frequently Asked Questions - STS 850 D1 SILVERCREST

How do I clean the SilverCrest STS 850 D1 toaster?

Unplug the toaster and let it cool. Wipe the exterior with a damp cloth. Pull out the crumb tray at the bottom, empty it, and wash it with warm soapy water. Do not immerse the toaster in water.

Can I toast bagels in this toaster?

Yes, the STS 850 D1 has a bagel function. Select the bagel mode to toast only the cut side of the bagel while warming the other side.

What does the defrost function do?

The defrost function extends the toasting time to properly thaw and toast frozen bread. Use it for frozen slices directly from the freezer.

How do I adjust the browning level?

Turn the browning control dial to your desired level (1-7). Level 1 is light toast, level 7 is dark. Start with a medium setting (3-4) and adjust to taste.

Why does the toaster turn off before the bread is toasted?

The toaster may have overheated or the browning setting is too low. Check that the slots are not blocked and increase the browning level. If the issue persists, contact support.

Is the crumb tray dishwasher safe?

It is recommended to wash the crumb tray by hand with mild detergent. High dishwasher temperatures may warp the tray.

Can I toast more than two slices at once?

No, the STS 850 D1 is a 2-slot toaster designed for two slices of bread. Toasting more may cause uneven results and overheating.

What is the power cord length?

The power cord is approximately 85 cm long, with a cord wrap underneath for storage.

Does the toaster have a cancel button?

Yes, press the cancel button at any time to stop the toasting cycle immediately.

Where can I find spare parts for the STS 850 D1?

Contact SilverCrest customer service or visit the manufacturer's website. Common spare parts include the crumb tray and heating elements.

USER MANUAL STS 850 D1 SILVERCREST

TOASTER STS 850 D1

GB IE NI CY

TOASTER

Operating instructions

DE AT CH

TOASTER

Bedienungsanleitung

GR CY

ФРУГАНИЕРА

Οδηγίες χρήσης

IAN 277391

GB IE NI CY

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

GR CY

GB/IE/NI/CY Operating instructions Page 1

Disposal of the packaging 3

Appliance description 3

Technical data....4

Safety instructions 4

Tips for use 6

Setting up 7

Before taking into use 7

Operation 7

Adjusting the browning level 7

Toasting 8

Interrupting the toasting process 8

Warming function 8

Defrost function 9

Crumb tray 9

Cleaning 9

Storage 10

Troubleshooting 10

Disposal 10

Kompernass Handels GmbH warranty 11

Service 12

Importer 12

Introduction

Congratulations on the purchase of your new appliance!

You have clearly decided in favour of a modern, high quality product. These operating instructions are a component of this product. They contain important information in regard to safety, use and disposal. Before using the product, familiarise yourself with all of these operating and safety instructions. Use this appliance only as described and only for the purposes indicated. In addition, pass these documents on, together with the product, to any future owner.

Copyright

This documentation is copyright protected.

Any copying or reproduction of it, including as extracts, as well as the reproduction of images, also in an altered state, is only permitted with the written authorisation of the manufacturer.

Limited liability

All technical information, data and instructions for the installation, connection and operation contained in these operating instructions correspond to the latest available at the time of printing and, to the best of our knowledge, take into account our previous experience and know-how.

No claims can be derived from the details, illustrations and descriptions in these instructions.

The manufacturer assumes no responsibility for damage caused by failure to observe these instructions, improper use, incompetent repairs, making unauthorized modifications, or using unapproved replacement parts.

Intended use

This appliance is intended exclusively for toasting slices of bread in private households. It is not intended for use with other foods or other materials.

This appliance is intended exclusively for use in domestic households. Do not use the appliance for commercial applications!

Items supplied

The appliance is delivered with the following components as standard:

• Toaster
• Operating instructions

1) Remove the appliance and the operating instructions from the carton.

2) Remove all packing material.

NOTICE

▶ Check the contents to ensure everything is present and for visible damage. ▶ If the delivery is not complete or has been damaged due to defective packaging or transportation, contact the Service Hotline (see section Service).

Disposal of the packaging

The packaging protects the appliance from transport damage. The packaging materials are selected from the point of view of their environmental friendliness and disposal technology and are therefore recyclable.

The recirculation of packaging into the material circuit saves on raw material and reduces the amount of waste generated. Dispose of packaging material that is no longer needed as per the regionally established regulations.

If possible, keep the appliance's original packaging during the warranty period so that, in the event of a warranty claim, you can pack the appliance ideally for its return.

