Product type	Electric cooker
Brand	Zanker
Model	KEV6040FBB
Height	85 cm
Width	50 cm
Depth	60 cm
Net weight	48 kg
Power supply	220-240 V / 50 Hz
Hob type	Radiant plates (4 burners)
Oven type	Multifunction electric oven
Oven capacity	65 L
Number of oven functions	8 (fan-assisted, top heat, bottom heat, grill, etc.)
Cleaning system	Pyrolytic (self-cleaning)
Energy class (oven)	A
Total power	10.8 kW
Oven lighting	Yes (1 bulb)
Safety features	Child lock, automatic shut-off, residual heat indicator
Display	Digital screen and timer
Hob material	Ceramic glass
Colour	Black (FBB)
Repairability	Spare parts available (heaters, glass, knobs)
Maintenance	Clean with vinegar or special ceramic glass cleaner

Frequently Asked Questions - KEV6040FBB ZANKER

How do I install my Zanker KEV6040FBB cooker correctly?

Place the cooker on a flat surface, at least 5 cm from walls. Plug it into a dedicated 220-240 V outlet. Refer to the manual for electrical connection.

Why are my cooking plates not turning on?

Check that the cooker is plugged in and the main circuit breaker has not tripped. Ensure the control knobs are pushed in and turned correctly.

How do I clean the ceramic glass hob?

Use a special ceramic glass scraper for burnt residues, then clean with a ceramic glass cleaner and a soft cloth.

How do I use the pyrolytic cleaning?

Ensure the oven is empty, select the pyrolytic function and set the duration (usually 1h30 to 3h). Once finished, clean the ashes with a damp cloth.

The oven heats less than the set temperature, what should I do?

Calibrate the temperature regulator (see manual) or replace the temperature sensor. Also check that the door closes properly.

How do I activate the child lock?

Press the 'Lock' button for 3 seconds until the lock symbol appears. To deactivate, repeat the operation.

What does error code 'E02' mean on the display?

Code 'E02' indicates a temperature sensor problem. Turn off the appliance, wait 5 minutes, then turn it on again. If the code persists, contact customer service.

How do I change the oven bulb?

Unplug the cooker, remove the bulb cover (located at the back of the oven), unscrew the old bulb and replace with a new heat-resistant bulb (300°C).

Can I use a steam cleaner for the oven?

No, this could damage electrical components. Use only a damp cloth or the built-in cleaning functions (pyrolysis).

Where can I download the full manual for the KEV6040FBB?

The manual is available for free on notice-facile.com and directly on the Zanker website. You can also download it as a PDF from our page.

USER MANUAL KEV6040FBB ZANKER

Diagram showing a circular object with downward arrows pointing to a plate with four circular holes, no text or symbols present.

Milieubescherming

Safety information	9
Safety instructions	10
Product description	12
Daily use	12
Helpful hints and tips	12

Care and cleaning	12
Troubleshooting	13
Installation	13
Environment concerns	14

Subject to change without notice.

Safety information

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.

Children and vulnerable people safety

⚠ Warning! Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they are supervised by an adult or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when it operates or when it cools down. Accessible parts are hot.
• If the appliance has a child safety device, we recommend that you activate it.
• Cleaning and user maintenance shall not be made by children without supervision.

General Safety

• The appliance and its accessible parts become hot during use. Do not touch the heating elements.
• Do not operate the appliance by means of an external timer or separate remote-control system.

• Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.

• Never try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.

• Do not store items on the cooking surfaces.
• Do not use a steam cleaner to clean the appliance.
• Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.
• If the glass ceramic surface is cracked, switch off the appliance to avoid the possibility of electric shock.

Safety instructions

Installation

Warning! Only a qualified person must install this appliance.

• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the appliance.
• Keep the minimum distance from the other appliances and units.
  • Always be careful when you move the appliance because it is heavy. Always wear safety gloves.
• Seal the cut surfaces with a sealant to prevent moisture to cause swelling.
• Protect the bottom of the appliance from steam and moisture.
• Do not install the appliance adjacent to a door or under a window. This prevents hot cookware to fall from the appliance when the door or the window is opened.
• If the appliance is installed above drawers make sure that the space, between the bottom of the appliance and the upper drawer, is sufficient for air circulation.
• The bottom of the appliance can get hot. We recommend to install a non-combustile separation panel under the appliance to prevent access to the bottom.

Electrical connection

Warning! Risk of fire and electrical shock.

• All electrical connections should be made by a qualified electrician.
• Before connecting the hob to an oven and before every wiring make sure the main terminals of both appliances are not live.
• Make sure the appliance is installed correctly. Loose and incorrect plug and socket can make the terminal become too hot.
• Make sure that a shock protection is installed.
• Do not let the electricity bonds touch the appliance or hot cookware, when you connect the appliance to the near sockets.
• Do not let the electricity bonds tangle.
• Use a strain relief clamp on cable.
• Use the correct mains cable.
• Make sure not to cause damage to the mains plug and to the mains cable. Contact the Service or an electrician to change a damaged mains cable.
• The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the holder), earth leakage trips and contactors.

Use

Warning! Risk of injury, burns or electric shock.

