USER MANUAL PIUMA IMETEC

[A]
(A) GUIDA ILLUSTRATIVA ILLUSTRATIVE GUIDE

[B1]

[C1][D1]

SCHEDA PRODOTTO PRODUCT DATA SHE

DATITARGA TECNICI TECHNICAL DATA

IMETEC

TYPE F6208

220-240 V 50 Hz 600 W

c€

www.imetec.com

Tel. +39.035.688.111 Fax +39.035.320.149

0415(MMY人)

M1001878

Dear customer, IMETEC thanks you for having purchased this product. We are certain you will appreciate the quality and reliability of this appliance, designed and manufactured with customer satisfaction in mind. This instruction manual has been drawn up in compliance with the European Standard EN 62079.

IMPORTANT!

uctions and warnings for safe use

Before using this appliance, carefully read the instructions and in particular the safety warnings, which must be complied with. Keep this manual and illustrative guide with the appliance for future consultation. Should you pass the appliance on to another user, make sure to also include this documentation.

NOTE: Should certain parts of this booklet be difficult to understand or should doubts arise, contact the company before using the product, at the address indicated on the last page.

INDEX

SAFETY WARNINGS PAGE 8

SYMBOLS PAGE 10

DESCRIPTION OF THE APPLIANCE AND ITS ACCESSORIES PAGE 10

ASSEMBLY PAGE 10

ACCESSORIES PAGE 10

USE PAGE 10

MAINTENANCE PAGE 11

STORING AND CARING FOR THE PRODUCT PAGE 12

TROUBLESHOOTING PAGE 12

DISPOSAL PAGE 13

ASSISTANCE AND WARRANTY

ILLUSTRATIVE GUIDE

TECHNICAL DATA

PAGE 14

I-II-III

IV

SAFETY WARNINGS

• After having removed the appliance from its packaging, verify its integrity based on the drawing and any presence of damage caused by transport. If in doubt, do not use the appliance and contact an authorised service centre.
- Do not let children play with the packaging! Keep the plastic bag out of the reach of children - risk of suffocation!
- Before connecting the appliance, check that the technical data (9) match the mains supply. The identification technical data (9) are found on the

appliance and on the power supply/battery charger (if present).

• This appliance must be used only for the purpose for which it was designed, namely as a vacuum cleaner for home use. Any other use is considered not compliant and therefore dangerous.
• This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the risks involved. Children must not play with the appliance. The appliance cannot be cleaned or serviced by children without adult supervision.

• DO NOT use the vacuum cleaner to vacuum:

• burning ashes, cigarette butts, etc.;

• liquids, such as carpet cleaners;
• sharp or hard objects, such as nails or large glass shards;
• fine powder, such as cement;

• toner powder (for laser printers, copy machines, etc.).

• ☉ NEVER use the vacuum cleaner without inserting the dust bag, dust container or filter.

• DO NOT use the appliance with wet hands, damp feet or barefoot.
• DO NOT pull the power cable or the appliance itself to remove the plug from the socket.
• DO NOT expose the appliance to humidity or weather conditions (rain, sun, etc.).
• Always disconnect the appliance from the mains supply before cleaning or performing maintenance and when the appliance is not in use.
• If the appliance is faulty or malfunctions, switch it off and do not tamper with it. Any repairs must only be carried out by an authorised technical service centre.
• If the power cable is damaged it must be replaced by an authorised technical service centre, so as to prevent all risks.
• ✉ NEVER pull or lift the appliance by its cable.
• ✉ NEVER submerge the appliance in water or other liquids.
• ✉ NEVER direct the flexible hose, pipe or any other accessory towards eyes or ears and do not put them in your mouth when they are connected to the vacuum cleaner.
• Always use the appliance with a motor protection filter to prevent damaging the motor and the vacuum cleaner.

EN

- The power cable must always be fully unwound to prevent hazardous overheating.

SYMBOLS

		Warning ON/OFF switch
		Prohibited Hard floors
		Protection class II Carpets

DESCRIPTION OF THE APPLIANCE AND ITS ACCESSORIES (Fig. A)

Refer to Figure [A] in the illustrative guide to verify your appliance equipment. All the figures are on the cover pages of these instructions for use

1. Handle

2. Manual cable winding system

2A Turning upper cable hook

2B Fixed lower cable hook

1. Fastening screw

2. Power cable with plug

3. Combination carpet/floor brush 5A Brush position toggle switch

4. Suction inlet

5. Dust bag compartment cover

6. Dust bag compartment opening lever

7. Dust collection system

9A. Dust bag guides

9B. Dust bag

9C. Safety interlock

9D. Motor protection filter

9E. Filter guides

1. ON/OFF switch

2. Dust bag full indicator

ASSEMBLY

• Loosen the fastening screw (3) of the handle (1) and remove it.
• Attach the handle (1) to the body of the appliance, taking care to assemble it correctly.
• Insert the fastening screw (3) and tighten it clockwise [Fig. B1].
• Select the combination brush (5) and connect the element to the intake connection (6).

