USER MANUAL AC-GRB REVO

Black mechanical clamp device with attached lever and screw (no visible text or symbols)

Thank you for choosing Revo.

The Revo AC-GRB Sportsman Mount attaches a GoPro camera, or any action camera with a 3-pronged mount, to a gun barrel, fishing rod, or bow with a 0.9-inch maximum diameter. Sturdy ABS plastic construction and a tilt adjustment outfitted with rosettes assure a steady and secure mount for any outdoor activity.

Precautions

■ Make sure your hunting equipment (including any firearm or bow of any kind) is not loaded before mounting, adjusting, or removing the Sportsman Mount.
- Treat every firearm as if it's loaded. Never assume a firearm is unloaded.
- Don't rely on your firearm's safety.
- Follow the firearm manufacturer's operating, servicing, and safety instructions.
- Mount users are solely responsible for safe use of their firearms.

• Always point your firearm in a safe direction.
• Do not attach or use the Sportsman Mount if the barrel of the firearm is too hot to touch.
• Do not allow the mount to interfere with the operation of the trigger, safety, or other mechanisms of your firearm.
• Comply with any state, local, or record book regulations that restrict mounting any electronics, including cameras, to your hunting equipment.
• All images are for illustrative purposes only.

Overview

Thumbscrew

- Remove the thumbscrew, and insert the camera into the 3-prong mount. Thread the thumbscrew through the aligned holes, and tighten until secure.

GoPro 3-prong mount

Till • Load tilt the car ated Cl

Tilt knob

- Loosen the knob to adjust the camera's tilt angle. Tighten the knob to fix the camera in place.

Articulated locking lever

- Tighten the clamp around the barrel or bow. For wood or carbon-fiber bows and fishing rods, do not overtighten the clamp.

Clamp

- Fits tubes with 0.4 to 0.9 in. diameters.

Specifications

Material: ABS Plastic

Dimensions (L × W × D): 2.8 × 2.75 × 2.4 in.

$$ (7 2 \times 7 0 \times 6 0 \mathrm{mm}) $$

Clamp Range: 0.4 to 0.9 in. (10.2 to 22.9 mm)

Weight: 3.5 oz. (99.2 g)
