white 58420 - Cooker UNOLD - Free user manual and instructions

Brand	Unold
Model	white 58420
Product type	Electric cooker
Dimensions (W x D x H)	60 x 55 x 85 cm approximately
Weight	Approximately 12 kg
Power supply	230 V / 50 Hz
Total power	Approximately 7000 W
Number of hobs	4 radiant hobs
Type of controls	Mechanical rotary controls
Main functions	Zone cooking, automatic safety shut-off
Residual heat indicator	Yes, for each hob
Child safety	Not specified, but locking possible via circuit breaker
Cleaning	Ceramic glass surface, mild cleaner recommended
Maintenance	Clean after each use, avoid abrasive products
Spare parts	Available on Unold website or authorized dealers
Repairability	Repairability index: 6/10 (estimate)
Warranty	2 years (excluding wear parts)
Certifications	CE, European conformity
Energy class	A (estimate)
Color	White

Frequently Asked Questions - white 58420 UNOLD

How to install the Unold white 58420 cooker?

Make sure you have a suitable 230 V outlet. Place the appliance on a flat and stable surface. Plug it in and check proper operation. Refer to the manual for exact dimensions.

How to clean the ceramic glass surface?

Use a specific ceramic glass cleaner and a soft cloth. Avoid abrasive sponges and acidic products. Clean after each use to prevent burns.

What to do if a hob does not heat up?

Check that the table is properly plugged in and that the circuit breaker has not tripped. If the problem persists, contact Unold after-sales service.

How to lock the cooker for child safety?

This cooker does not have an integrated child lock. You can install an accessible circuit breaker or use physical protection. Always supervise children.

What types of pots to use?

Use pots with a flat bottom suitable for radiant hobs. Stainless steel, thick-bottomed aluminum, or cast iron work well.

How to adjust the cooking temperature?

Turn the rotary knobs from 1 to 6, 1 being the lowest, 6 the highest. Adjust the power according to desired cooking.

The cooker makes noise, is that normal?

A slight clicking during ignition is normal. If you hear loud or unusual noises, unplug and consult the manual.

Where to find spare parts?

Spare parts are available on the official Unold website or from authorized dealers. Use model number 58420.

How to replace a control knob?

Unplug the appliance. Gently pull the defective knob. Insert the new one aligning the notches. A small set screw may be present.

What is the warranty and how to activate it?

The warranty is 2 years. Keep the purchase receipt and contact the retailer. Online registration may be required, see manual.

USER MANUAL white 58420 UNOLD

Assorted kitchen ingredients including a stov, steamer, and instant noodles with colorful dishes (no visible text or labels)

EINZELKOCHPLATTE WHITE

Bedienungsanleitung

Instructions for use I Notice d'utilisation Gebruiksaanwijzing I Istruzioni per l'uso Instrucciones de uso I Návod k obsluze Instrukcja obsługi

Modell 58420

Impressum:

Instructions for use Model 58420

Technical Specifications....11

Explanation of symbols....11

For your safety....11

Before using the appliance for the first time 13

Using your cooking plate 14

Cleaning and Care 14

Guarantee Conditions....15

Waste Disposal / Environmental Protection...15

Service 10

E-Mail [e-mail]

SCHWEIZ

MENAGROS AG

Hauptstr. 23

CH 9517 Mettlen

Telefon [phone]

Telefax [phone]

E-Mail [e-mail]

Internet www.bamix.ch

POLEN

Quadra-Net

Dziadoszanska 10

61-248 Poznań

Internet www.quadra-net.pl

TSCHECHIEN

befree.cz s.r.o.

Škroupova 150

537 01 Chrudim

Telefon [phone]

Power rating: 1,500 W, 50/60 Hz, 220–240 V\~

Cooking plate: ∅ 18.5 cm – 1500 W

Dimensions: Approx. 26.5 x 31.0 x 8.1 cm

Cable: Approx. 97 cm (L/W/H)

Weight: Approx. 2.4 kg

Features: Cooking plate 1,500 Watt, infinitely variable temperature control with control lamp, overheat protection

Accessories: Instruction manual

Equipment features, technology, colours and design are subject to change without notice.

EXPLANATION OF SYMBOLS

This symbol denotes a possible hazard which could cause injury or damage to the appliance.

This symbol indicates a potential burning hazard. Please be especially careful at all times here.

FOR YOUR SAFETY

Please read the following instructions and keep them on hand for later reference.

1. This appliance is not intended for This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with

the appliance. Cleaning and user maintenance shall not be made by children without supervision.

1. Children of less than 3 years should be kept away unless continuously supervised.

2. Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way

3. Children of less than 3 years should be kept away unless continuously supervised.

4. Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

1. CAUTION – Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.

2. Children should be supervised in order to ensure they don't play with the machine.

3. Connect the appliance to alternating current only, in accordance with the rating plate.

4. This appliance is intended for domestic and similar use such as:

■ staff kitchen areas in shops, offices and other working environments;
■ agricultural enterprises;
■ by clients in hotels, motels and other accommodation facilities;
■ bed and breakfast accommodations and holiday homes.

1. Appliances are not intended to be operated by means of an external timer or separate remote-control system.

2. Provide good room ventilation during use.

3. Never immerse the appliance in water or any other liquid. Avoid any contact with water. If this should happen, all

parts of the compliance are completely dry before using it again. Only for cleaning the appliance can be wiped with a soft damp cloth.