Appliance description

Illustration A:

1 Cable clamp

2 "Defrost" button

3 "Warm up" button

4 "Stop" button

5 Toasting dial

Illustration B:

6 Toasting slots

7 Operating button

8 Cable winder

9 Crumb tray

Technical data

Voltage 220 - 240 V ~, 50 / 60 Hz
Power consumption 850 W
	All of the parts of this appliance that come into contact with food are food-safe.

Safety instructions

RISK OF ELECTRIC SHOCK

• Arrange for damaged power cables and/or plugs to be replaced as soon as possible by a qualified specialist or by Customer Services. ▶ Use the appliance only in dry indoor areas, not outdoors. NEVER submerse the appliance in water or other liquids! If you do, then you could receive a potentially fatal electric shock. ▶ NEVER insert cutlery items or other metallic objects into the toaster slots.
• Ensure that the appliance can never come into contact with water. NEVER use the appliance adjacent to water or close to vessels containing liquids.
• Ensure that the power cable never gets wet or moist when the appliance is in use. Lay the cable such that it cannot be clamped or otherwise damaged. ▶ After use, always remove the plug from the mains power socket, this prevents the unintentional switching on of the appliance.

⚠ WARNING! RISK OF INJURY!

The appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

▶ Children should not play with the appliance.

- Cleaning and user maintenance should not be performed by children, unless they are older than 8 years of age and are supervised. Children younger than 8 years of age are to be kept away from the appliance and the power cable.

The appliance can become hot when it is in use. Therefore, only touch the operating elements.

▶ Use the appliance only on a stable, non-slippery and level surface.

- Do not use an external timing switch or a separate remote control system to operate the appliance.

▶ Unwind the power cable completely from the cable winder before using the appliance.

WARNING!

- Risk of burning if you do not use standard toast bread! Because of the smaller size or shape, there is a risk of touching hot parts when removing the toasted bread.

CAUTION - RISK OF FIRE!

▶ Bakery products can burn! You should therefore NEVER locate the appliance close to or underneath inflammable objects, especially not under curtains or suspended cupboards. - This appliance may not be used in close vicinity to flammable material. ▶ NEVER cover the toaster when it is in use.

Tips for use

■ Avoid using slices that are too big or too thick, as these can easily become jammed in the appliance. Should slices of bread become jammed, first disconnect the plug from the mains power socket. Release jammed slices of bread with a blunt wooden object (e.g. a wooden spatula or spoon). Thereby, do NOT touch the heater elements.

■ Differences in bread sorts, moisture content and the thickness of individual slices influence the browning of the toast. Therefore the bread for toasting should be kept in sealed packaging until required. Always initially try out a lower level of browning.

■ Use a lower level of browning if you are toasting dry bread, as dry bread browns faster than fresh bread.

■ Select a higher level of browning for dark bread than for light bread, for example, wheat bread.

The numbers on the toasting dial ⑤ are not time indications. They serve only as a guide for the browning.

■ To avoid an overheating of the toaster and to obtain an even browning of bread, wait for about 15 seconds between two toasting processes.

You should only use the highest level on the toasting dial ⑤ for large slices of dark bread. With this browning level light bread will scorch and become inedible. In addition, it may cause the generation of smoke. If this occurs, press the button "Stop" immediately and disconnect the power cable from the mains power socket.

Setting up

CAUTION - RISK OF FIRE

▶ You should therefore NEVER locate the appliance close to or underneath inflammable objects, especially not under curtains or suspended cupboards.

■ Unwind the cable completely from around the cable winder ⑧ and lead it through the cable clamp ①.

■ Place the appliance on a level and heat-resistant surface.

Insert the plug into a mains power socket.

When the toaster is not in use, always remove the plug from the mains power socket. This is the only way to ensure that the appliance is current-free.

Before taking into use

Operate the toaster without bread for 3 times at the maximum browning level "7".

Afterwards, clean the toaster as described in the chapter "Cleaning".

The operating slide ⑦ only engages when the cable is connected to a mains power socket. With the first usage a slight smell can arise (minimal smoke development is also possible). This is normal and dissipates after a short time. Provide for sufficient ventilation. For example, open a window.

Operation

Adjusting the browning level

The desired level of browning, from "light" (1) to "dark" (7), can be adjusted infinitely with the toasting dial ⑤.

Toasting

CAUTION - RISK OF FIRE!

When the appliance is in operation, do NOT cover the toasting slots ⑥. There will be a risk of fire! The appliance could be irreparably damaged!

If you only want to put one piece of toast into the toaster, turn the toasting dial ⑤ down by approx. 1/2 level to achieve the same level of browning as with 2 pieces of toast.

