Product Type	Freezer
Brand	Hotpoint
Model	MZAA 1 (TK).1
Net Capacity	100 L
Energy Class	A+
Annual Energy Consumption	220 kWh
Noise Level	39 dB(A)
Freezing Capacity	10 kg/24h
Storage Time in Case of Power Failure	12 hours
Temperature Range	-18°C to -24°C
Defrost System	Manual
Cooling System	Static
Dimensions (HxWxD)	850 x 550 x 600 mm
Weight	30 kg
Power Supply	220-240 V, 50 Hz
Climate Class	SN-T
Reversible Door	Yes
Quick Freeze Function	Yes
Temperature Control	Mechanical knob
Interior Light	Yes
Shelves Material	Glass
Maintenance	Clean with mild detergent; defrost periodically
Safety Features	Overload protection; automatic defrost reminder
Spare Parts Availability	Original parts available via authorized service
Warranty	2 years

Frequently Asked Questions - MZAA 1 (TK).1 HOTPOINT

How do I set the temperature on my Hotpoint MZAA 1 (TK).1 freezer?

To set the temperature, locate the mechanical knob inside the freezer. Turn it to the desired setting, usually between 1 (warmest) and 7 (coldest). A medium setting like 3-4 is recommended for normal use. Wait 24 hours for the temperature to stabilize.

How often should I defrost my freezer?

Defrost the freezer when the ice layer reaches approximately 5 mm (0.2 inches) thickness. This typically occurs every 6 to 12 months, depending on usage and humidity. Turn off the appliance, remove all food, and allow the ice to melt naturally.

What should I do if my freezer is not freezing properly?

First, check that the thermostat is set correctly. Ensure the door is fully closed and the seal is clean. Verify that the condenser coils are clean and not blocked. If the problem persists, the appliance may need professional servicing. Avoid overloading the freezer.

How do I clean my Hotpoint freezer?

Unplug the freezer and remove all food. Wash the interior with a mixture of warm water and mild detergent. Avoid abrasive cleaners. Rinse with clean water and dry thoroughly. Clean the door seal with soapy water. Reconnect the appliance before storing food.

What is the energy consumption of this freezer?

The annual energy consumption is approximately 220 kWh. This may vary depending on usage, ambient temperature, and load. For optimal energy efficiency, keep the freezer in a cool, ventilated location and avoid frequent door openings.

Is the door reversible on the Hotpoint MZAA 1 (TK).1?

Yes, the door is reversible. To change the opening direction, follow the instructions in the manual. You will need tools to remove and reattach the hinges. If unsure, contact a qualified technician.

What is the storage time during a power failure?

The freezer can keep food frozen for up to 12 hours in case of a power failure, provided the door remains closed. Do not open the door unnecessarily. If the power outage lasts longer, check the food condition.

Why is my freezer making unusual noises?

Freezers can produce various sounds such as humming, clicking, or gurgling, which are normal. However, if you hear a loud rattling or banging, ensure the appliance is level and stable. Also check that objects are not vibrating against the unit. If noise persists, contact service.

Can I install the freezer in a garage or unheated room?

This freezer is rated for climate class SN-T, meaning it can operate in ambient temperatures from 10°C to 43°C. It can be placed in unheated rooms as long as the temperature stays above 10°C. Avoid freezing temperatures as the oil may thicken and cause damage.

How do I obtain spare parts or service for my Hotpoint freezer?

Spare parts are available through authorised Hotpoint service centers. Contact Hotpoint customer support or visit the official website to locate a service provider. Always use genuine parts to maintain safety and warranty.

USER MANUAL MZAA 1 (TK).1 HOTPOINT

Kapının çıkarılması

TR

Genel görünüm

Diagram showing a curved arrow interacting with a bowl, indicating direction or movement (no text or symbols present)

Positioning and connection

Reversible doors

Description of the appliance, 14

Overall view

Start-up and use, 15

Starting the appliance

Using the freezer to its full potential

Maintenance and care, 16

Switching the appliance off

Cleaning the appliance

Avoiding mould and unpleasant odours

Defrosting the appliance

Precautions and tips, 17

General safety

Disposal

Respecting and conserving the environment

Troubleshooting, 18

Assistance, 19

! Before placing your new appliance into operation please read these operating instructions carefully. They contain important information for safe use, for installation and for care of the appliance.

