24 H01T2S2 - Television ECG - Free user manual and instructions

Product Type	Television
Brand	ECG
Model	24 H01T2S2
Screen Size	24 inches (diagonal)
Resolution	1366 x 768 pixels (HD Ready)
Display Type	LED
Audio Output Power	2 x 3W
Connectivity	HDMI, USB, VGA, Antenna, Headphone jack
Power Supply	100-240V AC, 50/60Hz
Power Consumption (Typical)	30W
Weight (with stand)	3.5 kg
Dimensions (W x H x D with stand)	55.4 x 36.2 x 16.5 cm
Functions	Teletext, Sleep Timer, Parental Control, DVB-T/T2/C tuner, Electronic Program Guide
Maintenance	Clean with soft dry cloth; do not use solvents
Safety Precautions	Keep away from moisture; disconnect during thunderstorms
Spare Parts Availability	Contact ECG customer service for spare parts
Repairability Index	6/10 (estimated)

Frequently Asked Questions - 24 H01T2S2 ECG

How do I connect external devices like a DVD player?

Use an HDMI cable to connect your device to one of the HDMI ports on the back of the ECG 24 H01T2S2. Then, press the Source button on the remote to select the correct HDMI input.

How can I scan for TV channels?

Press the Menu button on the remote, go to Channel or Installation, select Auto Tuning, and follow the on-screen instructions. Ensure the antenna is connected properly.

Why is the remote control not working?

First, check the batteries and replace them if needed. Ensure there are no obstacles between the remote and the TV's sensor. If still not working, try resetting the TV by unplugging it for a minute.

The picture is displayed but there is no sound. What should I do?

Check if the volume is muted or turned down low. Verify that the audio settings are correct (e.g., not set to external speakers). Also, ensure the connected device's audio output is properly configured.

Can I mount this TV on a wall?

Yes, the ECG 24 H01T2S2 is VESA compatible (typically 100x100mm or 75x75mm). Use a suitable wall mount kit and follow the instructions provided with the mount. Ensure the wall can support the TV's weight.

How do I play media from a USB drive?

Insert the USB drive into the USB port on the TV. Press the Source button and select USB. Use the remote to navigate and select the file you want to play. The TV supports common formats like MP4, AVI, MP3, and JPEG.

How can I reset the TV to factory settings?

Go to the Menu, select Settings or System, then choose Factory Reset or Default Settings. Confirm your selection. The TV will restart and erase all personalized settings.

The TV won't turn on. What could be the issue?

Check that the power cord is securely plugged into both the TV and a working outlet. Try a different outlet. If the standby light is off, the power supply may be faulty. Contact ECG support.

What is the screen resolution of this TV?

The ECG 24 H01T2S2 has a native resolution of 1366 x 768 pixels, which is HD Ready suitable for 720p content.

How can I reduce energy consumption?

Activate the Eco mode or Energy Saving feature in the picture settings. Lower the backlight level and set a sleep timer when not using the TV. Unplug the TV when not in use for extended periods.

USER MANUAL 24 H01T2S2 ECG

Blue background with a circle of twelve white dots, representing the European Union flag (no text or symbols beyond the pattern)

ENERG

ENERGIA - EVERYUEO

ECG

ECG24H01T2S2

ENERGIA · ЕНЕРГИЯ ENEРГЕИА · ENERGUA ENERGY · ENERGIE ENERGI

Simple icon of a power button with a square checkbox, no text or symbols present

2010/1062 - 2014
