Product Type	Alarm Clock Radio
Brand	AcuRite
Model	13024A1
Dimensions	6.1 x 3.3 x 3.9 inches (approx.)
Weight	0.8 lbs (approx.)
Power Source	AC adapter (included) with battery backup (requires 2 AAA batteries)
Display Type	Large LED display with adjustable brightness
Radio Bands	AM / FM
Number of Alarms	Dual alarms with programmable wake-up times
Alarm Sound Options	Radio or buzzer
Snooze Function	Yes, 9-minute snooze interval
Battery Backup	Yes, for clock and alarm settings during power loss
Sleep Timer	Yes, auto shut-off radio (up to 90 minutes)
Volume Control	Separate dials for radio volume and alarm volume
Time Format	12-hour or 24-hour display (user selectable)
Dimmer Control	Yes, high/low/off display brightness
Warranty	Limited 1-year warranty
Cleaning	Wipe with soft dry cloth; do not use liquid cleaners
Safety	For indoor use only; keep away from moisture and heat sources

Frequently Asked Questions - 13024A1 AcuRite

How do I set the time on the AcuRite 13024A1?

Press and hold the Clock button for 3 seconds until the hour digits flash. Use the +/- buttons to adjust the hour, then press Clock again to set minutes. Repeat for each setting.

How do I set the alarm?

Press and hold the Alarm 1 or Alarm 2 button until the hour flashes. Use the +/- buttons to set the hour, then press the same alarm button to set minutes. Choose radio or buzzer by pressing the Alarm Mode button.

How do I set the radio station?

Press the Power button to turn on the radio. Tune to desired frequency using the Tuning dial. For precise tuning, use the Scan button to search automatically.

The display is too bright at night. Can I dim it?

Yes, press the Dimmer button to cycle through high, low, and off brightness levels.

How do I enable battery backup?

Insert 2 AAA batteries (not included) into the battery compartment on the bottom of the unit. The clock will retain time and alarm settings during a power outage.

Why is my alarm not sounding?

Ensure the alarm is set and the alarm indicator (Alarm 1 or Alarm 2 icon) is displayed on the screen. Also check that the alarm volume is not turned down. Press the Alarm Mode button to select radio or buzzer.

Can I use the radio as a sleep timer?

Yes, press the Sleep button repeatedly to choose 10, 20, 30, 60, or 90 minutes. The radio will turn off automatically after the selected time.

How do I change between 12-hour and 24-hour time format?

While in time setting mode, after setting the minutes, the 12/24 hour option will appear. Press the + or - button to toggle between 12H and 24H.

What type of AC adapter does the clock use?

The included AC adapter is rated 6V DC, 300mA. Only use the adapter provided to avoid damage. The connector is a standard barrel jack.

How do I clean the unit?

Unplug the clock and wipe it with a soft, dry cloth. Do not use liquid cleaners, abrasives, or solvents, as they may damage the finish.

USER MANUAL 13024A1 AcuRite

Atomic Dual Alarm Clock

model 13024A1

CONTENTS

Unpacking Instructions ...... 2

Package Contents ...... 2

Product Registration ...... 2

Features & Benefits......3

Clock Setup 5

Atomic Clock 6

Set the Time & Date ...... 6

Placement Guidelines ...... 7

Using the Clock.... 8

USB Charging......8

Troubleshooting 9

Care & Maintenance......10

Specifications....10

FCC Information ....10

Customer Support...... 11

Warranty....11

Questions? Contact Customer Support at [phone] or visit www.AcuRite.com.

SAVE THIS MANUAL FOR FUTURE REFERENCE.

ACU RITE®

Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference.

Unpacking Instructions

Remove the protective film that is applied to the LCD screen prior to using this product. Locate the tab and peel off to remove.

Package Contents

1. Alarm clock
2. Power adapter
3. Instruction Manual

Features & Benefits

FRONT OF CLOCK

1. SNOOZE Button/Momentary Backlight
2. Alarm #1 ON/OFF Switch
3. Alarm #1 Setup Button
4. ^ & Buttons for setup preferences.
5. Alarm #2 Setup Button
6. Alarm #2 ON/OFF Switch

BACK OF CLOCK

1. +/- Brightness Button Adjusts display brightness.
2. +/- Alarm Volume Adjusts alarm volume.
3. USB Charging for compatible smartphones.
4. Power Adapter Input

BOTTOM OF CLOCK

(inside battery compartment)

1. RCC ON/OFF Switch
   Controls synchronization with the atomic signal.
2. °F/°C Temperature Units
3. RESET Button

Reset to factory defaults.