! Please keep these operating instructions for future reference. Pass them on to possible new owners of the appliance.

Positioning and connection

Positioning

1. Place the appliance in a well-ventilated humidity-free room.
2. Do not obstruct the rear fan grills. The compressor and condenser give off heat and require good ventilation to operate correctly and save energy.
3. Leave a space of at least 10 cm between the top part of the appliance and any furniture above it, and at least 5 cm between the sides and any furniture/side walls.
4. Ensure the appliance is away from any sources of heat (direct sunlight, electric stove, etc.).
5. In order to maintain the correct distance between the appliance and the wall behind it, fit the spacers supplied in the installation kit, following the instructions provided.

Levelling

1. Install the appliance on a level and rigid floor.
2. If the floor is not perfectly horizontal, adjust the refrigerator by tightening or loosening the rear feet.

Electrical connections

After the appliance has been transported, carefully place it vertically and wait at least 3 hours before connecting it to the electricity mains. Before inserting the plug into the electrical socket ensure the following:

• The appliance is earthed and the plug is compliant with the law.
• The socket can withstand the maximum power of the appliance, which is indicated on the data plate located inside the freezer (e.g. 150 W).
• The voltage is in the range of values indicated on the data plate located inside the freezer (e.g. 220-240V).
• The socket is compatible with the plug of the appliance. If the socket is incompatible with the plug, ask an authorised technician to replace it (see Assistance). Do not use extension cords or multiple sockets.

! Once the appliance has been installed, the power supply cable and the electrical socket must be easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced by authorised technicians only (see Assistance).

! The manufacturer declines any liability should these safety measures not be observed.

Reversible door

GB

Warning: Before attempting to remove the door, switch off the electrical supply and pull out the mains plug.

It is recommended that you remove any loose items/fittings from inside the appliance and place food into insulated containers whilst carrying out this operation.

You may require assistance to carefully lay the appliance onto its back onto suitable protective materials (i.e. original packaging).

Remove the door

1. Lay down the appliance on its back.
2. Unscrew, remove and retain the bottom hinge pin.
3. Slightly open the door and slide downward, remove and carefully place to one side.
4. Unscrew the hinge pin from the top right hand side and refit the pin into the hole in left hand side.
5. Use a thin blunt instrument to remove the top and bottom hinge bushes and blanking plugs from the door, take care not to mark the door handle.

Reposition the blanking plugs and bushes on the opposite side.

Replacing the door

1 . Carefully slide the door upward into the hinge pin.
2 .Fit the bottom hinge pin making sure that the door is aligned to the cabinet.
3. Carefully stand the appliance upright in it's required location and make sure it is sitting level on the floor. Open and close the door checking that the gasket makes a good seal without any gaps when the door is closed.
Note: Replace loose items/fittings back into the appliance and leave for at least 15 minutes before switching back on.

Description of the appliance

GB

Overall view

The instructions contained in this manual are applicable to different model refrigerators. The diagrams may not directly represent the appliance purchased.

Starting the appliance

! Before starting the appliance, follow the installation instructions (see Installation).

! Before connecting the appliance, clean the compartments and accessories well with lukewarm water and bicarbonate.

1. Insert the plug into the socket and ensure that the red ALARM and green POWER indicator lights illuminate (the TEMPERATURE ADJUSTMENT knob must not be on "0").
2. Turn the TEMPERATURE ADJUSTMENT knob to 3 position
3. When the red indicator light switches off, turn the TEMPERATURE ADJUSTMENT knob to a medium position. The freezer is now ready to be used.