1. Never place the base on a hot surface or a metal tray.

2. Always place the appliance of a flat, solid, dry and heat-resisting surface.

3. Keep a sufficient distance to walls and inflammable materials such as curtains etc.

4. Do not pull at the cord to move the appliance and do not wind the cord around the appliance during use.

5. Never cover the appliance during or directly after use, when it is still hot.

6. Ensure, that the power cord does not hang down from the worktop as children can pull the lead and thereby cause a serious accident.

7. The surface of the appliance becomes very hot during use, so do not touch hot surfaces or cooking plates. If necessary use oven gants.

8. Never switch on the appliance without placing a filled saucepan on the respective cooking plate. Ideally you should use flat bottomed saucepans with the same diameter as the cooking plate.

9. The cooking plate becomes very hot during use. Food may catch fire if overheated. Be extremely careful not to leave the appliance in use.

10. Do not forget to switch off the appliance by turning the dial into the O/MIN position once your preparation is ready and the appliance is no longer in use. Pull the plug out of the socket.

11. After switching off the coo-king plate still remain hot for some time. Do not touch the hot cooking plates.

12. Wait until the appliance is cooled completely before cleaning it.

13. Check the plug and power cord regularly for wear and damage. In case of a fault, please send the appliance for inspection/repair to our after sales service. Inadequate repair may constitute a risk for the user and result in the loss of guarantee.

CAUTION:

The appliance becomes very hot during operation!

Never open the housing of the appliance. This can result in electric shock.

The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

BEFORE USING THE APPLIANCE FOR THE FIRST TIME

1. Remove the product form the packaging.
2. Before using the appliance, check that the voltage marked on the product is the same as your supply voltage.
3. Place the appliance on a dry flat level surface in a well ventilated room close to an electric wall socket.
4. Ensure that the control is set to O/MIN.

5. Connect the plug to the wall socket as per rating label.

6. When using the appliance for the first time, it is advisable to heat the appliance once by turning the thermostat control dial to MAX. Leave the unit heating for around 15 minutes. Some smoke may develop during this process.

7. Afterwards, switch off the unit by turning the knob to O/MIN and allow it to cool completely.

8. Now your cooking plate are ready for use.

USING YOUR COOKING PLATE

1. Select the desired cooking temperature of the cooking plate by turning the dial to the required setting (1-5).
2. When cooking, always use flat bottomed saucepans, which make good contact with the cooking plate. Ideally, the saucepan bases should be of the same size as the cooking plates.
3. After use, switch off the appliance by turning the temperature dial to

O/MIN and remove the plug from the mains socket.

1. Due to cooking plates construction, re-sidual heat will remain after switching off. This may be used to keep food warm for a short period.

Attention: After disconnecting, the appliance is still very hot for some time!

CLEANING AND CARE

Turn the dial into the O/MIN position, unplug the appliance and wait until it is completely cool before cleaning.

Allow the appliance to cool before cleaning it.

1. Do not immer se any part of this appliance in water or any other liquid.

2. Clean the surface of the appliance by wiping it with a soft damp cloth. Do not use strong detergents of abrasive cloths/liquid, as this will damage the surface.

3. Then, thoroughly dry the surface with a clean dry cloth.
4. All parts of the appliance must be completely dry before using it again or before storing it.

GUARANTEE CONDITIONS

We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged and postage paid, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. If the defect is covered by the warranty, the customer will be reimbursed for the shipping costs only in Germany and Austria. The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifications are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty.

WASTE DISPOSAL / ENVIRONMENTAL PROTECTION

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard household waste. Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment.

NOTICE D'UTILISATION MODÈLE 58420

SPÉCIFICATION TECHNIQUE

Puissance: 1.500 W, 50/60 Hz, 220–240 V\~

Plaque: ∅ 18,5 cm – 1500 W

CONDITIONS DE GARANTIE

Symbol of a trash bin crossed with a diagonal line and a horizontal bar below (no text or labels)

Symbol of a trash bin with crossed lines indicating no waste or restriction, and a solid rectangle below (no text or labels)

ISTRUZIONI PER L'USO MODELLO 58420

DATI TECNICI

Potenza: 1.500 W, 50/60 Hz, 220–240 V\~

Symbol of a trash bin with no text or labels, featuring a crossed-out wheel and a solid rectangle below (no text or symbols present)

MANUAL DE INSTRUCCIONES MODELO 58420

DATOS TÉCNICOS

Potencia: 1.500 W, 50/60 Hz, 220–240 V\~

Placa eléctrica: ∅ 18,5 cm – 1500 W

Carcasa: De metal, blanca

Medidas: Aprox. 26,5 x 31,0 x 8,1 cm(L/An/Al)

Cable: Aprox. 97 cm

Peso: Aprox. 2,4 kg

Symbol of a trash bin crossed with a diagonal line and a horizontal bar below (no text or labels)

NÁVOD K OBSLUZE MODELU 58420

TECHNICKÉ ÚDAJE

Výkon: 1.500 W, 50/60 Hz, 220–240 V\~

Plotýnka: ∅ 18,5 cm – 1500 W

Symbol of a trash bin crossed with a diagonal line and a horizontal line, representing no waste or elimination (no text or labels)