Features & Benefits

1. Date
2. Atomic Clock

Sets itself to the correct time and automatically updates for Daylight Saving Time.

1. Atomic Signal Strength
2. Alarm #1 Time
3. Alarm #1 Days Active

Indicates alarm set for EVERY DAY, WEEKDAYS, or WEEKENDS.

1. Alarm #2 Time
2. Alarm #2 Days Active

Indicates alarm set for EVERY DAY, WEEKDAYS, or WEEKENDS.

1. Alarm Volume
2. Indoor Temperature

Clock Setup

1 Plug in Power Adapter

For the best performance, plug in the power adapter as the main power source for this product.

② Install or Replace Backup Batteries

1. Remove the battery compartment cover.
2. Insert 3 x AA alkaline batteries into the battery compartment, as shown. Follow the polarity (+/-) diagram in the battery compartment.
3. Replace the battery cover.

1 Plug in Power Adapter (on back of unit)

Exterior view of a gray rectangular electronic component with two mounting holes (no text or symbols visible)

2 Install or Replace Backup Batteries 3 AA alkaline batteries

IMPORTANT: Batteries are a backup power source to preserve records in the event of a power outage. Power adapter recommended as the primary power source to enjoy the full functionality of the product.

PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.

BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to be

used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire, as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge non-rechargeable batteries. DO NOT short-circuit the supply terminals.

Atomic Clock (RCC)

AcuRite atomic clocks use a radio-controlled signal (RCC) to synchronize to the correct time broadcast by the National Institute of Standards and Technology (NIST) Radio Station WWVB, located near Fort Collins, Colorado. WWVB broadcasts the current time and date with split-second accuracy.

The atomic clock and calendar will maintain the correct time and date, and automatically update for daylight saving time to provide the most accurate timekeeping standard possible.

When the RCC button, located under the battery compartment cover, is set to ON, the clock will automatically search for the atomic clock signal.

To manually search for the atomic signal, make sure the RCC button is set to ON, then press AND HOLD the "▲" button.

Please note: Signal reception is normally better at night and when the weather is clear. The atomic signal generally takes a few hours to synchronize, so it is important to manually set the time and date after powering on the clock.

Set the Time & Date

Press and hold the “⚙” button, located on the front of the clock, to enter SET MODE. Once in SET MODE the preference you are currently setting will blink on the clock.

To adjust the currently selected (flashing) item, press and release the “▲” or “▼” buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the "⚙️" button to adjust the next preference. The preference set order is as follows:

TIME ZONE (PST MST CST EST AST HAST AKST)

AUTO DST ON/OFF*

CLOCK HOUR

CLOCK MINUTE

CALENDAR MONTH

CALENDAR DATE

CALENDAR YEAR

You will automatically exit SET MODE if no buttons are pressed for 5 seconds. Enter SET MODE at any time by pressing and holding the "⚙️" button.

*If you live in an area that observes daylight saving time, DST should be set to ON.

Alarm Clock Placement

Place alarm clock in a dry area free of dirt and dust. To help ensure an accurate indoor temperature measurement, be sure to place the clock away from heat sources or vents.

Important Placement Guidelines

• To ensure accurate temperature measurement, place out of direct sunlight and away from any heat sources or vents.
• To maximize atomic signal reception, place unit away from large metallic items, thick walls, metal surfaces, or other objects that may limit radio communication.
• To prevent wireless interference, place unit at least 3 ft (.9 m) away from electronic devices (TV, computer, microwave, radio, etc.).

Using the Clock

Set the Alarm Time

Slide Alarm #1 and/or Alarm #2 switch ON (alarm time cannot be adjusted if the alarm is OFF).

Press and release the "1" or the "2" button to enter ALARM SET MODE.

To adjust the currently selected (flashing) item, press and release the “^” or “▼” buttons (press and HOLD to fast adjust).

To save your adjustments, press and release the "1" or "2" button to adjust the next preference. The preference set order is as follows:

ALARM CLOCK HOUR

ALARM CLOCK MINUTE

You will automatically exit ALARM SET MODE if no buttons are pressed for 5 seconds. Enter ALARM SET MODE at any time by pressing the "1" or "2" button.

Backlight

During power adapter use, press the Snooze button for momentary backlight at 100% brightness. During battery-powered use, press any button for momentary backlight.

The backlight MAY turn off at 2:00 AM and 3:00 AM to acquire the atomic clock (RCC) signal.

USB Charging

Charge your mobile device by plugging your device's USB power cord (not included) into the USB charging port on the back of the clock.