ACCESSORIES

Combination carpet/floor brush (5)

Adjust the combination brush according to the type of flooring, using the toggle switch (5A) [Fig. C1]:

- toggle switch (5A) position A

(extended bristles): for hard floors [Fig. C1-A];

- toggle switch (5A) position B

(retreated bristles): for rugs and carpets [Fig. C1-B].

USE

Fully unwind the power cable (4). To do so, turn the upper cable hook (2A) downwards [Fig. D1].

Using the vacuum cleaner with the cable fully or partly wound involves an overheating hazard!

NOTE:

1. Bear in mind that a new appliance can develop odours the first few times it is used. These odours are harmless and disappear shortly afterwards. Ventilate the room.
2. Transparent parts can become opaque, due to use.

Insert the plug into the socket, while holding the appliance by the handle to prevent it from falling in the event that it was not stored in the OFF position.

Press the ON/OFF button (10) once to switch the vacuum cleaner on or off ① [Fig. E1]:

Switch the appliance off after use, by pressing the ON-OFF button (10) ① and disconnect the plug from the socket.

Wind the cable (4) round the two hooks (2A and 2B) [Fig. D1]. Use the rubber clamp on the plug to fasten the latter to the cable.

MAINTENANCE

ATTENTION! Switch the appliance off and unplug it from the socket before opening the dust collection system!

Make sure all cleaned parts are completely dry before reusing the appliance.

CLEANING THE APPLIANCE

When necessary, clean the appliance with a damp cloth.

ATTENTION! DO NOT USE SOLVENTS OR OTHER AGGRESSIVE OR ABRASIVE DETERGENTS. THIS CAN DAMAGE THE SURFACE.

CLEANING THE COMBINATION BRUSH (5)

With the motor on and the bristles in position (A) (extended bristles), rub the lower part of the brush with your hand to remove dust and fluff that will be directly vacuumed.

REPLACING THE DUST BAG (9B)

Replace the dust bag (9B) as soon as the dust bag full indicator (11) turns red.

Due so promptly: this will prevent any suction loss, as well as an excessively full dust bag from breaking.

ATTENTION! The dust bag full indicator can also go on due to a reduction in suction caused by a large obstructing object. If so, switch the appliance off, unplug it and remove the object from the vacuum cleaner.

Change the dust bag (9B) according to the instructions below and while paying attention to the figures in the illustrative guide.

• Pull the dust bag compartment lever (8) [Fig. F1].
- Remove the dust bag compartment cover (7) [Fig. F2].
- Remove the dust bag (9B) making it slide upwards [Fig. F3A].
- Change the dust bag (9B) with a new one [Fig. F3B].
- Put the new dust bag in (9B) taking care to slide it inside the guides (9A) [Fig. F3C] all the way in and so that the safety interlock (9C) is in a vertical position.
- Fasten the dust bag compartment cover (7) to the appliance by inserting the lower part into its guide [Fig. F2].

EN

- Press the upper part of the dust bag compartment cover until it snaps into place, which indicates that the dust bag compartment lever is properly locked (8).

NOTE: The safety interlock (9C) does not allow closing the dust bag compartment cover (7) if the dust bag (9B) is missing or not fitted properly [Fig. F3C].

If suction does not increase after changing the dust bag (9B), replace the motor protection filter (9D).

CLEANING AND REPLACING THE MOTOR PROTECTION FILTER (9D)

NOTE:

• Replace the filter in the event it is damaged or impossible to clean.
• Replace the filter at least once a year.
• Failure to clean or replace the filter will make the manufacturer's warranty null and void.

• Pull the dust bag compartment lever (8) [Fig. F1].
- Remove the dust bag compartment cover (7) [Fig. F2].
- Remove the motor protection filter (9D) [Fig. F4A].
- Clean the filter (9C) by shaking and brushing the dust off with care. Use a soft brush to prevent any damage.
- If the filter (9D) is clogged with dust, wash it thoroughly with water. Take care not to damage the filter and let it dry completely.

ATTENTION! Let the filter dry for at least 24 hours after washing it. Do not reinstall the filter if it is damp!

