USER MANUAL HD 500 Dry and Style 500 Carmen

Black-and-white sketch portrait of a woman with long wavy hair, signed 'Pinty' below (no other text or symbols)

Close-up of a Dry & Style 500 hair dryer with no visible text or symbols on the device body

Model HD500 (230 V)

Gebruiksaanwijzing

Mode d'emploi

Gebrauchsanweisung

Manual

Product photo of a Dry & Style 500 hair dryer with hooded hood, shown in profile inset (no text or symbols on device body)

Instructions for use >

Thank you for purchasing the Carmen Dry & Style 500. Please read these instructions carefully before using the product and keep them in a safe place for future reference.

The product >

Name: Carmen Dry & Style

Model: HD500

Voltage: 230 V

For your safety >

The instructions include safety guidelines and other information important for the proper functioning of the appliance. Please read the instructions carefully and keep them in a safe place. If the appliance changes hands, be sure to give the instructions to the new owner. It is in your own interest to follow all safety guidelines.

Safety instructions >

• The appliance may only be used with the correct voltage (220/240 volt alternating current (AC)).
• Never use the appliance when taking a bath, a shower, above a wash basin filled with water or when your hands are wet. Never use the appliance near a bath, a wash basin or another recipient filled with water.
• Never submerge the appliance in water. The appliance may never come in contact with water when being cleaned.
• Never place a switched on appliance on a soft pillow or blanket.
• Ensure that the air suction and discharge openings are uncovered during use.
• The appliance has an overheating protection that will switch off the appliance should it overload (for example, because the air suction and discharge openings are covered). If the appliance is switched off during use, slide the switch to 0 and wait 5 minutes before you again switch on the appliance.
• Switch off the appliance when you are interrupting drying your hair for a longer period of time.
• Remove the plug from the socket:
• when faults occur during use
• before you clean the appliance
• every time you have stopped using it

16 · English

• Do not pull the cable when you remove the plug from the socket.
• Never wrap the cable around the appliance.
• Do not use the appliance:
• when the cable is damaged
• when the appliance shows visible signs of being damaged
• when the appliance has fallen
• We recommend not holding the air discharge opening too close to your hair to ensure your hair is not damaged.
• Avoid dangerous situations. Never, therefore, allow people with a motor disorder to use the appliance unsupervised.
• Children are not aware of the possible dangers of electrical appliances. Therefore, never allow children to use electrical appliances unsupervised.
• Ensure that the packaging material such as, for example, the plastic film remains outside the reach of children.

• A residual current operated circuit-breaker with a rated short-circuit break current of no more than 30 mA on the switch box can offer additional protection. Have an electrician provide advice regarding this issue. Dangerous situations can also occur when the appliance is switched off. Therefore, remove the plug from the socket after use.

• The cable of the appliance cannot be replaced. The appliance cannot be repaired in case of the cable being damaged or being faulty. The appliance must then be thrown away. Ask a service point recognised by the manufacturer for approval advice to avoid risks.
  • The appliance may not be used for any other purpose.

• Chemical waste: ensure that a faulty appliance cannot again be used. Ask your municipality about the relevant waste instructions.

Operating instructions >

Dry your hair using a towel after washing. It is best to put the curlers in when your hair is still towel dry. A hair strengthening product can first be applied to the hair if required.

The hair drier can be easily fastened by connecting the outlet connector of the hair drier to the air opening of the appliance. Ensure that the hair drier is firmly fastened to the appliance.

The hair drier can be removed by keeping the buttons pressed on the side of the appliance and disconnecting and removing the hair drier.

Main switch

0 = the appliance is switched off
1 = 250 watts, large quantity of hot air, fixing
2 = 500 watts, large quantity of hot air, optimal drying

Position the hair drier over the hair to be styled; the printed side of the hair drier is on the outside. The hair drier must be positioned flat and not in a creased manner.

The air opening of the appliance is connected to the hair drier. Insert the plug in the socket. Use the switch to regulate the required temperature (position 1=250 watts, position 2=500 watts). If your hair is towel dry, we recommend using position 2 and if your hair is nearly dry, we recommend using position 1.

You can move freely with the hair drier within the length of the mains cable.

Cleaning and maintenance >

Remove the plug from the socket before you clean the appliance. Never submerge the appliance in water. Ensure that the appliance does not become dirty. Clean the air suction opening regularly using a soft brush. Wipe the appliance using a moist cloth and dry it with a soft cloth. Remove the accessories and clean them.

18 · English

Guarantee >

The guarantee covers this product for a period of 2 years, with the exception of individual parts, beginning on the date of original purchase. Use of the guarantee does not result in extension of the guarantee period. The guarantee covers manufacturing faults and material faults in original parts.

This guarantee does not include normal wear and tear and damage to the product by accident or misuse, abuse, alteration to the product or use inconsistent with the technical and/or safety instructions required.

If your product requires repair, you should contact an authorized service dealer.

Never dispose of your appliance with the regular household waste. Follow the waste disposal regulations for your locality or return your appliance to the retailer. Retain the retailer's receipt as proof of purchase.

Carmen has a policy of continuous improvement in product quality and design. Carmen therefore reserves the right to change the specifications of its products at any time.

CARMEN®

Dry & Style 500 model HD500 (230 V)