Using the freezer to its full potential

• Use the TEMPERATURE CONTROL knob to adjust the temperature (see Description).
• Do not re-freeze food that is defrosting or that has already been defrosted. These foods must be cooked and eaten (within 24 hours).
• Fresh food that needs to be frozen must not come into contact with food that has already been defrosted. Fresh food must be stored in the top FREEZER and STORAGE compartment where the temperature drops below -18°C and guarantees rapid freezing.
• Do not place glass bottles which contain liquids, and which are corked or hermetically sealed in the freezer because they could break.
• The maximum quantity of food that may be frozen daily is indicated on the plate containing the technical properties located within the freezer (for example: Kg/24h: 4).

Freezig

1. Place the fresh food you wish to freeze inside the upper FREEZER and STORAGE compartment, making sure it is not in contact with food that has already been frozen and, if possible, position it so that it is in direct contact with the cooling shelves. Bear in mind that for food to be frozen and stored in good condition, the freezing process should take place quickly. This action is necessary when freezing large quantities of food (up to the maximum amount indicated on the data plate).

2. Placing large amounts of fresh food in the freezer may temporarily increase the temperature inside the appliance (this is indicated when the red ALARM light illuminates). This situation, as it is only temporary, does not adversely affect the storage conditions of food that is already frozen.

3. After 24 hours, once the freezing process is complete, return the TEMPERATURE ADJUSTMENT knob to its normal operating position.

! Do not open the door during freezing.

Storage

• Follow the instructions given on the packaging of frozen food carefully and consume the products within 3 months of the date they were bought.
• When buying frozen food, ensure that it has been stored at a suitable temperature and that the packaging is intact. To maintain the quality of frozen food, use suitable bags or containers when transporting it and place it inside the freezer as soon as possible.
• If the packaging shows signs of moisture or unusual swelling, it is likely that the product has been stored previously at an unsuitable temperature and that the contents have suffered as a result.
• In order to obtain a larger amount of space in the freezer, you can remove the central drawer, and place the food directly onto the evaporator plate. Make sure that, after having inserted the load, the door closes correctly.

! If there is a power cut or malfunction, do not open the freezer door. This will help maintain the temperature inside the freezer, ensuring that foods are conserved for at least 9 -14 hours.

Switching the appliance off

During cleaning and maintenance it is necessary to disconnect the appliance from the electricity supply: It is not sufficient to set the temperature adjustment knobs on "0" (appliance off) to eliminate all electrical contact.

Cleaning the appliance

• The external and internal parts, as well as the rubber seals may be cleaned using a sponge that has been soaked in lukewarm water and bicarbonate of soda or neutral soap. Do not use solvents, abrasive products, bleach or ammonia.
• The removable accessories may be soaked in warm water and soap or dishwashing liquid. Rinse and dry them carefully.
• The back of the appliance may collect dust which can be removed by delicately using the hose of a vacuum cleaner set on medium power. The appliance must be switched off and the plug must be pulled out before cleaning the appliance.

Avoiding mould and unpleasant odours

• The appliance is manufactured with hygienic materials which are odour free. In order to maintain an odour free refrigerator and to prevent the formation of stains, food must always be covered or sealed properly.
• If you want to switch the appliance off for an extended period of time, clean the inside and leave the doors open.

Defrosting the appliance

! Follow the instructions below.

Do not use objects with sharp or pointed edges to defrost the appliance as these may damage the refrigeration circuit beyond repair.

If the frost layer is greater than 5 mm, it is necessary to defrost manually:

1. The day before defrosting, turn the TEMPERATURE CONTROL knob to the "Fast Freeze" setting (the yellow FAST FREEZE indicator light illuminates) to further cool the food.
2. After 24 hours set the TEMPERATURE CONTROL knob on "0", which will switch the refrigerator off.
3. Wrap frozen foods in newspaper and place them in another freezer or in a cool place.
4. Leave the door open until the frost has melted completely. This can be made easier by placing containers with lukewarm water in the freezer compartment..

Diagram showing a curved arrow interacting with a bowl, indicating a process or movement (no text or symbols present)

1. Certain appliances are fitted with the DRAIN SYSTEM to lead the water outside. Let the water flow into a container (see diagram).

