Product type	Electric fan heater
Brand	TriStar
Model	KA-5031
Category	Heating
Dimensions (L x W x H)	20 x 15 x 25 cm
Weight	1.2 kg
Power supply	220-240 V, 50/60 Hz
Maximum power	2000 W
Power levels	2 levels (1000 W and 2000 W)
Adjustable thermostat	Yes
Fan-only function	Yes (cold air)
Overheat protection	Yes
Automatic shut-off if tipped over	Yes
Housing material	Heat-resistant plastic
Color	White and grey
Power cord length	1.5 m
Maintenance and cleaning	Clean the air intake grille with a damp cloth. Do not immerse.
Spare parts and repairability	Parts available through after-sales service
Warranty	2 years

Frequently Asked Questions - KA-5031 TRISTAR

How to set the desired temperature?

Turn the thermostat knob clockwise to increase the temperature. The unit will automatically turn off once the ambient temperature is reached.

The unit is not heating, what to do?

Check that the plug is properly connected and the thermostat is not set to minimum. If the problem persists, check the thermal fuse or contact after-sales service.

Can I use the heater in a bathroom?

No, this unit is not designed for use in humid rooms. It must be used in a dry and well-ventilated area.

The fan is running but the air is not hot, why?

Make sure the power selector is set to a heating position (1000W or 2000W) and not to 'fan only'. If the problem persists, the thermostat may be defective.

How to clean the unit?

Unplug the unit and allow it to cool down. Clean the air inlet grille with a soft, damp cloth. Do not use abrasive products and do not immerse in water.

The unit turns off by itself, is this normal?

Yes, this may be due to overheat protection or tip-over shut-off. Make sure the unit is on a stable surface and the grilles are not obstructed.

What are the available power levels?

The unit offers two power levels: 1000W and 2000W, as well as a 'fan' position for cold air flow.

The power cord is damaged, can I replace it?

Yes, the cord can be replaced. Please contact TriStar after-sales service for a suitable replacement part.

The unit emits a burning smell, is it dangerous?

A slight odor during first uses is normal (manufacturing residues). If the odor persists or becomes strong, unplug the unit and contact after-sales service.

Can I use an extension cord?

It is not recommended to use an extension cord. If necessary, use a cord in good condition, with a cross-section of at least 1.5 mm² and fully unwound.

USER MANUAL KA-5031 TRISTAR

Red Tristar portable electrical heater with black control knobs and mesh grille (no visible text or symbols)

Operation and maintenance

Remove all packaging of the device.

Check if the voltage of the appliance corresponds to the main voltage of your home.

Rated voltage : AC220-240V 50Hz

Place the appliance on a flat stable surface and ensure a minimum of 50 cm. free space around the unit. This device is not suitable for mounting or outdoor use.

First use

When the unit is first turned on, there will be a slight odor. This is normal, ensure adequate ventilation. This odor is only temporary and will disappear soon.

Use

Put the plug into a grounded outlet and switch on the control switch (no. 3) on the device. Set the desired heating mode.

Turn the thermostat switch (no. 2) clockwise to its highest position. If the room temperature is reached, turn the thermostat switch counter clockwise until you hear a click. The thermostat keeps the room temperature at the same temperature.

The heating pipes do not change color when the device is turned on.

When you want to use the appliance as a fan you only have to turn the thermostat switch (no. 2) to the left. The device does not heat, the fan will only rotate.

Never place objects on the heater, such as clothing or towels. Do not use the heater in the bathroom or other wet areas. The grids of the stove can be very hot.

The exterior of the unit is hot. Avoid any physical contact, you can seriously get injured. Let it cool down completely before it will be moved. Always use the handles (no. 1) at the top of the device to move

Protection against overheating

The device is equipped with an overheat protection which automatically switch off the device when the temperature inside the unit exceeds normal values.

This protection applies only to the device and has no effect on controlling the room temperature.

Turn the control switch in the "0" position and set the thermostat to the lowest setting.

Pull the plug from the socket. Let the device cool down completely. Please remove objects or dust from the air outlets, use a vacuum cleaner to clean gratings which have caused the malfunction or overheating.

Cleaning the unit

We recommend when using the device regularly, at least once a month cleaning.

Follow the instructions below to clean the device.

Turn off the unit before you begin to clean, turn the thermostat switch to the lowest position, remove the plug from the socket and wait until the device has cooled down completely.

Clean the outside of the appliance with a dry cloth. Do not use water or chemical treatment.

Do not immerse in water or other liquids.

IMPORTANT SAFEGUARDS

- Read all instructions before use.

- Do not touch hot surfaces. Use handles or knobs.

- To protect against electric shock, do not immerse cord, plug or appliance in water or any other liquid.

- Unplug from outlet when not in use and before cleaning. Allow the device to cool before putting on or taking off parts. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner.

- The use of accessory attachments not recommended by the appliance manufacturer may cause injuries and invalidate any warranty you may have.

- Do not use outdoors, or on or near direct heat sources

- Do not let cord hang over edge of table or counter, or touch hot surfaces or come into contact with the hot parts or allow the product to be situated underneath or close to curtains, window coverings etc.

• This appliance is for household use only and only for the purpose it is made for.

- The appliance must be placed on a stable, level surface.

- This appliance is an attended appliance, and as such should never be left ON or whilst hot without adult supervision.

- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

- Note: To avoid danger by the accidental resetting thermal protection, the device may not be powered through an external switching device, such as a timer, or connected to a circuit and is turned regularly by the subject.

- A damaged cord or plug must be replaced by an authorized technician to avoid a hazard. Do not repair the device yourself.

• Using an extension cord or something similar is not allowed.

- Do not place the heater directly under a wall outlet.

- Do not use this heater close to a bathtub, a shower or a swimming pool.

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

Guarantee

- The device supplied by our Company is covered by 24 month guarantee starting on the date of purchase (receipt).

- During the life of the guarantee any fault of the device or its accessories to material or manufacturing defects will be eliminated free of charge by repairing or, at our discretion, by replacing it. The guarantee services do not entail an extension of the life of the guarantee nor do they give rise to any right to a new guarantee!

- Proof of the guarantee is provided by the proof of purchase. Without proof of purchase no free replacement or repair will be carried out.

• If you wish to make a claim under the guarantee please return the entire machine in the original packaging to your dealer together with the receipt.
• Damage to accessories does not mean automatic free replacement of the whole machine. In such cases please contact our hotline. Broken glass or breakage of plastic parts are always subject to a charge.
• Defects to consumables or parts subject to wearing, as well as cleaning, maintenance or the replacement of said parts are not covered by the guarantee and hence are to be paid!
• The guarantee lapses in case of unauthorized tampering.
• After the expiry of the guarantee repairs can be carried by the competent dealer or repair service against the payment of the ensuing costs.

Guidelines for protection of the environment

This appliance should not be put into the domestic garbage at the end of its useful life, but must be disposed of at a central point for recycling of electric and electronic domestic appliances. This symbol on appliance, instruction manual and packaging puts your attention to this important issue. The materials used in this appliance can be recycled. By recycling used domestic appliances you contribute an important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection

Packaging

The packaging is 100% recyclable, return the packaging separated.

Product

This device is equipped with a mark according to European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring that the product correctly as waste is processed, it helps you may have adverse consequences for the environment and human health.

EC declaration of conformity

This device is designed, manufactured and marketed in accordance with the safety objectives of the Low Voltage Directive "No 2006/95/EC, the protection requirements of the EMC Directive 2004/108/EC "Electromagnetic Compatibility" and the requirement of Directive 93/68/EEC.

Symbol of a trash bin crossed with a diagonal line, no text or numbers present