1) After setting the desired browning level, insert the bread into the toaster slots ⑥. 2) Press the operating slide ⑦ downwards. The automatic bread centring device centres the inserted bread in the toaster slots ⑥. During the toasting process the control lamp integrated in the "Stop" button ④ glows. 3) When the desired level of browning has been reached the toaster switches itself off automatically, the slices are ejected to the top and the control lamp goes out.

Interrupting the toasting process

If you wish to interrupt the toasting procedure, press the button "Stop" ④. The toaster switches itself off and the bread slices are ejected upwards.

Warming function

The warming function enables you to warm bread without browning it. As an example, for toast that has gone cold. The bread is only briefly warmed.

1) Insert the bread and press the operating slide ⑦ downwards. 2) Press the "Warm up" button ③. The integrated control lamp lights up. 3) When the bread has been reheated, the appliance switches itself off automatically and the slices are ejected upwards.

Defrost function

By pressing the button "Defrosting" ②, also frozen bread can be thawed and toasted. With this, the toaster slowly warms the bread. Activating the defrost function will allow the frozen bread to achieve the same browning level as when you toast fresh bread.

1) After setting the desired browning level, insert the bread into the toaster slots ⑥. 2) Press the operating slide ⑦ downwards. 3) Press the button "Defrosting" ②. The integrated control lamp glows. 4) When the defrosting and toasting process is finished, the toaster switches itself off automatically, the control lamp integrated in the button "Defrosting" goes out and the bread slices are ejected to the top.

Crumb tray

When toasting, crumbs that fall from the bread are collected in the crumb tray ⑨.

1) To empty crumbs from the crumb tray ⑨, simply pull it out. 2) Tip out the crumbs. 3) Slide the crumb tray ⑨ back into the toaster so that it palpably engages.

Cleaning

RISK OF ELECTRIC SHOCK

▶ Disconnect the plug from the mains power socket before cleaning the appliance.

NEVER submerse the appliance in water or other liquids! If you do, then you could receive a potentially fatal electric shock.

WARNING! RISK OF INJURY!

▶ Allow the toaster to cool before cleaning it. Risk of Burns!

CAUTION - PROPERTY DAMAGE!

▶ Do not use aggressive or abrasive cleaning agents. These can damage the upper surfaces of the appliance.

■ Clean the appliance housing only with a dry or lightly moistened cloth.

■ To avoid the risk of fire, empty the crumb tray ⑨ at regular intervals.

Storage

- Clean the toaster as described in the chapter "Cleaning".

Wrap the power cable around the cable winder 8 on the underside of the toaster.

■ Store the toaster in a dry location.

Troubleshooting

Problem Cause Remedy
The appliance does not function.	The plug is not inserted into a mains power socket.	Connect the power cable into a mains power socket.
	The appliance is defective.	In this case, contact Customer Services.
The slices of toast are too dark.	The level of browning is set too high.	Set the toasting dial 5 somewhat lower.
The slices of bread are not toasted.	The level of browning is set too low.	Set the toasting dial 5 somewhat higher.
The operating slide 7 does not engage when it is pressed down.	The plug is not inserted into a mains power socket.	Insert the plug into a mains power socket.
	The appliance is defective.	In this case, contact Customer Services.

Disposal

Do not dispose of the appliance in your normal domestic waste. This product is subject to the provisions of European Directive 2012/19/EU (Waste Electrical and Electronic Equipment).

Dispose of the appliance through an approved disposal centre or at your community waste facility. Observe the currently applicable regulations. In case of doubt, please contact your waste disposal centre.

This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.

Warranty conditions

The validity period of the warranty starts from the date of purchase. Please keep your original receipt in a safe place. This document will be required as proof of purchase.

If any material or production fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you at our discretion. This warranty service is dependent on you presenting the defective appliance and the proof of purchase (receipt) and a short written description of the fault and its time of occurrence.

If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.

Warranty period and statutory claims for defects

The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.

Scope of the warranty

This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.

The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or fragile parts such as switches, batteries, baking moulds or parts made of glass.

The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.

This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications/repairs which have not been carried out by one of our authorised Service centres.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

- Please have the till receipt and the item number (e.g. IAN 12345) available as proof of purchase.

- You will find the item number on the type plate, an engraving on the front page of the instructions (bottom left), or as a sticker on the rear or bottom of the appliance.

- If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

- You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

You can download these instructions along with many other manuals, product videos and software on www.lidl-service.com.

Service

GB Service Great Britain

Tel.: [phone] (£ 0.10/Min.)

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]

CY Service Cyprus

Tel.: [phone]

E-Mail: [e-mail]

IAN 277391

Importer

Please note that the following address is not the service address. Please use the service address provided in the operating instructions.

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com
