Product Type	Surveillance Camera
Model	SEC-CAM350
Brand	Konig
Dimensions (W x H x D)	60 mm x 100 mm x 60 mm
Weight	200 g
Power Supply	DC 12V / 1A
Power Consumption	5 W (max)
Image Sensor	1/3" CMOS
Resolution	1920 x 1080 (Full HD)
Night Vision	Up to 20 m (IR LEDs)
Lens	3.6 mm fixed lens
Viewing Angle	70° (horizontal)
Motion Detection	Yes, with sensitivity adjustment
Audio	Built-in microphone
Connection Type	Wired (BNC + power)
Video Output	CVBS (1.0 Vp-p, 75 Ω)
Housing Material	Metal (aluminum alloy)
Environmental Rating	IP66 (weatherproof)
Operating Temperature	-10°C to +50°C
Mounting Type	Wall or ceiling bracket included
Included Accessories	Power adapter, mounting kit, manual
Maintenance	Wipe with dry cloth; do not use solvents
Safety	Use only provided power adapter; avoid exposure to extreme conditions
Spare Parts / Repairability	Contact Konig support for replacement parts; not user repairable

Frequently Asked Questions - SEC-CAM350 KONIG

How do I connect the SEC-CAM350 camera to my DVR?

Use a BNC cable to connect the video output of the camera to the BNC input of your DVR. Then connect the power adapter to the camera's power port. Ensure the DVR is set to the correct channel.

Why is the night vision not working?

The IR LEDs activate automatically in low light. If they do not turn on, check that the camera is receiving power and that the IR cut filter is not stuck. Also, ensure there is no bright light source near the camera that might prevent the sensor from switching to night mode.

What is the maximum cable length for video transmission?

For analog video (CVBS), the maximum recommended length is 100 meters (328 feet) using RG59 coaxial cable. Longer distances may require a video amplifier.

Can I use this camera outdoors?

Yes, the SEC-CAM350 has an IP66 rating, making it suitable for outdoor use. It is weatherproof and can withstand rain and dust.

How do I adjust the motion detection sensitivity?

Motion detection settings are configured on your DVR or NVR, not on the camera itself. Refer to your recorder's manual to adjust sensitivity, zone, and schedule.

The camera image is blurry. What should I do?

Clean the lens with a soft, dry cloth. Also, adjust the focus ring on the lens if available. If the image remains blurry, check the video cable connections or try a different channel on the DVR.

Does the camera support audio recording?

Yes, it has a built-in microphone. Audio is transmitted over the same coaxial cable if your DVR supports audio input. Otherwise, a separate audio cable may be required.

What type of power adapter is included?

The package includes a DC 12V, 1A power adapter with a barrel connector (5.5 mm outer x 2.1 mm inner). Ensure you use only the supplied adapter to avoid damage.

How do I mount the camera securely?

Use the included mounting bracket and screws. Drill holes for the anchors, attach the bracket to the wall or ceiling, then tighten the camera onto the bracket. Adjust the angle and tighten the locking screws.

The camera is not detected by my DVR. What could be wrong?

First, verify power is connected (LED should be on). Check the BNC cable and ensure the DVR channel is enabled and set to the correct input type (analog). Try connecting the camera directly to the DVR with a short cable to isolate issues.

USER MANUAL SEC-CAM350 KONIG

SEC-CAM350 CCTV MINI DOME CAMERA

Specifications:

• Image chip: 1/3" Sony CCD
- Lens: 3.6 mm
• Horizontal resolution: 420 TV lines
• Light sensitivity: 0.5 LUX
- Backlight compensation: automatic
• Electronic shutter: 1/50\~1/100.000sec
• S/N ratio: >48dB
- White balance: automatic
- Gain: automatic
• Gamma correction: >0.45
- Working temperature: -20°C 50°C
• Video out: BNC / <1.2Vp-p/75 Ohm
• Dimensions: ∅80x100mm
- Weight: 0.133 kg
• Voltage: 12V DC

Supplied without AC/DC adapter.

Recommended AC/DC adapter: SEC-P.SUP.10

Safety precautions:

To reduce risk of electric shock, this product should ONLY be opened by an authorized technician when service is required. Disconnect the product from mains and other equipment if a problem should occur. Do not expose the inside of the product to water or moisture.

Maintenance:

Clean only with a dry cloth. Do not use cleaning solvents or abrasives.

Warranty:

No guarantee or liability can be accepted for any changes and modifications of the product or damage caused due to incorrect use of this product.

General:

Designs and specifications are subject to change without notice. All logos brands and product names are trademarks or registered trademarks of their respective holders and are hereby recognized as such.

Attention:

This product is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collections system for these products.

Declaration of conformity

We,

Nedis B.V., De Tweeling 28, 5215MC 's-Hertogenbosch, The Netherlands, Tel.: [phone], Email: [e-mail]

Declare that product:

Brand: König Electronic

Model: SEC-CAM350

Description: CCTV Dome Camera

Is in conformity with the following standards:

EN 55022:2006, EN 61000-3-2:2006,

EN 61000-3-3:1995+A1:2001+A2:2005

EN 50130-4:1995+A1:1998+A2:2003, EN 61000-4-2/-3/-4/-5/-6/-11

And complies with the requirements of the European Union Directives.

's-Hertogenbosch, 11-05-2009

Mrs. J. Gilad

Purchase director