2. Clean and dry the freezer compartment carefully before switching the appliance on again.

3. Wait for approximately 2 hours, i.e. until the ideal storage conditions have been restored, before placing food in the freezer compartment.

! The appliance was designed and manufactured in compliance with international safety standards. The following warnings are provided for safety reasons and must be read carefully.

This appliance complies with the following Community Directives:

- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent amendments;

-89/336/EEC of 03.05.89 (Electromagnetic Compatibility) and subsequent amendments;

- 2002/96/CE..

General safety

• The appliance was designed for domestic use inside the home and is not intended for commercial or industrial use.
• The appliance must be used to store and freeze food products by adults only and according to the instructions in this manual.
• The appliance must not be installed outdoors, even in covered areas. It is extremely dangerous to leave the appliance exposed to rain and storms.
• Do not touch the appliance with bare feet or with wet or moist hands and feet.
• Do not touch the internal cooling elements: this could cause skin abrasions or frost/freezer burns.
• When unplugging the appliance always pull the plug from the mains socket, do not pull on the cable.
• Before cleaning and maintenance, always switch off the appliance and disconnect it from the electrical supply. It is not sufficient to set the temperature adjustment knobs on "0" (appliance off) to eliminate all electrical contact.
• In the case of a malfunction, under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or further malfunctioning of the appliance.
• Do not use any sharp or pointed utensils or electrical equipment - other than the type recommended by the manufacturer - inside the frozen food storage compartments.
• Do not put ice cubes taken directly from the freezer into your mouth.
• Do not allow children to tamper with the controls or play with the appliance. Under no circumstance should they be allowed to sit on the bins or to hang from the door.
• Keep packaging material out of the reach of children! It can become a choking or suffocation hazard.

Disposal

• Observe local environmental standards when disposing packaging material for recycling purposes.
• The European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance it must be separately collected.

Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.

Respecting and conserving the environment

• Install the appliance in a fresh and well-ventilated room. Ensure that it is protected from direct sunlight and do not place it near heat sources.
- Try to avoid keeping the door open for long periods or opening the door too frequently in order to conserve energy.
- Do not fill the appliance with too much food: cold air must circulate freely for food to be preserved properly. If circulation is impeded, the compressor will work continuously.
- Do not place hot food directly into the refrigerator. The internal temperature will increase and force the compressor to work harder and will consume more energy.
- Defrost the appliance if ice forms (see Maintenance). A thick layer of ice makes cold transference to food products more difficult and results in increased energy consumption.
- Regularly check the door seals and wipe clean to ensure they are free of debris and to prevent cold air from escaping (see Maintenance).

GB

If the appliance does not work, before calling for Assistance (see Assistance), check for a solution from the following list.

Malfunctions:	Possible causes / Solutions:
The green POWER indicator light does not illuminate.	The plug has not been inserted into the electrical socket, or not far enough to make contact, or there is no power in the house.
The indicator lights are on but the light is dim.	Pull out and reverse the plug before putting it back in the socket.
The ALARM indicator light remains illuminated constantly.	The door is not closed properly or has been open continuously.The door has been opened too frequently.The TEMPERATURE ADJUSTMENT knob is not in the correct position.
The motor runs continuously.	The door is not closed properly or is continuously opened.The outside ambient temperature is very high.The thickness of the frost exceeds 2-3 mm (see Maintenance).
The appliance makes a lot of noise.	The appliance has not been installed on a level surface (see Installation).The appliance has been installed between cabinets that vibrate and make noise.The internal refrigerant makes a slight noise even when the compressor is off. This is not a defect, it is normal.

Before calling for Assistance:

• Check if the malfunction can be solved on your own (see Troubleshooting).
• If after all the checks, the appliance still does not operate or the problem persists, call the nearest Service Centre

Communicating:

• type of malfunction
• appliance model (Mod.)
- serial number (S/N)

This information can be found on the data plate located on the bottom left side of the refrigerator compartment.

Never call on unauthorized technicians and always refuse spare parts which are not originals.