- Use this appliance in a household environment.

- Do not change the specification of this appliance.

• Do not let the appliance stay unattended during operation.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not put cutlery or saucepan lids on the cooking zones. They become hot.
• Set the cooking zone to "off" after use.
• Do not use the appliance as a work surface or as a storage surface.
• If the surface of the appliance is cracked, disconnect immediately the appliance from the power supply. This to prevent an electrical shock.

Warning! Risk of fire or explosion.

• Fats and oil when heated can release flammable vapours. Keep flames or heated objects away from fats and oils when you cook with them.
• The vapours that very hot oil releases can cause spontaneous combustion.
• Used oil, that can contain food remnants, can cause fire at a lower temperature than oil used for the first time.
• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

Warning! Risk of damage to the appliance.

• Do not keep hot cookware on the control panel.

• Do not let cookware to boil dry.

• Be careful not to let objects or cookware fall on the appliance. The surface can be damaged.

• Do not activate the cooking zones with empty cookware or without cookware.
• Do not put aluminium foil on the appliance.
• Cookware made of cast iron, aluminium or with a damaged bottom can cause scratches on the glass ceramic. Always lift these objects up when you have to move them on the cooking surface.

Care and Cleaning

Warning! Risk of damage to the appliance.

• Clean regularly the appliance to prevent the deterioration of the surface material.
• Do not use water spray and steam to clean the appliance.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

Disposal

Warning! Risk of injury or suffocation.

• Contact your municipal authority for information on how to discard the appliance correctly.
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.

General overview

1 Cooking zone 1200 W
2 Cooking zone 1800 W
3 Cooking zone 1200 W
4 Cooking zone 1800 W

Warning! The risk of burns from residual heat!

Daily use

You operate the hob with the knobs of the oven. The Daily Use chapter for the oven tells how to operate the hob.

When a cooking zone operates, it hums for a short time. This is typical of all ceramic glass

Helpful hints and tips

Cookware

• The bottom of the cookware must be as thick and flat as possible.
• Cookware made of enamelled steel and with aluminium or copper bottoms can cause the color change on the glass-ceramic surface.

Energy saving

Care and cleaning

Clean the appliance after each use. Always use cookware with clean bottom.

cooking zones and does not show that the appliance operates incorrectly.

• If it is possible, always put the lids on the cookware.
• Put cookware on a cooking zone before you start it.
• Stop the cooking zones before the end of the cooking time to use residual heat.
• The bottom of pans and cooking zones must have the same dimension.

Warning! The sharp objects and abrasive cleaning agents can cause damage to the appliance.

For your safety, do not clean the appliance with steam cleaners or high-pressure cleaners.

Scratches or dark stains on the glass-ceramic cause no effect on how the appliance operates.

To remove the dirt:

1. – Remove immediately: melted plastic, plastic foil, and food with sugar. If not, the dirt can cause damage to the appliance. Use a special scraper for the glass. Put the scraper on the glass surface at an acute angle and move the blade on the surface.

- Remove after the appliance is sufficiently cool: limescale rings, water rings, fat stains, shiny metallic discolorations. Use a special cleaning agent for glass ceramic or stainless steel.

1. Clean the appliance with a moist cloth and some detergent.

2. At the end rub the appliance dry with a clean cloth.

Troubleshooting

Problem Possible cause Remedy
You cannot activate the appliance or operate it.	Activate the appliance again and system.	set the heat setting in less than 10 seconds.
Problem with the house electrical system.	Examine the fuse in the electrical system of the house in the fuse box. If the fuses blow again and again, speak to qualified electrician.

If you tried the above solutions and cannot repair the problem, speak to your dealer or the customer service. Give the data from the rating plate, three digit letter code for the glass ceramic (it is in the corner of the glass surface) and an error message that comes on.

Make sure, you operated the appliance correctly. If not the servicing by a customer service technician or dealer will not be free of charge, also during the warranty period. The instructions about the customer service and conditions of guarantee are in the guarantee booklet.

Installation

Warning! Refer to the Safety chapters.

Before the installation, note down the serial number (Ser. Nr.) from the rating plate. The rating plate of the appliance is on its lower casing.

Built-in appliances

- Only use the built-in appliances after you assemble the appliance into correct built-in units and work surfaces that align to the standards.

Connection cable

• Use the correct mains cable of type H05BB-F Tmax 90°C (or higher) for a single phase or two phase connection.
• Replace the damaged mains cable with a special cable (type H05BB-F Tmax 90°C or higher). Speak to your local Service Centre.

Assembly

Diagram showing a mechanical setup with a circular component and a tray with four circular holes, no text or symbols present.

Environment concerns

The symbol ☒ on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by

inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

Packaging material

The packaging materials are friendly to the environment and can be recycled. The plastic compo- s are identified by marking: >PE<,>PS<, etc. Dis-

card the packaging materials as household waste at the waste disposal facilities in your municipality.

Sommaire

Diagram showing a beam supported by a tray with circular holes, with arrows indicating force direction (no text or symbols)

Diagram showing a beam supported by circular supports with arrows indicating force direction (no text or symbols)

Umwelttipps