USB charging is only available during power adapter use; USB charging is not active when operating on battery power only.

Note: Follow the manufacturer's instructions for your mobile device(s) to determine compatibility with the USB charging feature on this product. This product's USB port has a maximum output of 5V 1A (1000mA). Some devices may not support USB charging or may require a higher power rating than this product provides. Observe the charging status on your device. Ensure your device is working properly before attempting to charge.

Troubleshooting

Clock is too dark, hard to read or doesn't work	The backlight may automatically turn off for 10 minutes at 2:00am and 3:00am to acquire the atomic clock signal.Verify power adapter is plugged in.Check that the batteries are installed correctly. Batteries may need to be replaced.Increase brightness using +/- buttons, located on the back of the clock.The optimum viewing angle for this product is from slightly above it.Reset the unit by pressing the reset button, located on the bottom of the clock.
Inaccurate temperature	Make sure the clock is placed out of direct sunlight and away from any heat sources or vents (see page 7).
Atomic signal or time syncing problems	For additional troubleshooting, please visit:http://www.nist.gov/pml/div688/grp40/radioclocks.cfm

If your AcuRite product does not operate properly after trying the troubleshooting steps, visit www.AcuRite.com or call [phone] for assistance.

Care & Maintenance

Clock Care

Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air.

Specifications

TEMPERATURE RANGE	32°F to 122°F, 0°C to 50°C
POWER	5v power adapter3 x AA alkaline batteries (for backup only)

FCC Information

This device complies with part 15 of FCC rules. Operation is subject to the following two conditions:

1- This device may NOT cause harmful interference, and

2- This device must accept any interference received, including interference that may cause undesired operation.

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, There is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and the receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment.

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions:

(1) This device may not cause interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation of the device.

Customer Support

AcuRite customer support is committed to providing you with best-in-class service. For assistance, please have the model number of this product available and contact us in any of the following ways:

) 221-1252

[e-mail]

24/7 support at www.AcuRite.com

▶ Installation Videos ▶ Register your Product
▶ Instruction Manuals ▶ Support User Forum
▶ Replacement Parts ▶ Submit Feedback & Ideas

IMPORTANT

PRODUCT MUST BE REGISTERED TO RECEIVE WARRANTY SERVICE

PRODUCT REGISTRATION

Register online to receive 1 year warrantyprotection

www.AcuRite.com

SUPPORT

Support Forum

Archived Products

▶Register a Product

Limited One Year Warranty

At AcuRite, we proudly uphold our commitment to quality technology. Chaney Instrument Co. warrants that all products it manufactures to be of good material and workmanship, and to be free of defects when properly installed and operated for a period of one year from the date of purchase.

We recommend that you visit us at www.AcuRite.com for the fastest way to register your product. However, product registration does not eliminate the need to retain your original proof of purchase in order to obtain warranty benefits.

Chaney Instrument Co. warrants that all products it manufactures to be of good material and workmanship, and to be free of defects when properly installed and operated for a period of one year from the date of purchase. Remedy for breach of this warranty is limited to repair or replacement of the defective item(s). Any product which, under normal use and service, is proven to breach the warranty contained herein within ONE YEAR from date of sale will, upon examination by Chaney, and at its sole option, be repaired or replaced by Chaney. Transportation costs and charges for returned goods shall be paid for by the purchaser. Chaney hereby disclaims all responsibility for such transportation costs and charges. This

warranty will not be breached, and Chaney will give no credit for products it manufactures which have received normal wear and tear, been damaged (including by acts of nature), tampered, abused, improperly installed, damaged in shipping, or repaired or altered by others than authorized representatives of Chaney. The above-described warranty is expressly in lieu of all other warranties, express or implied, and all other warranties are hereby expressly disclaimed, including without limitation the implied warranty of merchantability and the implied warranty of fitness for a particular purpose. Chaney expressly disclaims all liability for special, consequential or incidental damages, whether arising in tort or by contract from any breach of this warranty. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. Chaney further disclaims all liability from personal injury relating to its products to the extent permitted by law. By acceptance of any of Chaney's products, the purchaser assumes all liability for the consequences arising from their use or misuse. No person, firm or corporation is authorized to assume for Chaney any other liability in connection with the sale of its products. Furthermore, no person, firm or corporation is authorized to modify or waive the terms of this paragraph, and the preceding paragraph, unless done in writing and signed by a duly authorized agent of Chaney. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

For in-warranty claims: Chaney Instrument Co. 965 Wells St., Lake Geneva, WI 53147