• If suction has not increased after changing the dust bag (9B) and cleaning the motor protection filter (9D), replace the filter with a new one.
• Reinstall the pre-motor filter (9D), inserting it in its guides (9E) [Fig. F4C].
• Fasten the dust bag compartment cover (7) to the appliance by inserting the lower part into its guide [Fig. F2].
• Press the upper part of the dust bag compartment cover until it snaps into place, which indicates that the dust bag compartment lever is properly locked (8).

STORING AND CARING FOR THE PRODUCT

When the appliance is not used, unplug it from the socket and store it in a dry and dust-free place. Attach the combination brush (5) with the bristles in position B (reduced bristles) to prevent any damage.

TROUBLESHOOTING

PROBLEM SOLUTION
The appliance does not go on.	·Ensure that the plug is connected to the socket. ·Make sure that the ON/OFF switch has been pressed.
The appliance turns off during use and does not turn on again.	·The vacuum cleaner is equipped with a protective motor thermostat that shuts off the appliance in the event of overheating! (caused by obstructing objects or a clogged dust collection system).·If triggered, switch the appliance off by pressing the ON/OFF switch and let it cool down completely for a few hours.·Remove any dust or the obstructing object before restarting the appliance.
The vacuum cleaner does not suction well.	·Electronic power control set to the minimum: Increase the power to Medium or Max.·The dust collection system is full: replace the dust collection bag.·The bag is not fastened correctly: make sure that the dust collection bag is fitted correctly.·The filter is clogged: clean or replace the filter.
The dust bag full indicator is red.	·The dust collection system is full: replace the dust collection bag.·The filter is clogged: clean or replace the filter.·The sack full indicator can also turn red due to a decrease in power caused by an object that is too large blocking the suction pipes: switch the appliance off, unplug it from the power outlet and remove the object from the vacuum cleaner.·A crevice tool is being used: reduce suction from the electronic power control
The dust collection compartment door does not close properly.	·A safety device prevents closing the dust bag compartment if the dust bag is missing. Make sure that the dust bag is not missing and that it is fitted correctly.
The vacuum cleaner produces odours the first few times it is used.	·These odours are harmless and disappear shortly afterwards. Ventilate the room.

DISPOSAL

The product is packaged in recyclable materials. Dispose of packaging in accordance with the environmental protection standards.

Pursuant to Art. 26 of Italian Legislative Decree no. 49 of 14 March 2014 "Implementation of Directive 2012/19/EU on waste electrical and electronic equipment (WEEE)", the crossed bin symbol on the appliance or its packaging indicates that the product must be disposed of separately from other waste at the end of its useful life.

The user must therefore take the appliance to an appropriate recycling centre for electrical and electronic equipment. Alternatively, instead of handling the disposal, the appliance can be handed over to the retailer when a new, equivalent appliance is purchased. Retailers of electronic products having a sales area of at least 400 m^2 can also be handed electronic products that are to be disposed of measuring less than 25 cm, free of charge and with no obligation to buy.

Appropriate separate collection for the subsequent procedure for the decommissioned appliance for recycling, which includes treatment and environmentally friendly disposal

EN

helps prevent adverse effects on the environment and health and promotes reusing and/or recycling materials that the appliance consists of.

ASSISTANCE AND WARRANTY

The appliance is guaranteed for a period of 2 years from the date of purchase. Evidence shall be constituted by the date indicated on the receipt/invoice (provided it is legible), unless the buyer can prove that the delivery occurred later.

In the case of a defective product existing prior to the date of delivery, IMETEC guarantees to repair or replace the appliance at no cost, unless one of the two solutions is disproportionate to the other. The buyer has the obligation to notify an IMETEC Service Centre of the non-conformity within two months after discovering the defect.

The warranty does not cover any part that may be defective due to:

a. Damage from transport or accidental drops,
b. Incorrect installation or inadequate electrical system,
c. Repairs or alterations made by unauthorised personnel,
d. Poor or incorrect maintenance and cleaning,
e. Product and/or product parts subject to wear and/or consumables,
f. Failure to comply with the appliance's operating instructions negligent or careless use,

The list above is purely indicative and not exhaustive and in any case, this warranty shall not cover all circumstances that cannot be attributed to manufacturing defects of the appliance. The warranty also does not cover any case of improper use of the appliance and professional use.

IMETEC declines all responsibility for any damage that may directly or indirectly be caused to persons, property and pets as a result of failure to comply with all the instructions provided in the Instructions and Warnings Manual regarding appliance installation, use and maintenance.

This is without prejudice to any contractual warranty claims against the seller.

Methods of support

Appliance repairs must be carried out by an IMETEC Service Centre. If the faulty appliance is under warranty, it must be sent to the Service Centre together with a fiscal document that attests the date of sale or delivery.
